or ON position.
The power lock is designed so that the power
switch position cannot be switched to LOCK
until the vehicle is into the P (Park) position.
When the power switch cannot be switched to
the LOCK position, proceed as follows.
1. Push the P position switch on the selectorlever to place the vehicle in the P (Park)
position.
2. Push the power switch to the OFF position. The power switch position indicator
*Awill
not illuminate.
3. Open the door. The power switch will change to the LOCK position.
The vehicle can be moved from the P
(Park) position if the power switch is in
the ON position and the brake pedal is
depressed.
POWER SWITCH POSITIONS
LOCK (Normal parking position)
The power switch can only be locked in this
position.
The power switch will be unlocked when it is
pushed to the ACC position while the driver is
carrying the Intelligent Key.
ACC (Accessories)
This position activates electrical accessories,
such as the radio, when EV system is OFF.
ON
This position turns on the EV (Electric Vehicle)
system and electrical accessories.
READY (Normal operating position)
This position turns on the EV (Electric Vehicle)
system, electrical accessories and the vehicle
can be driven.
OFF
The EV (Electric Vehicle) system can be turned
off.
The power switch cannot be placed in the
LOCK position until the vehicle is in the P (Park)
position.

.Do not hang items on the selector
lever. This may cause an accident
due to a sudden start.
. Do not shift to the ECO position
abruptly on slippery roads. This may
cause a loss of control.
NOTE:
If the accelerator pedal is depressed when
the vehicle is in the D (Drive) or ECO
position and the driver’s seat belt is
securely fastened, the parking brake will
be released automatically. See “Electric
parking brake” later in this section.

NOTE:
The vehicle automatically applies the P
(Park) position when the power switch is in
the OFF position.

NOTE:
.While the electric parking brake is
applied or released, an operating
sound is heard from the lower side of
the rear seat. However, this is not a
malfunction.
. When the electric parking brake is
frequently applied and released in a
short period of time, the electric park-
ing brake may not operate in order to
prevent the electric parking brake sys-
tem from overheating. If this occurs,
operate the electric parking brake
again after approximately 1 minute.
. The electric parking brake can be
released with the power switch in the
ON or READY to drive position.
. If the electric parking brake must be
applied while driving in an emergency,
pull up and hold the electric parking
brake switch. When you release the
parking brake switch, the parking
brake will be released.
. While pulling up on the electric parking
brake switch, the electric parking brake
is applied and a chime sounds. The
electric parking brake indicator light in
the meter and parking brake switch operation indicator illuminate. This
does not indicate a malfunction. The
electric parking brake indicator light
and parking switch operation indicator
turn off when the electric parking brake
switch is released.
. Pull up on the electric parking brake
switch twice so that the maximum
electric parking brake force can be
applied to the vehicle.
. When operating the electric parking
brake switch with the power switch in
the ON position, the electric parking
brake indicator light in the meter and
the electric parking brake switch op-
eration indicator turn on.
. Do not start driving while the parking
brake is applied. Doing so may cause
the parking brake to overheat or re-
duce its effectiveness, which could
result in an accident.
. When pulling the electric parking brake
switch with the power switch in the
OFF or ACC position, the electric park-
ing brake switch operation indicator
will continue to illuminate for a short
period of time.
