P182A TRANSFER HI-LO POSITION SENSOR
DTC LogicINFOID:0000000006222290
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC REPRODUCTION PROCEDURE
With CONSULT-III
1. Start the engine. CAUTION:
Never drive the vehicle.
2. Turn the 4WD shift switch AUTO ⇒4H ⇒4LO ⇒4H ⇒AUTO.
3. Drive at 20 km/h (12MPH) or more for 1 minute or more.
4. Perform self-diagnosis for “ALL MODE AWD/4WD”.
Is DTC
“P182A” detected?
YES >> Proceed to diagnosis procedure. Refer to DLN-83, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006222291
1.CHECK TRANSFER HI-LO POSITION SENSOR SIGNAL
1. Turn the ignition switch ON. CAUTION:
Never start the engine.
2. Check the voltage between transfer control unit harness connector and ground.
CAUTION:
After operating 4WD shift sw itch, move the vehicle back and forth to check voltage.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 2.
2.CHECK TRANSFER HI-LO POSITION SENSOR POWER SUPPLY
1. Turn the ignition switch OFF.
2. Disconnect transfer Hi-Lo position sensor harness connector.
3. Turn the ignition switch ON. CAUTION:
Never start the engine.
4. Check the voltage between transfer Hi-Lo position sensor harness connector terminals.
DTC Display item Malfunction detected condition Possible cause
P182A HI-LO POSITION SEN Malfunction related to transfer Hi-Lo po-
sition sensor has been detected.Internal malfunction of transfer Hi-Lo po-
sition sensor
+
−Condition Voltage
Transfer control unit
Connector Terminal
E59 6
Ground4WD mode: AUTO or 4H Approx. 0 V
4WD mode: 4L Approx. 5 V
25 4WD mode: AUTO or 4H Approx. 0 V
4WD mode: 4L Approx. 5 V
Revision: 2010 May2011 QX56

P182B TRANSFER LOCK POSITION SENSOR
DLN-85
< DTC/CIRCUIT DIAGNOSIS > [TRANSFER: ATX90A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
P182B TRANSFER LOCK POSITION SENSOR
DTC LogicINFOID:0000000006222292
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC REPRODUCTION PROCEDURE
With CONSULT-III
1. Turn the ignition switch OFF to ON.
2. Turn the 4WD shift switch AUTO ⇒4H ⇒4LO ⇒4H ⇒AUTO.
3. Perform self-diagnosis for “ALL MODE AWD/4WD”.
Is DTC
“P182B” detected?
YES >> Proceed to diagnosis procedure. Refer to DLN-85, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006222293
1.CHECK TRANSFER LOCK POSITION SENSOR
With CONSULT-III
1. Start the engine.
2. Turn the 4WD shift switch AUTO ⇒4H ⇒4LO ⇒4H ⇒AUTO.
3. Check “LOCK POSI SEN” of CONSULT-III “DATA MONITOR” for “ALL MODE AWD/4WD”.
What is the item on "DATA MONITOR"?
OPEN >> GO TO 7.
LOCK >> GO TO 7.
UNLEAN>>GO TO 6.
HI TEMP>>GO TO 5.
ERROR>> GO TO 5.
BAT >> GO TO 2.
GND >> GO TO 2.
2.CHECK TRANSFER LOCK POSITION POWER SUPPLY
1. Turn the ignition switch OFF.
2. Disconnect transfer positi on sensor harness connector.
3. Turn the ignition switch ON. CAUTION:
DTC Display item Malfunction detected condition Possible cause
P182B Lock POSITION SEN Malfunction related to transfer lock posi-
tion sensor has been detected. Transfer lock position sensor
- Transfer lock position sensor error
- Malfunction of transfer lock position
sensor circuit
Monitor item Condition Status
LOCK POSI SEN 4WD shift switch: AUTO or 4H OPEN
4WD shift switch: 4L LOCK
When transfer lock position sensor is unlearned. UNLEAN
When the temperature of transfer lock position sensor is
high.
HI TEMP
When transfer lock position sensor is malfunctioning. ERROR
When transfer lock position sensor signal circuit is short.
(Battery short) BAT
When transfer lock position sensor signal circuit is short.
(Ground short) GND
Revision: 2010 May2011 QX56

DLN-86
< DTC/CIRCUIT DIAGNOSIS >[TRANSFER: ATX90A]
P182B TRANSFER LOCK POSITION SENSOR
Never start the engine.
4. Check the voltage between transfer position sensor harness connector terminals.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.CHECK TRANSFER LOCK POSITION SENSOR POWER SUPPLY CIRCUIT
1. Turn the ignition switch OFF.
2. Disconnect transfer control unit harness connector.
3. Check the continuity between transfer control uni t harness connector and transfer lock position sensor
harness connector.
4. Check the continuity between transfer lock position harness connector and ground.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace error-detected parts.
4.CHECK TRANSFER LOCK POSITI ON SENSOR SIGNAL CIRCUIT
1. Turn the ignition switch OFF.
2. Disconnect transfer control unit harness connector.
3. Check the continuity between transfer control uni t harness connector and transfer lock position sensor
harness connector.
4. Check the continuity between transfer lock position harness connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace error-detected parts.
5.REPLACE TRANSFER LOCK POSITION SENSOR
1. Replace transfer lock position sensor. Refer to DLN-119, "
Removal and Installation".
2. Perform confirmation procedure again. Refer to DLN-85, "
DTC Logic".
Is the inspection result normal?
+ −
Voltag e
Transfer lock position sensor
Connector Terminal F40 1 2 Approx. 5 V
Transfer control unit Transfer lock position sensor Continuity
Connector Terminal Connector Terminal
E59 17
F40 1
Existed
30 2
Transfer lock position sensor -Continuity
Connector Terminal
F40 1 Ground Not existed
Transfer control unit Transfer lock position sensor Continuity
Connector Terminal Connector Terminal
E59 38 F40 3 Existed
Transfer lock position sensor -Continuity
Connector Terminal
F40 3 Ground Not existed
Revision: 2010 May2011 QX56

DLN-88
< DTC/CIRCUIT DIAGNOSIS >[TRANSFER: ATX90A]
P1830 ABS OPERATION SIGNAL
P1830 ABS OPERATION SIGNAL
DTC LogicINFOID:0000000006222294
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC REPRODUCTION PROCEDURE
With CONSULT-III
1. Start the engine and drive at 30 km/h (19 MPH) or more.
2. Perform self-diagnosis for “ALL MODE AWD/4WD”.
Is DTC
“P1830” detected?
YES >> Proceed to diagnosis procedure. Refer to DLN-88, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006222295
1.PERFORM ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) SELF-DIAGNOSIS
With CONSULT-III
Perform self-diagnosis for “ABS”.
Is any DTCs detected?
YES >> Check the DTCs.
NO >> GO TO 2.
2.ERASE SELF-DIAGNOSTIC RESULT
With CONSULT-III
1. Erase self-diagnostic results for “ALL MODE AWD/4WD”.
2. Start the engine and drive vehicle at 30 km/h (19 MPH) or more.
3. Check that ABS warning lamp turns OFF.
Does ABS warning lamp turn OFF?
YES >> GO TO 3.
NO >> Refer to BRC-123, "
Diagnosis Procedure".
3.CHECK TERMINALS AND HARNESS CONNECTORS
Check transfer control unit pin terminals for damage or loose connection with harness connector.
Is inspection result normal?
YES >> After turning the ignition switch OFF, perform DTC confirmation procedure again. When DTC
"P1830" is detected, Replace transfer control unit. Refer to DLN-107, "
Removal and Installation".
NO >> Repair or replace error-detected parts.
DTC Display item Malfunction detected condition Possible cause
P1830 ABS OP SIG Malfunction is detect
ed in ABS operation
signal that is outp ut from ABS actuator
and electric unit (control unit) through
CAN communication. Malfunction of ABS system
Revision: 2010 May2011 QX56

P1831 VDC OPERATION SIGNALDLN-89
< DTC/CIRCUIT DIAGNOSIS > [TRANSFER: ATX90A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
P1831 VDC OPERATION SIGNAL
DTC LogicINFOID:0000000006222296
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC REPRODUCTION PROCEDURE
With CONSULT-III
1. Start the engine and drive at 30 km/h (19 MPH) or more.
2. Perform self-diagnosis for “ALL MODE AWD/4WD”.
Is DTC
“P1831” detected?
YES >> Proceed to diagnosis procedure. Refer to DLN-89, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006222297
1.PERFORM ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) SELF-DIAGNOSIS
With CONSULT-III
Perform self-diagnosis for “ABS”.
Is any DTCs detected?
YES >> Check the DTCs.
NO >> GO TO 2.
2.ERASE SELF-DIAGNOSTIC RESULT
With CONSULT-III
1. Erase self-diagnostic results for “ALL MODE AWD/4WD”.
2. Start the engine and drive vehicle at 30 km/h (19 MPH) or more.
3. Check that ABS warning lamp turns OFF.
Does ABS warning lamp turn OFF?
YES >> GO TO 3.
NO >> Refer to BRC-122, "
Diagnosis Procedure".
3.CHECK TERMINALS AND HARNESS CONNECTORS
Check transfer control unit pin terminals for damage or loose connection with harness connector.
Is inspection result normal?
YES >> After turning the ignition switch OFF, perform DTC confirmation procedure again. When DTC
"P1831" is detected, Replace transfer control unit. Refer to DLN-107, "
Removal and Installation".
NO >> Repair or replace error-detected parts.
DTC Display item Malfunction detected condition Possible cause
P1831 VDC OP SIG Malfunction is detected in VDC opera-
tion signal that is output from ABS actu-
ator and electric unit (control unit)
through CAN communication.Malfunction of ABS system
Revision: 2010 May2011 QX56

DLN-90
< DTC/CIRCUIT DIAGNOSIS >[TRANSFER: ATX90A]
P1832 TCS OPERATION SIGNAL
P1832 TCS OPERATION SIGNAL
DTC LogicINFOID:0000000006222298
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC REPRODUCTION PROCEDURE
With CONSULT-III
1. Start the engine and drive at 30 km/h (19 MPH) or more.
2. Perform self-diagnosis for “ALL MODE AWD/4WD”.
Is DTC
“P1832” detected?
YES >> Proceed to diagnosis procedure. Refer to DLN-90, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006222299
1.PERFORM ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) SELF-DIAGNOSIS
With CONSULT-III
Perform self-diagnosis for “ABS”.
Is any DTCs detected?
YES >> Check the DTCs.
NO >> GO TO 2.
2.ERASE SELF-DIAGNOSTIC RESULT
With CONSULT-III
1. Erase self-diagnostic results for “ALL MODE AWD/4WD”.
2. Start the engine and drive vehicle at 30 km/h (19 MPH) or more.
3. Check that ABS warning lamp turns OFF.
Does ABS warning lamp turn OFF?
YES >> GO TO 3.
NO >> Refer to BRC-122, "
Diagnosis Procedure".
3.CHECK TERMINALS AND HARNESS CONNECTORS
Check transfer control unit pin terminals for damage or loose connection with harness connector.
Is inspection result normal?
YES >> After turning the ignition switch OFF, perform DTC confirmation procedure again. When DTC
"P1832" is detected, Replace transfer control unit. Refer to DLN-107, "
Removal and Installation".
NO >> Repair or replace error-detected parts.
DTC Display item Malfunction detected condition Possible cause
P1832 TCS OP SIG Malfunction is detected in TCS operation
signal that is outp
ut from ABS actuator
and electric unit (control unit) through
CAN communication. Malfunction of TCS system
Revision: 2010 May2011 QX56

U1000 CAN COMM CIRCUITDLN-91
< DTC/CIRCUIT DIAGNOSIS > [TRANSFER: ATX90A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
U1000 CAN COMM CIRCUIT
DescriptionINFOID:0000000006222300
CAN (Controller Area Network) is a serial communication li ne for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Many elec-
tronic control units are equipped onto a vehicle, and each control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with 2
communication lines (CAN-H line, CAN-L line) allowing a high rate of information transmission with less wiring.
Each control unit communicate data but selectively reads required data only.
DTC LogicINFOID:0000000006222301
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC REPRODUCTION PROCEDURE
With CONSULT-III
1. Turn the ignition switch OFF to ON.
2. Perform self-diagnosis for “ALL MODE AWD/4WD”.
Is DTC
“U1000” detected?
YES >> Proceed to diagnosis procedure. Refer to DLN-91, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006222302
1.PERFORM SELF-DIAGNOSIS
With CONSULT-III
Perform self-diagnosis for “ALL MODE AWD/4WD”.
Is DTC
“U1000” detected?
YES >> Proceed to LAN-18, "Trouble Diagnosis Flow Chart".
NO >> INSPECTION END
DTC Display item Malfunction detected condition Possible cause
U1000 CAN COMM CIRCUIT Transfer control unit is not transmitting/
receiving CAN communication signal for
2 seconds or more. CAN communication error
 Malfunction of transfer control unit
Revision: 2010 May2011 QX56

4WD WARNING LAMPDLN-97
< DTC/CIRCUIT DIAGNOSIS > [TRANSFER: ATX90A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
4WD WARNING LAMP
Component Function CheckINFOID:0000000006222308
1.CHECK 4WD WARNING LAMP FUNCTION
1. Turn the ignition switch OFF to ON.
2. Check that 4WD warning lamp light up.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Proceed diagnosis procedure. Refer to DLN-97, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006222309
1.CHECK POWER SUPPLY AND GROUND CIRCUIT
Perform the trouble diagnosis for power supply and ground circuit. Refer to DLN-64, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the error-detected parts.
2.PERFORM SELF-DIAGNOSIS
With CONSULT-III
Perform self-diagnosis for “ALL MODE AWD/4WD”.
Is any DTC detected?
YES >> Check the DTC.
NO >> GO TO 3.
3.CHECK 4WD WARNING LAMP SIGNAL
With CONSULT-III
1. Turn the ignition switch ON. CAUTION:
Never start the engine.
2. Check “4WD FAIL LAMP” of CONSULT-III “DATA MONITOR” for “ALL MODE AWD/4WD”.
Does the item on
“DATA MONITOR” indicate “On”?
YES >> Check combination meter. Refer to MWI-64, "COMBINATION METER : Diagnosis Procedure".
NO >> Replace transfer control unit. Refer to DLN-107, "
Removal and Installation".
Revision: 2010 May2011 QX56
