DUCT AND GRILLE
Install in the reverse order of removal.
REAR FLOOR GRILLE
REAR FLOOR GRILLE : Removal and InstallationINFOID:0000000006276298
REMOVAL
Disengage fixing metal clips, and then remove rear floor grille.
INSTALLATION
Install in the reverse order of removal.
FOOT DUCT
FOOT DUCT : Removal and InstallationINFOID:0000000006276299
REMOVAL
1. Remove steering member. Refer to HA-42, "HEATER & COOLING UNIT ASSEMBLY : Removal and
Installation".
2. Remove fixing screws, and then remove foot duct.
INSTALLATION
Install in the reverse order of removal.
FOOT GRILLE
FOOT GRILLE : Removal and InstallationINFOID:0000000006276300
REMOVAL
Driver side
1. Remove instrument lower panel RH. Refer to IP-14, "Removal and Installation".
2. Remove fixing screws, and then remove foot grille.
Passenger side
1. Remove instrument lower cover. Refer to IP-14, "Removal and Installation".
2. Remove fixing screws and clip, and then remove foot grille.
INSTALLATION
Install in the reverse order of removal.
REAR VENTILATOR DUCT LOWER
REAR VENTILATOR DUCT LOWER : Removal and InstallationINFOID:0000000006276301
REMOVAL
1. Remove luggage side lower finisher RH. Refer to INT-36, "LUGGAGE SIDE LOWER FINISHER :
Removal and Installation".
2. Remove mounting bolts, and then remove rear ventilator duct lower.
INSTALLATION
Install in the reverse order of removal.
REAR VENTILATOR DUCT UPPER
REAR VENTILATOR DUCT UPPER : Removal and InstallationINFOID:0000000006276302
REMOVAL
1. Remove back pillar garnish RH. Refer to INT-37, "BACK PILLAR GARNISH : Removal and Installation".
2. Remove mounting bolt, and then remove rear ventilator grille upper.
INSTALLATION
Install in the reverse order of removal.
Revision: 2010 May2011 QX56
VTL-14
< REMOVAL AND INSTALLATION >
BLOWER UNIT
BLOWER UNIT
Exploded ViewINFOID:0000000006276305
REMOVAL
DISASSEMBLY
1. Heater & cooling unit assembly 2. Steering member 3. Instrument stay LH
4. Instrument stay RH 5. Blower unit assembly
Refer to GI-4, "
Components" for symbols in the figure.
JMIIA0628GB
Revision: 2010 May2011 QX56
BLOWER UNITVTL-15
< REMOVAL AND INSTALLATION >
C
DE
F
G H
J
K L
M A
B
VTL
N
O P
Removal and InstallationINFOID:0000000006276306
REMOVAL
1. Remove A/C unit assembly. Refer to HA-42, "HEATER & COOLING UNIT ASSEMBLY : Removal and
Installation".
2. Remove mounting bolts, and then disconnect heater & cooling unit assembly and blower unit assembly.
INSTALLATION
Install in the reverse order of removal.
1. Shutter box case RH 2. Shutter box upper case 3. Packing
4. Bellmouth ring 5. Blower unit bracket 6. Intake upper case
7. Intake lower case 8. Blower motor assembly 9. Packing
10. Shutter box case LH 11. Intake door motor 12. Intake door
13. In-cabin microfilter 14. Filter cover
JMIIA0642ZZ
