ELECTRICALLY-CONTROLLED COOLING FAN COUPLINGEC-497
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
NO >> Repair or replace error-detected parts.
6.CHECK CAN COMMUNICATION
Refer to LAN-18, "
Trouble Diagnosis Flow Chart".
Is inspection result normal?
YES >> Check intermittent incident. Refer to GI-40, "Intermittent Incident".
NO >> Repair or Replace error-detected parts.
7.CHECK COOLING FAN SPEED SENSOR
Refer to EC-367, "
Diagnosis Procedure".
Is inspection result normal?
YES >> Replace electrically-controlled cooling fan coupling. Refer to CO-16, "Removal and Installation".
NO >> Repair or replace error-detected parts.
Revision: 2010 May2011 QX56

LOW PRESSURE FUEL PUMPEC-513
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
YES >> GO TO 4.
NO >> Repair or replace error-detected parts.
4.CHECK FUEL PUMP CONTROL CIRCUIT
1. Disconnect fuel level sensor unit and fuel pump harness connector.
2. Check the continuity between FPCM harness connecto r and fuel level sensor unit and fuel pump harness
connector.
3. Also check harness for short to ground and to power.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace error-detected parts.
5.CHECK LOW PRESSURE FUEL PUMP
Refer to EC-513, "
Component Inspection (Low Pressure Fuel Pump)".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Replace fuel level sensor unit and fuel pump. Refer to FL-5, "
Removal and Installation".
6.CHECK FPCM
Refer to EC-514, "
Component Inspection (FPCM)".
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-40, "Intermittent Incident".
NO >> Replace FPCM. Refer to EC-537, "
Removal and Installation".
Component Inspection (Low Pressure Fuel Pump)INFOID:0000000006218019
1.CHECK FUEL PRESSURE REGULATOR
1. Turn ignition switch OFF.
2. Check low fuel pressure. Refer to EC-153, "
Work Procedure".
Is inspection result normal?
YES >> INSPECTION END
NO >> GO TO 2.
2.CHECK LOW PRESSURE FUEL PUMP
1. Turn ignition switch OFF.
2. Disconnect fuel level sensor unit and fuel pump.
3. Check resistance between fuel level sens or unit and fuel pump terminals as follows.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace fuel level sensor unit and fuel pump. Refer to FL-5, "
Removal and Installation".
+−
Continuity
FPCM Fuel level sensor unit and fuel pump
Connector Terminal Connector Terminal
B41 6
C5 3
Existed
71
+ −
Condition Resistance
Fuel level sensor unit and fuel
pump
Te r m i n a l s
1 3 Temperature: 25 °C (77 °F) 0.2 - 5.0 Ω
Revision: 2010 May2011 QX56

EC-516
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
ON BOARD REFUELING VAPOR RECOVERY (ORVR)
ON BOARD REFUELING VA
POR RECOVERY (ORVR)
Component Function CheckINFOID:0000000006256490
1.CHECK ORVR FUNCTION
Check whether the following symptoms are present.
 Fuel odor from EVAP canister is strong.
 Cannot refuel/Fuel odor from the fuel filler opening is strong while refueling.
Are any symptoms present?
YES >> Proceed to EC-516, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006256491
1.INSPECTION START
Check whether the following symptoms are present.
A: Fuel odor from EVAP canister is strong.
B: Cannot refuel/Fuel odor from the fuel filler opening is strong while refueling.
Which symptom is present?
A>>GO TO 2.
B>>GO TO 7.
2.CHECK EVAP CANISTER
1. Remove EVAP canister with EVAP canister vent control valve and EVAP control system pressure sensor
attached.
2. Weigh the EVAP canister with EVAP canister vent control valve and EVAP control system pressure sensor
attached.
The weight should be l ess than 2.5 kg (5.5 lb).
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 4.
3.CHECK IF EVAP CANISTER IS SATURATED WITH WATER
Check if water will drain from EVAP canister (1).
 EVAP canister vent control valve (2)
Does water drain from the EVAP canister?
YES >> GO TO 4.
NO >> GO TO 6.
4.REPLACE EVAP CANISTER
Replace EVAP canister with a new one.
>> GO TO 5.
5.DETECT MALFUNCTIONING PART
Check the EVAP hose between EVAP canister and vehicle frame for clogging or poor connection.
>> Repair or replace EVAP hose.
6.CHECK REFUELING EVAP VAPOR CUT VALVE
Refer to EC-518, "
Component Inspection (EVAP Vapor Cut Valve)".
JSBIA0692ZZ
Revision: 2010 May2011 QX56

ON BOARD REFUELING VAPOR RECOVERY (ORVR)EC-517
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace refueling EVAP vapor cut valve with fuel tank.
7.CHECK EVAP CANISTER
1. Remove EVAP canister with EVAP canister vent c ontrol valve and EVAP control system pressure sensor
attached.
2. Weigh the EVAP canister with EVAP canister vent control valve and EVAP control system pressure sensor
attached.
The weight should be l ess than 2.5 kg (5.5 lb).
Is the inspection result normal?
YES >> GO TO 8.
NO >> GO TO 9.
8.CHECK IF EVAP CANISTER IS SATURATED WITH WATER
Check if water will drain from EVAP canister (1).
 EVAP canister vent control valve (2)
Does water drain from the EVAP canister?
YES >> GO TO 9.
NO >> GO TO 11.
9.REPLACE EVAP CANISTER
Replace EVAP canister with a new one.
>> GO TO 10.
10.DETECT MALFUNCTIONING PART
Check the EVAP hose between EVAP canister and vehicle frame for clogging or poor connection.
>> Repair or replace EVAP hose.
11 .CHECK VENT HOSES AND VENT TUBES
Check hoses and tubes between EVAP c anister and refueling control valve for clogging, kinks, looseness and
improper connection.
Is the inspection result normal?
YES >> GO TO 12.
NO >> Repair or replace hoses and tubes.
12.CHECK FILLER NECK TUBE
Check recirculation line for clogging, dents and cracks.
Is the inspection result normal?
YES >> GO TO 13.
NO >> Replace filler neck tube.
13.CHECK REFUELING EVAP VAPOR CUT VALVE
Refer to EC-518, "
Component Inspection (EVAP Vapor Cut Valve)".
Is the inspection result normal?
YES >> GO TO 14.
NO >> Replace refueling EVAP vapor cut valve with fuel tank.
14.CHECK FUEL FILLER TUBE
Check filler neck tube and hose connected to the fuel tank for clogging, dents and cracks.
JSBIA0692ZZ
Revision: 2010 May2011 QX56

EC-520
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
REFRIGERANT PRESSURE SENSOR
REFRIGERANT PRESSURE SENSOR
Component Function CheckINFOID:0000000006218026
1.CHECK REFRIGERANT PRESSURE SENSOR FUNCTION
1. Start engine and warm it up to normal operating temperature.
2. Turn A/C switch and blower fan switch ON.
3. Check the voltage between ECM harness connector terminals as per the following.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to EC-520, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006218027
1.CHECK REFRIGERANT PRESSURE SENSOR POWER SUPPLY CIRCUIT
1. Disconnect refrigerant pressu re sensor harness connector.
2. Turn ignition switch ON.
3. Check the voltage between refrigerant pressure sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.DETECT MALFUNCTIONING PART
Check the following.
 Harness for open or short between ECM and refrigerant pressure sensor
 Loose or poor connection for each connector and harness
>> Repair open circuit, short to ground or short to power in harness or connectors.
3.CHECK REFRIGERANT PRESSURE SENSOR GROUND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between refrigerant pre ssure sensor harness connector and ECM harness connec-
tor.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 4.
ECM Voltage (V)
Connector +–
Terminal Terminal
E80 144
(Refrigerant pressure sensor signal) 150 1.0 - 4.0
Refrigerant pressure sensor
Ground Voltage (V)
Connector Terminal
E77 1 Ground Approx. 5
Refrigerant pressure sensor ECM Continuity
Connector Terminal Connector Terminal
E77 3 E80 150 Existed
Revision: 2010 May2011 QX56

REFRIGERANT PRESSURE SENSOREC-521
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
4.DETECT MALFUNCTIONING PART
Check the following.
 Harness for open or short between ECM and refrigerant pressure sensor
 Loose or poor connection for each connector and harness
>> Repair open circuit, short to ground or short to power in harness or connectors.
5.CHECK REFRIGERANT PRESSURE SENSOR IN PUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Check the continuity between refrigerant pre ssure sensor harness connector and ECM harness connec-
tor.
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 7.
NO >> GO TO 6.
6.DETECT MALFUNCTIONING PART
Check the following.
 Harness for open or short between ECM and refrigerant pressure sensor
 Loose or poor connection for each connector and harness
>> Repair open circuit, short to ground or short to power in harness or connectors.
7.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
Is the inspection result normal?
YES >> Replace refrigerant pressure sensor. Refer to HA-39, "REFRIGERANT PRESSURE SENSOR :
Removal and Installation".
NO >> Repair or replace malfunctioning part.
Refrigerant pressure sensor ECM Continuity
Connector Terminal Connector Terminal
E77 2 E80 144 Existed
Revision: 2010 May2011 QX56

EC-524
< SYMPTOM DIAGNOSIS >[VK56VD]
ENGINE CONTROL SYSTEM SYMPTOMS
SYMPTOM DIAGNOSIS
ENGINE CONTROL SYSTEM SYMPTOMS
Symptom TableINFOID:0000000006218028
SYSTEM — BASIC ENGINE CONTROL SYSTEM
SYMPTOM
Reference
page
HARD/NO START/RESTART (EXCP. HA)
ENGINE STALL
HESITATION/SURGING/FLAT SPOT
SPARK KNOCK/DETONATION
LACK OF POWER/POOR ACCELERATION
HIGH IDLE/LOW IDLE
ROUGH IDLE/HUNTING
IDLING VIBRATION
SLOW/NO RETURN TO IDLE
OVERHEATS/WATER TEMPERATURE HIGH
EXCESSIVE FUEL CONSUMPTION
EXCESSIVE OIL CONSUMPTION
BATTERY DEAD (UNDER CHARGE)
Warranty symptom code AA AB AC AD AE AF AG AH AJ AK AL AM HA
Fuel Low pressure fuel pump circuit 11232 22 3 2 EC-512
Low fuel pressure sensor circuit 4 4EC-483
Fuel pressure regulator system 334444444 4EC-198
Fuel injector circuit 11232 22 2EC-498
Evaporative emission system 334444444 4EC-532
FRP sensor circuit 11222 22 2EC-276EC-279
High pressure fuel pump circuit 4 3
EC-501
Air Positive crankcase ventilation sys-
tem 334444444 41
EC-534
Incorrect idle speed adjustment 1 1 1 1 1 EC-139
Electric throttle control actuator 112332222 2 2EC-460EC-466
IgnitionIncorrect ignition timing adjustment33111 11 1
EC-139
Ignition circuit 11222 22 2EC-506
Main power supply and ground circuit 22333 33 23 EC-168
Revision: 2010 May2011 QX56

ENGINE CONTROL SYSTEM SYMPTOMSEC-525
< SYMPTOM DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Mass air flow sensor circuit
1
12 2
222 2 EC-201
Engine coolant temperature sensor circuit
333
EC-217
Air fuel ratio (A/F) sensor 1 circuit EC-181
EC-228
EC-232
EC-235
EC-238
Throttle position sensor circuit
22EC-219
EC-288
EC-406
EC-407
EC-475
Accelerator pedal position sensor circuit 3 2 1
EC-468EC-471
EC-478
Knock sensor circuit 2 3
EC-297
Engine oil temperature sensor 4 2 3EC-285
Crankshaft position sensor circuit 2 2EC-299
Camshaft position sensor circuit 3 2EC-303
Vehicle speed signal circuit 2 3 3 3EC-356
Power steering pressure sensor circuit 2 3 3EC-371
ECM 22333333333EC-376EC-378
EC-380
Intake valve timing control solenoid valve cir-
cuit
32 13223 3
EC-193
VVEL control module 3 4 4 3 EC-451EC-452
VVEL actuator motor 3 4 4 3
EC-390
VVEL actuator motor relay 3 4 4 3EC-393
VVEL control shaft position sensor 3 4 4 3EC-387
PNP signal circuit 3 3 3 3 3EC-383
Refrigerant pressure sensor circuit 2 3 3 4EC-520
Electrical load signal circuit 3EC-493
Air conditioner circuit 223333333 3 2HAC-60
ABS actuator and electric unit (control unit) 4BRC-60
SYMPTOM
Reference
page
HARD/NO START/RESTART (EXCP. HA)
ENGINE STALL
HESITATION/SURGING/FLAT SPOT
SPARK KNOCK/DETONATION
LACK OF POWER/POOR ACCELERATION
HIGH IDLE/LOW IDLE
ROUGH IDLE/HUNTING
IDLING VIBRATION
SLOW/NO RETURN TO IDLE
OVERHEATS/WATER TEMPERATURE HIGH
EXCESSIVE FUEL CONSUMPTION
EXCESSIVE OIL CONSUMPTION
BATTERY DEAD (UNDER CHARGE)
Warranty symptom code AA AB AC AD AE AF AG AH AJ AK AL AM HA
Revision: 2010 May2011 QX56
