2011 Citroen C4 RHD Owner's Manual

23
FAMILIARISATION
DRIVING SAFELY

Stop & Start


Engine going into STOP mode
Engine going into START mode
Deactivation/Reactivation
In certain circumstances the STOP
mode may not be available; the "ECO"

warning lamp fl ashes for a few seconds
then goes off.

- with a manual gearbox;
at speeds
below 12 mph (20 km/h), when you
put the gear lever into neutral, and
you release the clutch pedal,

- with the 6-speed electronic gear-
box system;
at speeds below
5 mph (8 km/h), when you press the
brake pedal or you put the gear le-
ver in position N
.



154


- with a manual gearbox;
when you
depress the clutch pedal,

- with the 6-speed electronic gear-
box system;



●
with the gear lever in position A

or M
, when you release the brake
pedal,

●
or gear lever in position N
and
brake pedal released, when you
change to position A
or M
,

●
or engage reverse.

In certain circumstances, START mode
may engage automatically; the "ECO"

warning lamp fl ashes then goes off.



155
You can deactivate the system at any
time by pressing the "ECO OFF"
button;
the button’s warning lamp comes on.



155

The "ECO"
warning lamp goes
off and the engine restarts: The "ECO"
warning lamp comes
on in the instrument panel and the
engine is put into standby:
The system is reactivated auto-
matically every time you start the
engine with the key.

Before refuelling or doing any-
thing under the bonnet, you
must switch off the ignition with
the key.

24
DRIVING SAFELY

Blind spot sensors
Parking space sensors

One of these messages appears to
indicate the level of diffi culty of the
manoeuvre:


)
Activate the function by pressing
control switch A
; the button’s warn-
ing lamp comes on.
The warning lamp located in the door
mirror comes to warn you of the arrival
of a vehicle in the blind spot detection
zone.



157


)
Select the function by pressing
control switch B
; the correspon-
ding warning lamp comes on in the
instrument panel.

)
Operate the direction indicators on
the side with the space to be mea-
sured; a message appears to con-
fi rm measurement is in progress.

)

Drive at a speed below 12 mph (20 km/h)
during measurement.

- Parking possible.


- Parking diffi cult.


- Parking not advised.





165

25
FAMILIARISATION
DRIVING SAFELY

Speed limiter "LIMIT"
Cruise control "CRUISE" Display in the instrument panel


Cruise control

1.
Limiter mode On/Off.

2.
Decrease the programmed value.

3.
Increase the programmed value.

4.
Speed limiter On/Off.

5.
Display the list of memorised
speeds.

160




161


1.
Cruise control mode On/Off.

2.
Programme a speed/Decrease the
programmed value.

3.
Programme a speed/Increase the
programmed value.

4.
Cruise control Off/Resume.

5.
Display the list of memorised
speeds.

160




163
The cruise control or speed limiter
mode appears in the instrument panel
when it is selected.
The values must be set with the engine
running.
In order to be programmed or activated,
the vehicle speed must be higher than
25 mph (40 km/h), with at least fourth
gear engaged on a manual gearbox
(second gear for the 6-speed electronic
gearbox system or automatic gearbox).

Speed limiter

26

1
MONITORING
27
TWO-TONE INSTRUMENT PANEL WITHOUT AUDIO SYSTEM

Dials and screens



1.
Rev counter (x 1 000 rpm or tr/min).

2.
Gear effi ciency indicator with manu-
al gearbox or gear lever position and
gear for the electronic gearbox sys-
tem or automatic gearbox.

3.
Cruise control or speed limiter setting.

4.
Digital speedometer (mph or km/h).

5.
Engine oil level indicator.
6.
Service indicator
(miles or km) then,
total mileage recorder.
These two functions are displayed
successively on switching on the
ignition.
Lighting dimmer setting (when making
an adjustment).

7.
Trip mileage recorder (miles or km).

8.
Fuel gauge and associated low fuel
level warning lamp ( a
or b
accord-
ing to version).

9.
Time.

Control buttons



A.
Lighting dimmer (available in night
mode).

B.
Reminder of servicing information.
Reset service indicator or trip mileage
recorder.

A
and B.
Setting the time and selecting
units.

1
28












TWO-TONE INSTRUMENT PANEL WITH AUDIO SYSTEM

Dials and screens



A.
Lighting dimmer (available in night
mode).

B.
Reminder of the servicing information.
Reset the service indicator or the
trip mileage recorder.

7.
Service indicator
(miles or km) then,
total mileage recorder.
These two functions are displayed
successively on switching on the
ignition.
Lighting dimmer setting (when making
an adjustment).

8.
Trip mileage recorder (miles or km).

9.
Fuel gauge and associated low fuel
level warning lamp ( a
or b
accord-
ing to version).

10.
Range (miles or km).

Control buttons



1.
Rev counter (x 1 000 rpm or tr/min).

2.
Gear effi ciency indicator for manual
gearbox or gear lever position and
gear for the electronic gearbox sys-
tem or automatic gearbox.

3.

Analogue speedometer (mph or km/h).


4.
Cruise control or speed limiter setting.

5.
Digital speedometer (mph or km/h).

6.
Engine oil level indicator.

1
29












CUSTOMISABLE COLOUR INSTRUMENT PANEL WITH AUDIO SYSTEM



1.
Rev counter (x 1 000 rpm or tr/min).

2.
Gear effi ciency indicator with man-
ual gearbox or gear lever position
and gear for the electronic gearbox
system or automatic gearbox.

3.

Analogue speedometer (mph or km/h).


4.
Cruise control or speed limiter setting.

5.
Digital speedometer (mph or km/h).

A.
Dial COLOUR: customisation of the
background colour of the dials.

B.
Screen COLOUR: customisation
of the background colour of the
screens.

C.
Lighting dimmer (available in night
mode).

D.
Reminder of the servicing information.
Reset the service indicator or the
trip mileage recorder.



Dials and screens


6.
Engine oil level indicator.

7.
Service indicator
(miles or km) then,
total mileage recorder.
These two functions are displayed
successively on switching on the
ignition.
Lighting dimmer setting (when making an adjustment).

8.
Trip mileage recorder (miles or km).

9.
Fuel gauge and associated low fuel
level warning lamp.

10.
Range (miles or km).

Control buttons

1
30
CUSTOMISABLE COLOUR INSTRUMENT PANEL ASSOCIATED WITH THE SATELLITE NAVIGATION SYSTEM


1.
Rev counter (x 1 000 rpm or tr/min).

2.
Gear effi ciency indicator with manual
gearbox or gear lever position and
gear for the electronic gearbox sys-
tem or automatic gearbox.

3.
Speedometer (mph or km/h).


Dials and screens


4.
Central colour screen associated
with the satellite navigation system.

5.
Fuel gauge and associated low fuel
level warning lamp.

6.
Trip mileage recorder (miles or km).

7.
Service spanner (if a service is due
or missed),
total mileage recorder.
(miles or km)


A.
Dial COLOUR: customisation of the
background colour of the dials.

B.
Screen COLOUR: customisation
of the background colour of the
screens.

C.
Lighting dimmer (in night mode).

D.
Start a manual test (procedure for
checking the status of systems and
display of vehicle alerts).
Reset service indicator or trip mileage
recorder.

Control buttons
