2011 Citroen C4 RHD Owner's Manual

295
08TRIP COMPUTER

Each press of the button, located at the end of the
wiper stalk, displays the different trip computer
information in succession, depending on the screen.


- th
e "vehicle
" tab with:
●
the ran
ge, the current fuel consumption and
the distance remaining to the destination or the Stop & Start time counter,

- the "1" tab
(trip 1) with:
●
t
he average speed, the average consumptionand the distance travelled calculated over
trip " 1 ",

- the "2" tab
(trip 2) with the same information for a second trip.

Z
ero reset
When the required trip is displa
yed, press the control
for more than two seconds.
Range:displays the distance which can travelled with the remaining fuel
detected in the tank, based on the average fuel consumption over the last few miles (kilometres).
This displa
yed value may vary signifi cantly following a change in the
vehicle speed or the relief of the route.
When the ran
ge falls below 20 miles (30 km), dashes are displayed.After fi lling with at least 5 litres of fuel, the range is recalculated and is
displayed when it exceeds 60 miles (100 km).
If, whilst driving, dashes are displayed continuously in place of the digits, contact a CITROËN dealer. ,g,

A FEW DEFINITIONS
Current fuel consumption:only calculated and displayed above 20 mph (30 km/h).
Average fuel consumption:
this is the average fuel consumption since
the last trip computer zero reset.
Distance travelled:calculated since the last trip computer zero reset.
Distance remaining to the destination: calculated with reference to
the fi nal destination, entered by the user. If guidance is activated, the navigation system calculates it as a current value.
Avera
ge speed: this is the average speed calculated since the last tripcomputer zero reset (ignition on).
Sto
p & Start time counter
(minutes/seconds or hours/minutes)
I
f your vehicle is fi tted with Stop & Start, a time counter calculates
the time spent in STOP mode during a journey.
It resets to zero ever
y time the ignition is switched on with the key.

296
09

RADIO

LANGUAGES
MEDIA


TEXT INFO


TRIP COMPUTER


DIAGNOSIS *
Fran
çais

Italiano

Nederlands

Portu
gues

Portu
gues-brasil

En
glish
Deutsch

Espanol

SCREEN MENU MAP
MONOCHROME A


MAIN FUNCTION
Choice A1
Choice A2
CHOICE A
CHOICE B...
PLAYBACK MODE
NORMAL
RANDOM
RANDOM ALL MEDIA

DATE AND TIME





VEHICLE PARAM
PARK BRAKE (Automatic electric parking brake)
BEND LIGHTING (Adaptive lighting: directional)

AUTO HEADLAMPS(Automatic illumination of headlamps)
REAR WIPE ACT (Rear wiper coupled to reverse gear)
GUIDE LAMPS (Guide-me-home lighting)
CABIN SELECT (Locking driver's door only: selectiveunlocking)
ELECTRIC BOOT (Permanent locking of the boot)
DAY LAMPS

RADIO TEXT

*

The parameters vary according to the vehicle.
1
11
2
2
2
2
2
2
1
2
1
2
2
1
1
2
2
2
1
1
1
1
1
1
1
1
1

297
09SCREEN MENU MAP

Trip computer

Vehicle diagnosis *








SCREEN C


Multimedia
Media parameters
Choice of pla
yback mode
Choice of track listing

Telephone
Call
Dial
Directory
Calls list
Voice mail box
Directory management
Consult an entry
Delete an entry
Delete all entries
Telephone management
Telephone status
Han
g up

Bluetooth connection


Connections management

Search for a device
N
ormal
R
andom
R
andom all
Repeat
B
y folders
B
y artists

By genres

By playlists

Radio parameters
*
The parameters vary according to the vehicle.
11
2
2
1
2
2
2
2
1
2
2
2
1
2
1
1
1
3
3
3
3
3
3
3
3
1

298
09 SCREEN MENU MAP





Personalisation-configuration
Defi ne the vehicle parameters
Access to the vehicle

Plip action
Drivin
g position setting

Unlocking boot only
Driving assistance

Parking brake automatic

Rear wipe in reverse gear
S
peeds memorised
Vehicle lighting

Directional headlamps
Da
ytime lights
Interior li
ghting
Follow-me-home headlamps
Welcome li
ghting
Choice of language Displa
y confi guration
Choice of units
Date and time adjustment
Display parameters
Brightness
Choice of sounds
1
2
3
3
3
2
3
3
3
2
3
3
2
3
3
1
1
2
2
2
2
1

299
FREQUENTLY ASKED QUESTIONS
QUESTIONANSWERSOLUTION
There is a difference in
sound quality between
the different audiosources (radio, CD...).
For optimum sound qualit
y, the audio settings (Volume, Bass, Treble,
Ambience, Loudness) can be adapted to the different sound sources,
which may result in audible differences when changing source (radio, CD...).
Check that the audio settings (Volume, Bass,
Treble, Ambience, Loudness) are adapted to
the sources listened to. It is advisable to set
the AUDIO functions (Bass, Treble, Front-Rear Fader, Left-Right Balance) to the middle position, select the musical ambience "None" and set theloudness correction to the "Active" position in CD
mode or to the "Inactive" position in radio mode.
When chan
ging the
settings for treble and
bass, the ambience
sett
ing is deselected.
When changing the
ambience setting,
tr
eble and bass are reset to zero.
Choosing an ambience imposes settings for treble and bass. Modifying
one without the other is not possible.Modi
fy the treble and bass settings or the ambience setting to obtain the desired sound
quality.
When chan
ging the
balance setting, distribution is deselected. Choosin
g a distribution setting imposes a balance setting. Modifying one
without the other is not possible.Modify the balance setting or the distribution
setting to obtain the desired sound quality. The
following tables contain answers to the most frequently asked questions.

300
FREQUENTLY ASKED QUESTIONS
QUESTIONANSWERSOLUTION
The quality of reception of the radio stationlistened to graduallydeteriorates or the storedstations do not function (no sound, 87.5 MHz is
displayed...).The vehicle is too
far from the transmitter used by the station listened to
or there is no transmitter in the geographical area through whichthe vehicle is travelling. Activate the RD
S function to enable the system
to check whether there is a more powerful
transmitter in the geographical area.
The environment
(hills, buildings, tunnels, basement car parks...) block
reception, including in RDS mode. This phenomenon is normal and does not indicatea failure of the audio equipment.
The aerial is absent or has been dama
ged (for example when goingthrough a car wash or into an underground car park). Have the aerial checked by a CITROËN dealer.
Sound cut-outs of 1 to2 seconds in radio mode. During this brief sound cut-out, the RDS searches for any frequency
permitting better reception of the station. Deactivate the RDS function if the phenomenon is
too frequent and always on the same route.
Th
e traffi c announcement (TA) is displayed. I do not receive any traffi cinformation.Th
e radio station does not broadcast traffi c information. Tune to a radio station which broadcasts traffi c
information.
The stored stations arenot found (no sound,87.5 MHz is displayed...). An incorrect waveband is selected.Press the BAND AST button to return to the
waveband (AM, FM1, FM2, DAB * ) on whichthe stations are stored.
* Digital Audio Broadcasting.

301
FREQUENTLY ASKED QUESTIONS
QUESTIONANSWERSOLUTION
The CD is ejected
automatically or is notplayed by the player. The
CD is inserted upside down, is unplayable, does not contain any audio data or contains an audio format which the player cannot play.
The
CD is protected by an anti-pirating protection system which is not
recognised by the audio equipment.- Check that the CD is inserted in the pla
yer
the right way up.
-
Check the condition of the CD: the CD cannot
be played if it is too damaged.
-
Check the content in the case of a recordedCD: consult the advice in the "Audio" section.
- The audio equipment's
CD player does not
play DVDs.
- Due to their qualit
y level, certain writeableCDs will not be played by the audio system.
The
CD player sound ispoor. The CD used is scratched or of poor qualit
y.Insert good quality CDs and store them in suitable conditions.
The audio settin
gs (bass, treble, ambience) are unsuitable. Set the treble or bass level to 0, without selectingan ambience.
The Bluetooth connectionis cut. The battery of the peripheral may not be suffi ciently charged. Recharge the battery of the peripheral device.
The messa
ge "USB
device error" is displayed
on the screen.The USB memor
y stick is not recognised.
The memory stick may be corrupt.Reformat the memory stick.

302
FREQUENTLY ASKED QUESTIONS
QUESTIONANSWERSOLUTION
A telephone connects
automatically,
disconnecting another
telephone. A
utomatic connection overrides manual connection. Modify the telephone settings to remove automatic connection.

An IPod is not recognised
when connecting to theUSB port.The IPod is of a generation that is not compatible with the USB. Connect the IPod to the AUX Jack socket using a
suitable cable (not supplied).
Th
e hard disk or deviceis not recognised when connecting to the USB port. Some hard disks and devices need a power suppl
y greater than is
provided by the audio system.
Connect the device to the 230 V socket, the 12 V
socket or an external power supply.
Caution
: ensure that the device does not transmit a voltage greater than 5 V (risk of destruction of
the system).
When streaming, the
sound cuts momentarily. Some telephones prioritise connection of the "hands-free" profi le. Delete the "hands-free" connection profi le toimprove streaming.
In "Random all" pla
y, not all of the tracks areplayed.
In "Random all" play, the system can only take into account up to999 tracks.
With the en
gine off, the
audio system switchesoff after a few minutes of use.When the en
gine is switched off, the audio system operating timedepends on the battery charge.
The switch-o
ff is normal: the audio system switches to economy modeand switches off to prevent discharging the vehicle's battery.
Start the vehicle's engine to increase the batterycharge.
The message "the audio
system is overheated"appears on the display.In order to protect the installation i
f the surrounding temperature is too high, the audio system switches to an automatic thermal protection mode
leading to a reduction of the volume or stopping of the playing of the CD.Switch the audio s
ystem off for a few minutes toallow the system to cool.
