2010 PONTIAC VIBE Owners Manual

Parking Brake and Automatic
Transmission P (Park) Mechanism
Check
{CAUTION
When you are doing this check,
the vehicle could begin to move.
You or others could be injured
and property could be damaged.
Make sure there is room in front
of the vehicle in case it begins to
roll. Be ready to apply the regular
brake at once should the vehicle
begin to move.Park on a fairly steep hill, with the
vehicle facing downhill. Keeping
your foot on the regular brake, set
the parking brake.
•To check the parking brake’s
holding ability: With the engine
running and transmission in
N (Neutral), slowly remove foot
pressure from the regular brake
pedal. Do this until the vehicle is
held by the parking brake only.
•To check the P (Park)
mechanism’s holding ability:
With the engine running, shift
to P (Park). Then release the
parking brake followed by the
regular brake.
Contact your dealer/retailer if
service is required. Underbody Flushing Service
At least every spring, use plain water
to flush any corrosive materials from
the underbody. Take care to clean
thoroughly any areas where mud and
other debris can collect.
Periodic Maintenance
Inspections
These inspections and services
should be performed at least twice a
year, for instance, each spring and
fall.
You should let your dealer/
retailer do these jobs. Make sure any
necessary repairs are completed
at once.
Service and Maintenance 10-13

Proper procedures to perform these
services can be found in a service
manual. SeeService Publications
Ordering Information on page 12-12 .
•Inspect the front and rear
suspension and steering system
for damaged, loose, or missing
parts or signs of wear. Inspect
power steering cables for proper
hook-up, binding, cracks, chafing,
etc. Clean and then inspect the
drive axle boot seals for damage,
tears, or leakage. Replace seals if
necessary.
•Inspect the complete exhaust
system. Inspect the body near
the exhaust system. Look for
broken, damaged, missing, or
out-of-position parts as well as
open seams, holes, loose
connections, or other conditions
which could cause a heat build-up
in the floor pan or could let
exhaust fumes into the vehicle.
SeeEngine Exhaust on
page 8-23.
•Inspect the complete fuel system
for damage or leaks.
•Inspect the cooling system
hoses and have them replaced
if they are cracked, swollen or
deteriorated. Inspect all pipes,
fittings and clamps; replace as
needed. Clean the outside of
the radiator and air conditioning
condenser. To help ensure proper
operation, a pressure test of the
cooling system and pressure cap
is recommended at least once
a year.
•Inspect the throttle system for
interference or binding, and for
damaged or missing parts.
Replace parts as needed.
Replace any components that
have high effort or excessive
wear. Do not lubricate accelerator
and cruise control cables.
•Inspect the complete brake
system. Inspect brake lines
and hoses for proper hook-up,
binding, leaks, cracks, chafing,
etc. Inspect disc brake pads for
wear and rotors for surface
condition. Inspect other brake
parts, including calipers, parking
brake, etc. You may need to have
your brakes inspected more often
if your driving habits or conditions
result in frequent braking.
10-14 Service and Maintenance

Recommended Fluids, Lubricants, and Parts
Recommended Fluids and Lubricants
UsageFluid/Lubricant
Engine Oil Engine oil which meets GM Standard GM6094M and displays the
American Petroleum Institute Certified for Gasoline Engines starburst
symbol. To determine the proper viscosity for the vehicle’s engine, see
Engine Oil on page 9-9
.
Engine Coolant 50/50 mixture of clean, drinkable water and use only DEX-COOL
®
Coolant. See
Engine Coolant on page 9-19 .
Hydraulic Brake/Clutch System Hydraulic Brake Fluid (GM Part No. U.S. 88862806, in Canada 88862807). Windshield Washer Optikleen
®Washer Solvent.
Parking Brake Cable Guides Chassis Lubricant (GM Part No. 12377985, in Canada 88901242) or
lubricant meeting requirements of NLGI #2, Category LB or GC-LB.
Automatic Transmission Automatic Transmission Fluid WS ATF (GM Part No. U.S. 88863400,
in Canada 88863401).
Manual Transmission GM Goodwrench
®Synthetic Manual Transmission Fluid
(GM Part No. U.S. 12346190, in Canada 10953477 — 1 quart)
or SAE 75W-90 GL-5 gear oil.
Manual Transmission Shift Linkage Chassis Lubricant (GM Part No. U.S. 12377985, in Canada 88901242)
or lubricant meeting requirements of NLGI #2, Category LB or GC-LB.
Clutch Linkage Pivot Points Chassis Lubricant (GM Part No. U.S. 12377985, in Canada 88901242)
or lubricant meeting requirements of NLGI #2, Category LB or GC-LB.
Service and Maintenance 10-15

UsageFluid/Lubricant
Floor Shift Linkage Lubriplate Lubricant Aerosol (GM Part No. U.S. 12346293,
in Canada 992723) or lubricant meeting requirements of NLGI #2,
Category LB or GC-LB.
Key Lock Cylinders Multi-Purpose Lubricant, Superlube (GM Part No. U.S. 12346241,
in Canada 10953474).
Chassis Lubrication Chassis Lubricant (GM Part No. U.S. 12377985, in Canada 88901242)
or lubricant meeting requirements of NLGI #2, Category LB or GC-LB.
Rear Axle (All-Wheel Drive) Axle Lubricant (GM Part No. U.S. 12345977, in Canada 10953482)
or SAE 80W-90 GL-5 gear lubricant.
Transfer Case (All-Wheel Drive) Axle Lubricant (GM Part No. U.S. 89021669, in Canada 89021670)
or SAE 80W-90 GL-5 API Hypoid Gear Lubricant.
Hood Latch Assembly, Secondary Latch, Pivots, Spring Anchor, and Release Pawl Lubriplate Lubricant Aerosol (GM Part No. U.S. 12346293,
in Canada 992723) or lubricant meeting requirements of NLGI #2,
Category LB or GC-LB.
Hood and Door Hinges Multi-Purpose Lubricant, Superlube (GM Part No. U.S. 12346241,
in Canada 10953474).
Weatherstrip Conditioning Weatherstrip Lubricant (GM Part No. U.S. 3634770, in Canada 10953518)
or Dielectric Silicone Grease (GM Part No. U.S. 12345579,
in Canada 992887).
10-16 Service and Maintenance

Maintenance Replacement Parts
Replacement parts identified below by name, part number, or specification can be obtained from your dealer/retailer.
PartGM Part Numbers Other Part Numbers
Engine Air Cleaner/Filter 1.8L L4 Engine 88975792—
2.4L L4 Engine 88975799—
Engine Oil Filter 1.8L L4 Engine* 19185485—
2.4L L4 Engine 88969580—
Passenger Compartment Air Filter 19184673—
Spark Plugs** 1.8L L4 Engine 19185438SK20HR11†
2.4L L4 Engine 88969636SK20R11†
IFR6A11††
*Oil Filter Element Kit includes element and seal.
**The engine is fitted with iridium-tipped spark plugs. Use only iridium-tipped spark plugs for better engine
performance.
† DENSO
†† NGK
Service and Maintenance 10-17

Maintenance Records
After the scheduled services are performed, record the date, odometer reading, who performed the service, and the
type of services performed in the boxes provided. Retain all maintenance receipts.
Maintenance Record
DateOdometer
Reading Serviced By Maintenance Record
10-18 Service and Maintenance

Maintenance Record (cont’d)
DateOdometer
Reading Serviced By Maintenance Record
Service and Maintenance 10-19

Maintenance Record (cont’d)
DateOdometer
Reading Serviced By Maintenance Record
