2010 JAGUAR XFR abs module

DTC Description Possible Causes Action Sensor or Left Rear
Vertical Acceleration
Sensor or Right Rear
Vertical Acceleration
Sensor supply partial
short to other circuit
or ground
Left Front Vertical
Acceleration Sensor or
Right Front Vertical
Acceleration Sensor or
Left Rear Vertical
Acceleration Sensor or
Right Rear Vertical
Acceleration Sensor
internal failure
Internal control
module failure U0001-88
High speed CAN
communication
bus - Bus off
Lost Communication
With Engine Control
Module (ECM) (CAN
Bus circuit fault)
Check Engine Control Module for stored DTCs. Refer to the
electrical circuit diagrams and check CAN Bus circuit for faults,
check CAN circuits for open circuits or shorts to power, ground
or other circuits U0100-00
Lost
Communication
With ECM/PCM A
- No sub type
information
Missing message from
ECM
Check Engine Control Module for stored DTCs. Refer to the
electrical circuit diagrams and check CAN Bus for circuit fault U0101-00
Lost
Communication
with TCM - No
sub type
information
Lost Communication
with Transmission
control module (TCM)
(CAN Bus circuit fault)
Check Transmission Control Module for stored DTCs. Refer to
the electrical circuit diagrams and check CAN Bus for circuit
fault U0103-00
Lost
Communication
With Gear Shift
Control Module
A - No sub type
information
Lost Communication
With Gear Shift
Module (GSM) (CAN
Bus circuit fault)
Check Gear Shift Module for stored DTCs. Refer to the
electrical circuit diagrams and check Can Bus for circuit faults U0121-00
Lost
Communication
With Anti-Lock
Brake System
(ABS) Control
Module - No sub type information
Lost Communication
With Anti-Lock Brake
System (ABS) Control
Module (CAN Bus
circuit fault)
Check Anti lock Brake System Control Module for stored DTCs.
Refer to the electrical circuit diagrams and check Can Bus
circuit to Anti lock Brake System Control Module for circuit
faults U0132-00 Lost
Lost Communication
Check Air Suspension Control Module for stored DTCs. Refer to Communication With Suspension With Air Suspension the electrical circuit diagrams and check CAN Bus circuit to Air Control Module Control Module (CAN Suspension Control Module for circuit faults A - No sub type Bus circuit fault information U0136-00
Lost
Communication
With Differential
Control Module -
Rear - No sub type information
Lost Communication
With Rear Differential
Control Module (CAN
Bus circuit fault)
Check Rear Differential Control Module for stored DTCs. Refer
to the electrical circuit diagrams and check Can Bus circuit to
Rear Differential Control Module for circuit faults U0140-00
Lost
Communication
With Body
Control Module -
No sub type
information
Lost Communication
With Body Control
Module (Front Smart
Junction Box) (CAN
Bus circuit fault)
Check Body Control Module for stored DTCs. Refer to the
electrical circuit diagrams and check CAN Bus circuit to Body
Control Module for faults U0142-00
Lost
Communication
With Body
Control Module
B - No sub type
information
Lost Communication
with rear smart
junction box (CAN Bus
circuit fault)
Check Rear Smart Junction Box for stored DTCs. Refer to the
electrical circuit diagrams and check Can Bus circuit to Rear
Smart Junction Box for faults U0155-00
Lost
Communication
With Instrument
Panel Cluster
Lost Communication
With Instrument Panel
Cluster (IPC) Control
Check Instrument Panel Cluster for stored DTCs. Refer to the
electrical circuit diagrams and check CAN Bus to Instrument
Panel Cluster for circuit fault

DTC Description Possible Causes Action (IPC) Control
Module - No sub
type information Module (CAN bus
circuit fault) U0300-00
Internal control
module software
incompatibility -
No sub type
information
CAN master
configuration ID
incorrect
Check Front Smart Junction Box vehicle configuration file,
check part number of adaptive damping control module U0401-68
Invalid Data
Received from
ECM/PCM A -
Event
information
Invalid Data Received
from Engine Control
Module
Check Engine Control Module for DTCs. Refer to the relevant
DTC index U0402-68
Invalid Data
Received from TCM - Event
information
Invalid Data Received
from Transmission
control module
Check for Transmission Control Module DTCs. Refer to relevant
DTC index U0404-68
Invalid Data
Received from
Gear Shift
Control Module
A - Event
information
Invalid data received
from gear shift control
module
Check Gear Shift Control Module for DTCs. Refer to the
relevant DTC index U0415-68
Invalid Data
Received From
Anti-Lock Brake
System (ABS)
Control Module -
Event
information
Invalid Data Received
From Anti-Lock Brake
System (ABS) Control
Module
Check for Anti lock Brake System DTCs. Refer to the relevant
DTC index U0421-68
Invalid Data
Received from
Suspension
Control Module
A - Event
information
Invalid Data Received
From Air Suspension
Control Module
Check Air Suspension Control Module for stored DTCs. Refer to
the relevant DTC index U0422-68
Invalid Data
Received From
Body Control
Module - Event
information
Invalid Data Received
From Body Control
Module (Front Smart
Junction Box)
Check Body Control Module (Front Smart Junction Box) for
stored DTCs. Refer to the relevant DTC index U0437-68
Invalid Data
Received From
Differential
Control Module -
Rear - Event
information
Invalid Data Received
From Rear Differential
Control Module
Check Rear Differential Control Module for stored DTCs. Refer
to the relevant DTC index U0443-68
Invalid Data
Received From
Body Control
Module B -
Event
information
Invalid Data Received
From body control
module B (Rear Smart
Junction Box)
Check rear smart junction box for DTCs and refer to relevant
DTC index U1A14-00 CAN
initialization
failure - No sub type information
CAN network harness
short, disconnected
Refer to circuit diagrams and check CAN Bus circuit for fault
(short to power, ground or open circuit) U2100-00
Initial
Configuration
Not Complete -
No sub type
information
Car Configuration
Data not loaded (New
Body Control Module
(Front Smart Junction
Box) fitted to vehicle
and not initialized)
Internal Body Control
Module (Front Smart
Junction Box) failure
Install car config to Front Smart Junction Box. Clear DTC and
retest systems U2101-00
Control Module
Configuration
Incompatible -
No sub type
information
Car Configuration
Data transmitted over
CAN does not match
adaptive damping
control module
internal config
Carry out the new module software installation procedure

Published: 17-Apr-2014
General Information - Diagnostic Trouble Code (DTC) Index DTC: Anti-Lock Braking System (ABS)
Description and Operation

Anti-Lock Braking System (ABS)


CAUTION: Diagnosis by substitution from a donor vehicle is NOT acceptable. Substitution of control modules does not
guarantee confirmation of a fault, and may also cause additional faults in the vehicle being tested and/or the donor vehicle
NOTES:


If the control module or a component is suspect and the vehicle remains under manufacturer warranty, refer to the
warranty policy and procedures manual, or determine if any prior approval programme is in operation, prior to the installation
of a new module/component


Generic scan tools may not read the codes listed, or may read only 5-digit codes. Match the 5 digits from the scan tool to
the first 5 digits of the 7-digit code listed to identify the fault (the last 2 digits give extra information read by the
manufacturer-approved diagnostic system)


When performing voltage or resistance tests, always use a digital multimeter accurate to three decimal places and with a
current calibration certificate. When testing resistance, always take the resistance of the digital multimeter leads into account


Check and rectify basic faults before beginning diagnostic routines involving pinpoint tests


Inspect connectors for signs of water ingress, and pins for damage and/or corrosion


If diagnostic trouble codes are recorded and, after performing the pinpoint tests, a fault is not present, an intermittent
concern may be the cause. Always check for loose connections and corroded terminals


Where an 'on demand self-test' is referred to, this can be accessed via the 'diagnostic trouble code monitor' tab on the
manufacturers approved diagnostic system


Check DDW for open campaigns. Refer to the corresponding bulletins and SSMs which may be valid for the specific
customer complaint and carry out the recommendations as required

The table below lists all Diagnostic Trouble Codes (DTCs) that could be logged in the anti-lock braking system module, for
additional diagnosis and testing information refer to the relevant Diagnosis and Testing Section.
For additional information, refer to: Anti-Lock Control - Stability Assist (206-09 Anti-Lock Control - Stability Assist, Diagnosis
and Testing).

DTC Description Possible Causes Action C0021-09
Brake Booster
Performance -
Component Failures
No vacuum available from
engine due to split/leaking
hose etc
Brake booster servo has
failed due to lack of vacuum
Check integrity of brake booster vacuum hose.
Check and install a new brake booster as required C0030-38
Left Front Tone
Wheel - Signal
frequency incorrect
Left front magnetic pulse
ring damaged/contaminated
Incorrect component
installed
Sensor internal fault
Check the left front magnetic pulse ring for damage
or contamination. Clean or replace as required. If no
damage/contamination found, suspect wheel speed
sensor. Refer to the Warranty Policy and Procedures
manual if a module/component is suspect. To
validate the repair and extinguish the lamps, the
vehicle needs to be driven above 9mph/15kph for
more than 10 seconds C0031-12
Left Front Wheel
Speed Sensor -
Short to battery
Electrical wiring harness
fault
Sensor internal fault
Refer to the electrical circuit diagrams and check the
wheel speed sensor circuit for short to power. Repair
harness as required. If no harness fault found,
suspect wheel speed sensor. Refer to the Warranty
Policy and Procedures manual if a www.JagDocs.com

DTC Description Possible Causes Action the CAN network U0140-00
Lost Communication
With Body Control
Module - No sub type
information
No sub type information
Refer to the electrical circuit diagrams and check
the power and ground connections to the module.
Using the manufacturer approved diagnostic
system, complete a CAN network integrity test.
Refer to the electrical circuit diagrams and check
the CAN network between the Central Junction
Box and Blind Spot Monitoring System Module U0155-00
Lost Communication
With Instrument Panel
Cluster (IPC) Control
Module - No sub type
information
No sub type information
Refer to the electrical circuit diagrams and check
the power and ground connections to the module.
Using the manufacturer approved diagnostic
system, complete a CAN network integrity test.
Refer to the electrical circuit diagrams and check
the CAN network between the Instrument Cluster
and Blind Spot Monitoring System Module U0232-00
Lost Communication
With Blind Spot
Monitoring System
Module - Left - No sub
type information
CAN bus circuit fault
Harness fault between left
side mirror and left side
module
Refer to the electrical circuit diagrams and check
the power and ground connections to the module.
Using the manufacturer approved diagnostic
system, complete a CAN network integrity test.
Refer to the electrical circuit diagrams and check
the CAN network between the left Blind Spot
Monitoring System Module and the right Blind
Spot Monitoring System Module
Refer to the electrical circuit diagrams and check
the left side harness between the left side mirror
and left hand module U0233-00
Lost Communication
With Blind Spot
Monitoring System
Module - Right - No sub
type information
CAN bus circuit fault
Harness fault between
right side mirror and right
side module
Refer to the electrical circuit diagrams and check
the power and ground connections to the module.
Using the manufacturer approved diagnostic
system, complete a CAN network integrity test.
Refer to the electrical circuit diagrams and check
the CAN network between the left Blind Spot
Monitoring System Module and the right Blind
Spot Monitoring System Module
Refer to the electrical circuit diagrams and check
the right side harness between the right side
mirror and right hand module U0300-00
Internal Control Module
Software Incompatibility
- No sub type
information
No sub type information
Check Central Junction Box for related DTCs and
refer to the relevant DTC Index. Check Restraints
Control Module for related DTCs and refer to DTC
Index. Check correct components are installed
and that the latest software version is installed U0415-68
Invalid Data Received
From Anti-Lock Brake
System (ABS) Control
Module - event
information
Event information
Using the manufacturer approved diagnostic
system check the central junction box and the
anti-lock brake system (ABS) control module for
related DTCs and refer to the relevant DTC Index U0422-68
Invalid Data Received
From Body Control
Module - Event
information
Event information
Check the Central Junction Box for related DTCs
and refer to the relevant DTC index U2100-00
Initial Configuration Not
Complete - No sub type
information
Car Configuration File
information not received
completely
Check/amend Car Configuration File using
manufacturer approved diagnostic system U2101-00
Control Module
Configuration
Incompatible - No sub
type information
Car Configuration File
information incompatible
to Control module
Check/amend Car Configuration File using
manufacturer approved diagnostic system U3000-44
Control Module - Data
memory failure
Control module data
memory failure
Refer to the electrical circuit diagrams and check
the power and ground circuits to the component.
Refer to the warranty policy and procedures
manual if a module is suspect

DTC Description Possible Causes Action system, complete a CAN network integrity test.
Refer to the electrical circuit diagrams and check
the CAN network U0103-00
Lost communication
With Gear Shift Module
A - No sub type
information
Gear shift control module /
system fault
Wiring harness fault
Check the Gear Shift Control Module for related
DTCs and refer to the relevant DTC index
Refer to the electrical circuit diagrams and check
the power and ground connections to the module.
Using the manufacturer approved diagnostic
system, complete a CAN network integrity test.
Refer to the electrical circuit diagrams and check
the CAN network U0104-00 Lost communication
Speed control module /
Check the Speed Control Module for related DTCs With Cruise Control Module A - No sub type system fault and refer to the relevant DTC index information Wiring harness fault Refer to the electrical circuit diagrams and check the power and ground connections to the module. Using the manufacturer approved diagnostic system, complete a CAN network integrity test. Refer to the electrical circuit diagrams and check the CAN network U0121-00
Lost communication
with Anti-Lock Braking
System (ABS) Control
Module - No sub type
information
Anti-Lock Braking System
control module / system
fault
Wiring harness fault
Check the Anti-Lock Braking System Control
Module for related DTCs and refer to the relevant
DTC index
Refer to the electrical circuit diagrams and check
the power and ground connections to the module.
Using the manufacturer approved diagnostic
system, complete a CAN network integrity test.
Refer to the electrical circuit diagrams and check
the CAN network U0155-00
Lost Communication
With Instrument Panel
Cluster (IPC) Control
Module - No sub type
information
Instrument Cluster /
system fault
Wiring harness fault
Check the Instrument Cluster for related DTCs
and refer to the relevant DTC index
Refer to the electrical circuit diagrams and check
the power and ground connections to the module.
Using the manufacturer approved diagnostic
system, complete a CAN network integrity test.
Refer to the electrical circuit diagrams and check
the CAN network U0300-00
Internal Control Module
Software
Incompatibility - No sub
type information
Car configuration file
stored in Park Brake
Module does not match the
master car configuration
file
Master car configuration
file not being transmitted
by master control module
Check all control modules for related DTCs and
refer to the relevant DTC index
Check the components installed on the vehicle
were installed by the factory or a dealer
Install the original components or a new one as
required U0401-00
Invalid Data Received
From ECM/PCM - No sub
type information
Invalid message from the
Engine Control Module
Check the Engine Control Module for related DTCs
and refer to the relevant DTC index U0404-00
Invalid Data Received
From Gear Shift Control
Module A - No sub type
information
Invalid message from the
gear shift control module
Check the Gear Shift Control Module for related
DTCs and refer to the relevant DTC index U0415-00
Invalid Data Received
From Anti-Lock Braking
System (ABS) Control
Module - No sub type
information
Invalid message from the
anti-lock Braking system
module
NOTE: This DTC may be stored even though no fault
condition is present and should be ignored unless the
customer has reported a electronic park brake concern.
Clear the DTC and retest. Verify the customer concern
prior to diagnosis

Check the Anti-Lock Braking System Control
Module for related DTCs and refer to the relevant
DTC index U0422-00
Invalid data received
from Central Junction
Box - No sub type
information
Invalid message from the
Central Junction Box
Check the Central Junction Box for related DTCs
and refer to the relevant DTC index

DTC Description Possible Causes Action
LR - Circuit UHEGO HEATER B -

Catalyst oxygen sensor heater
circuit control fuse failure
Post catalyst oxygen sensor-even
heater control circuit short circuit
to ground, short circuit to power,
open circuit, high resistance
Catalyst oxygen sensor heater
circuit control relay circuit short
circuit to ground, short circuit to
power, open circuit
Catalyst oxygen sensor heater
circuit control relay failure
Post catalyst oxygen sensor-even
failure Refer to the electrical circuit
diagrams and check post catalyst
oxygen sensor-even sensor fuse for
open circuit
Refer to the electrical circuit
diagrams and check post catalyst
oxygen sensor-even sensor circuit for
short circuit to ground, short circuit
to power, open circuit, high
resistance
Refer to the electrical circuit
diagrams and check catalyst oxygen
sensor heater circuit control relay
circuit for short circuit to ground,
short circuit to power, open circuit
Check and install a new catalyst
oxygen sensor heater control relay,
as required. Check and install a new
post catalyst oxygen sensor-even as
required. Refer to the warranty policy
and procedures manual, or determine
if any prior approval programme is in
operation, prior to the installation of
a new module/component P0069-29
MAP - Barometric Pressure
Correlation - Signal invalid
Manifold absolute pressure sensor
failure
Engine control module failure
Using the manufacturer approved
diagnostic system check datalogger
signal, Barometric Pressure Sensor
Voltage (0x035A). Check for related
manifold absolute pressure sensor
DTCs
Refer to the electrical circuit
diagrams and check manifold
absolute pressure sensor circuit for
short circuit to ground, short circuit
to power, open circuit
Check and install new manifold
absolute pressure sensor as
required. Check and install a new
engine control module as required.
Refer to the warranty policy and
procedures manual, or determine if
any prior approval programme is in
operation, prior to the installation of
a new module/component P0071-21
Ambient Air Temperature
Sensor Range/Performance -
Signal amplitude < minimum NOTES:


Jaguar - Circuit
AMBIENT_TEMP_SENSOR -


LR - Circuit TAMB TEMP -

Ambient air temperature sensor
circuit short circuit to ground, short
circuit to power, open circuit
Temperature and manifold absolute
pressure sensor circuit short circuit
to ground, short circuit to power,
open circuit
Ambient air temperature sensor
failure
Temperature and manifold absolute
pressure sensor failure
Using the manufacturer approved
diagnostic system check datalogger
signal, Ambient Air Temperature
Sensor Voltage (0x03BA)
Refer to the electrical circuit
diagrams and check ambient air
temperature sensor circuit for short
circuit to ground, short circuit to
power, open circuit
Refer to the electrical circuit
diagrams and check temperature and
manifold absolute pressure sensor
circuit for short circuit to ground,
short circuit to power, open circuit
Check and install a new ambient air
temperature sensor as required.
Check and install a new temperature
and manifold absolute pressure
sensor as required. Refer to the
warranty policy and procedures
manual, or determine if any prior
approval programme is in operation,
prior to the installation of a new
module/component P0071-22
Ambient Air Temperature
Sensor Range/Performance -
Signal amplitude > maximum NOTES:


- Circuit AMBIENT_TEMP_SENSOR -
Using the manufacturer approved
diagnostic system check datalogger
signal, Ambient Air Temperature
Sensor Voltage (0x03BA)
Refer to the electrical circuit www.JagDocs.com

DTC Description Possible Causes Action
LR - Circuit TAMB TEMP -

Ambient air temperature sensor
circuit short circuit to ground, short
circuit to power, open circuit
Temperature and manifold absolute
pressure sensor circuit short circuit
to ground, short circuit to power,
open circuit
Ambient air temperature sensor
failure
Temperature and manifold absolute
pressure sensor failure diagrams and check ambient air
temperature sensor circuit for short
circuit to ground, short circuit to
power, open circuit
Refer to the electrical circuit
diagrams and check temperature and
manifold absolute pressure sensor
circuit for short circuit to ground,
short circuit to power, open circuit
Check and install a new ambient air
temperature sensor as required.
Check and install a new temperature
and manifold absolute pressure
sensor as required. Refer to the
warranty policy and procedures
manual, or determine if any prior
approval programme is in operation,
prior to the installation of a new
module/component P0072-00
Ambient Air Temperature
Sensor Circuit Low - No sub
type information NOTES:


- Circuit AMBIENT_TEMP_SENSOR -


LR - Circuit TAMB TEMP -

Ambient air temperature sensor
circuit short circuit to ground, open
circuit, high resistance
Ambient air temperature sensor
failure
Using the manufacturer approved
diagnostic system check datalogger
signal, Ambient Air Temperature
Sensor Voltage (0x03BA)
Refer to the electrical circuit
diagrams and check ambient air
temperature sensor circuit for short
circuit to ground, open circuit, high
resistance
Check and install a new ambient air
temperature sensor as required.
Refer to the warranty policy and
procedures manual, or determine if
any prior approval programme is in
operation, prior to the installation of
a new module/component P0073-00
Ambient Air Temperature
Sensor Circuit High - No sub
type information NOTES:


- Circuit AMBIENT_TEMP_SENSOR -


LR - Circuit TAMB TEMP -

Ambient air temperature sensor
ground circuit high resistance,
open circuit
Ambient air temperature sensor
signal circuit short circuit to power
Ambient air temperature sensor
failure
Using the manufacturer approved
diagnostic system check datalogger
signals Ambient Air Temperature
Sensor Voltage (0x03BA)
Refer to the electrical circuit
diagrams and check ambient air
temperature sensor circuit for short
circuit to ground, high resistance,
short circuit to power. Check
connector terminals for corrosion or
damage
Check and install a new ambient air
temperature sensor as required.
Refer to the warranty policy and
procedures manual, or determine if
any prior approval programme is in
operation, prior to the installation of
a new module/component P007B-23
Charge Air Cooler
Temperature Sensor Circuit
Range/Performance (Bank 1)
- Signal stuck low
NOTE: - Circuit TMAP_TEMP_SENSOR
-

Charge air cooler temperature
sensor circuit poor / intermittent
connection
Charge air cooler temperature
sensor failure
Using the manufacturer approved
diagnostic system check datalogger
signal, Charge Air Temperature
Voltage (0x03EE)
Refer to the electrical circuit
diagrams and check charge air cooler
temperature sensor circuit for poor,
intermittent connection
Check and install a new charge air
cooler temperature sensor as
required. Refer to the warranty policy
and procedures manual, or determine
if any prior approval programme is in
operation, prior to the installation of
a new module/component

DTC Description Possible Causes Action P007B-24
Charge Air Cooler
Temperature Sensor Circuit
Range/Performance (Bank 1)
- Signal stuck high
NOTE: Jaguar circuit reference
IC_COOLANT_PMP_CTRL &
BOOST_PRESS_SENSOR_TEMP_SIG. Land
Rover circuit reference O_S_CACWPR &
I_A_BTS

Connector is disconnected,
connector pin is backed out,
connector pin corrosion
Fuse failure
Temperature and manifold absolute
pressure sensor circuit, short
circuit to ground, short circuit to
power, open circuit, high resistance
Temperature and manifold absolute
pressure sensor failure
Air charge coolant pump and
control circuit, short circuit to
ground, short circuit to power, open
circuit, high resistance
Air charge coolant pump relay
failure
Air charge coolant pump failure
Inspect connectors for signs of water
ingress, and pins for damage and/or
corrosion
Refer to electrical circuit diagrams
and check for fuse failure, install
new fuse as required
Refer to electrical circuit diagrams
and check the temperature and
manifold absolute pressure sensor
circuit for short circuit to ground,
short circuit to power, open circuit,
high resistance
Check and install a new temperature
and manifold absolute pressure
sensor as required
Refer to electrical circuit diagrams
and check the air charge coolant
pump and control circuit for short
circuit to ground, short circuit to
power, open circuit, high resistance
Refer to electrical circuit diagrams
and check the air charge coolant
pump for open circuit, high
resistance
Refer to the relevant section of the
workshop manual and check the air
charge coolant pump for correct
operation. Check and install a new
air charge coolant pump as required
Clear DTC and retest P007B-29
Charge Air Cooler
Temperature Sensor Circuit
Range/Performance (Bank 1)
- Signal invalid
NOTE: Jaguar circuit reference
IC_COOLANT_PMP_CTRL &
BOOST_PRESS_SENSOR_TEMP_SIG. Land
Rover circuit reference O_S_CACWPR &
I_A_BTS

Connector is disconnected,
connector pin is backed out,
connector pin corrosion
Fuse failure
Temperature and manifold absolute
pressure sensor circuit, short
circuit to ground, short circuit to
power, open circuit, high resistance
Temperature and manifold absolute
pressure sensor failure
Air charge coolant pump and
control circuit, short circuit to
ground, short circuit to power, open
circuit, high resistance
Air charge coolant pump relay
failure
Air charge coolant pump failure
Inspect connectors for signs of water
ingress, and pins for damage and/or
corrosion
Refer to electrical circuit diagrams
and check for fuse failure, install
new fuse as required
Refer to electrical circuit diagrams
and check the temperature and
manifold absolute pressure sensor
circuit for short circuit to ground,
short circuit to power, open circuit,
high resistance
Check and install a new temperature
and manifold absolute pressure
sensor as required
Refer to electrical circuit diagrams
and check the air charge coolant
pump and control circuit for short
circuit to ground, short circuit to
power, open circuit, high resistance
Refer to electrical circuit diagrams
and check the air charge coolant
pump for open circuit, high
resistance
Refer to the relevant section of the
workshop manual and check the air
charge coolant pump for correct
operation. Check and install a new
air charge coolant pump as required
Clear DTC and retest P007C-00
Charge Air Cooler
Temperature Sensor Circuit
Low (Bank 1) - No sub type
information
NOTE: - Circuit TMAP_TEMP_SENSOR
-

Charge air cooler temperature
sensor (Bank 1) circuit short circuit
to ground, open circuit, high
resistance
Charge air cooler temperature
sensor (Bank 1) failure
Refer to the electrical circuit
diagrams and check charge air cooler
temperature sensor (Bank 1) circuit
for short circuit to ground, open
circuit, high resistance
Check and install a new charge air
cooler temperature sensor (Bank 1)
as required. Refer to the warranty
policy and procedures manual, or
determine if any prior approval
programme is in operation, prior to
the installation of a new
module/component
