2010 INFINITI QX56 check engine

B2192 ID DISCORD, IMMU-ECMSEC-35
< COMPONENT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
B2192 ID DISCORD, IMMU-ECM
DescriptionINFOID:0000000005147099
BCM performs the ID verification with ECM that allows the engine to start. BCM starts the communication with
ECM if ignition switch is turned ON and starts the engi ne if the ID is OK. ECM prevents the engine from start-
ing if the ID is not registered.
DTC LogicINFOID:0000000005147100
DTC DETECTION LOGIC
NOTE:
• If DTC B2192 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
SEC-26, "
DTC Logic".
• If DTC B2192 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to
SEC-27, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> Refer to SEC-35, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000005147101
1.PERFORM INITIALIZATION
Perform initialization with CONSULT-III. Re-register all mechanical keys.
For initialization and registration of mechanical key. Refer to “CONSULT-III Operation Manual”.
Can the system be initialized and can the engine be started with re-registered mechanical key?
YES >> ID was unregistered.
NO >> GO TO 2
2.PEPLACE BCM
1. Replace BCM. Refer to BCS-59, "
Removal and Installation".
2. Perform initialization with CONSULT- III. Re-register all mechanical keys.
For initialization and registration of mechanical key. Refer to “CONSULT-III Operation Manual”.
Can the system be initialized and can the engine be started with re-registered mechanical key?
YES >> BCM is malfunctioning.
NO >> GO TO 3
3.PEPLACE ECM
1. Replace ECM. Refer to Removal and Installation.
2. Perform initialization with CONSULT- III. Re-register all mechanical keys.
For initialization and registration of mechanical key. Refer to “CONSULT-III Operation Manual”.
Can the system be initialized and can the engine be started with re-registered mechanical key?
YES >> ECM is malfunctioning.
NO >> GO TO 4
4.CHECK INTERMITTENT INCIDENT
Refer to GI-38, "
Intermittent Incident".
DTC No. Trouble diagnosis
name DTC detecting condition
Possible cause
B2192 ID DISCORD IMMU-
ECM The ID verification results between BCM and ECM
are NG. The registration is necessary. •BCM
•ECM
Revision: April 20092010 QX56

B2193 CHAIN OF ECM-IMMUSEC-37
< COMPONENT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
B2193 CHAIN OF ECM-IMMU
DescriptionINFOID:0000000005147102
BCM performs the ID verification with ECM that allows the engine to start. BCM starts the communication with
ECM if ignition switch is turned ON and starts the engi ne if the ID is OK. ECM prevents the engine from start-
ing if the ID is not registered.
DTC LogicINFOID:0000000005147103
DTC DETECTION LOGIC
NOTE:
• If DTC B2193 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
SEC-26, "
DTC Logic".
• If DTC B2193 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to
SEC-27, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> Refer to SEC-37, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000005147104
1.REPLACE BCM
1. Replace BCM. Refer to BCS-59, "
Removal and Installation".
2. Perform initialization with CONSULT-III. For initialization, refer to “CONSULT-III Operation Manual”.
Does the engine start?
YES >> BCM was malfunctioning.
NO >> ECM is malfunctioning. • Replace ECM.
• Perform ECM re-communicating function.
DTC No. Trouble diagnosis
name DTC detecting condition
Possible cause
B2193 CHAIN OF ECM-
IMMU Inactive communication between ECM and BCM • Harness or connectors
(The CAN communication line is
open or short)
•BCM
•ECM
Revision: April 20092010 QX56

SEC-38
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2194 ID DISCORD IMMU-I-KEY
B2194 ID DISCORD IMMU-I-KEY
DescriptionINFOID:0000000005147105
BCM performs the ID verification with Intelligent Key unit that allows the engine to start. BCM starts the com-
munication with Intelligent Key unit if ignition switch is turned ON and starts the engine if the ID is OK. BCM
prevents the engine from starting if the ID is not registered.
DTC LogicINFOID:0000000005147106
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> Refer to SEC-38, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000005147107
1.PERFORM INITIALIZATION
1. Perform initialization with CONSULT-III. Re-register all mechanical keys. For initialization and registration of mechanical key. Refer to “CONSULT-III Operation Manual”.
2. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> GO TO 2
NO >> ID was unregistered.
2.REPLACE BCM
1. Turn ignition switch OFF.
2. Replace BCM. Refer to BCS-59, "
Removal and Installation".
3. Perform initialization with CONSULT-III. Re-register all mechanical keys. For initialization and registration of mechanical key. Refer to “CONSULT-III Operation Manual”.
Can the system be initialized and can the engine be started?
YES >> BCM is malfunctioning.
NO >> GO TO 3
3.CHECK INTERMITTENT INCIDENT
Refer to GI-38, "
Intermittent Incident".
>> Inspection End.
DTC No. Trouble diagnosis
name DTC detecting condition
Possible cause
B2194 DISCORD IMMU-I-
KEY The ID verification results between BCM and Intel-
ligent Key unit are NG. The registration is neces-
sary. •BCM
• Intelligent Key unit
Revision: April 20092010 QX56

B2552 INTELLIGENT KEYSEC-39
< COMPONENT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
B2552 INTELLIGENT KEY
DescriptionINFOID:0000000005147108
Intelligent key unit performs engine start operation and steering lock control by crosschecking ID with the Intel-
ligent key.
DTC LogicINFOID:0000000005147109
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> Refer to SEC-39, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000005147110
1.REPLACE INTELLIGENT KEY UNIT
1. Replace Intelligent Key unit. Refer to SEC-120, "
Removal and Installation".
2. Perform initialization with CONSULT- III. Re-register all mechanical keys. Refer to “CONSULT-III Opera-
tion Manual”.
3. Start the engine.
Does the engine start?
YES >> Inspection End.
NO >> Perform “DTC confirmation procedure”. Refer to SEC-39, "
DTC Logic".
Special Repair RequirementINFOID:0000000005147111
1.REQUIRED WORK WHEN REPLACING INTELLIGENT KEY UNIT
Initialize control unit. Refer to CONSULT-III Operation Manual.
>> Inspection End.
DTC No. Trouble diagnosis
name DTC detecting condition
Possible cause
B2552 INTELLIGENT KEY
UNIT Malfunction is detected inside Intelligent
key unit.
Intelligent Key unit
Revision: April 20092010 QX56

SEC-40
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2590 ID DISCORD BCM-I-KEY
B2590 ID DISCORD BCM-I-KEY
DescriptionINFOID:0000000005147112
Intelligent Key unit performs the ID verification with BCM that allows the engine to start. BCM starts the engine
if the ID is OK and prevents the engine from
starting if the ID is not registered.
DTC LogicINFOID:0000000005147113
DTC DETECTION LOGIC
NOTE:
• If DTC B2590 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
SEC-26, "
DTC Logic".
• If DTC B2590 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to SEC-27, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> Refer to SEC-40, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000005147114
1.PERFORM INITIALIZATION
Perform initialization with CONSULT-III. Re-register all mechanical keys.
For initialization and registration of mechanical key. Refer to “CONSULT-III Operation Manual”.
Can the system be initialized and can the engine be started with re-registered mechanical key?
YES >> ID was unregistered.
NO >> BCM is malfunctioning. • Replace BCM. Refer to BCS-59, "
Removal and Installation".
• Perform initialization again
DTC No. Trouble diagnosis
name DTC detecting condition
Possible cause
B2590 ID DISCORD BCM-I-
KEY The ID verification results between BCM and Intel-
ligent Key unit are NG. The registration is neces-
sary. •BCM
• Intelligent Key unit
Revision: April 20092010 QX56

P1610 LOCK MODESEC-41
< COMPONENT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
P1610 LOCK MODE
DescriptionINFOID:0000000005147115
When the starting operation is carried more than five times consecutively under the following conditions, NATS
will shift to the mode which prevents the engine from being started.
• Unregistered mechanical key is used.
• BCM or ECM's malfunctioning.
DTC LogicINFOID:0000000005147116
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> Refer to SEC-41, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000005147117
1.CHECK ENGINE START FUNCTION
1. Perform the check for DTC except DTC P1610.
2. Use CONSULT-III to erase DTC after fixing.
3. Check that engine can start with registered mechanical key.
Does the engine start?
YES >> Inspection End.
NO >> GO TO 2
2.CHECK INTERMITTENT INCIDENT
Refer to GI-38, "
Intermittent Incident".
>> Inspection End.
DTC No. Trouble diagnosis
name DTC detecting condition
Possible cause
P1610 LOCK MODE When the starting operation is carried out
five or more times consecutively under the
following conditions.
• Unregistered mechanical key
• BCM or ECM's malfunctioning. —
Revision: April 20092010 QX56

SEC-42
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
P1611 ID DISCORD, IMMU-ECM
P1611 ID DISCORD, IMMU-ECM
DescriptionINFOID:0000000005197366
BCM performs the ID verification with ECM that allows
the engine to start. BCM starts the communication with
ECM if ignition switch is turned ON and starts the engine if the ID is OK. ECM prevents the engine from start-
ing if the ID is not registered.
DTC LogicINFOID:0000000005197367
DTC DETECTION LOGIC
NOTE:
• If DTC P1611 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to SEC-26, "
DTC Logic".
• If DTC B1611 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to
SEC-27, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> Refer to SEC-42, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000005197368
1.PERFORM INITIALIZATION
Perform initialization with CONSULT-III. Re-register all mechanical keys.
For initialization and registration of mechanical key. Refer to “CONSULT-III Operation Manual”.
Can the system be initialized and can the engine be started with re-registered mechanical key?
YES >> ID was unregistered.
NO >> GO TO 2
2.PEPLACE BCM
1. Replace BCM. Refer to BCS-59, "
Removal and Installation".
2. Perform initialization with CONSULT-III. Re-register all mechanical keys. For initialization and registration of mechanical key. Refer to “CONSULT-III Operation Manual”.
Can the system be initialized and can the engine be started with re-registered mechanical key?
YES >> BCM is malfunctioning.
NO >> GO TO 3
3.PEPLACE ECM
1. Replace ECM. Refer to Removal and Installation.
2. Perform initialization with CONSULT-III. Re-register all mechanical keys. For initialization and registration of mechanical key. Refer to “CONSULT-III Operation Manual”.
Can the system be initialized and can the engine be started with re-registered mechanical key?
YES >> ECM is malfunctioning.
NO >> GO TO 4
4.CHECK INTERMITTENT INCIDENT
Refer to GI-38, "
Intermittent Incident".
DTC No. Trouble diagnosis
name DTC detecting condition
Possible cause
P1611 ID DISCORD IMMU-
ECM The ID verification results between BCM and ECM
are NG. The registration is necessary. •BCM
•ECM
Revision: April 20092010 QX56

SEC-44
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
P1612 CHAIN OF ECM-IMMU
P1612 CHAIN OF ECM-IMMU
DescriptionINFOID:0000000005197369
BCM performs the ID verification with ECM that allows
the engine to start. BCM starts the communication with
ECM if ignition switch is turned ON and starts the engine if the ID is OK. ECM prevents the engine from start-
ing if the ID is not registered.
DTC LogicINFOID:0000000005197370
DTC DETECTION LOGIC
NOTE:
• If DTC P1612 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to SEC-26, "
DTC Logic".
• If DTC P1612 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to
SEC-27, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> Refer to SEC-44, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000005197371
1.REPLACE BCM
1. Replace BCM. Refer to BCS-59, "
Removal and Installation".
2. Perform initialization with CONSULT-III. For initialization, refer to “CONSULT-III Operation Manual”.
Does the engine start?
YES >> BCM was malfunctioning.
NO >> ECM is malfunctioning. • Replace ECM.
• Perform ECM re-communicating function.
DTC No. Trouble diagnosis
name DTC detecting condition
Possible cause
P1612 CHAIN OF ECM-
IMMU Inactive communication between ECM and BCM • Harness or connectors
(The CAN communication line is
open or short)
•BCM
•ECM
Revision: April 20092010 QX56
