2010 CHEVROLET IMPALA Owners Manual

A.Outlet Adjustment on page 4-20.
B. Remote Trunk Release Button. SeeTrunk on
page 3-12.
C.Turn Signal/Multifunction Lever on page 4-4.
D.Instrument Panel Cluster on page 4-22.
E.Hazard Warning Flashers on page 4-3.
F.Driver Information Center (DIC) on page 4-37.
G.Passenger Airbag Status Indicator on page 4-25.
H.Audio System(s) on page 4-57.
I.Exterior Lamps on page 4-9.
J.Instrument Panel Brightness on page 4-11.
K.Traction Control System (TCS) on page 5-7
(If Equipped).L.Tilt Wheel on page 4-3.
M.Cruise Control on page 4-6.
N.Hood Release on page 6-13.
O.Horn on page 4-3.
P.Audio Steering Wheel Controls on page 4-84
(If Equipped).
Q.Ignition Positions on page 3-20.
R.Climate Control System on page 4-16.
S.Accessory Power Outlet(s) on page 4-15.
T. Center Console Shift Lever (If Equipped).
SeeShifting Into Park on page 3-28.
U.Glove Box on page 3-42.
1-3

Initial Drive InformationThis section provides a brief overview about some of
the important features that may or may not be on your
specific vehicle.
For more detailed information, refer to each of the
features which can be found later in this owner manual.Remote Keyless Entry (RKE)
SystemThe RKE transmitter is used to remotely lock and
unlock the doors from up to 60 m (195 feet) away from
the vehicle.
Press
K
to unlock the
driver door. Press again
within five seconds to
unlock all remaining doors.Press
Q
to lock all doors.
Lock and unlock feedback can be personalized.
Press and hold
V
for approximately one second to
open the trunk.
Press
L
and release to locate the vehicle.
Press
L
and hold for more than two seconds to sound
the panic alarm.
Press
L
again to cancel the panic alarm.
SeeKeys on page 3-3andRemote Keyless Entry
(RKE) System Operation on page 3-4.
Remote Vehicle StartWith this feature the engine can be started from outside
of the vehicle.Starting the Vehicle1. Aim the RKE transmitter at the vehicle.
2. Press
Q
.
3. Immediately after completing Step 2, press and
hold
/
until the turn signal lamps flash.
When the vehicle starts, the parking lamps will turn
on and remain on as long as the engine is running.
The doors will be locked and the climate control system
may come on.
1-4

The engine will continue to run for 10 minutes. Repeat
the steps for a 10-minute time extension. Remote
start can be extended only once.Canceling a Remote StartTo cancel a remote start:•
Aim the RKE transmitter at the vehicle and press
and hold
/
until the parking lamps turn off.
•
Turn on the hazard warning flashers.
•
Turn the ignition switch out of LOCK/OFF position
and then back to LOCK/OFF.
SeeRemote Vehicle Start on page 3-7.
Door LocksFrom outside the vehicle, use the key in the door or the
Remote Keyless Entry (RKE) transmitter to lock or
unlock the vehicle. From the inside, pull up or push
down on the manual door lock knobs.
SeeDoor Locks on page 3-9.
Power Door LocksPower door lock switches are located on the front doors
near the handle.Q
:Press the bottom of the switch to lock all doors.
K
:Press the top of the switch to unlock all doors.
For more information, see:•
Power Door Locks on page 3-10.
•
Delayed Locking on page 3-10.
Trunk ReleaseIn addition to the trunk release button on the RKE
transmitter, there is a remote release
G
button
located on the left side of the instrument panel.
For more information seeTrunk on page 3-12.
1-5

WindowsOn vehicles with power windows, the switches are on
the driver door armrest. Each passenger door has
a switch that controls only that window.
Press the front of the switch to the first position to open
the window. Pull the switch up to close it.
For more information, seePower Windows on
page 3-15.
Seat AdjustmentManual Seats1. Lift the bar under the seat to unlock the seat.
2. Slide the seat to the desired position and release
the bar.
Try to move the seat to be sure it is locked in place.
SeeManual Seats on page 2-4.
1-6

Power SeatsMove the seat forward or rearward by moving the
control forward or rearward.
Raise or lower the front or rear of the seat cushion by
moving the front or rear of the control up or down.
SeePower Seats on page 2-5.
Power Reclining SeatbackTo raise or recline the seatback, tilt the top of the
control forward or rearward.
SeeReclining Seatbacks on page 2-6.
1-7

Manual LumbarIncrease or decrease the lumbar support by repeatedly
pushing down or pulling up on the lever.
SeeManual Lumbar on page 2-5.
Second Row SeatsOn vehicles with the Flip and Fold feature, the bottom
seat cushions can be flipped forward and the seatback
folded down to create an extended cargo area.
The vehicle also has an under seat storage area.
SeeSplit Folding Rear Seat on page 2-10for more
information.Head Restraint AdjustmentDo not drive until the head restraints for all occupants
are installed and adjusted properly.
For more information seeHead Restraints on page 2-2.
1-8

Safety BeltRefer to the following sections for important information
on how to use safety belts properly.•
Safety Belts: They Are for Everyone on page 2-12.
•
How to Wear Safety Belts Properly on page 2-17.
•
Lap-Shoulder Belt on page 2-25.
•
Lap Belt on page 2-30.
•
Lower Anchors and Tethers for Children (LATCH)
on page 2-43.
Sensing System for Passenger
AirbagThe passenger sensing system will turn off the right
front passenger frontal airbag under certain conditions.
The driver airbags, seat-side impact airbags, and
roof-rail airbags are not affected by this.
The passenger airbag status indicator will be visible on
the instrument panel when the vehicle is started.
SeePassenger Sensing System on page 2-66for
important information.
United States
Canada
1-9

Mirror AdjustmentExterior Mirrors
Controls for the outside
power mirrors are located
on the driver door armrest.
Press the left or right side of the selector located
beneath the control pad to adjust the driver or passenger
mirror. Then press the control pad to move the mirror
to the desired direction.
Interior MirrorVehicles with a manual rearview mirror can be adjusted
by holding the mirror in the center to move it for a
clearer view behind the vehicle. Adjust the mirror to
avoid glare from the headlamps behind. Pull the lever,
located at the bottom of the mirror for nighttime use.
Return the lever to its original position for the day
position.
Vehicles with an automatic dimming rearview mirror will
automatically adjust to reduce the glare of lights from
behind the vehicle. SeeAutomatic Dimming Rearview
Mirror on page 3-33.
1-10
