The garage door opener receiver (motor head unit)
could also have a row of dip switches that can be
used when programming the Universal Home
Remote. If the total number of switches on the motor
head and hand held transmitter are different, or if the
dip switch settings are different, use the dip switch
settings on the motor head unit to program the
Universal Home Remote. The motor head dip switch
settings can also be used when the original hand
held transmitter is not available.
The panel of switches might not appear exactly as
they do in the examples above, but they should
be similar.
The switch positions on the hand-held transmitter
could be labeled, as follows:
•
A switch in the up position could be labeled as
“Up,” “+,” or “On.”
•
A switch in the down position could be labeled
as “Down,” “−,” or “Off.”
•
A switch in the middle position could be labeled
as “Middle,” “0,” or “Neutral.” Example of Eight Dip Switches with Two Positions
Example of Eight Dip Switches with Three Positions
3-39

2. Write down the eight to 12 switch settings from left
to right as follows:
•
When a switch is in the up position, write “Left.”
•
When a switch is in the down position, write
“Right.”
•
If a switch is set between the up and down
position, write “Middle.”
The switch settings written down in Step 2 will
now become the button strokes to be entered into
the Universal Home Remote in Step 4. Be sure to
enter the switch settings written down in Step 2, in
order from left to right, into the Universal Home
Remote, when completing Step 4.
3. From inside your vehicle, first firmly press all three
buttons at the same time for about three seconds.
Release the buttons to put the Universal Home
Remote into programming mode.4. The indicator lights will blink slowly. Enter each
switch setting from Step 2 into your vehicle’s
Universal Home Remote. You will have two
and one-half minutes to complete Step 4. Now
press one button on the Universal Home Remote
for each switch setting as follows:
•
If you wrote “Left,” press the left button in the
vehicle.
•
If you wrote “Right,” press the right button in the
vehicle.
•
If you wrote “Middle,” press the middle button in
the vehicle.
3-40

5. After entering all of the switch positions, again,
firmly press and release all three buttons at the
same time. The indicator lights will turn on.
6. Press and hold the button that will be used to
control the garage door until the garage door
moves. The indicator light above the selected button
should slowly blink. This button may need to be
held for up to 55 seconds.
7. Immediately release the button when the garage
door moves. The indicator light will blink rapidly
until programming is complete.
8. Press and release the same button again.
The garage door should move, confirming
that programming is successful and complete.
To program another Fixed Code device such as an
additional garage door opener, a security device,
or home automation device, repeat Steps 1-8, choosing
a different button in Step 6 than what was used for
the garage door opener.Using Universal Home RemotePress and hold the appropriate button for at least half of
a second. The indicator light will come on while the
signal is being transmitted.
Reprogramming Universal Home
Remote ButtonsAny of the three buttons can be reprogrammed by
repeating the instructions.Erasing Universal Home Remote
ButtonsThe programmed buttons should be erased when the
vehicle is sold or the lease ends.
To erase either Rolling Code or Fixed Code on the
Universal Home Remote device:
1. Press and hold the two outside buttons at the
same time for approximately 20 seconds, until
the indicator lights, located directly above the
buttons, begin to blink rapidly.
2. Once the indicator lights begin to blink, release both
buttons. The codes from all buttons will be erased.
For help or information on the Universal Home Remote
System, call the customer assistance phone number
underCustomer Assistance Offices on page 8-6.
3-41

Storage AreasGlove BoxLift up on the glove box lever to open it.CupholdersCupholders may be built into the front center console,
front portion of the front center seat, and rear armrest of
the vehicle.Sunglasses Storage CompartmentA storage compartment for sunglasses may be located
above the rearview mirror. Push on cover to open
the compartment.Center Console StorageFor vehicles with a front center console storage area,
open it by pulling up on the latch located in the front of
the console cover.
Rear Storage AreaFor vehicles with a split folding rear seat, there are two
storage areas underneath. Pull the tab(s) located by
the passenger side safety belt buckle and the driver
side rear seat to access the storage areas. See
Split Folding Rear Seat on page 2-10for more
information.Rear Seat ArmrestFor vehicles with a rear seat armrest, pull the tab on the
armrest forward to access it.Convenience NetFor vehicles with a convenience net, it is located in
the rear. Use it to store small loads as far forward as
possible. The net should not be used to store heavy
loads.
3-42

Sunroof
On vehicles with a sunroof,
the sunroof switches are
located on the overhead
console.
The sunroof can only be operated when the ignition
is in ON/RUN, ACC/ACCESSORY, or when Retained
Accessory Power (RAP) is active. SeeRetained
Accessory Power (RAP) on page 3-21.
Q
(Vent/Express-Open):Press this switch once to
vent the sunroof when it is closed. When using the vent,
the sunshade should be fully opened. The sunshade
can be opened or closed manually by sliding it rearward
or forward.
From the vent position, press this switch again to
activate the express-open feature. Press the close
switch to stop movement of the sunroof. The sunshade
will automatically open when using express-open.
A deflector will automatically pop up when the sunroof is
opened. The deflector will retract when the sunroof is
closed.
R
(Close):Press and hold this switch until the sunroof
motor stops to close the sunroof, or release the
switch when the desired position has been reached.
3-43
