2010 Acura RL Owner's Manual

The radar sensor is located under
the Acura emblem in the f ront grille.
If the radar sensor cover is covered
with mud, dirt, dead leaves, wet
snow, etc., or if you put a sticker on
it, the CMBS will automatically shut
of f , and the CMBS indicator on the
instrument panel will come on. You
will also see a ‘‘CHECK CMBS
RADAR SENSOR’’ message on the
multi-inf ormation display f or about 5
seconds.Always keep the radar sensor cover
clean. If it gets dirty, clean it with
water or a mild detergent. Never use
chemical solvents or polishing
powder.Do not allow anything to impact the
radarsensorortheradarsensor
cover. If either of these parts
receives a strong impact, turn off the
system by pressing the CMBS of f
switch, and have your vehicle
checked by a dealer. If the f ront
grille ever needs to be repaired,
consult a dealer f irst.
If the radar sensor cover or the radar
sensor ever needs to be removed,
take your vehicle to a dealer.
There are three bolts on the sides of
the radar sensor. Do not tamper with
these bolts, or you may cause the
system to malf unction.
Radar Sensor
Collision Mitigation Brake System (CMBS)
414
RADAR SENSOR COVER
BOLTS
(Do not tamper)
——y
y
(y
y
2010 RL

The radar sensor may not always
scan as intended. Here are two
examples:Thetiresarenotcorrectly
maintained. Always make sure the
tire pressures are correct (see
page ), and that the tires are
the correct size and in good
condition (see Tires on page ). Your vehicle is tilted because of a
heavy load in the rear or from
modif ications to the suspension.
Do not overload your vehicle (see
Carrying Cargo on page ), and
do not make any modif ications to
the suspension (see Accessories
and Modif ications on page ). 474
474 387
389
Collision Mitigation Brake System (CMBS)
Driving
415
When the CMBS is on, the radar sensor
constantly scans f or vehicles ahead of
you. This means that driving on a road
with a f ew or no vehicles could cause a
CHECK CMBS RADAR SENSOR
message to appear on the multi-
inf ormation display. This is normal
and not a cause f or concern.
——y

y
(yy
2010 RL

If the system senses a likely collision
with a vehicle or object ahead of you,
it alerts you with an audible and a
visual alarm.The audible alarm is a constant
beeping sound; the visual alert is an
amber colored BRAKE message that
f lashes on the multi-inf ormation
display. If these alarms come on,
take the appropriate means to
prevent a collision (apply the brakes,
change lanes, etc.).To turn the CMBS off, press the
CMBS OFF switch on the dashboard
f or about 1 second. When you do this,
a beeper sounds, a CMBS indicator
on the instrument panel comes on,
and a CMBS OFF message appears
on the multi-information display. To
turn the system back on, press the
switch again for about 1 second.
Collision Alarm
CMBS OFF Switch
Collision Mitigation Brake System (CMBS)
416
CMBS OFF SWITCH
——y

y
(y
y
2010 RL

The CMBS will automatically
recover when these conditions are
improved.
Any of the conditions below can
cause the CMBS to shut of f . When
the system shuts off, the CMBS
indicator in the instrument panel
comes on, and a CHECK CMBS
SYSTEM message appears on the
multi-inf ormation display f or about 5
seconds.
An abnormal tire condition is
detected (wrong tire size, f lat tire,
etc.).
Extended of f -road or mountainous
driving.
Driving your vehicle with the
parking brake applied.
Driving your vehicle in bad
weather(rain,fog,snow,etc.).
A dirty emblem on the f ront grille.
When you turn the ignition switch to
the ON (II) position, the CMBS is
turned on if it was on previously.
Automatic Shut Of f
Collision Mitigation Brake System (CMBS)
Driving
417
——y
y
(yy
2010 RL

The CMBS indicator normally comes
on under these conditions:When you manually turn of f the
system.
When the system shuts off
automatically.
When you drive in bad weather
(rain, snow, f og, etc.). When the VSA system indicator
comes on (see page ).
When you turn the ignition switch
to the ON (II) position, the CMBS
indicator should come on f or a f ew
seconds, then go of f . If the
indicator comes on at any other
time and a CHECK CMBS
SYSTEM message appears on the
multi-inf ormation display, there is
a problem with the CMBS. You
can still drive your vehicle, but
CMBS will not be operating. Have
your vehicle checked by a dealer.
If anything covers the f ront grille
(dirt, mud, dry leaves, wet snow,
etc.).
This indicator comes on f or several
seconds when you turn the ignition
switch to the ON (II) position. It also
comesonandstaysonwhenyou
turn the CMBS off by pressing the
CMBS OFF switch.
To turn the CMBS back on, make
sure the vehicle is stopped and the
ignition switch is in the ON (II)
position, then press the CMBS OFF
switch f or about 1 second. 429
CMBS Indicator
Collision Mitigation Brake System (CMBS)
418
CMBS INDICATOR
——y
y
(yy
2010 RL

A vehicle cuts in f ront of you and
brakes suddenly.
When you accelerate rapidly and
approach the vehicle ahead of you
at high speed.Driving in heavy, stop-and-go
traffic.
The vehicle ahead of you is a
motorcycle or other small vehicle.
Immediately af ter you drive of f .
The CMBS may not activate under
some conditions. Here are a f ew
examples:
The distance between your vehicle
and the vehicle ahead of you is too
short.
A vehicle cuts in f ront of you at a
slow speed.
CONT INUED
Limitations
Collision Mitigation Brake System (CMBS)
Driving
419
YOUR VEHICLE
YOUR VEHICLE
——y
y
(yy
2010 RL

Even with little or no chance of a
collision, the CMBS may activate
under these conditions:
A vehicle suddenly crosses in f ront
of you. When you approach or pass a
vehicle ahead of you that is
turning lef t or right in an
intersection.
When you change lanes quickly,
then overtake the vehicle ahead of
you.
Collision Mitigation Brake System (CMBS)
420
YOUR VEHICLE
YOUR VEHICLE
The CMBS is not designed to detect
pedestrians.
——y
y
(yy
2010 RL

When you pass a low bridge at
high speed.When you approach train tracks at
the bottom of a hill and you do not
apply the brakes.Because of the road condition
(curved, winding, etc.) or the state of
your vehicle (turning angle, lane
position, etc.), CMBS can sometimes
mistake a stationary object (light
pole, traf f ic sign, etc.) as a vehicle
ahead of you and temporarily
operate. This is normal.
When you go over a sharp-edged
speed bump at high speed.
When you go over areas of
construction on the road surface.
Collision Mitigation Brake System (CMBS)
Driving
421
LOW BRIDGE
RAILS YOUR VEHICLE
SIGN, POLE, etc.
