2010 Acura RL Owner's Manual

To remove a head restraint f or
cleaning or repair, pull it up as f ar as
it will go. Push the release button,
then pull the restraint out of the seat-
back.When reinstalling a head restraint,
put the legs back in place. Then
adjust it to the appropriate height
while pressing the release button.
Make sure the head restraint locks
in position when you reinstall it.You can raise the rear head
restraints by hand.
To lower the rear head restraints f or
better visibility, press the rear head
restraint tilt button on the ceiling
console with the ignition switch in
the ON (II) position.
Seats
Removing t he Head Rest raint
158
REAR HEAD RESTRAINT
TILT BUTTON
REAR
Failure to reinstall the head
restraints can result in severe
injury during a crash.
Always replace the head
restraints before driving.
——y
y
(y
y
2010 RL

The driver’s and f ront passenger’s
seats have active head restraints. If
the vehicle is struck severely f rom
the rear, the occupant properly
secured with the seat belt will be
pushed against the seat-back and the
head restraint will automatically
move forward.
This reduces the distance between
the restraint and the occupant’s head.
It also helps protect the occupantsagainst whiplash and injuries to the
neck and upper spine.
Af ter a collision, the activated
restraint should return to its normal
position.
For a head restraint system to work
properly:
Do not hang any items on the head
restraints, or f rom the restraint
legs.
Do not place any object between
an occupant and the seat-back.
Install each restraint in its proper
location.
If the restraints do not return to their
normal position, or in the event of a
severe collision, have the vehicle
inspected by an Acura dealer.
Only use genuine Acura
replacement head restraints.
A ct ive Head Rest raint s
Seats
Inst rument s and Cont rols
159
——y

y
(y
y
2010 RL

The rear seat armrest is in the
center of the rear seat. Pivot it down
to use it.To open the cover, pull down the
rear seat armrest. Pull on the tab at
the top of the inner partition, and
press on the button to f ully release
the cover. To close the cover, swing
it up, and push f irmly on the top.
Make sure it latches properly.Make sure all items in the trunk and
those extending through the pass-
through are secured.
For security, this cover can be
locked and unlocked only with the
built-in key. To lock the cover, insert
thekey,andturnitclockwise.
Never drive with this cover open and
the trunk lid open.
See
on
page . 56
Rear Seat Armrest
Trunk Pass-through Cover
Carbon Monoxide Hazard
Seats
160
COVER
KNOB
——y
y
(y
y
2010 RL

Keeptheinsideandoutsidemirrors
clean and adjusted f or best visibility.
Be sure to adjust the mirrors bef ore
you start driving.The inside mirror can automatically
darken to reduce glare. To turn on
this feature, press the button on the
bottom of the mirror. The AUTO
indicator comes on as a reminder.
When it is on, the mirror darkens
when it senses the headlights of a
vehicle behind you, then returns to
normal visibility when the lights are
gone. Press the button again to turn
of f this f eature. Move the selector switch to L
(driver’s side) or R (passenger’s
side).
Push the appropriate edge of the
adjustment switch to move the
mirrorright,left,up,ordown.
1.
2.
CONT INUED
Mirrors
A djusting the Power Mirrors
Inst rument s and Cont rols
161
INDICATOR
AUTO BUTTONSENSOR
SELECTOR
SWITCHADJUSTMENT SWITCH
——y
y
(y
y
2010 RL

The outside mirrors are heated to
remove fog and frost. With the
ignition switch in the ON (II)
position, turn on the heaters by
pressing the button. The indicator in
the button comes on as a reminder.
Press the button again to turn the
heaters off. Pressing this button also
turns the rear window def ogger on
and off.
When you f inish, move the
selector switch to the center (off)
position. This turns of f the
adjustment switch so you can’t
move a mirror out of position by
accidentally bumping the switch.
Outside mirror positions can be
stored in the driving position
memory system (see page ). Both outside door mirrors have a
reverse tilt f eature. When in reverse,
the selected mirror will tilt down
slightly to improve your view as you
parallel park. Shif ting out of reverse
will return the mirror to its original
position.
To tilt the driver’s mirror, place
the selector switch in the left
position.
To tilt the passenger’s mirror,
place the switch in the right
position.
To turn the feature off, place the
switch in the center position.
3.
163 PowerMirrorHeaters
Reverse Tilt Door Mirror
Mirrors
162
HEATED MIRROR BUTTON
——y

y
(y
y
2010 RL

CONT INUED
Store a driving position only when
the vehicle is parked.Turn the ignition switch to the ON
(II) position. You cannot add a
new driving position to the
memory unless the ignition switch
is in the ON (II) position. You can
recall a memorized position with
the ignition switch in any position.
Adjust the seat to a comfortable
position (see page ).
Adjust the steering wheel to a
comf ortable position (see page ).
Adjust the outside mirrors f or best
visibility (see page ).
Your vehicle has a memory feature
f or the steering wheel, driver’s seat,
and outside mirror positions.
Two seat, steering wheel, and
outside mirror positions can be
stored in separate memories. You
select a memorized position by
pushing the appropriate button.
If you do not turn the heaters off,
they will shut themselves of f af ter 5
to 40 minutes (depending on the
ambient temperature). It also shuts
of f when you turn of f the ignition
switch.
You can also select the memorized
positions by unlocking the doors
with the remote. Each remote has a
driver’s ID (see page ). The
driver’s ID (Driver 1) corresponds to
the memorized positions stored with
the memory button (1). The driver’s
ID (Driver 2) corresponds to the
memorized positions stored with the
memory button (2).1.
2.
148 156
173
161
Storing a Driving Position in
Memory
Driving Position Memory System
Mirrors, Driving Position Memory System
Inst rument s and Cont rols
163
——y
y
(y
y
2010 RL

Press the desired memory button
(1 or 2) until you hear a beep. Make sure the shif t lever is in
Park.
To select a memorized position, do
this:
To cancel the storing procedure
after pressing the MEMO button:
Do not press a memory button
within 5 seconds.
Readjust the seat or steering
position.
Readjust the outside mirror
position.
Each memory button stores only one
driving position. Storing a new
position erases the previous setting
stored in that button’s memory.
All stored driving positions will be
lost if your vehicle’s battery goes
dead or is disconnected.
Press the MEMO button on the
driver’s door. You will hear a beep.
The indicator in the memory
buttons (1 and 2) will blink.
Immediatelypressoneof the
memory buttons (1 or 2) until you
hear two beeps. The indicator in
the memory button will stay on.
The current positions of the
driver’s seat, steering wheel, and
outside mirrors are now stored. 1.
2.
3.
Driving Position Memory System
Selecting a Memorized Position
164
MEMORY BUTTONS
MEMORY
BUTTONS
MEMO BUTTON
——y
y
(y
y
2010 RL

You can use the adjustment switches
to change the positions of the seat,
steering wheel, or outside mirrors
af ter they are in their memorized
position. If you change the
memorized position, the indicator in
the memory button will go out. To
keep this driving position f or later
use, you must store it in the driving
position memory.
To stop the system’s automatic
adjustment, do any of the f ollowing:
Press any button on the control
panel: MEMO, 1, or 2.
If you select a memorized position
without pushing the ignition switch
knob or inserting the built-in key in
the ignition switch, only the seat and
outside mirrors will adjust. To get
the system to also adjust the steering
wheel, push and turn the ignition
switch or insert the built-in key in
the ignition switch. You will hear two
beeps when it is complete. Push any of the adjustment
switches f or the seat or steering
wheel.
Shif t out of Park.
Adjust the outside mirrors.
The system will move the seat,
steering wheel, and outside mirrors
to the memorized positions. The
indicator in the selected memory
button will f lash during movement.
When the adjustments are complete,
you will hear two beeps, and the
indicator will remain on.
To change the ‘‘MEMORY
POSITION LINK’’ setting, see page
.
104
Driving Position Memory System
Inst rument s and Cont rols
165
——y
y
(y
y
2010 RL
