2009 TOYOTA YARIS HATCHBACK Owners Manual

205
3-2. Using the audio system
3
Interior features
l
ID3 and WMA tags
ID3 tags can be added to MP3 files, making it possible to record the track
title and artist name, etc.
The system is compatible with ID3 Ver. 1.0, 1.1, and Ver. 2.2, 2.3 ID3 tags.
(The number of characters is based on ID3 Ver. 1.0 and 1.1.)
WMA tags can be added to WMA files, making it possible to record the
track title and artist name in the same way as with ID3 tags.
l MP3 and WMA playback
When a disc containing MP3 or WMA files is inserted, all files on the disc
are first checked. Once the file check is finished, the first MP3 or WMA\
file
is played. To make the file check finish more quickly, we recommend you
do not write in any files other than MP3 or WMA files or create any unnec-
essary folders.
If the discs contain a mixture of music data and MP3 or WMA format data,
only music data can be played.
l Extensions
If the file extensions .mp3 and .wma are used for files other than MP3 and
WMA files, they will be mistakenly recognized and played as MP3 and
WMA files. This may result in large amounts of interference and damage
to the speakers.
l Playback
• To play MP3 file with steady sound quality, we recommend a fixed bit
rate of 128 kbps and a sampling frequency of 44.1 kHz.
• CD-R or CD-RW playback may not be possible in some instances, depending on the characteristics of the disc.
• There is a wide variety of freeware and other encoding software for MP3 and WMA files on the market, and depending on the status of the
encoding and the file format, poor sound quality or noise at the start of
playback may result. In some cases, playback may not be possible at
all.
• When files other than MP3 or WMA files are recorded on a disc, it may take more time to recognize the disc and in some cases, playback may
not be possible at all.
• Microsoft, Windows, and Windows Media are the registered trade- marks of Microsoft Corporation in the U.S. and other countries.

206 3-2. Using the audio system
NOTICE
nCDs and adapters that cannot be used ( →P. 198)
n CD player precautions ( →P. 199)

207
3-2. Using the audio system
3
Interior features
Optimal use of the audio system
Using the AUDIO CONTROL function
nChanging sound quality modes
Pressing selects the mode to be changed in the following
order.
BAS → TRE → FA
D → BAL → ASL
n Adjusting sou
nd quality
Turning adjusts the level.
Sound qual-
ity modeMode
displayedLevelTurn to the leftTurn to the right
BassBAS-5 to 5LowHighTrebleTRE-5 to 5
Front/rear balanceFA DR7 to F7Shifts to rearShifts to front
Left/right balanceBALL7 to R7Shifts to leftShifts to right
Displays the current mode
Changes the following set -
ting
Sound quality and volume
b
alance.
The sound quality and bal-
ance setting can be changed
to produce the b
est sound.

208 3-2. Using the audio system
nAdjusting the Automatic Sound Levelizer (ASL)
When “ASL“ is selected, turning to the right changes the
“ASL level in the order of the “LOW”, “MID” and “HIGH”.
Turning to the left turns “ASL“ off.
ASL automatically adjusts the volume and tone quality according
to the
vehicle speed.
nTrademark owned by SRS Labs, Inc.
The audio system utilizes SRS FOCUS® and SRS TruBass® audio
enhancement technologies, under license from SRS Labs, Inc., in all modes
except AM radio mode.
FOCUS, TruBass, SRS and
symbols are trademarks of SRS Labs,
Inc. FOCUS and TruBass technologies are incorporated under license from
SRS Labs, Inc.

209
3-2. Using the audio system
3
Interior features
Using the AUX adapter (if equipped)
nOperating portable audio devices connected to the audio system
The volume can be adjusted using the vehicle’s audio controls. All other
adjustment
s must be made on the portable audio device itself.
n When
using a portable audio devi ce connected to the power outlet
Noise may occur during playback. Use the power source of the portable
audio device.
This adapter can be used to connect a portable audio device and lis-
ten to it through the vehicle’
s speakers.
Connect the portable audio
device.
Press .

210
3-3. Using the interior lights
Interior lights list
nIlluminated entry system (if equipped)
When the interior light switch is in the DOOR position, the interior light auto -
matically turns on/off according to whether the doors are locked/unlocked
and whether the doors are
open/closed and the engine switch position.
n T
o prevent the battery from being discharged
If the interior light remains on when the door is not fully closed and the inte -
rior light switch is in the DOOR position, the light will go off automatically
af
ter 20 minutes.
n Customization that can be co nfigure
d at Toyota dealer
Settings (e.g. The time elapsed before lights turn off) can be changed.
(Customizable features →P. 369)
Interior light (→P. 2 11 )
Personal lights ( →P. 2 1 1 )

211
3-3. Using the interior lights
3
Interior features
Interior light
ON
OFF
DOOR position
Personal lights
On/off
Interior light and personal lights

212
3-4. Using the storage features
List of storage features
Glove boxes
Upper glove box
Pull up the lever.
Cup holders
Auxiliary boxes
Glove boxes
Bottle holders
Glove boxes
