2009 SATURN ASTRA Owners Manual

Seats and Restraints......... 1-1
Front Seats
.................... 1-2
Rear Seats
.................... 1-7
Safety Belts
................... 1-8
Airbag System
..............1-24
Child Restraints
.............1-38
Keys, Doors and
Windows............................ 2-1
Keys
............................. 2-2
Doors and Locks
............ 2-5
Theft-Deterrent Systems
... 2-8
Windows
......................2-10
Mirrors
.........................2-11
Sunroof
........................2-12
Storage.............................. 3-1
Storage
......................... 3-1
Instruments and
Controls............................. 4-1
Instrument Panel
Overview
.................... 4-2
Warning Lights, Gages,
and Indicators
............4-11Driver Information
Center (DIC)
.............4-25
OnStar
®System
............4-38
Lighting............................. 5-1
Lighting
......................... 5-1
Infotainment...................... 6-1
Audio System(s)
............. 6-1
Climate Controls............... 7-1
Climate Controls
............. 7-1
Driving and Operating....... 8-1
Starting and Operating
Your Vehicle
............... 8-2
Driving Your Vehicle
......8-15
Fuel
............................8-34
Vehicle Service
and Care............................ 9-1
Service
.......................... 9-2
Owner Checks
................ 9-4
Headlamp Aiming
..........9-26
Bulb Replacement
.........9-28
Electrical System
...........9-34Tires
...........................9-40
Tire Changing
...............9-60
Jump Starting
...............9-69
Towing
........................9-73
Appearance Care
..........9-73
Technical Data.................10-1
Vehicle Identication
......10-1
Capacities and
Specications
............10-2
Service and
Maintenance.....................11-1
Service and
Maintenance
..............11-1
Customer Information......12-1
Customer Information
.....12-1
Reporting Safety
Defects
...................12-14
Vehicle Data Recording
and Privacy
.............12-16
Index................................... i-1
2009 Saturn ASTRAM
ProCarManuals.com

SATURN and the SATURN Emblem
are registered trademarks, and
the name ASTRA is a trademark of
Saturn Corporation. GENERAL
MOTORS and GM are registered
trademarks of General Motors
Corporation.
This manual includes the latest
information at the time it was
printed. Saturn reserves the right to
make changes after that time
without further notice.
This manual describes features that
may or may not be on your
specic vehicle.Read this manual from beginning to
end to learn about the vehicle’s
features and controls. Pictures,
symbols, and words work together
to explain vehicle operation.
Keep this manual in the vehicle for
quick reference.
Canadian Owners
A French language copy of this
manual can be obtained from your
dealer/retailer or from:
Helm, Incorporated
P.O. Box 07130
Detroit, MI 48207
1-800-551-4123
helminc.com
Propriétaires Canadiens
On peut obtenir un exemplaire de
ce guide en français auprès de
concessionnaire ou à l’adresse
suivante:
Helm Incorporated
P.O. Box 07130
Detroit, MI 48207
1-800-551-4123
helminc.com
Index
To quickly locate information about
the vehicle use the Index in the
back of the manual. It is an
alphabetical list of what is in the
manual and the page number where
it can be found.
ii Preface
Litho in U.S.A.
Part No. 25918346 A First Printing©2008 General Motors Corporation. All Rights Reserved.
ProCarManuals.com

Cautions and Notices
A circle with a slash through it is a
safety symbol which means “Do
Not,” “Do not do this” or “Do not let
this happen.”
A box with the word CAUTION is
used to tell about things that
could hurt you or others if you were
to ignore the warning.
{CAUTION
These mean there is something
that could hurt you or other
people.
Cautions tell what the hazard is and
what to do to avoid or reduce the
hazard. Read these cautions.A notice tells about something that
can damage the vehicle.
Notice:These mean there is
something that could damage
your vehicle.
Many times, this damage would not
be covered by the vehicle’s
warranty, and it could be costly. The
notice tells what to do to help
avoid the damage.
There are also warning labels on
the vehicle which use the same
words, CAUTION or Notice.
Vehicle Symbols
The vehicle has components and
labels that use symbols instead
of text. Symbols are shown along
with the text describing the operation
or information relating to a specic
component, control, message,
gage, or indicator.
M:This symbol is shown when
you need to see your owner manual
for additional instructions or
information.
*:This symbol is shown when
you need to see a service manual
for additional instructions or
information.
Preface iii
ProCarManuals.com

Vehicle Symbol Chart
Here are some additional symbols
that may be found on the vehicle
and what they mean. For more
information on the symbol, refer to
the index.
9:Airbag Readiness Light
#:Air Conditioning
!:Antilock Brake System (ABS)
g:Audio Steering Wheel
Controls or OnStar®
$:Brake System Warning Light
":Charging System
I:Cruise Control
B:Engine Coolant Temperature
O:Exterior Lamps
#:Fog Lamps
.:Fuel Gage
+:Fuses
i:Headlamp High/Low-Beam
Changer
j:LATCH System Child Restraints
*:Malfunction Indicator Lamp
::Oil Pressure
}:Power
/:Remote Vehicle Start
>:Safety Belt Reminders
7:Tire Pressure Monitor
F:Traction Control
M:Windshield Washer Fluid
iv Preface
ProCarManuals.com

Seats and
Restraints
Front Seats
Manual Seats.....................1-2
Seat Height Adjuster...........1-2
Lumbar Seat Adjustment. . . .1-3
Reclining Seatbacks...........1-3
Head Restraints..................1-5
Heated Seats.....................1-6
Rear Seats
Rear Seat Operation...........1-7
Safety Belts
Safety Belts........................1-8
How to Wear Safety
Belts Properly..................1-12
Lap-Shoulder Belt.............1-18
Safety Belt Use During
Pregnancy.......................1-22
Safety Belt Extender.........1-22
Safety Belt Check.............1-22
Care of Safety Belts.........1-23
Replacing Safety Belt
System Parts After a
Crash
..............................1-23
Airbag System
Airbag System..................1-24
Where Are the Airbags?. . .1-26
When Should an Airbag
Inate?............................1-27
What Makes an Airbag
Inate?............................1-28
How Does an Airbag
Restrain?........................1-28
What Will You See After
an Airbag Inates?..........1-29
Passenger Sensing
System............................1-30
Servicing Your
Airbag-Equipped
Vehicle
............................1-35
Adding Equipment to
Your Airbag-Equipped
Vehicle
............................1-36
Airbag System Check.......1-37
Replacing Airbag System
Parts After a Crash.........1-37
Child Restraints
Older Children..................1-38
Infants and Young
Children..........................1-40
Child Restraint Systems. . . .1-43
Where to Put the
Restraint.........................1-44
Lower Anchors and
Tethers for Children
(LATCH)
..........................1-46
Replacing LATCH System
Parts After a Crash...........1-50
Securing Child Restraints
(Rear Seat).....................1-51
Securing Child Restraints
(Right Front Seat)...........1-53
Seats and Restraints 1-1
ProCarManuals.com

Front Seats
Manual Seats
{CAUTION
You can lose control of the
vehicle if you try to adjust a
manual driver’s seat while the
vehicle is moving. The sudden
movement could startle and
confuse you, or make you push a
pedal when you do not want to.
Adjust the driver’s seat only when
the vehicle is not moving.To move a manual seat forward or
rearward:
1. Lift the bar to unlock the seat.
2. Slide the seat to the desired
position and release the bar.
Try to move the seat with your body
to be sure the seat is locked in place.
Seat Height Adjuster
To raise and lower the manual
seat, move the lever up or down
repeatedly until the seat is at the
desired height.
1-2 Seats and Restraints
ProCarManuals.com

Lumbar Seat Adjustment
On seats with this feature, turn the
knob clockwise or counterclockwise
to increase or decrease the
lumbar support.
Reclining Seatbacks
{CAUTION
You can lose control of the vehicle
if you try to adjust the seat while
the vehicle is moving. The sudden
movement could startle and
confuse you, or make you push a
pedal when you do not want to.
Adjust the driver’s seat only when
the vehicle is not moving.
{CAUTION
Sitting in a reclined position when
the vehicle is in motion can be
dangerous. Even if when buckled
up, the safety belts cannot do
their job when reclined like this.
The shoulder belt cannot do its job
because it will not be against your
body. Instead, it will be in front of
you. In a crash, you could go into
it, receiving neck or other injuries.
The lap belt cannot do its job
either. In a crash, the belt could
go up over your abdomen.
The belt forces would be there, not
at your pelvic bones. This could
cause serious internal injuries.
For proper protection when the
vehicle is in motion, have the
seatback upright. Then sit well
back in the seat and wear the
safety belt properly.
Seats and Restraints 1-3
ProCarManuals.com

To adjust a manual reclining
seatback, turn the knob. Do not lean
on the seatback while adjusting it.
Seatback Latches (Three Door
Model)
For easy entry/exit to the rear seats
on three door models:
1. Lift the lever, and tilt the seatback
forward.
2. Lower the lever and move the
entire seat completely forward.
{CAUTION
If either seatback is not locked, it
could move forward in a sudden
stop or crash. That could cause
injury to the person sitting there.
Always push and pull on the
seatbacks to be sure they are
locked.
To return the seat to the upright
position:
1. Remove any objects in front of or
behind the seat.
2. Move the entire seat rearward.
3. Lift the lever located on the
outboard side of the seat
and return the seatback to the
upright position.
4. Lower the lever then push and
pull on the seatback to be sure
it is locked in place.
1-4 Seats and Restraints
