PASSENGER COMPARTMENT CONNECTION
UNIT
UCH
Vdiag No.: 44
Fault finding - Introduction 87B - 2
Fault finding - List and location of components 87B - 7
Fault finding - Operating diagram 87B - 8
Fault finding - Role of components 87B - 9
Fault finding - Replacement of components 87B - 13
Fault finding - Configurations and programming 87B - 14
Fault finding - Fault summary table 87B - 24
Fault finding - Interpretation of faults 87B - 25
Fault finding - Conformity check 87B - 68
Fault finding - Status summary table 87B - 84
Fault finding - Interpretation of statuses 87B - 86
Fault finding - Parameter summary table 87B - 144
Fault finding - Interpretation of parameters 87B - 145
Fault finding - Command summary table 87B - 151
Fault finding - Interpretation of commands 87B - 152
Fault finding - Customer complaints 87B - 164
Fault finding - Fault Finding Chart 87B - 167
Fault finding - Tests 87B - 177

87B-2
MR-413-X44-87B000$048.mif
V5
87B
PASSENGER COMPARTMENT CONNECTION UNIT
Fault finding - Introduction
1. SCOPE OF THIS DOCUMENT
This document presents the fault finding procedure applicable to all computers with the following specifications:
2. PREREQUISITES FOR FAULT FINDING
Documentation type
Fault finding procedures (this manual):
–Assisted fault finding (integrated into the diagnostic tool),
–Dialogys.
Wiring Diagrams:
–Visu-Schéma (CD-ROM), paper.
Type of diagnostic tools
–CLIP
Special tooling required
3. REMINDER
To run fault finding on the vehicle computers, switch on the ignition.
To cut off the + after ignition feed, proceed as follows:Vehicle(s): New Twingo
Function concerned: Passenger compartment
connection unitName of computer: UCH
Vdiag No.: 44
Special tooling required
Multimeter
Elé. 1681 Universal bornier
–Switch on the ignition with the key.
–Connect the diagnostic tool and perform the required operations.
–Switch off the ignition with the key.
–Disconnect the diagnostic tool.
–Switch off the ignition.
UCH_V44_PRELI
MR-413-X44-87B000$048.mif
UCH
Vdiag No.: 44

87B-3
MR-413-X44-87B000$048.mif
V5
UCH
Vdiag No.: 44PASSENGER COMPARTMENT CONNECTION UNIT
Fault finding - Introduction87B
Faults
Faults are declared as either present or stored (depending on whether they appeared in a certain context and have
disappeared since, or whether they remain present but have not been diagnosed within the current context).
The present or stored status of faults should be taken into consideration when the diagnostic tool is used following
the + after ignition supply being switched on (without operating the system components).
For a present fault, apply the procedure described in the Interpretation of faults section.
For a stored fault, note the faults displayed and apply the instructions in the Notes section.
If the fault is confirmed when the instructions in the Notes section are applied, the fault is present. Deal with the fault
If the fault is not confirmed, check:
–the electrical lines which correspond to the fault,
–the connectors for these lines (for oxidation, bent pins, etc.),
–the resistance of the component detected as faulty,
–the condition of the wires (melted or split insulation, wear).
Conformity check
The aim of the conformity check is to check data that does not produce a fault on the diagnostic tool because the
data is inconsistent. Therefore, this stage is used to:
–carry out fault finding on faults that do not have a fault display, and which may correspond to a customer
complaint.
–check that the system is operating correctly and that there is no risk of a fault recurring after repairs.
This section gives the fault finding procedures for statuses and parameters and the conditions for checking them.
If a status is not behaving normally or a parameter is outside the permitted tolerance values, consult the
corresponding fault finding page.
Customer complaints - Fault finding chart
If the test with the diagnostic tool is OK but the customer complaint is still present, the fault should be dealt with by
Customer complaints.
A summary of the overall procedure to follow is provided on the following page in the
form of a flow chart.

87B-4
MR-413-X44-87B000$048.mif
V5
UCH
Vdiag No.: 44PASSENGER COMPARTMENT CONNECTION UNIT
Fault finding - Introduction87B
4. FAULT FINDING PROCEDURE
Perform a pre-diagnostic on the
system
Print the system fault finding log
(available on CLIP and in the
Workshop Repair Manual or
Technical Note)
Connect CLIP
no
Dialogue with
computer?
yes
Read the faults
no
Faults
present
yes
Deal with present faults
Deal with stored faults
no
The cause is
still presentFault
solved
yes
See ALP no. 1
Conformity check
no
The cause is
still presentFault
solved
yes
Use fault finding charts
(ALPs)
no
The cause is
still presentFault
solved
yes
Contact the Techline with the
completed fault finding log

87B-5
MR-413-X44-87B000$048.mif
V5
UCH
Vdiag No.: 44PASSENGER COMPARTMENT CONNECTION UNIT
Fault finding - Introduction87B
4. FAULT FINDING PROCEDURE (continued)
Wiring check
Fault finding problems
Disconnecting the connectors and/or manipulating the wiring harness may temporarily remove the cause of a fault.
Electrical measurements of voltage, resistance and insulation are generally correct, especially if the fault is not
present when the analysis is made (stored fault).
Visual inspection
Look for damage under the bonnet and in the passenger compartment.
Carefully check the fuses, insulators and wiring harness routing.
Look for signs of oxidation.
Tactile inspection
While manipulating the wiring harness, use the diagnostic tool to note any change in fault status from stored to
present.
Make sure that the connectors are properly locked.
Apply light pressure to the connectors.
Twist the wiring harness.
If there is a change in status, try to locate the source of the fault.
Inspection of each component
Disconnect the connectors and check the appearance of the clips and tabs, as well as the crimping (no crimping on
the insulating section).
Make sure that the clips and tabs are properly locked in the sockets.
Check that no clips or tabs have been dislodged during connection.
Check the clip contact pressure using an appropriate model of tab.
Continuity, insulation and resistance check
Check the continuity of entire lines, then section by section.
Look for a short circuit to earth, to + 12 V or to another wire.
If a fault is detected, repair or replace the wiring harness.

87B-6
MR-413-X44-87B000$048.mif
V5
UCH
Vdiag No.: 44PASSENGER COMPARTMENT CONNECTION UNIT
Fault finding - Introduction87B
5. FAULT FINDING LOG
You will always be asked for this log:
–when requesting technical assistance from the Techline,
–for approval requests when replacing parts for which approval is obligatory
–to be attached to monitored parts for which reimbursement is requested. The log is needed for warranty
reimbursement, and enables better analysis of the parts removed.
6. SAFETY ADVICE
Safety rules must be observed during any work on a component to prevent any damage or injury:
–check the battery voltage to avoid incorrect operation of computer functions,
–Use the proper tools. IMPORTANTIMPORTANT
Any fault on a complex system requires thorough fault finding with the appropriate tools. The
FAULT FINDING LOG, which should be completed during the procedure, enables you to keep
track of the procedure which is carried out. It is an essential document when consulting the
manufacturer.
IT IS THEREFORE ESSENTIAL THAT THE FAULT FINDING LOG IS FILLED OUT EVERY TIME IT IS
REQUESTED BY TECHLINE OR THE WARRANTY RETURNS DEPARTMENT

87B-7
MR-413-X44-87B000$096.mif
V5
87B
ENGINE HARNESS
FRONT ENGINE WIRING & ADDITIONAL HEADLIGHTS
DOOR WIRING
CEILING WIRING
PASSENGER COMPARTMENT WIRING
REAR BUMPER WIRING
TAILGATE WIRING
1UCH
2Passenger Compartment Relay/Fuse Box
3Electric power-assisted steering.
4Transponder ring.
5Air conditioning panel.
6One touch window/anti-pinch module.
7Exterior temperature sensor.
8Rain/light sensor & interior temperature sensor.
9Anti-pinch/sunroof.
2ABS computer.
2Injection computer.
3Preheating unit.
4Sequential gearbox computer.
5Engine fuse and relay box.
6Alternator.
7
2
61
2
3
5
4
8
5
7
43
1
6
9
PASSENGER COMPARTMENT CONNECTION UNIT
Fault finding
- List and location of components
MR-413-X44-87B000$096.mif
UCH
Vdiag No.: 44

87B-8
MR-413-X44-87B000$144.mif
V5
87B
PASSENGER COMPARTMENT CONNECTION UNIT
Fault finding - Operating diagram
1UCH.
2Air conditioning.
3Interior lighting.
4Exterior lighting, signals.
5One touch windows and electric sunroof.
6Alarm.
7Radiofrequency key.
8Starter.
9Opening elements.
10 Front/rear wipers, washers.
11 Alternator.
12 BSS* connection
*BSS: (see Role of components, Role of connection BSS).
1
8
3
2
11
10
9
7
6
5
4
12
MR-413-X44-87B000$144.mif
UCH
Vdiag No.: 44
