2009 MITSUBISHI ASX Owners Manual

• The operation mode is not in OFF.
l The
time between unlocking and automatic
locking can be adjusted. Consult a
MITSUBISHI MOTORS Authorized Service
Point.
On vehicles equipped with MITSUBISHI
Multi-Communication System (MMCS),
screen operations can be used to make the ad-
justment. Refer to the separate owner’s man-
ual for details.
Operation confirmation when locking and un-
locking
Operation can be confirmed as shown below. How-
ever, the room lamp will only illuminate if the
front room lamp switch is in the “DOOR” position
or the rear room lamp switch (except for vehicles
equipped with the sunshade) is in the middle (•) po-
sition.
When locking: The turn-signal lamps will blink once.
When unlock-
ing: The room lamp illuminates for
approximately 15 seconds, the
turn-signal lamps blink twice.
NOTE l Functions

can be modified as stated below.
For further information, please contact your
MITSUBISHI MOTORS Authorized Service
Point.
On vehicles equipped with MITSUBISHI
Multi-Communication System (MMCS),
screen operations can be used to make the ad-
justment. Refer to the separate owner’s man-
ual for details. • Set the confirmation function (blinking of
the
turn-signal lamps) to operate only
when the vehicle is locked or only when
the vehicle is unlocked.
• Disable the operation confirmation func- tion (blinking of the turn-signal lamps).
• Change the number of blinks for the oper- ation confirmation function (blinks of the
turn-signal lamps).
Operation of the Dead Lock System
With a vehicle that has a Dead Lock System, it is
possible to set the Dead Lock System using the driv-
er’s or front passenger’s door lock/unlock switch,
or the tailgate LOCK switch. (Refer to “Dead Lock
System” on page 1-23.)
Electronic immobilizer (Anti-theft
starting system) E00306400387
The electronic immobilizer has been designed to sig-
nificantly

reduce the possibility of vehicle theft.
The purpose of the system is to immobilize the ve-
hicle if an invalid start is attempted. A valid start
attempt can only be achieved (subject to certain con-
ditions) using a keyless operation system “regis-
tered” to the immobilizer system.
All of the keys provided with your new vehicle
have been programmed into the vehicle’s electron-
ics. Refer to “Engine switch” on page 1-11. NOTE
l If

you lose one of the keyless operation keys,
contact a MITSUBISHI MOTORS Author-
ized Service Point as soon as possible.
To obtain a replacement or extra spare key,
take your vehicle and all remaining keys to
your MITSUBISHI MOTORS Authorized
Service Point. All the keys have to be re-reg-
istered in the immobilizer computer unit.
The immobilizer can register up to 4 differ-
ent keys.
Engine switch E00306500548
In order to prevent theft, the engine will not start un-
less

a preregistered keyless operation key is used.
(Engine immobilizer function)
If you are carrying the keyless operation key, you
can start the engine.
Also refer to “Starting and driving: Starting the en-
gine” on pages 4-13 and 4-14. Locking and unlocking
1-11 1

CAUTION
l
The indication lamp (A) will flash orange
when there is a problem or malfunction
in the keyless operation system. Never
drive if the indication lamp on the engine
switch is flashing orange. Immediately
contact a MITSUBISHI MOTORS Au-
thorized Service Point.
l If the engine switch operation is not
smooth and feels like it is sticking, do not
operate the switch. Immediately contact a
MITSUBISHI MOTORS Authorized
Service Point.
NOTE l When

operating the engine switch, press the
switch all the way in. If the switch is not
fully pressed, the engine may not start or the
operation mode may not change. If the en-
gine switch is pressed correctly, there is no
need to hold the engine switch down.
Operation mode of the engine switch and its func-
tion
OFF
The indication lamp on the engine switch turns off.
The operation mode cannot be put in OFF when
the selector lever is in any position other than the
“P” (PARK) position (CVT).
ACC
The audio system and other electric devices can be
operated.
The indication lamp on the engine switch illumi-
nates orange. ON
All electric devices can be operated.
The

indication lamp on the engine switch illumi-
nates green.
The indication lamp turns off when the engine is
running.
NOTE
l Your vehicle is equipped with an electronic
immobilizer. To start the engine, the ID code
which the transponder inside the key sends
must match the one registered in the immobil-
izer computer.
(Refer to “Electronic immobilizer (Anti-theft
starting system)” on page 1-11.)
Changing the operation mode E00312200032
If you press the engine switch without depressing
the

brake pedal (CVT) or the clutch pedal (M/T),
you can change the operation mode in the order of
OFF, ACC, ON, OFF. CAUTION
l
When
the engine is not running, put the
operation mode in OFF. Leaving the oper-
ation mode in ON or ACC for a long time
when the engine is not running may cause
the battery to be discharged, making it im-
possible to start the engine, lock and un-
lock the steering wheel.
l When the battery is disconnected, the cur-
rent operation mode is memorized. After
reconnecting the battery, the memorized
mode is selected automatically. Before dis-
connecting the battery for repair or re-
placement, make sure to put the opera-
tion mode in OFF.
Be careful if you are not sure which oper-
ation mode the vehicle is in when the bat-
tery is run down.
l The operation mode cannot be changed
from OFF to ACC or ON if the keyless op-
eration key is not detected to be in the ve-
hicle. Refer to “Keyless operation system:
Operating range for starting the engine
and changing the operation mode” on
page 1-09.
ACC power auto-cutout function E00312300033
After approximately 30 minutes has elapsed with
the

operation mode in ACC, the function automati-
cally cuts out the power for the audio system and
other electric devices that can be operated with that
mode.
When the engine switch is pressed while the opera-
tion mode is in ACC, the power is supplied again
to those devices. Locking and unlocking
1-12
1

NOTE
l It is possible to modify functions as follows:
• The
time until the power cuts out can be
changed to approximately 60 minutes.
• The ACC power auto-cutout function can be deactivated.
For details, consult a MITSUBISHI
MOTORS Authorized Service Point.
On vehicles equipped with MITSUBISHI
Multi-Communication System (MMCS),
screen operations can be used to make the ad-
justment.
Refer to the separate owner’s manual for de-
tails.
Warning activation E00305900486
In order to prevent vehicle theft or the accidental op-
eration

of the keyless operation system, the buzzer
and the display on the information screen in the mul-
ti-information display are used to alert the driver.
If a warning is activated, always check the vehicle
and the keyless operation key. The warning is also
displayed if there is a fault in the keyless operation
system.
If any of the following warnings are activated,
please contact a MITSUBISHI MOTORS Author-
ized Service Point. There is a fault in the keyless opera-
tion system.
The battery in the keyless operation
system key has worn out.
Put the operation mode in OFF and
then start the engine again.
If

the warning is not cancelled, there
is a fault in the electronic immobiliz-
er (Anti-theft starting system).
Please contact a MITSUBISHI
MOTORS Authorized Service Point. In the following cases, a warning is activated, but it
can be cancelled if the correct actions are followed.
l The

ID codes for the keyless operation key
and vehicle do not match. You could be carrying another key-
less

operation key with a different
code, or the keyless operation key
could be outside the operating range.
Refer to “Keyless
operation key take-
out monitoring system” on page
1-13. l
Even
though you press the driver’s or front
passenger’s door lock/unlock switch, or the
tailgate LOCK switch, the doors and tailgate
are not locked. Refer to “Key

lock-in prevention sys-
tem” on page 1-14. Refer to “Door

ajar prevention sys-
tem” on page 1-14. Refer to “Operation

mode OFF re-
minder system” on page 1-14. Keyless operation key take-out monitoring system
E00308000420 When the vehicle is parked with the operation
mode

in any mode other than OFF, if you close the
door after opening any of the doors and taking the
keyless operation key out of the vehicle, a warning
displays and the buzzer sounds 4 times.
NOTE
l If you take the keyless operation key out of
the vehicle through a window without open-
ing a door, the keyless operation key take-
out monitoring system does not operate. Locking and unlocking
1-13 1

l
It is possible to change the setting to make
the keyless operation key take-out monitor-
ing system operate if you take the keyless op-
eration key out from the vehicle through a
window without opening a door. For further
information, please contact your
MITSUBISHI MOTORS Authorized Service
Point.
l Even if you have the keyless operation key
within the engine start operating range, if the
keyless operation key and vehicle ID codes
cannot be matched, for example due to the
ambient environment or electromagnetic con-
ditions, the warning may be activated.
Key lock-in prevention system E00308100391When the operation mode is in OFF, if you close
all

the doors and the tailgate with the keyless oper-
ation key left in the vehicle and you try to lock the
doors and tailgate by pressing the driver’s or front
passenger’s door lock/unlock switch, or the tailgate
LOCK switch, a warning is issued with the warn-
ing display and the buzzer buzzing for approximate-
ly 3 seconds and you cannot lock the doors and tail-
gate. NOTE
l Make

sure you have the keyless operation
key with you before locking the doors. Even
if you leave the keyless operation key inside
the vehicle, it is possible that the doors will
lock depending on the surrounding environ-
ment and wireless signal conditions.
Door ajar prevention system E00308200347 When the operation mode is in OFF, if you try to
lock

the doors and tailgate by pressing the driver’s
or front passenger’s door lock/unlock switch, or the
tailgate LOCK switch with one of the doors or the
tailgate not completely closed, a warning is issued
with the warning display and the buzzer buzzing
for approximately 3 seconds and you cannot lock
the doors and tailgate.
Operation mode OFF reminder system E00308300348 When the operation mode is in any mode other
than

OFF, if you close all the doors and the tailgate
then try to lock the doors and tailgate by pressing
the driver’s or front passenger’s door lock/unlock
switch, or the tailgate LOCK switch, a warning is
issued with the warning display and the buzzer buzz-
ing for approximately 3 seconds and you cannot
lock the doors and tailgate.
Steering wheel lock E00306800235
To lock
Press
the engine switch to put the operation mode
in OFF.
Open one of the doors.
To unlock
The following methods can be used to unlock the
steering wheel.
l Put the operation mode in ACC.
l Start the engine. CAUTION
l
If
the engine is stopped while driving, do
not open a door or press the UNLOCK
switch on the remote control switch until
the vehicle stops in a safe place.
This could cause the steering wheel to
lock, making it impossible to operate the
vehicle.
l Carry the key with you when leaving the
vehicle.
If your vehicle needs to be towed, put the
operation mode in ACC to unlock the
steering wheel. Locking and unlocking
1-14
1

NOTE
l When
the following operation is performed
with the operation mode in OFF, the steering
wheel is locked. • Open or close one of the doors (exceptthe tailgate).
• Lock all doors and the tailgate with the keyless entry system or the keyless opera-
tion function.
l When the steering wheel does not unlock,
the warning will be displayed on the informa-
tion screen in the multi-information display.
Press the engine switch again while moving
the steering wheel slightly. Starting and stopping the engine
E00306900395
Tips for starting l The

operation mode can be in any mode to
start the engine. l
The
starter motor will be turning for up to ap-
proximately 15 seconds if the engine switch
is released at once. Pressing the engine
switch again while the starter motor is still
turning will stop the starter motor. The start-
er motor will be turning for up to approxi-
mately 30 seconds while the engine switch is
pressed.
If the engine does not start, wait for a while
and then attempt to start the engine again. Try-
ing repeatedly with the starter motor still run-
ning will damage the starter mechanism.
l [Diesel-powered vehicles]
While the vehicle is stationary with the
clutch pedal fully depressed, the engine revo-
lutions do not rise to over 3,000 rpm in order
to protect the engine even if the accelerator
pedal is depressed. WARNING
l Never
run the engine in a closed or poor-
ly ventilated area any longer than is nee-
ded to move your vehicle in or out of the
area. Carbon monoxide gases are odour-
less and can be fatal. CAUTION
l
Never
attempt to start the engine by push-
ing or pulling the vehicle.
l Do not run the engine at high rpm or
drive the vehicle at high speed until the en-
gine has had a chance to warm up. Starting the engine (petrol-powered vehicles)
E00307000478
The starting procedure is as follows:
1.

Fasten the seat belt.
2. Make sure the parking brake is applied.
3. Depress and hold the brake pedal.
4. Fully depress the clutch pedal (M/T).
NOTE l On vehicles with the Auto Stop & Go
(AS&G) system, the starter will not operate
unless the clutch pedal is fully depressed
(Clutch interlock).
5. On vehicles equipped with M/T, place the gearshift lever in the “N” (Neutral) position.
On vehicles equipped with CVT, make sure
the selector lever is in the “P” (PARK) posi-
tion.
Vehicles with M/T Vehicles with CVT Locking and unlocking
1-15 1

NOTE
l The
engine can only be started when the se-
lector lever is in the “P” (PARK) or “N”
(NEUTRAL) position (CVT).
For safety reasons, the engine should be star-
ted when the selector lever is in the “P”
(PARK) position in which the driving wheels
lock.
6. Press the engine switch.
7. Make sure that all warning lamps are func- tioning properly.
NOTE l Minor noises may be heard on engine start-
up. These will disappear as the engine warms
up.
Starting the engine (diesel-powered vehicles) E00308600051
1. Fasten the seat belt.
2.

Make sure the parking brake is applied.
3. Depress and hold the brake pedal.
4. Fully depress and hold the clutch pedal.
NOTE l On vehicles with the Auto Stop & Go
(AS&G) system, the starter will not operate
unless the clutch pedal is fully depressed
(Clutch interlock). 5. Place
the gearshift lever in the “N” (Neutral)
position. 6. Press the engine switch.
The
diesel preheat indication lamp will first
illuminate, and then after a short time go out,
indicating that preheating is completed. The
engine will start.
NOTE l If the engine is cold, the diesel preheat indi-
cation lamp is on for a longer time.
l Putting the operation mode in ON will also
start preheating the engine. When the engine
has not been started within about 5 seconds
after the diesel preheat indication lamp went
out, put the operation mode in OFF. Then, at-
tempt the engine start procedure to preheat
the engine again.
l Minor noises may be heard on engine start-
up. These will disappear as the engine warms
up. Using the MIVEC engine
The

MIVEC engine automatically switches its in-
take-valve control between a low-speed mode and
a high-speed mode in accordance with driving con-
ditions for maximum engine performance.
NOTE
l To protect the engine, the high-speed mode
may not be selected while the engine coolant
temperature is low.
Stopping the engine E00312600023 WARNING
l Do
not operate the engine switch while
driving except in an emergency. If the en-
gine is stopped while driving, the brake
servomechanism will cease to function
and braking efficiency will deteriorate.
Also, the power steering system will not
function and it will require greater man-
ual effort to operate the steering. This
could result in a serious accident.
NOTE l If

you have to bring the engine to an emergen-
cy stop while driving, press and hold the en-
gine switch for 3 seconds or more, or press it
quickly 3 times or more. The engine will
stop and the operation mode will go to ACC. Locking and unlocking
1-16
1

l
Do not stop the engine with the selector lever
in
any position other than the “P” (PARK) po-
sition (CVT). If the engine is stopped with
the selector lever in any position other than
the “P” (PARK) position, the operation
mode will go to ACC rather than OFF.
Put the operation mode in OFF after placing
the selector lever in the “P” (PARK) position.
1. Stop the vehicle.
2. Fully engage the parking brake while depress-ing the brake pedal.
3. On vehicles with M/T, press the engine switch to stop the engine, move the gearshift
lever to the 1 st
(on a uphill) or “R” (Reverse)
(on a downhill) position.
On vehicles with CVT, move the selector lev-
er to the “P” (PARK) position, press the en-
gine switch to stop the engine.
If the keyless operation key is not oper-
ating properly E00312500035
Insert the keyless operation key into the key slot in
the

glove box. Starting the engine and changing the
operation mode should now be possible. Remove the keyless operation key from the key
slot

after starting the engine or changing the opera-
tion mode. NOTE
l Do

not insert into the key slot anything other
than the keyless operation key. This could
cause damage or a malfunction.
l Remove the object or additional key from the
the keyless operation key before inserting the
key into the key slot.
The vehicle may not be able to receive the
registered ID code from the registered key.
Therefore, the engine may not start and the
operation mode may not change.
Keyless operation key reminder If the operation mode is in OFF and the driver’s
door

is opened with the keyless operation key in
the key slot, a warning is issued with the warning
display and the buzzer buzzing for approximately 3
seconds to remind you to remove the key.
To operate without using the keyless
operation function E00306000123
Emergency key E00307200278
The emergency key is built into the keyless opera-
tion

key. If the keyless operation function cannot
be used, for example because the keyless operation
key battery has worn out or the vehicle battery is
flat, you can lock and unlock the driver’s door with
the emergency key. To use the emergency key (A),
unlock the lock knob (B) and remove it from the
keyless operation key (C). NOTE
l Only

use the emergency key for emergen-
cies. If the keyless operation key battery
wears out, replace it as quickly as possible so
that you can use the keyless operation key. Locking and unlocking
1-17 1

l
After using the emergency key, always re-
turn it into the keyless operation key.
Locking and unlocking the driver’s door
Turning the emergency key in the forward direc-
tion locks the door, and turning it in the rear direc-
tion unlocks the door. Also refer to “Locking and
unlocking: Doors” on page 1-21. 1- Lock
2-

Unlock Keyless entry system
E00307700606
Press

the remote control switch, and all doors and
the tailgate will be locked or unlocked as desired. It
is also possible to operate the outside rear-view mir-
rors. 1-
LOCK ( ) switch
2- UNLOCK ( ) switch
3-

Indication lamp
To lock
Press the LOCK switch (1). All the doors and the
tailgate will be locked. The turn-signal lamps will
blink once when the doors and the tailgate are locked.
NOTE l With a vehicle that has a Dead Lock System,
pressing the LOCK switch (1) two times in
succession causes the Dead Lock System to
be set. (Refer to “Setting the system” on
page 1-23.) To unlock
Press

the UNLOCK switch (2). All the doors and
the tailgate will be unlocked. If the front room
lamp switch is in the “DOOR” position or the rear
room lamp switch (except for vehicles equipped
with the sunshade) is in the middle ( ·) position at
this time, the room lamp will come on for approxi-
mately 15 seconds and the turn-signal lamps will
blink twice.
Depending on the vehicle model, the position and
tail lamps can also be set to turn on for approximate-
ly 30 seconds.
Refer to “Instruments and controls: Welcome
light” on page 3-47.
NOTE
l Except for vehicles equipped with a Dead
Lock System, the door and tailgate unlock
function can be set so that only the driver’s
door unlocks when the UNLOCK switch (2)
is pressed once.
If the door and tailgate unlock function is set
to work as described above, all the doors and
the tailgate unlock when the UNLOCK
switch is pressed two times in succession.
Refer to “Setting of door and tailgate unlock
function” on page 1-19.
l The indication lamp (3) comes on each time
a switch is pressed.
l If the UNLOCK switch (2) is pressed and no
door or tailgate is opened within approximate-
ly 30 seconds, relocking will automatically
occur. Locking and unlocking
1-18
1
