2009 HONDA CIVIC COUPE Owners Manual

To change the driver’s side bulb,
start the engine, turn the steering
wheel all the way to the right, and
turn of f the engine. To change the
passenger’s side bulb, turn the
steering wheel to the lef t. Remove the electrical connectorf rom the bulb by pushing on the
tab to unlock it, then slide the
connector of f the bulb.Remove the bulb f rom the
headlight assembly by turning it
one-quarter turn counterclockwise.
Insert the new bulb into the hole,
and turn it one-quarter turn
clockwise to lock it in place.
Push the electrical connector back
onto the bulb. Make sure it is on
all the way.
Turn on the headlights to test the
new bulb.
Use a Phillips-head screwdriver to
remove the screw from the inner
f ender, and pull the inner f ender
cover back. Reinstall the inner f ender cover.
Then reinstall the screw and
tighten it securely.
2.
1.
3.4.
5.
6.
7.
8.
Lights
L ow Beam Headlight
326
SCREW
BULB
ELECTRICAL CONNECTOR
\f—\f—\fy

y
(+\fy\f
y
2009 Civic Coupe

Remove the bulb f rom the socket
by pushing the bulb in and turning
it counterclockwise until it unlocks.
Install the new bulb in the socket.
Turn it clockwise to lock it in place.
Insert the socket back into the
headlight assembly. Turn it
clockwise to lock it in place.
Turn on the lights to make sure
the new bulb is working.
Remove the socket from the
headlight assembly by turning it
one-quarter turn counterclockwise.
To change the driver’s side bulb,
start the engine, turn the steering
wheel all the way to the right, and
turn of f the engine. To change the
passenger’s side bulb, turn the
steering wheel to the lef t.
Use a Phillips-head screwdriver to
remove the screw from the inner
f ender, and pull the inner f ender
cover back.
Reinstall the inner f ender cover.
Then reinstall the screw and
tighten it securely.
4.
5.
6.
7.
8.
3.
2.
1.
Lights
Replacing the Front Side Marker/
Parking/Turn Signal Light Bulb
Maint enance
327
\f—\f—\fy

y
(+\fy\fy
2009 Civic Coupe

Open the trunk.Pull the bulb straight out of its
socket. Push the new bulb straight
into the socket until it bottoms.
Remove the screw in the center of
the fastener on the side of the
trunk lining. Pull the lining back. Reinstall the socket into the light
assembly by turning it clockwise
until it locks.
Turn on the lights to make sure
the new bulb is working.
Reinstall the trunk lining. Make
sure it is installed under the edge
of the trunk seal.
Put the f astener into the hole on
the side of the trunk lining.
Reinstall the screw.
Determine which of the f our bulbs
is burned out: stop/tail-light, back-
up light, side marker light, or turn
signal light.
Remove the socket by turning it
one-quarter turn counterclockwise.
1. 2.
3.4.
5.
6.
7.
8.
Replacing Rear Bulbs
Lights
328
FASTENER
\f—\f—\fy

y
(+\fy\fy
2009 Civic Coupe

If equipped
Your vehicle uses halogen light
bulbs. When replacing a bulb, handle
it by its plastic case, and protect the
glass from contact with your skin or
hard objects. If you touch the glass,
clean it with denatured alcohol and a
clean cloth.
Thefoglightswereproperlyaimed
when your vehicle was new. If you
regularly carry heavy items in the
trunk, readjustment may be required.
Adjustment should be done by your
dealer or another qualif ied
technician.Remove the mounting bolts with a
wrench.
Pull the f og light assembly f rom
the bumper while taking out the
tabs from the bracket.
1. 2.
CONT INUED
ReplacingaFogLightBulb
Lights
Maint enance
329
MOUNTING BOLTSHalogen light bulbs get very hot when
lit. Oil, perspiration, or a scratch on
the glass can cause the bulb to overheat
and shatter.
\f—\f—\fy

\fy
(+\fy\fy
2009 Civic Coupe

Remove the electrical connector
f rom the bulb by pushing on the
tab and pulling the connector
down.
Remove the bulb f rom the f og
light assembly by turning it one-
quarter turn counterclockwise.Insert the new bulb into the hole,
and turn it one-quarter turn
clockwise to lock it in place.
Push the electrical connector back
onto the bulb. Make sure it is on
all the way.
Turn on the f og lights to test the
new bulb.
Reinstall the f og light assembly
into the bumper while setting the
tabs in the bracket. Tighten the
mounting bolts securely.
The license plate has two lights
above it. You can access either of
them from the back of the trunk lid.
If your vehicle has a trunk lining,
these bulbs should be replaced by
your dealer.
6.
7.
8.
4. 5.
3.
Lights
Rear License Plate Light Bulbs
330
ELECTRICAL CONNECTOR TAB
\f—\f—\fy


\fy
(+\fy\fy
2009 Civic Coupe

If your seat belts get dirty, use a sof t
brush with a mixture of mild soap
and warm water to clean them. Do
not use bleach, dye, or cleaning
solvents. Let the belts air-dry bef ore
you use the vehicle.
Remove the socket f rom the light
assembly by turning it one-quarter
turn counterclockwise.
Open the trunk, then remove the
holding clips f rom the cover, and
remove the cover. Pull the bulb straight out of its
socket. Push the new bulb straight
into the socket until it bottoms.
Reinstall the socket. Turn it
clockwise until it locks. Make sure
the new bulb is working.
Reinstall the cover, and tighten its
holding clips securely.
The high-mount brake light should
be replaced by your dealer.
2.
1. 3.
4.
5.
CONT INUED
On DX, Canadian DX-G, and LX models
OnEX,EX-L,andSimodels
Replacing a High-mount Brake
Light Bulb
Cleaning the Seat Belts
Lights, Cleaning the Seat Belts
Maint enance
331
SOCKET LOOP
BULB
\f—\f—\fy


y
(+\fy\fy
2009 Civic Coupe

If equipped
Dirt build-up in the loops of the seat
belt anchors can cause the belts to
retract slowly. Wipe the insides of
the loops with a clean cloth
dampened in mild soap and warm
water or isopropyl alcohol.If you remove a f loor mat, make sure
tore-anchoritwhenyouputitback
in your vehicle.
If you use a non-Honda f loor mat,
make sure it f its properly and that it
canbeusedwiththefloormat
anchors. Do not put additional f loor
mats on top of the anchored mat.
The driver’s and right rear
passenger’s f loor mats that came
with your vehicle hook over the f loor
mat anchors. This keeps the f loor
mats f rom sliding f orward and
possibly interf ering with the pedals
(driver’s floor mat) or with the seat
weight sensors (right rear f loor mat).
Floor Mats
Cleaning the Seat Belts, Floor Mats
332
\f—\f—\fy

y
(+\fy\fy
2009 Civic Coupe

Check the condition of the wiper
blades at least every six months.
Replace them if you f ind signs of
cracking in the rubber, areas that are
getting hard, or if they leave streaks
and unwiped areas when used.
This f ilter removes the dust and
pollenthatisbroughtinfromthe
outside through the heating and
cooling system.
Have your dealer replace the filter
when this service is indicated by a
maintenance message on the
inf ormation display. It should be
replaced every 15,000 miles (24,000
km) if you drive primarily in urban
areas that have high concentrations
of soot in the air, or if the f low f rom
the heating and cooling system
becomeslessthanusual.
To replace a wiper blade:
Raise each wiper arm of f the
windshield, lif ting the driver’s side
first, then the passenger’s side.
1.
CONT INUED
On models with A/C
Wiper Blades
Dust and Pollen Filter
Dust and Pollen Filter, Wiper Blades
Maint enance
333
Do not open the hood when the wiper
arms are raised, or you will damage the
hood and wiper arms.
