2009 FIAT DOBLO bluetooth

44
Blue&Me™communicates with your per-
sonal devices using USB and Bluetooth®
technology.
To get updated information on the com-
patibility of personal devices with
Blue&Me™, contact a Fiat Dealership or
go to the dedicated area on www.fiat.com.
MOBILE PHONES WITH
Bluetooth
®TECHNOLOGY
Blue&Me™is compatible with most mo-
bile phones that support Bluetooth
®1.1
and the 1.5 HandsFree profile (refer to the
Bluetooth
®connection specifications in
your mobile phone handbook).
As a result of the different software ver-
sions available on the market for differ-
ent models of mobile phone, some addi-
tional functions (e.g. second call manage-
ment, call transfer from hands-free system
to mobile phone and vice versa, etc.) may
not correspond exactly to the description
in the mobile phone user manual. In any
case, your ability to have a hands-free con-
versation is not compromised. Mobile phones with
phonebook management
If your mobile phone is able to automatically
transmit contacts via Bluetooth
®, the en-
tire phonebook will automatically be copied
onto Blue&Me™during registration.
To see the list of mobile phones and func-
tions supported, go to the the Blue&
Me™section of www.fiat.com or call
Customer Services on 800.3428.0000.
Here, you can find:
❒a quick guide with usage tips;
❒a guide to using a mobile phone for reg-
istration;
❒advice on connecting an iPod;
❒the nine available voice recognition lan-
guage files that can be downloaded in-
dividually onto Blue&Me™(Italian,
French, English, German, Spanish, Por-
tuguese, Dutch, Polish, Brazilian).Mobile phones with individual
contact management
If your mobile phone is able to transmit
individual phonebook contacts via Blue-
tooth
®, during the registration procedure
you will be asked to transfer the names us-
ing your phone.
Mobile phones with SMS message
management (not all mobiles
support listening to incoming text
messages)
If your mobile phone is able to transmit
SMS messages via Bluetooth
®, you can
read incoming texts via the Blue&Me™
hands-free system, save them to an inbox
or delete them.
TECHNOLOGY COMPATIBLE WITH Blue&Me™
604_39_206 DOBLO BLUE GB 1ed 17-09-2009 16:55 Pagina 44

47
Compatible playlist formats
The Media Player can play playlists in the
following formats:
❒.m3u – file containing a list of tracks.
(versions 1 and 2)
❒.wpl – Windows®-based file that con-
tains a playlist. (the capacity limit of the
playlist in this format is 300 kb). You can
create .wpl playlists by using Microsoft
®
Windows Media®Player.
The Media Player does not support nest-
ed or connected playlists. Both relative
and absolute paths to songs in the playlists
are supported.
The player does not support playlists gen-
erated by a software application based on
special preferences or criteria.
The playlists created by an iPod cannot be
read.
The player will play playlists that include
paths that lead to digital audio files in the
folder.
For further information on creating
playlists for Blue&Me™, refer to the
SUGGESTIONS FOR USING THE ME-
DIA PLAYER section.
Note on brands
Microsoft®and Windows®are registered trademarks of Microsoft Corporation.
Sony®is a registered trademark of Sony Corporation.
Ericsson®is a registered trademark of Telefonaktiebolaget LM Ericsson.
Motorola®is a registered trademark of Motorola, Inc.
Nokia®is a registered trademark of Nokia Corporation.
Siemens®is a registered trademark of Siemens AG.
Orange
™is a registered trademark of Orange Personal Communications Services Limited.
Audiovox®is a registered trademark of Audiovox Corporation.
Bluetooth®is a registered trademark of Bluetooth®SIG, Inc.
Lexar
™and JumpDrive®are registered trademarks of Lexar Media, Inc.
SanDisk®and Cruzer™are registered trademarks of SanDisk Corporation.
iPod, iTunes and iPhone are registered trademarks of Apple Inc.
All the other brand names are property belonging to the respective owners.
604_39_206 DOBLO BLUE GB 1ed 17-09-2009 16:56 Pagina 47

55
TABLE OF VOICE COMMANDS FOR SETTINGS
• Settings
• Set
• Configure
Activates the SETTINGS
menu of the hands-free
system
• Multimedia file
settings
Activates the
MEDIA PLAYERmenu
• Random play
• Shuffle
Plays/stops playing
tracks in a random order
• Repeat track
Plays/stops playing the
same track continuously
• User data
Activates USER DATAmenu
Delete users
Deletes all users' registration data
• Add contactsTransfers the names of individual
contacts from a connected mobile phone
to the hands-free system
N.B.Function available only for mobile
phones with individual contact
management (**)
• Delete allDeletes registration data and all contacts of
all registered telephones, restoring the hands-
free system to its original settings
Displays the identification code
of your hands-free system
• Connection code
• Connection codeActivates the GPRS CODEmenu
• Delete contacts
• Delete phonebook
• Delete numbersDeletes the current phonebook
• Copy contacts
• Copy phonebook
• Copy numbers Transfers the contacts from a connected
mobile phone to the hands-free system.
N.B.Function available only for mobile
phones with contacts
management (*)
• Registration
• Register
• Register
• Register user
Activates the registration
process for a new mobile phone
Activates the ADVANCED OPTIONSmenu
Exits the SETTINGSmenu
Automatically plays/stops
playing audio when USB drive
is inserted
• Advanced options
• Exit
• Exit• Automatic play
• Autoplay(*) If your phone can automatically forward its contacts via Bluetooth®, the entire
phonebook will be automatically copied to the hands-free system during registration.
(**) If your phone can forward individual contacts from the phonebook via Bluetooth
®,
during the registration process you will be asked to transfer the names using your mobile
phone.
• System code
604_39_206 DOBLO BLUE GB 1ed 17-09-2009 16:56 Pagina 55

58
Problem Probable cause Possible solution
The display shows:
NO PHONE
Or the system says
“No phone connected”
The display shows:
PHONE DISCONNECTED
The display shows:
REGISTRATION FAILED
Or the system says
“Registration unsuccessful.
Please try again”
❒Turn the mobile phone on
❒Make sure that your phone has
been registered
❒Make sure that the Bluetooth®
connection between your mobile
phone and the vehicle's hands-free
system has been activated
(“Blue&Me” identification)
❒Make sure that the mobile
phone that you registered on the
vehicle's hands-free system is within
the system's operating range
❒Turn the mobile phone off and on
again to restore the connection
with Blue&Me™
❒Restart Blue&Me™by turning the
ignition key to STOPand then back
to MAR
❒Check that the PIN number is correct
and try to enter it again
❒Turn the mobile phone off and on again
and then repeat the registration process

SETTINGS – MOBILE PHONE
REGISTRATION
❒The mobile registered is switched off
❒The mobile registered is not within
the system's operating range
(it should be within about
10 m from the system)
❒The Bluetooth®connection
between the system and the mobile
has been disabled on your mobile
phone (“Blue&Me” identification)
❒An error has been detected in
your mobile phone's Bluetooth®
connection
❒During a phone conversation,
the mobile phone left the hands-free
system's operating range
❒An error was detected during the
registration procedure
604_39_206 DOBLO BLUE GB 1ed 17-09-2009 16:56 Pagina 58

61
Problem Probable cause Possible solution
The system prompts you to enter
a PIN code, but you are not registering
a phone
When you are very near the vehicle and
you take a call with the answer button
on your mobile phone, the vehicle's
hands-free function is automatically
activated (the speaker's voice is played
over the speakers in the passenger
compartment)Select DELETE USERSon the
system and delete all the registrations,
then register the mobile phone again

SETTINGS – MANAGING DATA
AND CONTACTS

SETTINGS – MOBILE PHONE
REGISTRATION
Refer to your mobile phone's manual
to find out how to configure the call
management mode After you have deleted the user infor-
mation relating to the registration of
your mobile phone, the Bluetooth
®
connection between the phone and
Blue&Me™is no longer active
For some types of mobile phone,
you need to set the incoming call
management mode to automatic
transfer to the hands-free system
or transfer on request (by means of
specific controls on the mobile phone)
604_39_206 DOBLO BLUE GB 1ed 17-09-2009 16:56 Pagina 61

64
SMS MESSAGE READER
Problem Probable cause Possible solution
I can receive SMS messages on my
mobile phone but not on Blue&Me™
The SMS messages received from the
phone operator's service centre
incorrectly display the sender's name
or number
Blue&Me™has stopped receiving
messages from your mobile phone
Some SMS messages on your mobile
phone are not displayed in the SMS
message inbox of Blue&Me™
Check that your mobile phone supports
the function of transferring SMS messages
via Bluetooth
®or, for more information,
refer to the LIST OF PHONES SUPPORTED
BY BLUE&ME™section or the
Blue&Me™section of www.fiat.com.
–
On the notification settings menu,
set VISUAL+AUDIBLE
or the VISUAL NOTIFICATION

SMS MESSAGE READER
FUNCTIONS – NOTIFICATION
SETTINGS
IT IS possible to delete SMS messages
saved by Blue&Me™.

SMS MESSAGE READER
FUNCTIONS, paragraphs on
MANAGING SMS MESSAGES and
DELETING ALL SMS TEXT MESSAGES Not all mobile phones support the
transfer of an SMS message to
Blue&Me™
Not all mobile phones support the correct
transfer to Blue&Me™of the name of the
service provider that has sent the SMS
message
You may have accidentally chosen
NOT ACTIVE in the menu
Notification settings
Blue&Me™is capable of reading
and saving the last 20 SMS messages
received while the mobile phone is connected
to the system.Messages received in other
contexts are not transferred to
Blue&Me™
604_39_206 DOBLO BLUE GB 1ed 17-09-2009 16:56 Pagina 64

72
PERSONAL DATA PROTECTION
The functions provided by the Blue&Me™device include the handling of personal data. To avoid unauthorised access to such in-
formation, the device was created in such a way that:
❒Personal data linked to the operation of the hands-free system (contacts and call log) are only accessible after automatic recog-
niton of the user's mobile phone via Bluetooth®;
❒The personal data on your device can be deleted using the appropriate Blue&Me™functions.

For further information on deleting personal details, refer to the SETTINGS -MANAGING USER DATA section.
IMPORTANT When leaving the vehicle in a service centre, bear in mind that the personal data stored on Blue&Me™(contacts
and call log), may be subject to detection or improper use. Before leaving your vehicle at a service centre, you can delete all the
registered user data and the contacts saved on Blue&Me™.

For further information on deleting user data and contacts, please refer to the SETTINGS – MANAGING USER DATA section.
604_39_206 DOBLO BLUE GB 1ed 17-09-2009 16:56 Pagina 72
