19
Blue&Me™allows you to make and re-
ceive calls using your mobile phone
equipped with Bluetooth
®technology,
using voice recognition or steering wheel
controls.
You can use voice commands to phone
your contacts by saying their name and/or
surname, or you can phone numbers that
are not stored, by saying the number out
loud, or you can call the sender of a re-
ceived text message.
With the steering wheel controls, you can
phone the names in your phonebook or
bring up your call log by selecting the name
you want in the sub-menu CALL LOG
or CONTACTS.
Furthermore, you can respond to in-
coming calls, redial an engaged number,
receive a call alert, read an SMS message
or delete it.

If you have any difficulties using the tele-
phone functions through the vehicle's
hands-free system, see the TROU-
BLESHOOTING – HANDS-FREE section.
N.B.
❒Before you can make and receive tele-
phone calls with the hands-free system,
you need to register your mobile phone
on the system.

For more information, see the SET-
TINGS – REGISTERING YOUR MOBILE
PHONE section.
❒To activate the vehicle's hands-free sys-
tem, the igntion key must be turned to
MAR.
❒If you turn the ignition key to STOP
during a phone conversation, you can
continue the conversation for another
15 minutes via the hands-free system.MAKING A CALL
A call can be made in one of the follow-
ing ways:
❒Call a name in the phonebook
❒Call a number using voice commands
❒Call a number using the mobile phone
keypad
❒Call a number from your call log
❒Call the sender of a received SMS mes-
sage

For more information, refer to the SMS
MESSAGE READER FUNCTIONS –
MANAGING SMS messages chapter.
HANDS-FREE FUNCTIONS
604_39_206 DOBLO BLUE GB 1ed 17-09-2009 16:55 Pagina 19

24
Transferring a call from
the hands-free system
to your mobile
To transfer a phone conversation from the
hands-free system to your mobile phone,
press SRC/OK.
You can talk on your mobile and continue to
use the steering wheel controls. In particu-
lar, if you have more than one active con-
versation, you can press
ß/MENUto switch
from one phone call to the other;
press
ß/MENUfor more than one second
to end the conversation.Putting a call on hold
To put an ongoing phone call on hold and
disable the microphone so that the other
person cannot hear you, press
&/ESC. TELECONFERENCING
(only for phones with Bluetooth
®
that support this function)
The conference call function allows you to
make a phone call to a third person dur-
ing an active call. You can speak to both
people at the same time.
To activate a teleconference, make the
new call while you already have a call un-
der way by following the procedure de-
scribed in the MAKING A CALL section.
When the Teleconferencing function is
active, the display will read “CONFER-
ENCE”.
Once the conference is activated, hold-
ing down the
ß/MENU button will end
both calls.
604_39_206 DOBLO BLUE GB 1ed 17-09-2009 16:55 Pagina 24

25
If your mobile phone with Bluetooth®
supports the SMS message reader function,
when a new text message is received,
Blue&Me
™will notify you through an
audible signal and ask you if you want to
read it (depending on the notification op-
tions set).
To see the list of mobile phones and func-
tions supported, see the Blue&Me
™on
the www.fiat.com website or call Customer
Services on 800.3428.0000.

For information on the notification op-
tions, refer to the Notification settings.
?
If you want Blue&Me™to read
the text message received, press
SRC/OKor
ß/MENU. The SMS
message will be read taking into ac-
count any abbreviations and emoti-
cons within the text.
If you do not want to read the SMS
message, press
&/ESC,Blue&Me™
will not read the message, but it will
save it so you can read it later (for
more information, please refer to the
Read last message receivedpara-
graph).
}
Or, with voice commands:
if you say “Yes”, Blue&Me™will
read the text in the message, tak-
ing into account any abbreviations
present, but, if you do not want to
read the message, just say “No”: the
system will save it so you can read
it later (for more information please
refer to the Read last message
receivedparagraph). READ LAST MESSAGE RECEIVED
When an SMS message is received,
whether it is read or not, Blue&Me
™will save it to an inbox (refer to theInbox
paragraph).
?
If you want to read the last message
received, activate the Blue&Me™Main Menu and select the MES-
SAGE READERoption, then press
SRC/OKor
ß/MENU.
Select the READ LASToption
and press SRC/OKor
ß/MENU,
Blue&Me™will read the last mes-
sage received.
}
Or, with voice commands:
Press
‘and say “Read last”:
Blue&Me™will read the last mes-
sage received.
SMS MESSAGE READER FUNCTIONS
(only fo r compatible mobile phones)
604_39_206 DOBLO BLUE GB 1ed 17-09-2009 16:55 Pagina 25

26
INBOX
Blue&Me™stores up to 20 messages re-
ceived (if there are concatenated mes-
sages, this number may be lower) whilst
connected to your Bluetooth
®mobile
phone. When the inbox is full, receipt of
a new message involves deleting the old-
est message even if it has not been read
yet. It is also possible to individually or
completely delete the messages in the in-
box (refer to the MANAGING SMS MES-
SAGES paragraph).
?
If you want to read a specific saved
message, activate the Main Menu of
Blue&Me™and select the MES-
SAGE READERoption, then
press SRC/OKor
ß/MENU.
Select the option RECEIVED MES-
SAGES, then press SRC/OKor
ß/MENU. Scroll through the saved
messages until you reach the one you
want: the system will display infor-
mation on the identity of the sender
of the message, where available. Se-
lect READand press SRC/OKor
ß/MENU, Blue&Me™will read the
selected text message.
}
Or, with voice commands:
Press
‘and say “Message read-
er”; after the audible signal, say “Re-
ceived messages”: Blue&Me™
will display the information on the
first message in the inbox (if in the
phonebook, the message sender's
number will be displayed).
IT IS possible to scroll through the
Inboxby saying “Previous” or
“Next”; when you see the desired
message, say “Read”: Blue&Me™
will read the selected message.
If you say “Delete”, the system will
delete the selected message.MANAGING SMS MESSAGES
For each text message received,
Blue&Me™allows you to:
❒ read it
❒ call the sender's phone number di-
rectly
❒ delete it
?
To do this manually whilst reading a
message, activate the Main Menu of
Blue&Me™and then you can select
the desired function by using the
SRC/ OKor
ß/MENUbuttons.
}
Or, with voice commands:
Press
‘and say “Read” or “Call”
or “Delete”: the system will select
the chosen option.
604_39_206 DOBLO BLUE GB 1ed 17-09-2009 16:55 Pagina 26

36
The SETTINGSmenu gives you the fol-
lowing choices:
❒Register a mobile phone
❒Manage user data
❒Advanced options.
To operate within the Settingsmenu
when the car is stationary, you can use
either the steering wheel controls or voi-
ce commands. When the car is moving,
you can use only voice commands. In-
structions for both methods follow.

IF YOU HAVE SOME DIFFICULTIES
USING THE BLUE&ME™ settings func-
tions, see the TROUBLESHOOTING
section.REGISTERING A MOBILE PHONE
In order to use your mobile phone with
the vehicle's hands-free function, it must
be registered.
During the registration process, the
hands-free system searches for a phone
with Bluetooth
®technology in its re-
ception range. If it finds one, it establish-
es a connection with it by using a Person-
al Identification Number (PIN). After you
have registered your mobile phone on the
system, you can use it with the hands-free
system.
IMPORTANT The PIN code used for reg-
istering a mobile phone is produced ran-
domly by the system each time a new
phone is registered, therefore you do not
need to remember it. If you lose it, you
can still use the hands-free system.
You only need to register your phone
once; after that, Blue&Me™will auto-
matically connect to it every time you get
in the vehicle and turn the ignition key to
MAR.You can register your mobile phone by
choosing REGISTRATIONin the SET-
TINGSmenu.
?
To perform the registration manu-
ally, proceed as follows:
Activate the Main Menu by pressing
ß/MENUand select SETTINGS
by pressing SRC/OKor
ß/MENU.
Select REGISTRATIONand then
press SRC/OKor
ß/MENU. The
system begins the registration
process.
The system displays the PIN code
necessary for registering the mobile
phone on the instrument panel and
repeats it out loud. It is important
to know that this PIN is only used
for registering the mobile phone; it
is not your SIM card PIN.
For the next two stages, consult your
mobile phone manual on how to reg-
ister and connect with Bluetooth
®
devices.
SETTINGS
604_39_206 DOBLO BLUE GB 1ed 17-09-2009 16:55 Pagina 36

37
On your mobile phone, look for the
option that finds in-range Blue-
tooth
®devices (it may be called
Find, Add Device, etc.). From the list
of available Bluetooth
®devices,
choose “Blue&Me” (the name that
identifies the Blue&Me™system
on your vehicle).
When prompted by your phone, en-
ter the PIN number shown on the
instrument panel display. If the reg-
istration was successful, the system
will say “Connection in progress”
and you get confirmation at the end
when the display shows details of the
mobile phone registered.
It is important to wait for this con-
firmation message – if you press
ß/MENUor &/ESCbefore it ap-
pears, you risk cancelling the regis-
tration process. If registration fails,
an error message will appear; in this
case, you will need to start again.The first time a mobile phone is reg-
istered, the system says “Wel-
come” as soon as it is connected.
This welcome message will not be
delivered during subsequent regis-
trations or connections of the same
mobile phone.
The system will ask you if you want
to copy across the contacts of the
phone you have just registered.
Copying the phonebook is recom-
mended.
To copy the contacts, press SRC/
OKor
ß/MENU. If you do not
want to copy the phonebook, press
&/ESC. If you do not copy the
phonebook at this point, you can
copy it later by choosing SET-
TINGS, USER DATA, CON-
TACTS.
On some mobile phones, the names
in the phonebook are not copied
automatically, but have to be trans-
ferred by using the mobile phone
keypad. If prompted by the system,
carry out this procedure following
the specific instructions for your
mobile phone and press
ß/MENU
when you have finished.
}
Or, with voice interaction:
Press
‘and say “Settings” and
then, at the end of the message from
the system, say “Register user”.
The system displays the PIN code
for registration on the instrument
panel and repeats it out loud.
For the next two stages, consult
your mobile phone manual on how
to register and connect with Blue-
tooth
®devices.
On your mobile phone, look for the
option that finds in-range Blue-
tooth
®devices (it may be called
Find, Add Device, etc.). From the list
of available Bluetooth
®devices,
choose “Blue&Me” (name that
identifies your vehicle's hands-free
system).
When prompted by your mobile
phone, enter the PIN code shown
on the display with your mobile
phone keypad. If the registration
was successful, the system will say
“Connection in progress” and
you get confirmation at the end
when the display shows details of
the mobile phone registered.
604_39_206 DOBLO BLUE GB 1ed 17-09-2009 16:55 Pagina 37

38
It is important to wait for this con-
firmation message – if you press
ß/MENUor &/ESCbefore it ap-
pears, you risk cancelling the regis-
tration process. If registration fails,
an error message will appear; in this
case, you will need to start again.
The first time a mobile phone is reg-
istered, the system says “Welcome”
as soon as it is connected. This wel-
come message will not be delivered
during subsequent registrations or
connections of the same mobile
phone.
The system will ask you if you want
to copy the phonebook from the
phone you have just registered.
Copying the phonebook onto the
system is recommended. To copy
the phonebook, say “Yes”. If you do
not want to copy the phonebook,
say “No”.
On some mobile phones, the names
in the phonebook are not copied au-
tomatically, but have to be trans-
ferred by using the mobile phone
keypad. If prompted by the hands-
free system, carry out this procedure
following the specific instructions for
your mobile phone and press
ß/MENUwhen you have finished.Suggestions
To improve the voice recognition of the
names in your phonebook and the pro-
nunciation accuracy of Blue&Me™, try
to enter and save your contacts as follows:
❒Avoid abbreviations.
❒Write foreign names the way they are
pronounced according to the rules of
the Blue&Me™language set on your
vehicle. For example, it is advisable to
enter “Thorsten” as “Torsten” to im-
prove recognition and get the system to
pronounce the names correctly.
❒When you add or amend names in the
phonebook, enter the appropriate signs
for any accents so that they are pro-
nounced correctly and recognised by the
system. For example, it is advisable to
enter “Nicolo Rebora” as “Nicolò Réb-
ora” to get the correct pronunciation.
❒When you add or amend names in the
phonebook, remember that some isolat-
ed upper-case letters can be read as ro-
man numerals (e.g. V can be read as five).
❒When you call people using voice
recognition, do not use shortened ver-
sions of the name or middle initials. N.B.
❒You only need to register your phone
once.
❒You can register up to five mobile
phones on the system, which can be
used one at a time.
❒To connect a mobile phone to
Blue&Me™that has already been reg-
istered, you always need to switch on
the phone's Bluetooth
®setting.
❒Before you transfer the contacts from
your mobile phone to the hands-free
system, make sure the name of each
person is unique and clearly recognis-
able so that the voice recognition sys-
tem works properly.
❒The system will copy only valid con-
tacts, i.e. those containing a name and
at least one phone number.
604_39_206 DOBLO BLUE GB 1ed 17-09-2009 16:55 Pagina 38

39
❒If you want to register your mobile phone
again, you must first cancel the old regis-
tration. During this operation, all the user
data registered on the system will be
deleted. To delete the old
registration, se-
lect USER DATA, DELETE USERS.
Delete the “Blue&Me” device from the
list of Bluetooth®devices on your mo-
bile phone, following the instructions in
your mobile phone manual.
❒If a phonebook is copied that contains
more than 1000 names, the system may
operate more slowly and the voice
recognition of the names in your
phonebook may be impaired.
❒If you accidentally cancel your registra-
tion, you will need to repeat the
process. MANAGING USER DATA
It is possible to amend the user data saved
on the hands-free system. In particular,
you can delete the data relating to the mo-
bile phones registered on the system,
delete the active phonebook at a given
moment or delete both at the same time.
In this way, the system is restored to its
original settings. It is also possible to trans-
fer the phonebook or individual contacts
from the mobile phone to the hands-free
system, if this has not been done during
the registration process. You can amend
the data used by the system by choosing
USER DATA.
?
To access the USER DATAmenu
manually, proceed as follows:
Activate the Main Menu by pressing
ß/MENUand select SETTINGS
by pressing SRC/OKor
ß/MENU.
Select USER DATAand then press
SRC/OKor
ß/MENU.
}
Or, with voice interaction:
Press
‘and say “Settings” and
then, after the message from the
system, say “User Data”.
In the USER DATAmenu, you
can perform the functions described
below.
604_39_206 DOBLO BLUE GB 1ed 17-09-2009 16:55 Pagina 39
