2009 DODGE CARAVAN Owners Manual

VEHICLE MODIFICATIONS/ALTERATIONS
WARNING!
Any modifications or alterations to this vehicle could
seriously affect its roadworthiness and safety and
may lead to an accident resulting in serious injury or
death.
INTRODUCTION 7
1
ProCarManuals.com

ProCarManuals.com

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
CONTENTS
A Word About Your Keys................. 12
▫Wireless Ignition Node (WIN)............. 12
Sentry KeyImmobilizer System............ 15
▫Replacement Keys..................... 16
Vehicle Security Alarm System — If Equipped . . 18
▫Rearming Of The System................ 18
Illuminated Entry System — If Equipped...... 20
Remote Keyless Entry (RKE) — If Equipped.... 21
▫Using The RKE Transmitter.............. 21Remote Starting System — If Equipped....... 28
▫How To Use Remote Start............... 28
Door Locks........................... 31
▫Manual Door Locks.................... 31
▫Power Door Locks — If Equipped.......... 33
Windows............................. 37
▫Power Vent Windows — If Equipped....... 37
▫Power Windows...................... 38
2
ProCarManuals.com

Sliding Side Door....................... 42
▫Power Sliding Side Door — If Equipped..... 43
▫Sliding Side Door Child Protection Lock..... 47
Liftgate.............................. 49
▫Power Liftgate — If Equipped............ 50
Storage Bin Safety Warning................ 53
▫Safety Warning....................... 53
Occupant Restraints..................... 55
▫Lap/Shoulder Belts.................... 56
▫Automatic Locking Retractors (ALR) Mode
— If Equipped........................ 62
▫Seat Belt Pretensioners.................. 62▫Enhanced Seat Belt Use Reminder System
(BeltAlert).......................... 63
▫Seat Belts And Pregnant Women........... 64
▫Seat Belt Extender..................... 64
▫Supplemental Restraint System (SRS) -
Airbag............................. 65
▫Airbag System Components.............. 66
▫Front Seat Airbag Features............... 66
▫Airbag Deployment Sensors And Controls.... 70
▫Event Data Recorder (EDR).............. 76
▫Integrated Child Booster Seat — If Equipped . . 78
▫Integrated Child Seat — If Equipped........ 80
▫Child Restraints....................... 81
10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
ProCarManuals.com

Rear Seat Delete Feature (Commercial Vehicles
Only) — If Equipped..................... 90
▫Restraining Infants And Small Children With
Seat Delete Feature (Commercial Vehicles
Only).............................. 91
Engine Break-In Recommendations.......... 93Safety Tips............................ 94
▫Safety Checks You Should Make Inside The
Vehicle............................. 94
▫Periodic Safety Checks You Should Make
Outside The Vehicle.................... 95
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11
2
ProCarManuals.com

A WORD ABOUT YOUR KEYS
Your vehicle uses a keyless ignition system. This system
consists of a Remote Keyless Entry (RKE) transmitter
with integrated ignition key and a Wireless Ignition
Node (WIN) with integral ignition switch. You can insert
the double-sided key into the ignition switch with either
side up.
Wireless Ignition Node (WIN)
The Wireless Ignition Node (WIN) operates similarly to
an ignition switch. It has four operating positions, three
with detents and one that is spring-loaded. The detent
positions are OFF, ACC, and ON. The START position is
a spring-loaded momentary contact position. When re-
leased from the START position, the switch automatically
returns to the ON position.
WIN Ignition Positions
1–OFF 3–ON
2 – ACC (ACCESSORY) 4 – START 12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
ProCarManuals.com

Integrated Ignition Key
The integrated ignition key operates the ignition switch.
It also contains the Remote Keyless Entry (RKE) trans-
mitter and a Valet Key, which stores in the rear of the RKE
transmitter.
The Valet Key allows for entry into the vehicle should the
battery in the vehicle or the RKE transmitter go dead. The
Valet Key is also for locking the glove box. You can keep
the Valet Key with you when valet parking.
To remove the Valet Key from the RKE transmitter, slide
the mechanical latch at the top of the RKE transmitter
sideways with your thumb and then pull the key out
with your other hand.NOTE:You can insert the double-sided Valet Key into
the lock cylinder with either side up.
Valet Key Removal
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13
2
ProCarManuals.com

Tip Start Feature
1. Do not press the accelerator pedal during this process.
2. Insert the integrated ignition key into the ignition
switch.
3. Turn the ignition switch to the START position and
release it as soon as the starter engages.
The starter motor will continue to run and will disengage
automatically when the engine begins running.
Ignition Key Removal
Place the shift lever in PARK. Turn the ignition key to the
OFF position and then remove the key.
NOTE:Power window switches will also remain active
for up to 90 seconds after the ignition switch has been
turned OFF, depending upon the accessory delay setting.
Opening the front door will cancel this feature.
WARNING!
NEVER leave children alone in a vehicle. Leaving
unattended children in a vehicle is dangerous for a
number of reasons. A child or others could be seri-
ously or fatally injured. Don’t leave the key in the
ignition. A child could operate power windows,
other controls, or move the vehicle
CAUTION!
An unlocked car is an invitation to thieves. Always
remove the key from the ignition and lock all doors
when leaving the vehicle unattended.
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
