2009 CHEVROLET CORVETTE Owners Manual

7. Pull the cable to release the tonneau cover. 8. Push forward on the front edge (A) of the
convertible top to allow the rear edge (B) of the
convertible top to be moved to its full-down position.
2-63

9. Then move the top rearward to its fully-stored
position.
10. After the top is stored, apply one even push on the
center of the front edge (A) of the convertible top to
assure that the top is fully retracted.
11. Close the tonneau cover (B) by pressing down on it
with a swift, rm motion.
Raising the Manual Convertible Top
1. Park on a level surface. Shift an automatic
transmission into P (Park) and set the parking brake.
Shift a manual transmission into N (Neutral) and set
the parking brake.
2. Lower both windows.
3. Make sure the ignition is off.
4. Tilt the driver’s seat forward and press the tonneau
cover release button, or use the manual release
cable if battery power has been lost. See Step 6
under “Lowering the Manual Convertible Top” earlier
in this section.
After pressing the release button, the driver’s
and passenger’s door glass should retract to
the full-down position, if they have not already
been lowered.
5. Lift the tonneau cover.
2-64

6. Pull the convertible top up by rmly gripping the
front edge (A) near the center and applying a
brisk upward and forward motion to get the top
in the full-up position.7. Lift the rear edge (B) of the convertible top to its
full-up position by rst raising the front edge (A).
8. Close the tonneau cover (C) by pushing it down
with a swift, rm motion.
9. Lower the rear edge (B) of the convertible top
by rst slightly pushing the front edge (A) of the
convertible top forward.
10. Push the front edge (A) of the convertible top down
from the outside of the vehicle, or pull the front
edge (A) of the convertible top down from the center
pull-down handle located in the inside of the vehicle.
2-65

11. Pull the top front latch handle down and turn it
counterclockwise to lock the convertible top.
Convertible Top (Power)
For care and cleaning of the convertible top see
Convertible Top on page 5-98under “Service and
Appearance Care”. High pressure car washes may
cause water to enter the vehicle.
To operate the power convertible top use the
following steps.
Notice:Leaving the convertible top down and
exposing the interior of your vehicle to outdoor
conditions may cause damage. Always close
the convertible top if leaving your vehicle outdoors.
Notice:Lowering the convertible top when there
are objects in the storage area could damage
it or break the glass rear window. Always verify that
no objects are in the storage area before lowering
the convertible top.
Notice:Lowering the top if it is damp, wet, or dirty
can cause stains, mildew, and damage to the inside
of your vehicle. Dry off the top before lowering it.
2-66

Notice:If you lower the top on your vehicle in cold
weather (0°F/-18°C or lower), you may damage top
components. Do not lower the top in cold weather.
Notice:If you raise or lower the convertible top
while the vehicle is in motion, you could damage the
top or the top mechanism. The repairs would not be
covered by your warranty. Always put an automatic
transmission in P (Park) or a manual transmission
in N (Neutral) before raising or lowering the
convertible top.
Lowering the Power Convertible Top
1. Park on a level surface. Start the engine. Shift an
automatic transmission into P (Park) and set the
parking brake. Shift a manual transmission
into N (Neutral), and set the parking brake.
2. Make sure the trunk is closed and the rear trunk
partition in the rear storage area is in the fastened
upright position, and that no objects are forward
of the divider. See “Rear Trunk Partition” under
Rear Storage Area on page 2-52.3. Release the convertible top front latch, located
above the inside rearview mirror, by pulling and
turning it clockwise toward the driver’s door.
Push upward on the front edge. The windows
will automatically lower.
2-67

4. Push and hold the
bottom of the power
convertible top button,
located to the left of the
steering wheel, on the
instrument panel.
The windows will automatically lower and the convertible
top will lower into the rear of the vehicle. A chime will
sound when the convertible top has lowered completely.
If the radio is on the sound may be muted for a brief
time due to a new audio system equalization being
loaded.
If the convertible top is operated multiple times,
the engine should be running to prevent drain on the
vehicle’s battery. Under certain conditions, the Driver
Information Center (DIC) may display a message
regarding the power convertible top. SeeDIC Warnings
and Messages on page 3-54for more information.Raising the Power Convertible Top
Notice:If you raise or lower the convertible top
while the vehicle is in motion, you could damage
the top or the top mechanism. The repairs would
not be covered by your warranty. Always put
an automatic transmission in P (Park) or a manual
transmission in N (Neutral) before raising or
lowering the convertible top.
1. Park on a level surface. Start the engine. Shift
an automatic transmission into P (Park) and set
the parking brake. Shift a manual transmission
into N (Neutral) and set the parking brake.
2. Make sure the trunk lid is closed and the rear trunk
partition in the rear storage area is in the fastened
upright position, and that no objects are forward
of the divider. See “Rear Trunk Partition” under
Rear Storage Area on page 2-52.
3. Push and hold the top of the power convertible top
button. The top will raise and the windows will lower
if they were in the raised position. A chime will
sound when the top is raised completely.
4. After the convertible top is completely raised,
release the power convertible top button.
5. Pull the convertible front top latch down and turn it
counterclockwise to lock the convertible top.
2-68

If the radio is on the sound may be muted for a brief
time due to a new audio system equalization being
loaded.
If the vehicle has lost power, the convertible top can still
be raised by releasing pressure on the hydraulic pump,
located under the passenger’s side of the tonneau cover,
by using the following steps. The carpet liner on the
passenger’s side must be pulled back to access the
hydraulic pump.
Manual operation of the power convertible top cannot
be attempted for ve minutes from the last time the
convertible top button was pressed if the top is notcompletely stowed, with the top down and the tonneau
latched, or closed, with the front top latch locked in place,
at the time the convertible top button was released.
1. Open the tonneau cover by pulling the emergency
release cable.
The tonneau cover emergency release cable is
located behind the passenger’s seat head restraint,
on the underside forward edge of the tonneau cover.
Also, seeHatch on page 2-13for information on the
emergency trunk release handle.
2-69

Be careful when opening the tonneau cover by hand.
If the tonneau cover is opened quickly, damage can
occur to the hinging mechanism, which can prevent
proper operation of the convertible top.
2. Locate the pressure release bolt on the front side of
the hydraulic pump.3. Use the wrench, located in the console, and
turn the pressure release bolt counterclockwise
one revolution, to relieve pressure to the hydraulic
pump. This will allow you to manually raise the
convertible top.
4. Then follow the steps under raising the manual
convertible top. See “Convertible Top (Manual)”
underConvertible Top (Manual) on page 2-59
orConvertible Top (Power) on page 2-66
When power is restored to the vehicle, the hydraulic bolt
must be tightened, by turning it clockwise. The power
convertible top button can then be used to lower or raise
the convertible top.
If the power convertible top is operated multiple times,
the engine should be running to prevent drain on the
vehicle’s battery. Under certain conditions, the Driver
Information Center (DIC) may display a message
regarding the power top. SeeDIC Warnings and
Messages on page 3-54for more information.
If the battery has been disconnected, the power
windows must be initialized for the power top to operate.
SeePower Windows on page 2-17for more information.
2-70
