2008 TOYOTA PRIUS Owners Manual

329
3
Interior features
PRIUS_U_(L/O_0802)
3-7. Other interior features
Sun visors
Forward position: Flip down.
Side position: Flip down,
unhook, and swing to the
side.
ITY37P001

330
3-7. Other interior features
PRIUS_U_(L/O_0802)
Vanity mirror
Slide the cover.ON: The light turns on when the cover is
opened.
OFF: Turns the light off.

331
3-7. Other interior features
3
Interior features
PRIUS_U_(L/O_0802)
Clock
■The clock is displayed when
The “POWER” switch is in ACCESSORY or ON mode.
■ When the 12 volt battery is disconnected
The time display will automatically be set to 1:00.
■ When the instrument panel lights ar e turned on the brightness of the
time indicator will be reduced.
Adjusts the hour
Adjusts the minutes.
ITY37P003

332
3-7. Other interior features
PRIUS_U_(L/O_0802)
Power outlet
■The power outlet can be used when
The “POWER” switch is in ACCESSORY or ON mode.
The power outlet can be used for 12V accessories that run on less
than 10A.
Instrument panel
Rear console box

333
3-7. Other interior features
3
Interior features
PRIUS_U_(L/O_0802)
NOTICE
■
To avoid damaging the power outlet
Close the power outlet lid when not in use.
Foreign objects or liquids that enter the power outlet may cause a short cir-
cuit.
■ To prevent the fuse from being blown
Do not use an accessory that uses more than 12V/10A.
■ To prevent 12 volt battery discharge
Do not use the power outlet longer than necessary when the engine is not
running.

334
3-7. Other interior features
PRIUS_U_(L/O_0802)
Armrest
NOTICE
■To prevent damage to the armrest
Do not place too much strain on the armrest.
Pull the armrest down for use.
ITY37P006

335
3-7. Other interior features
3
Interior features
PRIUS_U_(L/O_0802)
Floor mats
CAUTION
■When inserting the floor mat
Observe the following precautions.
Failure to do so may result in the floor mat slipping and interfering with the
movement of the pedals during driving, resulting in an accident.
● Make sure the floor mat is properly placed on the vehicle carpet and the
correct side faces upward.
● Do not place floor mats on top of existing mats.
Securely place a mat that matches the size of the space on the car-
pet.
Secure the floor mat using the
hooks provided.

336
3-7. Other interior features
PRIUS_U_(L/O_0802)
Luggage compartment features
■Cargo hooks
Cargo hooks are provided for
securing loose items.
■ Auxiliary box
Turn the knob to the
“UNLOCK” position and open
the lid.
Hold the lid open by inserting
the support rod into the slot.
ITY37P008
LOCK
UNLOCK
LOCK
UNLOCK
ITY37P009
STEP1
ITY37P010
STEP2
