2008 PONTIAC GRAND PRIX display

RIGHT FRONT TURN LAMP OUT
This message displays when the vehicle’s right front
turn signal needs to be replaced. SeeFront Turn Signal,
Parking and Fog Lamps on page 5-57for bulb
replacement procedures.
This message displays only while the ignition is in
ON/RUN. A chime sounds for two seconds while this
message is displayed. Press the set/reset button
to acknowledge this message and to clear it from
the screen.
This message continues to display if it has not
been acknowledged when the engine is turned off.
It also re-displays for three seconds if the message
has been acknowledged, but the condition still exists
when the engine is turned off.
If the condition still exists, the message re-appears
when the engine is turned on.
RIGHT REAR TURN LAMP OUT
This message displays when the vehicle’s right rear
turn signal needs to be replaced. SeeTaillamps,
Turn Signal, and Stoplamps on page 5-58for bulb
replacement procedures.
This message displays only while the ignition is in
ON/RUN. A chime sounds for two seconds while this
message is displayed. Press the set/reset button
to acknowledge this message and to clear it from
the screen.
This message continues to display if it has not
been acknowledged when the engine is turned off.
It also re-displays for three seconds if the message
has been acknowledged, but the condition still exists
when the engine is turned off.
If the condition still exists, the message re-appears
when the engine is turned on.
3-80

SERVICE ABS SYSTEM
This symbol comes on
with this message.
If the vehicle has the Antilock Brake System (ABS), this
message displays when the vehicle’s brakes are not
functioning properly. Have the brake system serviced by
your dealer/retailer as soon as possible.
This message displays only while the ignition is in
ON/RUN. A chime sounds for two seconds while this
message is displayed. Press the set/reset button
to acknowledge this message and to clear it from
the screen.
This message continues to display if it has not
been acknowledged when the engine is turned off.
It also re-displays for three seconds if the message
has been acknowledged, but the condition still exists
when the engine is turned off.
If the condition still exists, the message re-appears
when the engine is turned on.
SERVICE BRAKE SYSTEM
This symbol comes on
with this message.
This message displays when the vehicle’s brakes are
not functioning properly. Have the brake system serviced
by your dealer/retailer as soon as possible.
This message displays only while the ignition is in
ON/RUN. A chime sounds for two seconds while this
message is displayed. Press the set/reset button
to acknowledge this message and to clear it from
the screen.
This message continues to display if it has not
been acknowledged when the engine is turned off.
It also re-displays for three seconds if the message
has been acknowledged, but the condition still exists
when the engine is turned off.
If the condition still exists, the message re-appears
when the engine is turned on.
3-81

SERVICE BRAKE APPLY SENSOR
This message displays when the brake apply sensor is
not functioning properly. The vehicle still has brakes
when this warning message displays, but you should
have the vehicle serviced by your dealer/retailer as soon
as possible.
This message displays only while the ignition is in
ON/RUN. A chime sounds for two seconds while this
message is displayed. Press the set/reset button
to acknowledge this message and to clear it from
the screen.
This message continues to display if it has not
been acknowledged when the engine is turned off.
It also re-displays for three seconds if the message
has been acknowledged, but the condition still exists
when the engine is turned off.
If the condition still exists, the message re-appears
when the engine is turned on.
SERVICE PARK LAMPS
This message displays if one of the vehicle’s parking
lamps needs to be replaced. SeeFront Turn Signal,
Parking and Fog Lamps on page 5-57for bulb
replacement procedures.
This message displays only while the ignition is in
ON/RUN. A chime sounds for two seconds while this
message is displayed. Press the set/reset button
to acknowledge this message and to clear it from
the screen.
This message continues to display if it has not
been acknowledged when the engine is turned off.
It also re-displays for three seconds if the message
has been acknowledged, but the condition still exists
when the engine is turned off.
If the condition still exists, the message re-appears
when the engine is turned on.
3-82

SERVICE STABILITY SYSTEM
This symbol comes on
with this message.
If the vehicle has the StabiliTrak
®Plus system, this
message displays when it is not functioning properly.
A warning light also appears on the instrument
panel cluster. SeeTraction Control System (TCS)
Warning Light on page 3-47. SeeStabiliTrak
®Plus
System on page 4-8for more information. Have
the StabiliTrak
®Plus system serviced by your
dealer/retailer as soon as possible.
This message displays only while the ignition is in
ON/RUN. A chime sounds for two seconds while this
message is displayed. Press the set/reset button
to acknowledge this message and to clear it from
the screen.
This message continues to display if it has not
been acknowledged when the engine is turned off.
It also re-displays for three seconds if the message
has been acknowledged, but the condition still exists
when the engine is turned off.If the condition still exists, the message re-appears
when the engine is turned on.
SERVICE THEFT SYSTEM
This message displays if there is a problem with
the theft-deterrent system programmed in the key.
A fault has been detected in the system which means
that the system is disabled and it is not protecting
the vehicle. The vehicle usually restarts; however, you
may want to take the vehicle to your dealer/retailer
before turning off the engine. SeeKeys on page 2-2
for information on the PASS-Key III system.
This message displays only while the ignition is in
ON/RUN. A chime sounds for two seconds while
this message is displayed. Press the set/reset button
to acknowledge this message and to clear it from
the screen.
This message continues to display if it has not
been acknowledged when the engine is turned off.
It also re-displays for three seconds if the message
has been acknowledged, but the condition still exists
when the engine is turned off.
If the condition still exists, the message re-appears
when the engine is turned on.
3-83

SERVICE TIRE MONITOR SYSTEM
This message displays if a part on the Tire Pressure
Monitor System (TPMS) is not working properly. The tire
pressure light also ashes and then remains on during
the same ignition cycle. SeeTire Pressure Light on
page 3-49. Several conditions may cause this message
to appear. SeeTire Pressure Monitor Operation on
page 5-72for more information. If the warning comes on
and stays on, there may be a problem with the TPMS.
See your dealer/retailer.
This message displays only while the ignition is in
ON/RUN. Press the set/reset button to acknowledge
this message and to clear it from the screen.
This message continues to display if it has not
been acknowledged when the engine is turned off.
It also re-displays for three seconds if the message
has been acknowledged, but the condition still exists
when the engine is turned off.
If the condition still exists, the message re-appears
when the engine is turned on.
SERVICE TRACTION SYSTEM
This symbol comes on
with this message.
If the vehicle has the traction system, this message
displays when the system is not functioning properly.
A warning light also appears on the instrument panel
cluster. SeeTraction Control System (TCS) Warning
Light on page 3-47. SeeTraction Control System (TCS)
on page 4-6orEnhanced Traction System (ETS) on
page 4-7for more information. Have the system serviced
by your dealer/retailer as soon as possible.
This message displays only while the ignition is in
ON/RUN. A chime sounds for two seconds while this
message is displayed. Press the set/reset button
to acknowledge this message and to clear it from
the screen.
This message continues to display if it has not
been acknowledged when the engine is turned off.
It also re-displays for three seconds if the message
has been acknowledged, but the condition still exists
when the engine is turned off.
If the condition still exists, the message re-appears
when the engine is turned on.
3-84

SERVICE VARIABLE EFFORT
STEERING
This symbol comes on
with this message.
If the vehicle has the variable effort steering system,
this message displays if this system is not functioning
properly. SeeSteering on page 4-10for more
information. Have the system serviced by your
dealer/retailer as soon as possible.
This message displays only while the ignition is in
ON/RUN. A chime sounds for two seconds while this
message is displayed. Press the set/reset button
to acknowledge this message and to clear it from
the screen.
This message continues to display if it has not
been acknowledged when the engine is turned off.
It also re-displays for three seconds if the message
has been acknowledged, but the condition still exists
when the engine is turned off.
If the condition still exists, the message re-appears
when the engine is turned on.
SERVICE VEHICLE SOON
This symbol comes on
with this message.
This message displays when a non-emissions related
malfunction occurs. Have the vehicle serviced by
your dealer/retailer as soon as possible.
This message displays only while the ignition is in
ON/RUN. A chime sounds for two seconds while this
message is displayed. Press the set/reset button
to acknowledge this message and to clear it from
the screen.
This message continues to display if it has not
been acknowledged when the engine is turned off.
It also re-displays for three seconds if the message
has been acknowledged, but the condition still exists
when the engine is turned off.
If the condition still exists, the message re-appears
when the engine is turned on.
3-85

STABILITY CONTROL ACTIVE
This symbol comes on
with this message.
If the vehicle has the StabiliTrak
®Plus system, this
message displays when the system is engaged
and actively assisting the driver with directional control
of the vehicle. Slippery road conditions may exist
when this warning message is displayed, so driving
should be adjusted accordingly. STABILITY CONTROL
ACTIVE also appears in the Head-Up Display (HUD),
if your vehicle has this feature.
This message displays only while the ignition is in
ON/RUN. This message stays on until road conditions
change and StabiliTrak
®Plus is not active.
This message cannot be acknowledged and cleared
from the screen.
STABILITY CONTROL OFF
This symbol comes on
with this message.
If the vehicle has the StabiliTrak
®Plus system, this
message displays when the system turns off. This
message displays only while the ignition is in ON/RUN.
A chime sounds once and the message stays on for
three seconds and then disappears. A warning
light indicating that this system is deactivated also
appears on the instrument panel cluster. SeeTraction
Control System (TCS) Warning Light on page 3-47.
When the StabiliTrak
®Plus system is off, the system will
not be engaged and will not actively assist the driver
with directional control of the vehicle. SeeStabiliTrak
®
Plus System on page 4-8.
3-86

Any of the following conditions may cause the
StabiliTrak®Plus system to turn off:
The StabiliTrak®Plus system on the GXP
option is manually turned off. SeeStabiliTrak®
Plus System on page 4-8for more information.
The battery is low.
There is a StabiliTrak®Plus system failure.
See your dealer/retailer for service.
STARTING DISABLED DUE TO
ELECTRONIC THROTTLE CONTROL
This message displays when there is a malfunction
with the electronic throttle control which prevents
the vehicle from starting. Have the vehicle serviced
by your dealer/retailer.
This message only appears while the ignition is in
ON/RUN, and will not disappear until the problem
is resolved. A chime sounds for two seconds.
This message cannot be acknowledged.
STARTING DISABLED DUE TO
THEFT SYSTEM
This message displays when the system detects a
malfunction in the content theft-deterrent system and
prevents the vehicle from starting.This message only appears while the ignition is in
ON/RUN, and will not disappear until the problem
is resolved. A chime sounds for two seconds.
This message cannot be acknowledged.
TRACTION CONTROL ACTIVE
This symbol comes on
with this message.
If the vehicle has the traction system, this message
displays when the system is on. TRACTION CONTROL
ACTIVE also appears in the Head-Up Display (HUD),
if your vehicle has this feature.
This message only displays while the ignition is in
ON/RUN and will not disappear until driving conditions
change and the system is no longer active.
This message cannot be acknowledged or cleared
from the screen.
3-87
