Page 105 of 123
99
PRACTICAL INFORMATION
-
Front fog lamps
H1 55W
P r e s s u n d e r t h e a c c e s s l a p t o r e-
lease it.
O p e n t h e l a p .
Turn the cover to remove it.
Disconnect the bulb.
Press the two ends of the securing
clip to release the bulb. Rear fog lamp P21W
Unclip the lamp and release the as-
sembly.
Turn the pin connector a quarter turn
and remove it.
Change the bulb.
Number plate lights
W5W
Insert a thin screwdriver into one of the
outer holes of the transparent cover.
Push it outwards to unclip it.
Remove the transparent cover.
Change the faulty bulb.
Page 106 of 123
PRACTICAL INFORMATION
1 0 0 -
CHANGING A FUSE
The fuse boxes are located under
the fascia and in the engine compart-
ment.
Correct Incorrect
Pliers A
Fascia fuse box
Unscrew the catch a quarter turn us-
ing a coin then remove the cover to
gain access to the fuses.
The spare fuses and the pliers
A are
secured on the inside of the fascia
fuse box cover. R e m o v i n g a n d i t t i n g a f u s e
Before changing a fuse, the cause of the fault must be foun
d and remedied. The
fuse numbers are indicated on the fuse box.
Use the pliers A.
Always replace a faulty fuse with a fuse of the same rating .
Page 107 of 123
PRACTICAL INFORMATION
1 0 0 -
CHANGING A FUSE
The fuse boxes are located under
the fascia and in the engine compart-
ment.
Correct Incorrect
Pliers A
Fascia fuse box
Unscrew the catch a quarter turn us-
ing a coin then remove the cover to
gain access to the fuses.
The spare fuses and the pliers
A are
secured on the inside of the fascia
fuse box cover. R e m o v i n g a n d i t t i n g a f u s e
Before changing a fuse, the cause of the fault must be foun
d and remedied. The
fuse numbers are indicated on the fuse box.
Use the pliers A.
Always replace a faulty fuse with a fuse of the same rating .
Page 108 of 123
1 0 1
PRACTICAL INFORMATION
-
Fuse N° Rating Functions
1 15A Heated seat - Alarm
4 2 0 AMultifunction display - Boot lighting - Audio equipment - Stee ring wheel controls - Trailer
5 15A Automatic gearbox diagnostics
6 1 0 A C o o l a n t l e v e l - A u t o m a t i c g e a r b o x - A u d i o e q u i p m e n t - S t e e r i n g w h e e l a n g l e s e n s o r ( E S P )
7 15A D r i v i n g s c h o o l a c c e s s o r y - A l a r m i t t e d a s a n a c c e s s o r y
9 3 0 A Rear electric windows
1 0 4 0 A Rear screen and mirror demisting
11 15A Rear windscreen wiper
1 2 3 0 A Front electric windows - Sunroof
14 1 0 AEngine fuse box - Air bags - Steering wheel controls - Rain sensor
15 15A Instrument panel - Multifunction display - Air condition ing - Audio equipment
1 6 3 0 A L o c k i n g / u n l o c k i n g c o n t r o l s f o r d o o r s , b o n n e t a n d b o o t
2 0 1 0 A Right-hand brake light
2 1 15A Left-hand brake light - 3rd brake light
2 2 2 0 A Front courtesy light - Map reading light - Glove box lighting - Lighter
S1 Shunt PARC shunt
Page 109 of 123
PRACTICAL INFORMATION
1 0 2 -
or The electrical circuit of
your vehicle is designed
to operate with standard
or optional equipment.
Before installing other electri-
cal equipment or accessories in
your vehicle, consult a PEUGEOT
dealer.
Some electrical accessories or the
w a y i n w h i c h t h e y a r e i t t e d m a y
have an adverse effect on the op-
e r a t i o n o f y o u r v e h i c l e ( i t s e l e c -
tronic control circuits, the audio
circuit and the electrical charging
circuit).
PEUGEOT declines any respon-
sibility for expenses incurred
through the repair of your vehicle
or for any malfunctions resulting
from the installation of auxiliary
accessories, not supplied and not
recommended by PEUGEOT and
not installed in accordance with
PEUGEOT's instructions, in par-
ticular for any equipment the pow-
er consumption of which exceeds
1 0 m i l l i a m p s .
Fuse N° Rating Functions
1 * 2 0 AFan unit
2 * 6 0 A A B S / E S P
3 * 3 0 A A B S / E S P
4 * 7 0 ABuilt-in systems interface supply
5 * 7 0 ABuilt-in systems interface supply
6 * - Not used
7 * 3 0 A Ignition switch supply
8 * 2 0 A A u d i o e q u i p m e n t a m p l i i e r Engine compartment fuse box
T o g a i n a c c e s s t o t h e b o x i n t h e e n g i n e c o m p a r t m e n t ( n e x t t o t h e b a t t e r y ) , u n c l i p
the cover.
After carrying out work, close the cover very carefully.
* The maxi fuses provide additional protection for the electr ical systems. Any
work on these fuses must be carried out by a PEUGEOT dealer.
Page 110 of 123
1 0 3
PRACTICAL INFORMATION
-
Fuse N° Rating Functions
1 1 0 A P r e - h e a t u n i t ( d i e s e l ) - W a t e r i n d i e s e l s e n s o r - R e v e r s i n g l i g h t s s w
i t c h - S p e e d s e n s o r -
A i r l o w s e n s o r ( d i e s e l )
2 15A Canister solenoid valve - Fuel pump
3 1 0 A A B S / E S P e n g i n e c o n t r o l u n i t - E S P s t o p s w i t c h
4 1 0 A Automatic gearbox control unit - Engine control unit
5 - Not used
6 15A Front fog lamps
7 2 0 AHeadlamp wash pump
8 2 0 A Fan assembly relay - Engine control unit - Diesel injection pump
- Diesel high pressure
regulator - Engine management solenoid valve
9 15A Left-hand dipped beam
1 0 15A Right-hand dipped beam
11 1 0 ALeft-hand main beam
1 2 15A Right-hand main beam
13 15A Horn
14 1 0 A Front and rear windscreen wash pumps
15 3 0 A Throttle housing heater - Diesel injection pump - Oxygen senso
r - Engine control unit -
A i r l o w s e n s o r - I g n i t i o n c o i l - E n g i n e m a n a g e m e n t s o l e n o i d v a l v e - D i e s e l h e a t e r -
Injectors
1 6 3 0 A Air pump relay
17 3 0 A High and low speed windscreen wiper
1 8 4 0 A Air conditioning fan
Page 111 of 123
PRACTICAL INFORMATION
1 0 4 -
BATTERY
To charge the battery using a bat-
tery charger:
- Disconnect the battery,
- Follow the instructions for use
given by the battery charger
manufacturer,
- Reconnect starting with the n e g a t i v e ( - ) t e r m i n a l ,
- Check that the terminals and connectors are clean. If they are
c o v e r e d w i t h s u l p h a t e ( w h i t e o r
greenish deposit), disconnect
them and clean them. - W a i t f o r 2 m i n u t e s
after switching off
the ignition before
disconnecting the
battery.
- Never disconnect a terminal when the engine is running.
- Never charge a battery w i t h o u t i r s t d i s c o n n e c t i n g t h e
terminals.
- Close the windows and the roof before disconnecting the
battery.
- After every reconnection of the battery, switch on the
ignition and wait 1 minute
before starting to allow the
electronic systems to be
i n i t i a l i s e d . I f s l i g h t d i f i c u l t i e s
are experienced after this,
please consult a PEUGEOT
dealer.
It is advisable to disconnect the
battery if the vehicle is not to be
used for a period of more than
one month.
ECONOMY MODE
FUNCTION
After the engine has stopped, certain
f u n c t i o n s ( w i n d s c r e e n w i p e r , e l e c
-
tric windows, courtesy lights, audio
equipment, etc.) can only be used for
a combined duration of approximately
thirty minutes, to prevent discharging
the battery.
Once the thirty minutes are over, a
switching to economy mode mes-
sage appears on the multi-function
display and the active functions are
put on standby.
These functions are reactivated au-
tomatically next time the vehicle is
driven.
In order to resume the use of these
functions immediately, the engine
must be started and left to run for a
few minutes.
The time available to you will then
be double the duration for which the
engine is left running. However,
this period will always be between
i v e a n d t h i r t y m i n u t e s .
To start the vehicle from another
battery:
- Connect the red cable to the
p o s i t i v e ( + ) t e r m i n a l s o f t h e
two batteries,
- Connect one end of the green o r b l a c k c a b l e t o t h e n e g a t i v e ( - )
terminal of the slave battery,
- Connect the other end of the green or black cable to an
earth point on the broken down
vehicle, as far as possible from
t h e b a t t e r y ( f o r e x a m p l e , r i g h t -
hand engine mounting),
- Operate the starter, let the engine run,
- Wait for the engine to return to idle, then disconnect the cables.
A l a t b a t t e r y p r e v e n t s t h e
engine from starting.
Page 112 of 123
1 0 5
PRACTICAL INFORMATION
-
FITTING SPEAKERS
T h e f a c t o r y - i t t e d e q u i p m e n t a l l o w s
t h e i t t i n g o f :
- 1 6 5 m m d i a m e t e r s p e a k e r s i n
the front doors,
- 1 3 0 m m d i a m e t e r s p e a k e r s i n the rear doors,
- 2 2 . 5 m m d i a m e t e r t w e e t e r s i n the mirror trims. Making the connections
A1 : -
A 2 : -
A3 : -
A4 : -
A5 : -
A 6 : ( + v e ) I g n i t i o n p o s i t i v e
A 7 : ( + v e ) P e r m a n e n t
A 8 : E a r t h
B 1 : ( + ) R e a r r i g h t s p e a k e r
B 2 : ( - ) R e a r r i g h t s p e a k e r
B 3 : ( + ) F r o n t r i g h t s p e a k e r a n d
tweeter
B 4 : ( - ) F r o n t r i g h t s p e a k e r a n d tweeter
B 5 : ( + ) F r o n t l e f t s p e a k e r a n d t w e e t e r
B 6 : ( - ) F r o n t l e f t s p e a k e r a n d t w e e t e r
B 7 : ( + ) R e a r l e f t s p e a k e r
B 8 : ( - ) R e a r l e f t s p e a k e r
Consult a PEUGEOT dealer
before installing audio equip-
ment or speakers in your
vehicle.
FITTING AUDIO EQUIPMENT
Your vehicle is equipped with certain
f a c t o r y - i t t e d a u d i o e q u i p m e n t :
- roof aerial,
- coaxial aerial cable,
- basic interference suppression,
- supply to front speakers,
- supply to rear speakers,
- t w o 8 - w a y c o n n e c t o r s .
