Page 73 of 123
69
VISIBILITY
-
M a n u a l i n t e r i o r m i r r o r
The interior mirror has two positions:
- day (normal),
- night (anti-dazzle).
To change from one to the other,
push or pull the lever on the lower
edge of the mirror. M a n u a l e x t e r i o r m i r r o r s
Move the lever in all four directions
to adjust.
When the vehicle is parked, the ex-
terior mirrors can be folded back
manually.
E l e c t r i c e x t e r i o r
m i r r o r s
Turn knob 1 to the right or to the left
to select the corresponding mirror.
Move knob 1 in all four directions to
adjust.
Objects observed in the
driver's and passenger's
mirrors are in reality closer
than they appear. This must be taken into account to
judge correctly the distance of vehi-
cles approaching from behind.
F o l d - b a c k e l e c t r i c
m i r r o r s
With the ignition on, turn knob 1 to
position A.
Page 74 of 123
LAYOUT
70 -
HEADLAMP ADJUSTMENT
Depending on the load in your vehi-
cle, it is recommended that the head-
lamp beam is adjusted.
0. 1 or 2 people in the front
seats.
-. 3 people.
1. 5 people.
2. 5 people + maximum
authorised load.
3. Driver + maximum
authorised load.
Initial setting is position 0.
STEERING WHEEL HEIGHT
ADJUSTMENT
When stationary, lower the handle to
unlock the steering wheel.
Adjust to the desired height and
lift the handle to lock the steering
wheel.
HORN
Press one of the spokes of
the steering wheel.
Page 75 of 123
71
LAYOUT
-
COURTESY LIGHTS
Map-reading light (button B)
With the key in the accessories or ig-
nition on position, turn button B to the
left or to the right.
AREAS FOR TOLL CARDS/
CAR PARK TICKETS
The athermic windscreen has two
n o n - r e l e c t i v e z o n e s l o c a t e d e i t h e r
side of the base of the interior mirror.
T h e y a r e i n t e n d e d f o r a f i x i n g t o l l
cards and/or car park tickets.
SUN VISOR
T h e s u n v i s o r s a r e i t t e d w i t h a v a n i t y
m i r r o r , w i t h a c o n c e a l i n g l a p o n t h e
driver's side.
Permanently off.
Permanently on when the
key is in the accessories po-
sition or with the ignition on.
Front courtesy light (button A)
In this position, it comes on
for about 30 seconds:
- on unlocking the vehicle,
- when opening a door,
- when opening the tailgate and the rear screen (206 SW),
- on switching off the ignition.
It switches off on locking the vehicle.
T h e c o u r t e s y l i g h t l a s h e s w h i l e d r i v -
ing if a door or the boot is not closed
correctly.
Page 76 of 123
LAYOUT
72 -
GLOVE BOX
To open the glove box, lift the handle.
The light comes on when the cover
is opened.
1. Handbook pack storage.
2. Can holder.
3. Pen holder.
4. Spectacles storage.
5. Map storage.
6. Coin storage.
FRONT ASHTRAY
To empty, close the cover.
Pull the lug and release the ashtray
upwards.
LIGHTER
Press and wait a few moments until it
springs out automatically.
It is supplied with power with the igni-
tion key in the accessories position
(1st notch).
Page 77 of 123
73
LAYOUT
-
Luggage retaining net
U s e t h e s t o w i n g r i n g s o n t h e b o o t l o o r
and on the back of the rear seat to
hook on your luggage retaining net.
There are several options for storing
the shelf:
- either behind the front seats,
- or behind the rear seat using the luggage retaining net,
- o r l a t i n t h e b o o t .
Rear parcel shelf
To remove the shelf:
- unhook the two strings
1,
- slightly raise the shelf, then remove it.
BOOT LAYOUT
Retaining strap
A strap secured to the side of the
boot enables you to secure various
o b j e c t s ( c a n s , i r s t a i d k i t , e t c . ) .
Page 78 of 123
DRIVING
74 -
'PORSCHE TIPTRONIC
SYSTEM' AUTOMATIC
GEARBOX
The four speed automatic gearbox
offers a choice between the comfort
of integral automatic operation , en-
hanced by a sport and a snow pro-
gramme, or manual gear changing .Gear selection gate
F
Move the lever in the gate to
select a position.
The indicator light corresponding
to the position selected appears
on the instrument panel screen.
P ark: to immobilise the vehicle and
to start the engine , with the hand-
brake on or off.
R everse: to reverse (select this po-
sition with the vehicle stationary, en-
gine at idle).
N eutral: to start the engine and to
park , with the handbrake on.
If position N is inadvertently engaged
while driving, allow the engine to re-
turn to idle before engaging position
D to accelerate.
D rive: for driving in automatic mode.
M anual: for selection of gears.
S : sport programme.
T : snow programme. Moving Off
With the engine running, to move off
from position
P:
F it is essential to press the
brake pedal to exit position P ,
F select position R, D or M, then
gradually release the pressure
on the brake pedal; the vehicle
moves off immediately.
You can also move off from position N:
F release the handbrake, with your
foot on the brake,
F select position R, D or M, then
gradually release the pressure
on the brake pedal; the vehicle
moves off immediately.
Starting the engine
F with the handbrake on, select
position P or N in the gate,
F turn the ignition key to the Start
position. WARNING
When the engine is at idle, brakes not
applied, if position
R, D or M is se-
lected, the vehicle moves even with-
out the accelerator being pressed.
For this reason, do not leave chil-
dren unsupervised inside the ve-
hicle, with the engine running.
When maintenance operations need
to be carried out with the engine run-
ning, apply the handbrake and select
position P.
Page 79 of 123
75
DRIVING
-
Automatic operation
Automatic changing of the four
gears:
F select position D in the gate.
The gearbox always selects the most
suitable gear according to the follow-
ing parameters:
- t h e r o a d p r o i l e ,
- the vehicle load.
The gearbox is then operating in
auto-adaptive mode, without any ac-
tion on your part. If you take your foot off the accel-
erator suddenly, the gearbox will not
change to a higher gear for reasons
of safety.
Manual operation
Manual
changing of the four gears :
F select position M in the gate,
F push the lever to the + sign to
change to a higher gear,
F pull the lever to the - sign to
change to a lower gear.
You can change from position D
(driving in automatic mode) to posi-
tion M (driving in manual mode) at
any time.
WARNING
Never select position N when the ve-
hicle is moving.
Never select positions P or R unless
the vehicle is stationary.
Never change between positions to op-
timise braking on a slippery surface.
Notes
For immediate maximum accelera-
tion without touching the gear lever,
press the accelerator pedal down as
far as it will go (kickdown). The gear-
box will automatically change down
or maintain the gear selected until
maximum engine speed is reached.
When the brake is applied, the gear-
box will automatically change down
i n o r d e r t o p r o v i d e e f i c i e n t e n g i n e
braking. Sport and snow programmes
In addition to the auto-adaptive pro-
gramme, there are two special pro-
grammes.
The programme is displayed on the
instrument panel screen.
Sport programme
F
Press button S once the engine
has been started.
The gearbox automatically favours
sporty driving and more dynamic ac-
celeration.
Snow programme
This programme improves starting
and drive when traction is poor.
F Press button T once the engine
has been started.
The gearbox adapts to driving on
slippery roads.
Note: you can return to the auto-
adaptive programme at any time.
F Press button S or T again to
switch off the programme you
are in. Notes
It is only possible to change from one
gear to another if the vehicle speed
and engine speed permit. If they do
not, the vehicle will operate tempo-
rarily in automatic mode.
When the vehicle is stationary or
moving very slowly, the gearbox au-
tomatically selects gear
M1.
Programmes S (sport) and T (snow)
do not operate in manual mode.
Page 80 of 123
DRIVING
76 -
HANDBRAKE
Operating abnormality
Any operating abnormality is indi-
cated by an audible signal, accom-
panied by the message 'Automatic
gear fault' on the multi-function dis-
play, by a "-" a n d l a s h i n g o f t h e
Sport and Snow warning lights on the
instrument panel display.
In this situation the gearbox oper-
ates in downgrade mode (locked in
3rd gear). You may feel a substan-
tial knock when changing from P to
R and from N to R (this will not cause
any damage to the gearbox).
Do not exceed 60 mph (100 km/h),
respecting local speed limits.
Consult a PEUGEOT dealer.
I f t h e b a t t e r y i s l a t a n d t h e
lever is in position P, it will
be impossible to change
to another position.
In particular, do not force the lever
or there is a risk the gearbox may
be damaged. When the vehicle is be-
ing driven, illumination of
this warning light and of the
STOP
warning light, accom-
panied by an audible signal
and a message on the multifunction
display, indicates that the handbrake
is still on or has not been properly
released.
When parking on a slope,
direct your wheels to im-
mobilise them against the
pavement, pull the hand-
brake and engage a gear.
Applying
Pull the handbrake to immobilise
your vehicle.
Releasing
Pull on the handle and press the but-
ton to release the handbrake.
