VTL-10
< PRECAUTION >[WITHOUT 7 INCH DISPLAY]
PRECAUTIONS
O-Ring Part Numbers and Specifications
WARNING:
Check that all refrigerant is discharged into the recycling equipment and the pressure in the system is
less than atmospheric pressure. Then gradually loosen the discharge side hose fitting and remove it.
CAUTION:
Observe the following when replacing or cleaning refrigerant cycle components.
Store it in the same way at it is when mounted on the car when the compressor is removed. Failure
to do so causes lubricant to enter the low-pressure chamber.
Use always a torque wrench and a back-up wrench when connecting tubes.
Plug immediately all openings to prevent entry of dust and moisture after disconnecting tubes.
Connect the pipes at the final stage of the operation when installing an air conditioner in the vehicle.
Never remove the seal caps of pipes and other components until just before required for connection.
Allow components stored in cool areas to warm to working area temperature before removing seal
caps. This prevents condensation from forming inside A/C components.
Remove thoroughly moisture from the refrigeration system before charging the refrigerant.
Replace always used O-rings.
Apply lubricant to circle of the O-rings shown in illustration when connecting tube. Be careful not to
apply lubricant to threaded portion.
O-ring must be closely attached to the groove portion of tube.
Be careful not to damage O-ring and tube when replacing the O-ring.
Connect tube until a click can be heard. Then tighten the nut or bolt by hand. Check that the O-ring is
installed to tube correctly.
Connection type Piping connection point Part number QTY O-ring size
NewLow-pressure flexible hose to low-pressure pipe 92474 N8210 1 19
High-pressure pipe to condenser pipe assembly (Outlet) 92471 N8210 1 8
Condenser pipe assembly (Inlet) to high-pressure flexible
hose92472 N8210 1 12
Condenser assembly to condenser pipe as-
semblyInlet 92472 N8210 1 12
Outlet 92471 N8210 1 8
Low-pressure pipe to expansion valve 92473 N8210 1 16
High-pressure pipe to expansion valve 92471 N8210 1 8
Compressor to low-pressure flexible hose 92474 N8210 1 19
Compressor to high-pressure flexible hose 92472 N8210 1 12
Liquid tank to condenser assemblyInlet
92471 N82101
8
Outlet 1
FormerRefrigerant pressure sensor to liquid tank J2476 89956 1 10
Expansion valve to evaporator pipe assemblyInlet 92475 71L00 1 12
Outlet 92475 72L00 1 16
Evaporator to evaporator pipe assemblyInlet 92475 71L00 1 12
Outlet 92475 72L00 1 16
Name : NISSAN A/C System Oil Type S
Page 4835 of 5121
VTL-24
< ON-VEHICLE REPAIR >[WITHOUT 7 INCH DISPLAY]
AMBIENT SENSOR
AMBIENT SENSOR
Exploded ViewINFOID:0000000003774663
Removal and InstallationINFOID:0000000003774664
REMOVAL
1. Remove engine under cover. Refer to EXT-28, "Exploded View".
2. Disconnect ambient sensor connector (A), and then remove
ambient sensor (1).
INSTALLATION
Installation is basically the reverse order of removal.
1. Ambient sensor
JPIIA0898ZZ
JPIIA0899ZZ
Page 4836 of 5121
IN-VEHICLE SENSOR
VTL-25
< ON-VEHICLE REPAIR >[WITHOUT 7 INCH DISPLAY]
C
D
E
F
G
H
J
K
L
MA
B
VTL
N
O
P
IN-VEHICLE SENSOR
Exploded ViewINFOID:0000000003774665
Removal and InstallationINFOID:0000000003774666
REMOVAL
1. Remove instrument lower panel LH. Refer to IP-11, "Exploded View".
2. Remove mounting screw (A), and then remove in-vehicle sensor
(1).
INSTALLATION
Installation is basically the reverse order of removal.
1. In-vehicle sensor 2. Instrument lower panel LH
JPIIA0902ZZ
JPIIA0903ZZ
Page 4837 of 5121
VTL-26
< ON-VEHICLE REPAIR >[WITHOUT 7 INCH DISPLAY]
SUNLOAD SENSOR
SUNLOAD SENSOR
Exploded ViewINFOID:0000000003774667
Removal and InstallationINFOID:0000000003774668
REMOVAL
1. Disconnect sunload sensor connector, and then remove sunload
sensor (1).
INSTALLATION
Installation is basically the reverse order of removal.
1. Sunload sensor
JPIIA0904ZZ
JPIIA0905ZZ
Page 4838 of 5121
INTAKE SENSOR
VTL-27
< ON-VEHICLE REPAIR >[WITHOUT 7 INCH DISPLAY]
C
D
E
F
G
H
J
K
L
MA
B
VTL
N
O
P
INTAKE SENSOR
Exploded ViewINFOID:0000000003821339
1. Ventilator seal 2. Defroster seal 3. Distributor upper case
4. Center case 5. Heater & cooling unit case cover 6. Foot duct 1 (right)
7. Foot duct 2 (right) 8. Air mix door motor (passenger side) 9. Evaporator pipe assembly
10. Expansion valve 11. O-ring 12. Evaporator
13. Filter cover 14. Air conditioner filter 15. Case packing
16. Heater & cooling unit case (right) 17. Cooler pipe grommet 18. Grommet
19. Heater pipe grommet 20. Heater pipe support 21. Drain hose
22. Heater & cooling unit case (left) 23. Air mix door motor (driver side) 24. Heater core
25. Heater pipe cover 26. Foot duct 2 (left) 27. Foot duct 1 (left)
28. Aspirator hose 29. Aspirator 30. Mode door motor
31. Main link 32. Rod link 33. Ventilator door link
34. Mode door lever 35. Ventilator door lever 36. Max. cool door link
JPIIA0906GB
Page 4839 of 5121
![NISSAN TEANA 2008 Service Manual VTL-28
< ON-VEHICLE REPAIR >[WITHOUT 7 INCH DISPLAY]
INTAKE SENSOR
Removal and Installation
INFOID:0000000003774670
REMOVAL
1. Remove evaporator pipe assembly. Refer to HA-54, "Exploded View".
2. Disc NISSAN TEANA 2008 Service Manual VTL-28
< ON-VEHICLE REPAIR >[WITHOUT 7 INCH DISPLAY]
INTAKE SENSOR
Removal and Installation
INFOID:0000000003774670
REMOVAL
1. Remove evaporator pipe assembly. Refer to HA-54, "Exploded View".
2. Disc](/manual-img/5/57391/w960_57391-4838.png)
VTL-28
< ON-VEHICLE REPAIR >[WITHOUT 7 INCH DISPLAY]
INTAKE SENSOR
Removal and Installation
INFOID:0000000003774670
REMOVAL
1. Remove evaporator pipe assembly. Refer to HA-54, "Exploded View".
2. Disconnect intake sensor connector.
3. Slide evaporator (1) toward the right side of the vehicle (as
shown in the figure), and then remove intake sensor (2).
INSTALLATION
Installation is basically the reverse order of removal.
CAUTION:
Replace O-rings with new ones. Then apply compressor oil to them when installing.
Mark the mounting position of intake sensor bracket prior to removal so that the reinstalled sensor
can be located in the same position.
Do not rotate the bracket insertion part when removing and installing the intake sensor.
Check for refrigerant leakage when charging refrigerant.
37. Defroster door link 38. Foot door link 39. Max. cool door lever
40. Foot door lever 41. Defroster door lever 42. Adapter case
43. Distributor lower case 44. Ventilator door 45. Intake sensor
46. Intake sensor bracket 47. Foot door 48. Max. cool door
49. Defroster door 50. Air mix door (Slide door)
Refer to GI-4, "
Components" for symbols in the figure.
JPIIA0907ZZ
Page 4847 of 5121
![NISSAN TEANA 2008 Service Manual VTL-36
< ON-VEHICLE REPAIR >[WITHOUT 7 INCH DISPLAY]
HEATER & COOLING UNIT ASSEMBLY
1. Ventilator seal 2. Defroster seal 3. Distributor upper case
4. Center case 5. Heater & cooling unit case cover 6. NISSAN TEANA 2008 Service Manual VTL-36
< ON-VEHICLE REPAIR >[WITHOUT 7 INCH DISPLAY]
HEATER & COOLING UNIT ASSEMBLY
1. Ventilator seal 2. Defroster seal 3. Distributor upper case
4. Center case 5. Heater & cooling unit case cover 6.](/manual-img/5/57391/w960_57391-4846.png)
VTL-36
< ON-VEHICLE REPAIR >[WITHOUT 7 INCH DISPLAY]
HEATER & COOLING UNIT ASSEMBLY
1. Ventilator seal 2. Defroster seal 3. Distributor upper case
4. Center case 5. Heater & cooling unit case cover 6. Foot duct 1 (right)
7. Foot duct 2 (right) 8. Air mix door motor (passenger side) 9. Evaporator pipe assembly
10. Expansion valve 11. O-ring 12. Evaporator
13. Filter cover 14. Air conditioner filter 15. Case packing
16. Heater & cooling unit case (right) 17. Cooler pipe grommet 18. Grommet
19. Heater pipe grommet 20. Heater pipe support 21. Drain hose
22. Heater & cooling unit case (left) 23. Air mix door motor (driver side) 24. Heater core
25. Heater pipe cover 26. Foot duct 2 (left) 27. Foot duct 1 (left)
28. Aspirator hose 29. Aspirator 30. Mode door motor
31. Main link 32. Rod link 33. Ventilator door link
34. Mode door lever 35. Ventilator door lever 36. Max. cool door link
37. Defroster door link 38. Foot door link 39. Max. cool door lever
40. Foot door lever 41. Defroster door lever 42. Adapter case
43. Distributor lower case 44. Ventilator door 45. Intake sensor
46. Intake sensor bracket 47. Foot door 48. Max. cool door
JPIIA0906GB
Page 4855 of 5121
![NISSAN TEANA 2008 Service Manual VTL-44
< ON-VEHICLE REPAIR >[WITHOUT 7 INCH DISPLAY]
HEATER CORE
Removal and Installation
INFOID:0000000003774686
REMOVAL
1. Remove heater & cooling unit assembly. Refer to VTL-35, "Exploded View".
2. NISSAN TEANA 2008 Service Manual VTL-44
< ON-VEHICLE REPAIR >[WITHOUT 7 INCH DISPLAY]
HEATER CORE
Removal and Installation
INFOID:0000000003774686
REMOVAL
1. Remove heater & cooling unit assembly. Refer to VTL-35, "Exploded View".
2.](/manual-img/5/57391/w960_57391-4854.png)
VTL-44
< ON-VEHICLE REPAIR >[WITHOUT 7 INCH DISPLAY]
HEATER CORE
Removal and Installation
INFOID:0000000003774686
REMOVAL
1. Remove heater & cooling unit assembly. Refer to VTL-35, "Exploded View".
2. Remove mounting screws (A), and then remove foot duct (left)
(1).
3. Remove heater pipe grommet (1).
4. Remove mounting screw (A), and then remove heater pipe sup-
port (2).
5. Remove mounting screws (B), and then remove heater pipe
cover (3).
6. Slide heater core (1) to leftward (as shown in the figure).
INSTALLATION
Installation is basically the reverse order of removal.
CAUTION:
Replace O-rings with new ones. Then apply compressor oil to them when installing.
Check for refrigerant leakage when charging refrigerant.
NOTE:
Refer to CO-9, "
Refilling" when filling radiator with engine coolant.
Charge the refrigerant.
37. Defroster door link 38. Foot door link 39. Max. cool door lever
40. Foot door lever 41. Defroster door lever 42. Adapter case
43. Distributor lower case 44. Ventilator door 45. Intake sensor
46. Intake sensor bracket 47. Foot door 48. Max. cool door
49. Defroster door 50. Air mix door (Slide door)
Refer to GI-4, "
Components" for symbols in the figure.
JPIIA0925ZZ
JPIIA0926ZZ
JPIIA0927ZZ
