2008 MERCEDES-BENZ SLK350 Owner's Manual

424 Practical hints
Battery
Removing the battery
Remove the screw on the swivel bar.
Remove the swivel bar.
Pull out the battery ventilation hose
from the battery (depending on battery
arrangement in your vehicle model, the
ventilation hose is located either on the
left or right side of the battery).
Take out the battery.
Charging and reinstalling batteryCharge battery in accordance with the
instructions of the battery charger
manufacturer.
Reinstall the charged battery. Follow
the previously described steps in
reverse order.Warning!G
Never charge a battery while still installed in
the vehicle unless the accessory battery
charge unit approved by Mercedes-Benz is
being used. Gases may escape during charg-
ing and cause explosions that may result in
paint damage, corrosion or personal injury.
An accessory battery charge unit specially
adapted for Mercedes-Benz vehicles and
tested and approved by Mercedes-Benz is
available, permitting the charging of the
battery in its installed position. Contact an
authorized Mercedes-Benz Center for infor-
mation and availability. Charge battery in
accordance with the separate instructions
for the accessory battery charger.
!The battery, its filler caps and the ventilation
hose must always be securely installed when the
vehicle is in operation.

425 Practical hints
Battery
Reconnecting the battery
Turn off all electrical consumers.
Connect the battery positive lead2
(
page 422) and fasten its cover.
Connect the battery negative lead3
(
page 422).
Reinsert water tray 1 (page 423).
Push in locks2 (page 423) and turn
one quarter turn.
!Always connect the battery in the order
described below. Otherwise the vehicle’s
electronics can be damaged.
!Never invert the terminal connections!
iThe following procedures must be carried
out following any interruption of battery power
(e.g. due to reconnection):

Set the clock (page 141).

Synchronize the power windows
(
page 239).

426 Practical hints
Jump starting
If the battery is discharged, the engine can
be started with jumper cables and the bat-
tery of another vehicle. Observe the follow-
ing:

Jump starting should only be performed
when the engine and catalytic convert-
er are cold.

Do not start the engine if the battery is
frozen. Let the battery thaw out first.

Only jump start from batteries with the
same voltage rating (12 V). Jump start-
ing with a higher voltage battery could
damage the vehicle’s electrical system,
which will not be covered by the
Mercedes-Benz Limited Warranty.

Only use jumper cables with sufficient
cross-section and insulated terminal
clamps.

Always make sure the jumper cables
are not on or near pulleys, fans, or
other parts that move when an engine
is started or running.
Warning!G
Failure to follow these directions will cause
damage to the electronic components, and
can lead to a battery explosion and severe
injury or death.
Never lean over batteries while connecting
or jump starting, as you could otherwise be
injured.
Battery fluid contains sulfuric acid. Do not
allow this fluid to come in contact with eyes,
skin or clothing. In case it does, immediately
flush affected area with water, and seek
medical help if necessary.
A battery will also produce hydrogen gas,
which is flammable and very explosive. Keep
flames or sparks away from battery, avoid
improper connection of jumper cables,
smoking, etc.
Attempting to jump start a frozen battery
can result in it exploding, causing personal
injury.
Read all instructions before proceeding.
!Vehicles with automatic transmission*:
Do not tow-start vehicle.
!Avoid repeated and lengthy starting
attempts.
Do not attempt to start the engine using a
battery quick charge unit.
If the engine does not run after several
unsuccessful starting attempts, have it checked
at the nearest authorized Mercedes-Benz
Center.
Excessive unburned fuel generated by repeated
failed starting attempts may damage the
catalytic converter and may present a fire risk.
Make sure the jumper cables do not have loose
or missing insulation.
Make sure the cable clamps do not touch any
other metal part while the other end is still at-
tached to a battery.

427 Practical hints
Jump starting
Make sure the two vehicles do not
touch.
Turn off all electrical consumers.
Apply the parking brake (page 59).
Make sure the gear selector lever* is
set to positionP (manual transmission
to Neutral).
Open the hood (page 294).
Flip up cover from positive under hood
terminal2 in front of water tray1
(
page 423).1Positive terminal of charged battery
2Positive terminal
3Negative terminal of charged battery
4Negative terminal
Connect positive terminal1 of the
charged battery with positive
under-hood terminal2 in front of the
water tray with one jumper cable.
Clamp the cable to positive terminal1
of the charged battery first.
Start the engine of the vehicle with the
charged battery and run at idle speed.
Connect negative terminal3 of the
charged battery with negative
under-hood terminal4 with the
second jumper cable. Clamp the cable
to negative terminal3 of the charged
battery first.
Start the engine of the disabled
vehicle.
You can now turn on the electrical
consumers. Do not switch on the
headlamps under any circumstances.
Remove the jumper cables first from
negative terminals3 and4 and then
from positive terminals2 and1.
You can now switch on the headlamps.
Have the battery checked at the
nearest authorized Mercedes-Benz
Center.
Warning!G
Keep flames or sparks away from battery.
Do not smoke.
Observe all safety instructions and precau-
tions when handling automotive batteries
(
page 302).
!Never invert the terminal connections.

428 Practical hints
Towing the vehicle
Mercedes-Benz recommends that the vehi-
cle be transported with all wheels off the
ground using flatbed or appropriate wheel
lift/dolly equipment.
When circumstances do not permit the
recommended towing methods, the vehi-
cle may be towed with all wheels on the
ground or front wheels raised only so far as
necessary to have the vehicle moved to a
safe location where the recommended
towing methods can be employed.
!Vehicles with automatic transmission*: Do
not tow-start vehicle.
!Use flatbed or wheel lift/dolly equipment
with the SmartKey in the starter switch in
position0.
Do not tow with sling-type equipment. Towing
with sling-type equipment over bumpy roads will
damage radiator and supports.
To prevent damage during transport, do not tie
down vehicle by its chassis or suspension parts.
Use the towing eyes.
Switch off the tow-away alarm (
page 91) and
the automatic central locking (
page 102).
Warning!G
If circumstances require towing the vehicle
with all wheels on the ground, always tow
with a tow bar if:

the engine will not run

there is a malfunction in the brake
system

there is a malfunction in the power
supply or in the vehicle’s electrical
system
This is necessary to adequately control the
towed vehicle.
Prior to towing the vehicle with all wheels on
the ground, make sure the SmartKey is in
starter switch position2.
If the SmartKey is left in starter switch
position0 for an extended period of time, it
can no longer be turned in the switch. In this
case, the steering is locked. To unlock,
remove SmartKey from starter switch and
reinsert.
Warning!G
With the engine not running, there is no
power assistance for the brake and steering
systems. In this case, it is important to keep
in mind that a considerably higher degree of
effort is necessary to brake and steer the
vehicle. Adapt your driving accordingly.
!If the vehicle is towed with the front axle
raised, the gear selector lever* must be in
positionN (manual transmission: gear shift lever
in neutral position) and the engine must be shut
off (SmartKey in starter switch position0or1).
Active braking action through the ESP
® may
otherwise seriously damage the brake system.
When towing the vehicle with all wheels on the
ground, the gear selector lever* must be in
positionN (manual transmission: gear shift lever
in neutral position) and the SmartKey must be in
starter switch position2.
When towing the vehicle with all wheels on the
ground or the front axle raised, the vehicle
may be towed only for distances up to
30 miles (50 km) and at a speed not to
exceed 30 mph (50 km/h).

429 Practical hints
Towing the vehicle
Installing towing eye bolt
The towing eye bolt is supplied with the ve-
hicle tool kit, located in the compartment
underneath the trunk floor (
page 389).
The towing eyes are located on the passen-
ger side in the front and rear bumper.
Take vehicle tool kit out of trunk
(
page 389).
Front cover
1Cover in front bumper
!Towing of the vehicle should only be done
using the properly installed towing eye bolt.
Never attach a tow cable, tow rope or tow rod to
the vehicle chassis, frame or suspension parts.
iWhen towing the vehicle with all wheels on
the ground, please note the following:
With the automatic central locking activated and
the SmartKey in starter switch position2, the
vehicle doors lock if the left front wheel as well
as the right rear wheel are turning at vehicle
speeds of approximately 9 mph (15 km/h) or
more.
To prevent the vehicle door locks from locking,
deactivate the automatic central locking
(
page 102).
iTo signal turns while being towed with the
hazard warning flasher in use, switch on ignition
and activate the combination switch for the left
or right turn signal in the usual manner – only the
selected turn signal will operate.
Upon canceling the turn signal, the hazard warn-
ing flasher will operate again.
iThe gear selector lever* will remain locked
in positionP (vehicles with automatic transmis-
sion*) and the SmartKey will not turn in the
starter switch if the battery is disconnected or
discharged. For more information, see “Battery”
(
page 422) or “Jump starting” (page 426).
Vehicles with automatic transmission*:
For information on manual unlocking of gear
selector lever, see (
page 396).

430 Practical hints
Towing the vehicle
Removing
Press mark on cover1.
Cover1 springs open at the top right
corner.
Pull at the protruding part of cover1
and fold cover down to reveal the
threaded hole for the towing eye bolt.
Do not disconnect cover1 from its
check strap.
Screw towing eye bolt in to its end stop
and tighten with wheel wrench.Installing
Unscrew the towing eye bolt using the
wheel wrench.
To reinstall cover1, tilt the marked
lower left corner towards the opening.
Maintaining its tilted position, insert
cover1 by applying the latches at the
top left and lower right corner into the
opening.
To close cover1, press on the diago-
nal opposite side of the marked corner
until it fully engages.Rear coverExample illustration (AMG vehicles and
vehicles with Sport Package* have a square
cover)
1Cover in rear bumperiMake sure the cover’s check strap does not
get caught when closing.

431 Practical hints
Towing the vehicle
Removing
Press mark on cover1.
Cover1 springs open at the top.
Pull at the protruding part of cover1
and fold cover down to reveal the
threaded hole for the towing eye bolt.
Do not disconnect cover1 from its
check strap.
Screw towing eye bolt in to its end stop
and tighten with wheel wrench.Installing
Unscrew the towing eye bolt using the
wheel wrench.
To reinstall cover1, tilt the marked
lower edge towards the opening.
Maintaining its tilted position, insert
cover1 by applying the latches at the
marked lower edge into the opening.
To close cover1, press on the un-
marked top until it fully engages.
iMake sure the cover’s check strap does not
get caught when closing.
