2008 MERCEDES-BENZ SLK350 Owner's Manual

144 Controls in detail
Control system
Setting locator lighting
With the locator lighting feature activated
and the exterior lamp switch in
positionU, the following lamps will
switch on during darkness when the vehi-
cle is unlocked with the SmartKey:

Parking lamps

Tail lamps

License plate lamps

Side marker lamps

Front fog lamps
The locator lighting switches off when the
driver’s door is opened.
If you do not open a door after unlocking
the vehicle with the SmartKey, the lamps
will switch off automatically after approxi-
mately 40 seconds.
Move the selection marker with
buttonæorç to the
Lighting
submenu.
Press buttonjork repeatedly
until the message
Surround Lighting
Function
appears in the multifunction
display.
The selection marker is on the current
setting.
Press buttonæorç to switch
the locator lighting function
On or Off.
Turn the exterior lamp switch to
positionU when exiting the vehicle
(
page 55).
The locator lighting feature is
activated.Setting night security illumination
(Headlamps delayed shut-off)
Use this function to set whether you would
like the exterior lamps to remain on for
15 seconds during darkness after exiting
the vehicle and closing all doors.
With the headlamps delayed shut-off
feature activated and the exterior lamp
switch in positionU before the engine
is turned off, the following lamps will
switch on when the engine is turned off:

Parking lamps

Tail lamps

License plate lamps

Side marker lamps

Front fog lamps

145 Controls in detail
Control system
If after turning off the engine you do not
open a door or do not close an opened
door, the lamps will automatically switch
off after 60 seconds.
Move the selection marker with
buttonæorç to the
Lighting
submenu.
Press buttonjork repeatedly
until the message
Headlamps Delayed
Shut-off
appears in the multifunction
display.
The selection marker is on the current
setting.
Press buttonæorç to switch
the headlamps delayed shut-off feature
On or Off.
Turn the exterior lamp switch to
positionU before turning off the
engine (
page 55).
The headlamps delayed shut-off
feature is activated.
You can temporarily deactivate the
delayed shut-off feature:
Before exiting the vehicle, turn the
SmartKey in the starter switch to
position0.
Then turn it to position2 and back to
position0.
The delayed shut-off feature is deacti-
vated. It will reactivate as soon as you
reinsert the SmartKey in the starter
switch.Setting interior lighting delayed shut-off
Use this function to set whether you would
like the interior lighting to remain on for
10 seconds during darkness after you have
removed the SmartKey from the starter
switch.
Move the selection marker with
buttonæorç to the
Lighting
submenu.
Press buttonjork repeatedly
until the message
Interior Lighting
Delayed Shut-off
appears in the
multifunction display.
The selection marker is on the current
setting.
Press buttonæorç to
switch the interior delayed shut-off
feature
On or Off.

146 Controls in detail
Control system
Vehicle submenu
Access the
Vehicle submenu via the
Settings menu. Use the Vehicle submenu
to make general vehicle settings.
The following functions are available:
For additional information on central
locking, see “Automatic central locking”
(
page 102).Selecting audio search function
Use of the Audio search function to
select a radio station (
page 133) will
enable you to start a frequency scan
(
Frequency) or select a radio station stored
in memory (
Memory).
Move the selection marker with
buttonæ orç to the
Vehicle
submenu.
Press buttonj ork repeatedly
until the message
Audio Search
Function
appears in the multifunction
display.
The selection marker is on the current
setting.
Press buttonæ orç to select
Frequency or Memory.Setting automatic locking
Use this function to activate or deactivate
the automatic locking system.
With the automatic locking system
activated, the vehicle is centrally
locked at vehicle speeds of approximately
9mph(15km/h).
Move the selection marker with
buttonæorç to the
Vehicle
submenu.
Press buttonjork repeatedly
until the message
Automatic Door
Lock
appears in the multifunction
display.
The selection marker is on the current
setting.
Press buttonæorç to set the
automatic central locking to
On or Off.
FunctionPage
Selecting audio search function146
Setting automatic locking146

147 Controls in detail
Control system
Convenience* submenu
Access the
Convenience submenu via the
Settings menu. Use the Convenience sub-
menu to change the settings for a number
of convenience features.
The following function is available:Activating easy-entry/exit feature*
Use this function to activate and
deactivate the easy-entry/exit feature
(
page 44).
Move the selection marker with
buttonæorç to the
Convenience submenu.
Press buttonjork repeatedly
until the message
Easy-entry
Function
appears in the multifunction
display.
The selection marker is on the current
setting.
Press buttonæorç to switch
the easy-entry function
On or Off.
FunctionPage
Activating easy-entry/exit
feature*147
Warning!G
You must make sure no one can become
trapped or injured by the moving steering
wheel when the easy-entry/exit feature is
activated.
To cancel steering wheel movement, do one
of the following:

Move steering wheel adjustment stalk*
(
page 44).

Press one of the memory position
buttons* or the memory buttonM*
(
page 107).
Do not leave children unattended in the ve-
hicle, or with access to an unlocked vehicle.
Children could open the driver’s door and
unintentionally activate the easy-entry/exit
feature, which could result in an accident
and/or serious personal injury.

148 Controls in detail
Control system
Trip computer menu
Use the trip computer menu to call up
statistical data on your vehicle.
The following information is available:Fuel consumption statistics since start
Press buttonèorÿ repeatedly
until the message
From Start appears
in the multifunction display.
1Statistics called up: since start
2Time elapsed since start
3Average fuel consumption since start
4Average speed since start
5Distance driven since startFuel consumption since last reset
Press buttonèorÿ repeatedly
until the message
From Start appears
in the multifunction display.
Press buttonjork repeatedly
until the message
From Reset appears
in the multifunction display.
1Statistics called up: since last reset
2Time elapsed since last reset
3Average fuel consumption since last
reset
4Average speed since last reset
5Distance driven since last resetFunctionPage
Fuel consumption statistics
since start148
Fuel consumption statistics
since last reset148
Resetting fuel consumption
statistics149
Calling up range
(distance to empty)149
iAll statistics stored since the last engine
start will be reset approximately four hours after
the SmartKey in the starter switch is turned to
position0 or removed from the starter switch.
Resetting will not occur if you turn the SmartKey
back to position1or2 within this time period.

149 Controls in detail
Control system
Resetting fuel consumption statistics
Press and hold reset buttonJuntil
the values of the statistics are reset
to
0.Calling up range (distance to empty)
Press buttonèorÿ repeatedly
until the message
From Start appears
in the multifunction display.
Press buttonjork repeatedly
until the message
Range: appears in
the multifunction display.
The calculated remaining driving range
based on the current fuel tank level
appears in the multifunction display.
TEL* menu
iThe fuel consumption statistics reset auto-
matically to
0 when either of the following values
is exceeded:

distance covered:
100 000 miles (100 000 km)

time elapsed: 10 000 hours
iIf only very little fuel is left in the tank, a
vehicle at the fuel pump is shown instead of the
range.
Warning!G
A driver’s attention to the road must always
be his/her primary focus when driving. For
your safety and the safety of others, we rec-
ommend that you pull over to a safe location
and stop before placing or taking a tele-
phone call. If you choose to use the tele-
phone while driving, please use the
hands-free device and only use the tele-
phone when weather, road, and traffic
conditions permit.
Some jurisdictions prohibit the driver from
using a cellular telephone while driving a
vehicle.
Bear in mind that at a speed of just
30 mph (approximately 50 km/h), your
vehicle is covering a distance of
44 feet (approximately 14 m) every second.


150 Controls in detail
Control system
You can use the functions in the TEL menu
to operate your telephone, provided it is
connected to a hands-free system and
switched on.
Switch on the telephone and Audio or
COMAND*.
See separate operating instructions.
Press buttonèorÿ repeatedly
until the
TEL menu appears in the
multifunction display.Which messages will appear in the multi-
function display depends on whether your
telephone is switched on or off:

If the telephone is switched off, the
message in the multifunction display is:
PHONE OFF.

If the telephone is switched on:
The telephone will then search for a
network. During this time the multi-
function display is empty.
As soon as the telephone has found a
network,
Ready is indicated in the mul-
tifunction display.
This standby message indicates that your
telephone is ready for use and you can op-
erate it using the control system.Answering a call
When your telephone is ready to receive
calls, you can answer a call at any time. In
the multifunction display you will see the
message, or if available, the caller ID
(name and number):Audio system
COMAND*
Press buttons.
You have answered the call.
The duration of the call appears in the
multifunction display.
Never operate radio transmitters equipped
with a built-in or attached antenna (i.e. with-
out being connected to an external antenna)
from inside the vehicle while the engine is
running. Doing so could lead to a malfunc-
tion of the vehicle’s electronic system, pos-
sibly resulting in an accident and/or
personal injury.

151 Controls in detail
Control system
Ending a call or rejecting an incoming
call
Press buttont.
Dialing a number from the phone book
If your telephone is ready to receive calls,
you may select and dial a number from the
phone book at any time.
Press buttonèorÿ repeatedly
until the
TEL menu and the standby
message appear in the multifunction
display.
Press buttonjork.
The control system reads the phone
book which is stored in the telephone.
This may take up to 30 seconds. In the
multifunction display you will see the
message
Please Wait.
When the message
Please wait
disappears, the phone book has been
loaded.
Press buttonjork repeatedly
until the desired name appears in the
multifunction display.
The stored names are displayed in
ascending or descending alphabetical
order.
1Selected name from phone bookPress buttons.
The control system dials the selected
phone number.

If the connection is successful, the
name of the party you called and
the duration of the call will appear
in the display.

If no connection is made, the con-
trol system stores the dialed num-
ber in the redial memory.
or
Cancel the call you have intended to
make by pressing buttont.
iIf you press and hold buttonj ork
for longer than 1 second, the system scrolls
rapidly through the list of names until you
release the button again.
Cancel the quick search mode by pressing
buttont.
