2008 MERCEDES-BENZ CL-Class Comand Manual

384 Controls in detailMirrorsActivating exterior rear view mirror parking position
Follow these steps to activate the mirror
parking position so that the passen-
ger-side exterior rear view mirror will be
turned downward to the stored position.
Make sure you have stored a parking
position for the passenger-side exterior
rear view mirror (
page 387).

Make sure the “Lower mirror when re-
versing” function in the “Exterior Mirror
Convenience Settings” submenu of the
COMAND system is selected
(page 262).

Switch on the ignition (
page 365).1Selector switch for right or left exterior
mirror

Press switch1 repeatedly until the
exterior mirror on the front passenger
side is selected.

Shift the automatic transmission in re-
verse gearR.
The passenger-side exterior rear view
mirror will be turned downward to the
stored position.
The exterior rear view mirror returns to its
previously stored driving position:


when you switch off the ignition


10 seconds after you have put the au-
tomatic transmission out of reverse
gearR


immediately once your vehicle exceeds
a speed of approximately 6 mph
(10 km/h)


immediately when you press button1
for driver’s side exterior rear view mir-
ror.
i
With the automatic transmission in reverse
gear R, the previously selected exterior rear view
mirror is activated.
i
If you adjust the exterior mirrors while they
are in the parking position, the new mirror posi-
tion is stored as a new parking position.

385 Controls in detail
Memory function
Memory function
Prior to operating the vehicle, the driver
should check and adjust the seat height,
seat position fore and aft, and seat back-
rest angle if necessary, to ensure adequate
control, reach, and comfort. The head
restraint should also be adjusted for
proper height. See also the section on
air bags (
page 42) for proper seat
positioning.
In addition, adjust the steering wheel to
ensure adequate control, reach, operation
and comfort. Both the interior and exterior
rear view mirrors should be adjusted for
adequate rear vision.
Fasten seat belts. Infants and small
children should be seated in a properly se-
cured restraint system that complies with
U.S. Federal Motor Vehicle Safety
Standards 213 and 225 and
Canadian Motor Vehicle Safety Standards
213 and 210.2.With the memory function you can store up
to three different configurations.
The following settings are stored when us-
ing the buttons on the driver’s door:


Driver’s seat: head restraint height,
seat and backrest position, backrest
curvature in lumbar area


Lumbar support (CL 550)


Drive-dynamic multicontour seat*:
activation/deactivation, sides of back-
rest, backrest curvature in lumbar and
shoulder area


Steering wheel position


Exterior rear view mirrors position
Warning!
G
Do not activate the memory function while
driving. Activating the memory function
while driving could cause the driver to lose
control of the vehicle.Warning!
G
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle.
Even with the SmartKey or SmartKey with
KEYLESS-GO* removed from the starter
switch or the SmartKey with KEYLESS-GO*
removed from the vehicle, the memory func-
tion can be operated. Therefore, do not
leave children unattended in the vehicle, or
with access to an unlocked vehicle. A child’s
unsupervised access to a vehicle could re-
sult in an accident and/or serious personal
injury.

386 Controls in detailMemory functionThe following settings are stored when us-
ing the buttons on the passenger door:

Front passenger seat, head restraint
high and backrest position


Lumbar support (CL 550)


Drive-dynamic multicontour seat*:
activation/deactivation
MMemory button
1 2 3Memory position buttons
Storing positions into memory
Adjust the seat (
page 368) to the de-
sired position.

On the driver’s side: adjust the steering
wheel (
page 379) and the exterior
rear view mirrors (
page 381) to the
desired position.

Press memory buttonM.

Release memory buttonM and press
one of the memory position buttons
1,2or3 within 3 seconds.
All the settings are stored at the
selected position.
Recalling positions from memory
Press and hold one of the memory
position buttons1,2or3 until the
seat, steering wheel and exterior rear
view mirrors have completely moved to
the stored positions.
!
Do not operate the power seats using a
memory position button if the seat backrest is in
an excessively reclined position. Doing so could
cause damage to front or rear seats.
First move seat backrest to an upright position.
i
Releasing the memory position button
immediately stops movement to the stored
positions.
The drive-dynamic multicontour front seat*
and/or lumbar support (CL 550) will continue to
be adjusted.

387 Controls in detail
Memory function
Storing exterior rear view mirror park-ing position
For easier parking, you can adjust the pas-
senger-side exterior rear view mirror so
that you can see the right rear wheel as
soon as you engage reverse gearR.
For information on activating the parking
position, see “Activating exterior rear view
mirror parking position” (
page 384).
1Memory button M
2Adjustment button
3Selector switch for right or left exterior
mirror

Stop the vehicle.

Make sure the ignition is switched on
(page 365).

Press switch3 until the exterior mir-
ror on the front passenger side is se-
lected.

Adjust the passenger-side exterior rear
view mirror with button2 so that you
see the rear wheel and the road curb.

Press memory button M.

Within 3 seconds, press one of adjust-
ment buttons2.
The parking position is stored if the
mirror does not move.
i
If the mirror does move, repeat the above
steps. After the setting is stored, you can move
the mirror again.

388 Controls in detailFastening the seat beltsWarning!
G
Always fasten your seat belt before driving
off. Always make sure all of your passengers
are properly restrained.
Failure to wear and properly fasten and
position your seat belt greatly increases
your risk of injuries and their likely severity
in an accident. You and your passengers
should always wear seat belts.
If you are ever in an accident, your injuries
can be considerably more severe without
your seat belt properly buckled. Without
your seat belt buckled, you are much more
likely to hit the interior of the vehicle or be
ejected from it. You can be seriously injured
or killed.
In the same crash, the possibility of injury or
death is lessened if you are wearing your
seat belt. The air bags can only provide the
protection they were designed to afford if
the occupants are using their seat belts
(page 42).
Warning!
G
According to accident statistics, children
are safer when properly restrained in the
rear seating positions than in the front seat-
ing position. Thus, we strongly recommend
that children be placed in the rear seats
whenever possible. Regardless of seating
position, children 12 years old and under
must be seated and properly secured in an
appropriately sized infant restraint, toddler
restraint, or booster seat recommended for
the size and weight of the child. For addi-
tional information, see “Children in the vehi-
cle” (
page 57).
A child’s risk of serious or fatal injuries is
significantly increased if the child restraints
are not properly secured in the vehicle and
the child is not properly secured in the child
restraint.
Warning!
G
Never let more people ride in the vehicle
than there are seat belts available. Be sure
everyone riding in the vehicle is correctly re-
strained with a separate seat belt. Never use
a seat belt for more than one person at a
time.Warning!
G
Never ride in a moving vehicle with the seat
backrest in an excessively reclined position
as this can be dangerous. You could slide
under the seat belt in a collision. If you slide
under it, the belt would apply force at the ab-
domen or neck. That could cause serious or
even fatal injuries. The seat backrest and
seat belt provide the best restraint when the
wearer is in a nearly upright position and the
belt is properly positioned on the body.

389 Controls in detail
Fastening the seat belts
1Belt outlet
2Latch plate
3Buckle
4Release button

Pull the seat belt smoothly from the
seat belt outlet 1.

Place the shoulder portion of the belt
across the top of your shoulder and the
lap portion across your hips.

Push latch plate2 into buckle3 until
it clicks.

If necessary, tighten the lap portion to
a snug fit by pulling shoulder portion
up.

To release the seat belt, press release
button4 and guide latch plate back to
belt outlet.
Warning!
G
Read and observe the additional warning no-
tices printed in the “Safety and Security”
section (
page 40).

390 Controls in detailFastening the seat beltsProper use of seat belts

Do not twist the belt when fastening.


Adjust seat belt so that the shoulder
portion is located as close as possible
to the middle of the shoulder (it should
not touch the neck). Never pass the
shoulder portion of the belt under your
arm.


Position the lap belt as low as possible
on your hips (over hip joint) and not
across the abdomen.


Place the seat backrest in a nearly up-
right position.


Never use a seat belt for more than one
person at a time.


Do not fasten a seat belt around a per-
son and another object at the same
time. When using a seat belt to secure
infant restraint, toddler restraint, or
booster seat always follow the child
seat manufacturer’s instructions.


Check your seat belt during travel to
make sure that it is properly posi-
tioned.


Make sure the seat belt is always fitted
snugly. Take special care of this when
wearing loose clothing.For more information, see “Seat belts”
(
page 53).
Warning!
G
Do not pass belts over sharp edges. They
could tear.
Do not allow the belt to get caught in the
door or in the seat adjustment mechanism.
This could damage the belt.
Never attempt to make modifications to
seat belts. This could impair the effective-
ness of the belts.
Do not bleach or dye seat belts as this may
severely weaken them. In a crash, they may
not be able to provide adequate protection.
Damaged seat belts or belts that were highly
stressed in an accident must be replaced.
Contact an authorized Mercedes-Benz
Center.

391 Controls in detail
Lighting
Lighting
Exterior lamp switch
The exterior lamp switch is located on the
dashboard to the left of the steering wheel.
i
If you drive in countries where vehicles drive
on the other side of the road than the country in
which the vehicle is registered, you must have
the headlamps modified for symmetrical low
beams. Relevant information can be obtained at
any authorized Mercedes-Benz Center.
i
The active Bi-Xenon headlamps monitor
your steering angle and driving speed, then auto-
matically shift their beams to either side to bet-
ter follow the curvature of the road ahead,
increasing usable illumination over conventional
headlamps.
1‚
Standing lamps, left (turn left two
stops)
2ˆ
Standing lamps, right (turn left
one stop)
3M
Off
Daytime running lamp mode
(page 393)
4*
Automatic headlamp mode
Daytime running lamp mode
(page 393)
5C
Parking lamps (also tail lamps, li-
cense plate lamps, side marker
lamps, instrument panel lamps)
6B
Low beam headlamps or high
beam headlamps
7‡
Front fog lamps
8†
Rear fog lamp
i
If you hear a warning signal you have forgot-
ten to switch off the low beam headlamps or the
parking lamps before opening the driver’s door.
In addition the message “Please Switch Off
Lights” appears in the multifunction display.
Switch off the low beam headlamps or the park-
ing lamps.
If the message “Turn Lights Off or Remove Key”
appears in the multifunction display remove the
SmartKey from the starter switch or switch off
the automatic headlamp mode.
!
Failure to switch off the exterior lamps when
leaving the vehicle may result in a discharged
battery.
