288 Control systemsInstrument cluster control systemRoute guidance active
The image on the multifunction display de-
pends on whether you are being notified of
a driving maneuver.
No notification of driving maneuverExample illustration1Distance to destination
2Symbol for “follow the course of the
road”
3Distance to next driving maneuver
4Street you are currently driving onNotification of driving maneuver with-
out lane recommendation
Example illustration1Street into which the driving maneuver
leads
2Symbol for “driving maneuver”
3Distance to driving maneuver and visu-
al distance display
When you are being notified of a driving
maneuver, you will see a visual distance
display 3 next to the driving maneuver
symbol. The visual distance display is re-
duced from bottom to top the closer you
come to the announced driving maneuver.Navigation status displays in the instru-
ment cluster
While route guidance is active, the follow-
ing messages may be shown on the multi-
function display:


<
You have reached your destination.


“Area of dest. reached”
You have arrived in the area of your
destination. The message appears, for
example, for relatively large POIs.


“New Route…”
COMAND calculates a new route, e.g.
because you have deviated from the
calculated route or due to a detour re-
port. Afterward, COMAND continues
route guidance.

289 Control systems
Instrument cluster control system


“Calculating Route”
COMAND is calculating a route. After-
ward, COMAND starts route guidance.


“Off Map”
The vehicle’s location is outside of the
digital map’s range. The vehicle is in an
off-map position (
page 238).


“Off Mapped Road”
The vehicle is either on a road that has
not been digitized (
page 238) or on
the side of a road, e.g. in a parking
space.


“No Route”
COMAND cannot calculate a route to
the selected destination.


“Direction of Dest.”
The vehicle has gone off the map dur-
ing route guidance (
page 238).
Audio menu
The functions in the “Audio” menu operate
the audio equipment which you currently
have turned on.
If no audio equipment is currently turned
on, the message: “Audio OFF” is shown in
the multifunction display.
Selecting radio station
Turn on COMAND and select “Radio”
(page 98).

Press ( or & to select the
“Audio” menu.

Selecting a preset station: Briefly
press % or $.

Selecting a station using the search
function: Press and hold %
or$.1Station frequency
2Waveband

Press æ or ç to adjust the vol-
ume.
i
The menu overview can be found on
(
page 284).
i
You can only change the frequency band
and save new stations using COMAND
(
page 98).

290 Control systemsInstrument cluster control systemSelecting satellite radio channel
The satellite radio is treated as a radio ap-
plication.
Turn on COMAND and select
“Sat Radio” (
page 104).

Press ( or & to select the
“Audio” menu.

Press % or $ to select a station.
1Channel number and/or name
2SAT mode

Press æ or ç to adjust the
volume.Operating DVD changer/audio CD/
audio DVD/MP3

Turn on COMAND and select “CD”,
“DVD-Audio” or “MP3” (
page 112).

Press ( or & to select the “Au-
dio” menu.

Press % or $ to select a track.
Example: audio CD1Current track

Press æ or ç to adjust the vol-
ume.
Operating video DVD

Turn on COMAND and select “Video”

“Video”
“Video DVD”
(page 130).

Press ( or & to select the “Au-
dio” menu.
1Current scene
2Disc number

Press % or $ to select a scene.
i
A subscription to SIRIUS Satellite Radio ser-
vice provider is required for the satellite radio op-
eration. Contact an authorized Mercedes-Benz
Center for details and availability for your vehi-
cle.
For more information on satellite radio
(
page 104).
i
When you play a CD or DVD with text, the
multifunction display shows the name and num-
ber of the track. For MP3s, only the track is
shown.

291 Control systems
Instrument cluster control system
AMG menu
The main screen of the AMG menu shows
you

the gear currently engaged


the engine oil temperature


the vehicle supply voltage

Press ( or & to select the
“AMG” menu.
1Gear indicator
2Upshift indicator “up”
3Engine oil temperature
4Vehicle supply voltageIf the engine reaches the overspeed range
in the manual shift program, you will see
“up” 2 next to gear indicator 1 as a re-
minder to upshift.
Use buttons % or $ to select the fol-
lowing functions in the AMG menu:RACETIMER
The RACETIMER allows you to time and
save driving stretches in hours, minutes
and seconds.

Press ( or & to select the
“AMG” menu.

Press % to select the RACETIMER.
i
This function is only available in CL 63 AMG
and CL 65 AMG only.
i
The engine oil temperature value and unit
will be shown in blue if the engine oil tempera-
ture has not yet reached 176°F (80°C). During
this time, avoid driving at full engine speed.
Function
Page
RACETIMER
291
Overall analysis
293
Lap analysis
294
Warning!
G
The RACETIMER feature is for use only on
roads and in conditions where high speed
driving is permitted. Racing on public roads
is prohibited under all circumstances and
the driver is and must always remain re-
sponsible for following posted speed limits.


292 Control systemsInstrument cluster control system1Gear indicator
2RACETIMER
3Seconds display
4Lap
Starting RACETIMER: Press æ.

Displaying intermediate time:
Pressç.
The intermediate time is shown for
5 seconds.

Stopping RACETIMER: Press æ.

To select a different display, press
$, ( or &.Saving lap time and starting a new lap

Press buttonç while the timer is
running.
The intermediate time will be shown for
5 seconds.

Press buttonç within 5 seconds.
The intermediate time shown will be
saved as a lap time.
The RACETIMER begins timing the new
lap. The new lap begins to be timed as
soon as the intermediate time is called
up.
1Gear indicator
2RACETIMER
3Best lap time
i
You can start the RACETIMER when the en-
gine is running or the starter switch is in
position2 (
page 365).
i
While the RACETIMER is being displayed,
you cannot adjust the audio volume using but-
tons æ or ç.
i
When you stop the vehicle and turn the
Smartkey to position 1 (
page 365) or, in vehi-
cles with KEYLESS-GO*, turn off the engine and
do not open the driver’s door, the RACETIMER
stops timing. Timing is resumed when you switch
the ignition back on or restart the engine and
then press æ button.
i
When you switch on the Night View Assist*
(
page 481) while the RACETIMER is operating,
the RACETIMER will continue to run in the back-
ground but cannot be operated with the multi-
function steering wheel buttons.
To stop the RACETIMER, switch off the Night
View Assist* first.
i
You can save up to 16 laps.


293 Control systems
Instrument cluster control system
Resetting current lap
Press buttonæ while the timer is
running.
The timer stops.

Press buttonç.
The lap time is reset to “0”.
Deleting all laps

Press buttonæ while the timer is
running.
The timer stops.

Press buttonç for at least
3 seconds.

Press buttonæ to start timer again.
The saved laps are deleted.
or

Press #.The reset menu appears in the multi-
function display.

Press % to select “Yes” and confirm
with #.
The saved laps are deleted.Overall analysis

Press ( or & to select the
“AMG” menu.

Press $ repeatedly until the overall
analysis appears in the multifunction
display.
1Overall analysis of RACETIMER
2Overall driving time
3Maximum speed
4Overall distance driven
5Average speed

To select a different display, press
$, ( or &.
i
It is not possible to delete a single saved lap.
i
These functions are only available if you
have saved at least one lap and have stopped the
RACETIMER.

294 Control systemsInstrument cluster control systemLap analysis
Press ( or & to select the
“AMG” menu.

Press $ repeatedly until the lap
analysis appears in the multifunction
display.
1Lap number
2Lap time
3Maximum speed
4Lap length
5Average speed during lap

Press $ or % to see other lap
analyses.

To select a different display, press
( or &.
Telephone menu*
You can use the functions in the “Tele-
phone” menu to operate your telephone,
provided it is inserted in the cradle and
switched on.
i
These functions are only available if you
have saved at least two laps and have stopped
RACETIMER.
i
Each lap is shown in its own submenu. The
fastest lap is indicated by flashing symbol 1.
i
The menu overview can be found on
(
page 284).Warning!
G
Some jurisdictions prohibit the driver from
using a mobile telephone while driving.
Whether or not prohibited by law, for safety
reasons, the driver should not use the mo-
bile telephone while the vehicle is in motion.
Stop the vehicle in a safe location before
placing or answering a call.
If you nonetheless choose to use the mobile
phone while driving, please use the hands-
free feature and be sure to pay attention to
the traffic situation at all times. Use the mo-
bile phone only when road, weather and traf-
fic conditions permit.

295 Control systems
Instrument cluster control system
Logging-on to a network
Switch on the telephone and COMAND
(page 83).

Press ( or & to select the “Tele-
phone” menu.
Which messages appear in the multifunc-
tion display depends on whether your tele-
phone is switched on or off.


If the telephone is off, the message in
the multifunction display is: “Telephone
OFF”.


If the telephone is not inserted in the
cradle, the message in the multifunc-
tion display is: “No telephone inserted”.


If the PIN or unlock code is not yet en-
tered, the message in the multifunction
display is “Please enter PIN” or “Enter
unlock code”.


If the telephone is switched on, the
telephone will then search for a net-
work. During this time, the multifunc-
tion display is blank. If no network
available, the multifunction display
reads “No Service”.


If the telephone is on, as soon as the
telephone has found a network,
“Ready” or “Ready (Roaming)” appears
in the multifunction display.
Otherwise, you may not be able to observe
traffic conditions and could endanger your-
self and others.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is
covering a distance of 44 feet (approxima-
tely 14 m) every second.Warning!
G
Never operate radio transmitters equipped
with a built-in or attached antenna (i.e. with-
out being connected to an external antenna)
from inside the vehicle while the engine is
running. Doing so could lead to a malfunc-
tion of the vehicle’s electronic system, pos-
sibly resulting in an accident and/or
personal injury.
i
Various mobile phone cradles can be in-
stalled in the front center armrest, see separate
installation instructions for the mobile phone
cradle. These mobile phone cradles can be ob-
tained from an authorized Mercedes-Benz Cen-
ter. For more information about telephone
(
page 519).
