152 Control systemsCOMAND telephone*Switching the hands-free microphone
on or off
Switching screen to telephone
mode: Call up main telephone menu
(page 145).

Switching off microphone:
Select “Mic OFF” and press n.
or

Press F shortcut button.
If the microphone is switched off,
the> symbol appears in the main
area.

Switching on microphone:
Select “Mic ON”.
or

Press F shortcut button.
The> symbol disappears.
Sending a character string via DTMF
Answering machines or other devices can
be controlled by character strings (e.g. for
remote query functions).
Sending character strings via the DTMF
menu

During a call, select “DTMF”.
The DTMF dialing display appears.1Back to the call display
2Character entry
3To call up the phone book

Sending individual characters:
Rotateymz or slide omp and select
desired character.
Each character you select can be seen
in the main area and is sent immediate-
ly.
i
The name of the person you are speaking
with can only be seen in display 7 if his or her
telephone number and name have been saved in
the COMAND address book or phone book on
the mobile phone. The telephone number must
also be saved in the same way in which the per-
son you are talking to transmits it.
i
This function is not possible with every mo-
bile phone. If the mobile phone supports the
function, you can use it during the call connec-
tion and also during a call.

153 Control systems
COMAND telephone*

Sending a phone book entry as a
character string: Select “Name”.

Select desired phone book entry.
The entry is immediately sent as a char-
acter string.

Switching back to the call display:
Select “Y”.
Sending character strings via the tele-
phone keypad

Press corresponding button on tele-
phone keypad.
Each character you select is immedi-
ately sent.Ending an active call

Ending a call: Select “4END” in the
call display.
or

Press t on the telephone keypad or
on the multifunction steering wheel.
The COMAND display will change to
the previously selected display, if
applicable.
Transferring a call
From the hands-free system to the
Bluetooth
® headset
The call transfer is controlled by pressing
the PTT button on the Bluetooth
® headset
(see headset operating instructions). Nor-
mally, it is sufficient to press the PTT but-
ton once, but under certain circumstances
you may have to press it a second time.
Once the call has been transferred to the
Bluetooth
® headset, all the functions will
be available to you which are described in
the “Functions during a single-call connec-
tion” section (
page 151).
Exception: “Switching the hands-free mi-
crophone on or off” function (
page 152).
i
Telephone numbers containing the + char-
acter may impair the function.
i
The + character may impair the function.
i
The use of a Bluetooth
® headset requires
Bluetooth
® to be activated and the Bluetooth
®
headset to be authorized (
page 176).

154 Control systemsCOMAND telephone*From the Bluetooth
® headset to the
hands-free system
On most Bluetooth
® headsets, you press
the PTT button on the headset twice quick-
ly to transfer the call (see headset operat-
ing instructions).
From the hands-free system to the mo-
bile phone

If the mobile phone has a folding up-
per section: Flip upper section open.

Take mobile phone out of cradle.
The “No telephone inserted” message
appears on the COMAND display. Sub-
sequent operation is only possible us-
ing the mobile phone.From the mobile phone to the
hands-free system

Insert mobile phone into cradle.
Once the call has been transferred to
the hands-free feature, all the functions
will be available to you which are de-
scribed in the “Functions during a sin-
gle-call connection” section
(page 151).
COMAND phone book
The COMAND phone book contains both
the COMAND address book entries and
mobile phone entries that have at least
one telephone number.
The COMAND address book entries are
permanently available even when a mobile
phone is not inserted in the cradle.
When the mobile phone is inserted in the
cradle, COMAND will read the phone book
entries in the mobile phone and compares
them with the COMAND address book en-
tries.

155 Control systems
COMAND telephone*
If any of the telephone numbers of a phone
book entry in the mobile phone are the
same as an address book entry, COMAND
will only display the address book entry.
If the entries are not the same, the CO-
MAND phone book will show the phone
book entry in the mobile phone.
Calling up the COMAND phone book
Select “Telephone”
“Name”.
The COMAND phone book appears.
Illustration: a phone book with name dis-
play and smart speller activated1Category symbol
2Upper entry from address book (with-
out category symbol)
3Symbol + for several telephone num-
bers (subentries) under the main entry
4Symbol for summarized entries
from the mobile phone with the same
name but different telephone numbers
5Smart speller
6Voice entry symbol
7To close the phone bookEntries with category symbol 1 come
from the mobile phone. The following cate-
gory symbols are possible:


= symbol for “Mobile” category


= symbol for “Home” category


= symbol for “Work” category


= symbol for “Fax” category


= symbol for “Pager” category


= symbol for “Main” category or for
unknown category or for phone entries
that are saved on the SIM card of a
GSM mobile phone
Entries without a category symbol or with
the symbol come from the COMAND
address book.
Entries with the symbol contain a voice
entry. Voice entries can be added to the
address book (
page 173). This function
is available in vehicles with Voice Control.

156 Control systemsCOMAND telephone*Switching between the smart speller
and the list
Switching from the smart speller to
the list: Slide mq repeatedly or press
n until the smart speller is hidden.
or

Rotate ymz or slide omp and
select?.
The smart speller is hidden.
Illustration: list of phone book entries with
name display and hidden smart speller1Back to smart speller
2To switch phone book display (“123” or
“ABC”)
3Symbol + for several telephone num-
bers (subentries) under the main entry,
subentry list is closed
4To call up options
5Symbol / for open subentry list
6List of phone book entries
7Subentry list with category symbols
and telephone numbers

Switching from the list to the smart
speller: Select “Back” from the list.
or

Press back button L in the center
console (
page 84).

Changing phone book display in the
list: Select “123” or “ABC”.
The screen changes to telephone num-
ber or name display.
i
The following options are available under
“Options” menu item 4:


Displaying details about an entry
(page 158)


Creating a new entry in the address book
(page 158)


Deleting an entry (
page 160)


Saving a phone book entry from mobile
phone in the address book (
page 160)


Adding a telephone number to an address
book entry (
page 162)

157 Control systems
COMAND telephone*
Closing the COMAND phone book
In the smart speller, select “Back”.
or

Press back button L in the center
console (
page 84).
Selecting an entry in the COMAND
phone book
Selecting entries using the smart speller

Switch from the list to the smart speller
if necessary.

Changing smart speller language:
Select !.

Select desired language.

Changing smart speller character
set: Select #.
Depending on the previous setting, you
will change to letters with special char-
acters or to numbers with special char-
acters.

Entering characters: Select the char-
acters of the entry you are searching
for one by one.

Deleting individual characters: Se-
lect ) and briefly press n.
Each time you enter or delete a charac-
ter, the closest match will be displayed
at the top of the list.

Deleting an entire entry: Select )
and press and hold n until the entry is
deleted.

Canceling search: Switch from the
smart speller to the list.
The entry at the top of the list is auto-
matically highlighted.Selecting using the list

If necessary, switch from the smart
speller to the list.

Rotate ymz or slide qmr until the de-
sired entry is highlighted.
Selecting subentries

Select an entry with the + symbol and
press n.
The + symbol changes to / and the
subentries are displayed.

Rotate ymz or slide qmr until the de-
sired subentry is highlighted.

158 Control systemsCOMAND telephone*Displaying details of an entry
COMAND can also show a shortened entry
in its entirety. For entries featuring suben-
tries, the detailed view is only available for
the subentries and not for the main entry.
Select entry (
page 157).

Select “Options”
“Details”.
The detailed view appears.

Closing detailed view: Slide qmr or
omp or press n or back button L
in the center console (
page 84).Starting to dial the number of an entry

Select entry (
page 157).

Press n.
or

Press s on the telephone keypad.
A list appears if the entry contains sub-
entries.
Select desired subentry.

Press n again.
or

Press s on the telephone key-
pad.Assigning a New Entry in the Address
Book

Select “Options”
“New Entry” in the
COMAND phone book list.

Selecting a number category:
Select a category, e.g. “Home”.

Selecting a telephone category:
Select a category, e.g. “Land Line”.

Confirming selection: Select “Save”.
The input menu appears with the data
fields.
i
This function is used to create a new entry in
the address book and to enter the data (first
name, last name and telephone number) manu-
ally.

159 Control systems
COMAND telephone*
1Data field
2Input mark (cursor)
3Input characters
Changing data field: Slide qmr re-
peatedly until desired data field is high-
lighted.
or

Select [ or ] repeatedly until de-
sired data field is highlighted.

Entering data into a field: Select all
characters one by one from the input
characters line 3.

Toggling upper and lower case for
the input characters: Select & or
(.

Changing language for the input
characters: Select !.

Select desired language.

Changing character set for the input
characters: Select #.
Depending on the previous setting, you
will change to letters with special char-
acters or to numbers with special char-
acters.

Displaying special characters as in-
put characters: Select !
“Sym-
bols”.

Returning input characters to nor-
mal characters: Select !
the
desired language.

Moving cursor in the data field:
SelectY or Z.

Deleting individual characters:
Select) and briefly press n.
The character to the left of the cursor is
deleted.

Deleting an entire entry: Select )
and press and hold n until the entry is
deleted.

Saving an entry: Select ?.

Canceling an entry: Select “Back”.
If one of the data fields contains data, a
prompt will appear asking whether you
want to save the entry.
Select “Yes” or “No”.
The entry will either be saved or
not, depending on your selection.
