For cars with an annual mileage of
below 20,000 km (for example about
15.000 km) the following yearly in-
spection programme is advised:
❒check tyre conditions/wear and
adjust pressure if required (in-
cluding the spare wheel);
❒check light system operation
(headlights, direction indicators,
hazard lights, boot lights, passen-
ger compartment lights, warning
lights, etc.);
❒wiper and windscreen washer sys-
tem check (adjustment of spray
nozzles/wear on wiper blades)
❒check front disk brake pad condi-
tions and wear;
❒visually inspect the conditions of:
engine, gearbox, transmission,
pipes and hoses (exhaust - fuel
feed - brakes), rubber parts
(boots, sleeves, bushes, etc.);❒check cleanness of bonnet and
boot locks and lever cleanness and
lubrication;
❒check battery charge;
❒visual check on various drive belt
conditions;
❒check and top up, if required, fluid
levels (engine coolant, brake fluid,
windscreen washer fluid, battery
fluid, etc);
❒replace engine oil;
❒replace engine oil filter;
❒replace pollen filter (where pro-
vided).
ADDITIONAL
CHECKS
Every 1,000 km or before long jour-
neys, check and top up if required:
❒engine coolant fluid level;
❒brake fluid level;
❒windscreen washer fluid level;
❒tyre pressure and conditions.
Every 3,000 km check the following
and top-up, if required: engine oil
level.
You are recommended to use FL Se-
lenia products, designed and pro-
duced specifically for Lancia cars (see
table “Capacities” in section “Techni-
cal specifications”).
IMPORTANT - Engine oil
Should prevailing use of the car be
under one of the following specially
heavy conditions:
❒trailer or caravan towing;
❒dusty roads;
❒short distances (less than 7-8 km)
repeated and with external tem-
peratures below zero;
165-186 MUSA 3ed GB 12-11-2007 11:39 Pagina 169

170
WARNING
LIGHTS AND
MESSAGES
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
STARTING
AND
DRIVING
IN AN
EMERGENCY
MAINTENANCE
AND CARE
❒frequently idling engines or long
distance low speed driving (e.g.
taxis or door-to-door deliveries) or
in case of a long term inactivity;
❒replace engine oil more frequently
than required on “Service sched-
ule”.
IMPORTANT - Air cleaner
If the car is used on dusty roads
change the air cleaner more fre-
quently than the indications in the
“Service schedule”. If in doubt as to
how often the engine oil and air
cleaner should be changed according
to how you use the car, contact a Lan-
cia Dealership.IMPORTANT - Pollen filter
If the car is used frequently in dusty
or heavily polluted environments it is
advisable to replace the filtering ele-
ment more frequently; in particular it
should be replaced if a reduction of
the amount of air admitted to the pas-
senger compartment is noted.
IMPORTANT - Diesel filter
The possibility of topping up with
diesel fuel not complying with EN590
European Norm might make it neces-
sary to replace the filter more fre-
quently than indicated in the “Service
schedule”.IMPORTANT - Battery
The charge in the battery should be
checked at the start of winter to limit
the risk of electrolyte freezing.
Perform this inspection more fre-
quently if the car is mainly used for
short distances or if electrical devices
running with the key off are installed,
particularly after-market. If the car is
used in hot climates or in particularly
heavy duty conditions, it is advisable
to check the battery fluid (electrolyte)
level at more frequent intervals com-
pared to those provided for in the
“Service Schedule”.
Car maintenance should be
entrusted to Lancia Dealer-
ship. For routine and minor
maintenance operations
you wish to carry out yourself, al-
ways make sure you have the proper
equipment, genuine Lancia spare
parts and the necessary fluids; do
not however carry out these opera-
tions if you have no experience.
165-186 MUSA 3ed GB 12-11-2007 11:39 Pagina 170

171
WARNING
LIGHTS AND
MESSAGES
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
STARTING
AND
DRIVING
IN AN
EMERGENCY
MAINTENANCE
AND CARE
CHECKING
