TROUBLE DIAGNOSISEC-115
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O73 Y
Engine coolant temperature
sensor [Engine is running] Approximately 0 - 4.8V
Output voltage varies with engine
coolant temperature.
74 LG/B Heated oxygen sensor 2
(bank 1) [Engine is running]
 Revving engine from idle to 3,000 rpm quick-
ly after the following conditions are met
- Engine: After warming up.
- Keeping the engine speed between 3,500 and 4,000 rpm for 1 minute and at idle for 1
minute under no load 0 - Approximately 1.0V
78 B/R Sensor ground
(Heated oxygen sensor) [Engine is running]

Warm-up condition
 Idle speed Approximately 0V
79
80
81 SB
GY
OR Ignition signal No. 6
Ignition signal No. 4
Ignition signal No. 2 [Engine is running]

Warm-up condition
 Idle speed NOTE:
The pulse cycle changes depending on rpm
at idle 0 - 0.2V
[Engine is running]
 Warm-up condition
 Engine speed: 2,500 rpm 0.1 - 0.4V
82 B/W Sensor ground
(APP sensor 1, ASCD steer-
ing switch, ICC steering
switch) [Engine is running]

Warm-up condition
 Idle speed Approximately 0V
83 G/OR Sensor ground
(APP sensor 2) [Engine is running]

Warm-up condition
 Idle speed Approximately 0V
85 PU Data link connector [Ignition switch: ON]
 CONSULT-III or GST: DisconnectedApproximately 5V - Battery volt-
age (11 - 14V)
86 P CAN communication line — —
90 L/B Sensor power supply
(APP sensor 1) [Ignition switch: ON]
Approximately 5V
91 G Sensor power supply
(APP sensor 2) [Ignition switch: ON]
Approximately 5V
94 L CAN communication line — —
98 Y/R Accelerator pe
dal position
sensor 2 [Ignition switch: ON]
 Engine stopped
 Accelerator pedal: Fully released
0.15 - 0.60V
[Ignition switch: ON]
 Engine stopped
 Accelerator pedal: Fully depressed 1.95 - 2.40V
TER-
MI-
NAL NO. WIRE
COLOR ITEM CONDITION DATA (DC Voltage)
SEC986C
SEC987C
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

EC-116
< SERVICE INFORMATION >[VQ35DE]
TROUBLE DIAGNOSIS
99 G/YICC steering switch
(models with ICC system) [Ignition switch: ON]
 ICC steering switch: OFF
Approximately 4.3V
[Ignition switch: ON]
 MAIN switch: Pressed Approximately 0V
[Ignition switch: ON]
 CANCEL switch: Pressed Approximately 1.3V
[Ignition switch: ON]
 RESUME/ACCELERATE switch: Pressed Approximately 3.7V
[Ignition switch: ON]
 SET/COAST switch: Pressed Approximately 3.0V
[Ignition switch: ON]
 DISTANCE switch: Pressed Approximately 2.2V
99 G/Y ASCD steering switch
(models with ASCD system) [Ignition switch: ON]
 ASCD steering switch: OFF
Approximately 4.0V
[Ignition switch: ON]
 MAIN switch: Pressed Approximately 0V
[Ignition switch: ON]
 CANCEL switch: Pressed Approximately 1.0V
[Ignition switch: ON]
 RESUME/ACCELERATE switch: Pressed Approximately 3.0V
[Ignition switch: ON]
 SET/COAST switch: Pressed Approximately 2.0V
101 P/L Stop lamp switch [Ignition switch: OFF]
 Brake pedal: Fully released
Approximately 0V
[Ignition switch: OFF]
 Brake pedal: Slightly depressed BATTERY VOLTAGE
(11 - 14V)
102 LG/B PNP switch [Ignition switch: ON]
 Selector lever: P or N
Approximately 0V
[Ignition switch: ON]
 Except above position BATTERY VOLTAGE
(11 - 14V)
104 L/OR Throttle co ntrol motor relay[Ignition switch: OFF]
BATTERY VOLTAGE
(11 - 14V)
[Ignition switch: ON] 0 - 1.0V
106 OR Accelerator pedal position
sensor 1 [Ignition switch: ON]
 Engine stopped
 Accelerator pedal: Fully released
0.5 - 1.0V
[Ignition switch: ON]
 Engine stopped
 Accelerator pedal: Fully depressed 3.9 - 4.7V
107 PU/W Fuel tank temperature sen-
sor [Engine is running] Approximately 0 - 4.8V
Output voltage varies with fuel
tank temperature.
108 SB ICC brake switch
(models with ICC system)
ASCD brake switch
(models with ASCD system) [Ignition switch: ON]
 Brake pedal: Slightly depressed
Approximately 0V
[Ignition switch: ON]
 Brake pedal: Fully released BATTERY VOLTAGE
(11 - 14V)
109 W/L Ignition switch [Ignition switch: OFF]
0V
[Ignition switch: ON] BATTERY VOLTAGE
(11 - 14V)
TER-
MI-
NAL NO. WIRE
COLOR
ITEM CONDITION DATA (DC Voltage)
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

EC-118
< SERVICE INFORMATION >[VQ35DE]
TROUBLE DIAGNOSIS
ItemDIAGNOSTIC TEST MODE
WORK SUP-
PORT SELF-DIAGNOSTIC
RESULTS DATA
MONI-
TOR ACTIVE
TEST DTC & SRT
CONFIRMATION
DTC*
1FREEZE FRAME
DATA*
1
SRT
STATUS DTC
WORK
SUP-
PORT
ENGINE CONTROL COMPONENT PARTS
INPUT
Crankshaft position sensor (POS) ×××
Camshaft position sensor (PHASE) ×××
Mass air flow sensor ××
Engine coolant temperature sensor ××××
Air fuel ratio (A/F) sensor 1 ××××
Heated oxygen sensor 2 ××××
Vehicle speed sensor ×××
Accelerator pedal position sensor ××
Throttle position sensor ×××
Fuel tank temperature sensor ×××
EVAP control system pressure sen-
sor ××
Intake air temperature sensor ×××
Knock sensor ×
Refrigerant pressure sensor ×
Closed throttle position switch (ac-
celerator pedal position sensor sig-
nal) ×
Air conditioner switch ×
Park/neutral position (PNP) switch ××
Stop lamp switch ××
Power steering pressure sensor ××
Battery voltage ×
Load signal ×
Fuel level sensor ××
ICC steering switch ××
ASCD steering switch ××
ICC brake switch ××
ASCD brake switch ××
Snow mode switch ×
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

TROUBLE DIAGNOSISEC-119
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
X: Applicable
*1: This item includes 1st trip DTCs.
*2: This mode includes 1st trip freeze frame data or freeze frame data. The items appear on CONSULT-III screen in freeze frame
data
mode only if a 1st trip DTC or DTC is detected. For details, refer to “Freeze Frame Data and 1st Trip Freeze Frame Data”.
*3: Always “CMPLT ” is displayed.
WORK SUPPORT MODE
Work Item
ENGINE CONTROL COMPONENT PARTS
OUTPUT
Fuel injector ××
Power transistor (Ignition timing) ××
Throttle contro l motor relay ××
Throttle control motor ×
EVAP canister purge volume con-
trol solenoid valve ××××
Air conditioner relay ×
Fuel pump relay ×××
Cooling fan relay ×××
Air fuel ratio (A/F) sensor 1 heater ××
×*
3
Heated oxygen sensor 2 heater ××
×*3
EVAP canister vent control valve ×× ××
Intake valve timing control solenoid
valve ×××
Calculated load value ××
Item
DIAGNOSTIC TEST MODE
WORK SUP-
PORT SELF-DIAGNOSTIC
RESULTS DATA
MONI- TOR ACTIVE
TEST DTC & SRT
CONFIRMATION
DTC*
1FREEZE FRAME
DATA*
1
SRT
STATUS DTC
WORK SUP-
PORT
WORK ITEM CONDITION USAGE
FUEL PRESSURE RELEASE  FUEL PUMP WILL STOP BY TOUCHING “START” DUR- ING IDLING.
CRANK A FEW TIMES AFTER ENGINE STALLS. When releasing fuel pressure from
fuel line
IDLE AIR VOL LEARN  THE IDLE AIR VOLUME THAT KEEPS THE ENGINE WITHIN THE SPECIFIED RANGE IS MEMORIZED IN
ECM. When learning the idle air volume
SELF-LEARNING CONT  THE COEFFICI ENT OF SELF-LEARNING CONTROL
MIXTURE RATIO RETURNS TO THE ORIGINAL COEF-
FICIENT. When clearing the coefficient of
self-learning control value
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

EC-120
< SERVICE INFORMATION >[VQ35DE]
TROUBLE DIAGNOSIS
*: This function is not necessary in the usual service procedure.
SELF-DIAG RESULTS MODE
Self Diagnostic Item
Regarding items of DTC and 1st trip DTC, refer to
EC-55, "Emission-Related Diagnostic Information".
Freeze Frame Data and 1st Trip Freeze Frame Data
EVAP SYSTEM CLOSE CLOSE THE EVAP CANISTER VENT CONTROL VALVE IN
ORDER TO MAKE EVAP SYSTEM CLOSE UNDER THE
FOLLOWING CONDITIONS.
 IGN SW ON
 ENGINE NOT RUNNING
 AMBIENT TEMPERATURE IS ABOVE 0 °C (32 °F).
 NO VACUUM AND NO HIGH PRESSURE IN EVAP SYS- TEM
 FUEL TANK TEMP. IS MORE THAN 0 °C (32 °F).
 WITHIN 10 MINUTES AFTER STARTING “EVAP SYS- TEM CLOSE”
 WHEN TRYING TO EXECUTE “EVAP SYSTEM CLOSE” UNDER THE CONDITION EXCEPT ABOVE, CONSULT-
III WILL DISCONTINUE IT AND DISPLAY APPROPRI-
ATE INSTRUCTION.
NOTE:
WHEN STARTING ENGINE, CONSULT-III MAY DIS-
PLAY “BATTERY VOLTAGE IS LOW. CHARGE BAT-
TERY”, EVEN IN USING CHARGED BATTERY. When detecting EVAP vapor leak
point of EVAP system
VIN REGISTRATION  IN THIS MODE VIN IS REGISTERED IN ECM When registering VIN is ECM
TARGET IDLE RPM ADJ*  IDLE CONDITION When setting target idle speed
TARGET IGN TIM ADJ*  IDLE CONDITION Wh en adjusting target ignition tim-
ing
WORK ITEM CONDITION USAGE
Freeze frame data
item* Description
DIAG TROUBLE
CODE
[PXXXX]  The engine control co
mponent part/control system has a trouble code, it is displayed as “PXXXX”. (Refer to
EC-17
.)
FUEL SYS-B1  “Fuel injection system status” at the moment a malfunction is detected is displayed.
 One mode in the following is displayed. “Mode2”: Open loop due to detected system malfunction
“Mode3”: Open loop due to driving conditions (power enrichment, deceleration enleanment)
“Mode4”: Closed loop - using oxygen sensor(s) as feedback for fuel control
“Mode5”: Open loop - has not yet satisfied condition to go to closed loop
FUEL SYS-B2
CAL/LD VALUE [%]  The calculated load value at the moment a malfunction is detected is displayed.
COOLANT TEMP
[
° C] or [ °F]  The engine coolant temperature at the moment a malfunction is detected is displayed.
L-FUEL TRM-B1 [%]  “Long-term fuel trim” at the moment a malfunction is detected is displayed.  The long-term fuel trim indicates much more gradual feedback compensation to the base fuel schedule than short-term fuel trim.
L-FUEL TRM-B2 [%]
S-FUEL TRM-B1 [%]  “Short-term fuel trim” at the moment a malfunction is detected is displayed.
 The short-term fuel trim indicates dynamic or instantaneous feedback compensation to the base fuel sched-
ule.
S-FUEL TRM-B2 [%]
ENGINE SPEED [rpm]  The engine speed at the moment a malfunction is detected is displayed.
VEHICL SPEED
[km/h] or [mph]  The vehicle speed at the moment a malfunction is detected is displayed.
ABSOL TH-P/S [%]  The throttle operat ing angle at the moment a malfunct ion is detected is displayed.
B/FUEL SCHDL
[msec]  The base fuel schedule at the moment a malfunction is detected is displayed.
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

TROUBLE DIAGNOSISEC-121
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
*: The items are the same as those of 1st trip freeze frame data.
DATA MONITOR MODE
Monitored Item
×
: Applicable
INT/A TEMP SE
[° C] or [ °F]  The intake air temperature at the moment a malfunction is detected is displayed.
INT MANI PRES [kPa]  Always a certain value is displayed.
 These items are not efficient for S50 models.
FTFMCH1 Freeze frame data
item* Description
Monitored item Unit Description Remarks
ENG SPEED rpm  Indicates the engine speed computed from the sig-
nal of the crankshaft position sensor (POS) and
camshaft position sensor (PHASE).  Accuracy becomes poor if engine speed
drops below the idle rpm.
 If the signal is interrupted while the en-
gine is running, an abnormal value may
be indicated.
MAS A/F SE-B1 × The signal voltage of the mass air flow sensor is
displayed.  When the engine is stopped, a certain
value is indicated.
B/FUEL SCHDL × Base fuel schedule indicates the fuel injection
pulse width programmed into ECM, prior to any
learned on board correction.
A/F ALPHA-B1 %  The mean value of the air-fuel ratio feedback cor-
rection factor per cycle is indicated.  When the engine is stopped, a certain
value is indicated.
 This data also includes the data for the air-fuel ratio learning control.
A/F ALPHA-B2
×
COOLAN TEMP/S °C or ° The engine coolant temperature (determined by
the signal voltage of the engine coolant tempera-
ture sensor) is displayed.  When the engine coolant temperature
sensor is open or short-circuited, ECM
enters fail-safe mode. The engine cool-
ant temperature determined by the ECM
is displayed.
A/F SEN1 (B1) ×
 The A/F signal computed from the input signal of
the Air fuel ratio (A/F) sensor 1 is displayed.
A/F SEN1 (B2) ×
HO2S2 (B1) ×
 The signal voltage of the heated oxygen sensor 2 is
displayed.
HO2S2 (B2) ×
HO2S2 MNTR(B1) RICH/
LEAN  Display of heated oxygen sensor 2 signal:
RICH: means the amount of oxygen after three way
catalyst is relatively small.
LEAN: means the amount of oxygen after three
way catalyst is relatively large.  When the engine is stopped, a certain
value is indicated.
HO2S2 MNTR(B2) RICH/
LEAN
VHCL SPEED SE km/h or
mph  The vehicle speed computed from the vehicle
speed signal sent from combination meter is dis-
played.
BATTERY VOLT V  The power supply voltage of ECM is displayed.
ACCEL SEN 1 ×
 The accelerator pedal position sensor signal volt-
age is displayed.  ACCEL SEN 2 signal is converted by
ECM internally. Thus, it differs from ECM
terminal voltage signal.
ACCEL SEN 2
×
TP SEN 1-B1 V  The throttle position sensor signal voltage is dis-
played.  THRTL SEN 2 signal is converted by
ECM internally. Thus, it differs from ECM
terminal voltage signal.
TP SEN 2-B1 V
FUEL T/TMP SE
°C or ° The fuel temperature (determined by the signal
voltage of the fuel tank temperature sensor) is dis-
played.
INT/A TEMP SE °C or °F  The intake air temperature (determined by the sig-
nal voltage of the intake air temperature sensor) is
indicated.
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

EC-122
< SERVICE INFORMATION >[VQ35DE]
TROUBLE DIAGNOSIS
EVAP SYS PRES V The signal voltage of EVAP control system pres-
sure sensor is displayed.
FUEL LEVEL SE V  The signal voltage of the fuel level sensor is dis-
played.
START SIGNAL × Indicates start signal status [ON/OFF] computed by
the ECM according to the signals of engine speed
and battery voltage.  After starting the engine, [OFF] is dis-
played regardless of the starter signal.
CLSD THL POS × Indicates idle position [ON/OFF] computed by ECM
according to the accelerator pedal position sensor
signal.
AIR COND SIG × Indicates [ON/OFF] condition of the air conditioner
switch as determined by the air conditioner signal.
P/N POSI SW × Indicates [ON/OFF] condition from the park/neutral
position (PNP) switch signal.
PW/ST SIGNAL × [ON/OFF] condition of the power steering system
(determined by the signal voltage of the power
steering pressure sensor) is indicated.
LOAD SIGNAL × Indicates [ON/OFF] condition from the electrical
load signal.
ON: Rear window defogger switch is ON and/or
lighting switch is in 2nd position.
OFF: Both rear window defogger switch and light-
ing switch are OFF.
IGNITION SW × Indicates [ON/OFF] condition from ignition switch
signal.
HEATER FAN SW × Indicates [ON/OFF] condition from the heater fan
switch signal.
BRAKE SW × Indicates [ON/OFF] condition from the stop lamp
switch signal.
INJ PULSE-B1 ×
 Indicates the actual fuel injection pulse width com-
pensated by ECM according to the input signals.  When the engine is stopped, a certain
computed value is indicated.
INJ PULSE-B2 ×
IGN TIMING × Indicates the ignition timing computed by ECM ac-
cording to the input signals.  When the engine is stopped, a certain
value is indicated.
CAL/LD VALUE %  Calculated load value indicates the value of the cur-
rent air flow divided by peak air flow.
MASS AIRFLOW g·m/s  Indicates the mass air flow computed by ECM ac-
cording to the signal voltage of the mass air flow
sensor.
PURG VOL C/V %  Indicates the EVAP canister purge volume control
solenoid valve control value computed by the ECM
according to the input signals.
 The opening becomes larger as the value increas- es.
INT/V TIM(B1) °CA
 Indicates [ °CA] of intake camshaft advanced angle.
INT/V TIM(B2) °CA
INT/V SOL(B1) %  The control condition of the intake valve timing con- trol solenoid valve (determined by ECM according
to the input signals) is indicated.
 The advance angle becomes larger as the value in-
creases.
INT/V SOL(B2) %
AIR COND RLY
× The air conditioner relay control condition (deter-
mined by ECM according to the input signals) is in-
dicated.
FUEL PUMP RLY × Indicates the fuel pump relay control condition de-
termined by ECM according to the input signals.
Monitored item Unit Description Remarks
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

TROUBLE DIAGNOSISEC-123
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
VENT CONT/V
× The control condition of the EVAP canister vent
control valve (determined by ECM according to the
input signals) is indicated.
ON: Closed
OFF: Open
THRTL RELAY × Indicates the throttle co
ntrol motor relay control
condition determined by the ECM according to the
input signals.
COOLING FAN HI/MID/
LOW/
OFF  The control condition of the cooling fan (determined
by ECM according to the input signals) is indicated.
HI: High speed operation
MID: Middle speed operation
LOW: Low speed operation
OFF: Stop
HO2S2 HTR (B1) × Indicates [ON/OFF] condition of heated oxygen
sensor 2 heater determined by ECM according to
the input signals.
HO2S2 HTR (B2)
×
I/P PULLY SPD rpm  Indicates the engine speed computed from the tur-
bine revolution sensor signal.
VEHICLE SPEED km/h or
mph  Indicates the vehicle speed computed from the rev-
olution sensor signal.
IDL A/V LEARN YET/
CMPLT  Display the condition of idle air volume learning
YET: Idle Air Volume Learning has not been per-
formed yet.
CMPLT: Idle Air Volume Learning has already been
performed successfully.
TRVL AFTER MIL km or
mile  Distance traveled while MIL is activated.
SNOW MODE SW ON/OFF  Indicates [ON/OFF] condition from the snow mode
switch signal.
A/F S1 HTR(B1) %  Air fuel ratio (A/F) sensor 1 heater control value computed by ECM according to the input signals.
 The current flow to the heater becomes larger as the value increases.
A/F S1 HTR(B2) %
AC PRESS SEN V
 The signal voltage from the refrigerant pressure
sensor is displayed.
VHCL SPEED SE km/h or
mph  The vehicle speed computed from the vehicle
speed signal sent from TCM is displayed.
SET VHCL SPD km/h or
mph  The preset vehicle speed is displayed.
MAIN SW ON/OFF  Indicates [ON/OFF] condition from MAIN switch
signal.
CANCEL SW ON/OFF  Indicates [ON/OFF] condition from CANCEL switch
signal.
RESUME/ACC SW ON/OFF  Indicates [ON/OFF] condition from RESUME/AC-
CELERATE switch signal.
SET SW ON/OFF  Indicates [ON/OFF] condition from SET/COAST
switch signal.
BRAKE SW1 ON/OFF  Indicates [ON/OFF] condition from ASCD brake
switch signal.
BRAKE SW2 ON/OFF  Indicates [ON/OFF] condition of stop lamp switch
signal.
Monitored item Unit Description Remarks
