Without CONSULT-III
1. Start engine and warm it up to normal operating temperature.
2. Check idle speed. Refer to EC-84, "
Idle Speed and Ignition Timing Check".
OK or NG
OK >> GO TO 15.
NG >> GO TO 17.
15.CHECK IGNITION TIMING AGAIN
1. Run engine at idle.
2. Check ignition timing with a timing light. Refer to EC-84, "
Idle Speed and Ignition Timing Check".
OK or NG
OK >> GO TO 19.
NG >> GO TO 16.
16.CHECK TIMING CHAIN INSTALLATION
Check timing chain installation. Refer to EM-64
.
OK or NG
OK >> GO TO 17.
NG >> 1. Repair the timing chain installation. 2. GO TO 4.
17.DETECT MALFUNCTIONING PART
Check the following.
 Check camshaft position s ensor (PHASE) and circuit.
Refer to EC-324
.
 Check crankshaft position sensor (POS) and circuit.
Refer to EC-319
.
OK or NG
OK >> GO TO 18.
NG >> 1. Repair or replace. 2. GO TO 4.
18.CHECK ECM FUNCTION
1. Substitute another known-good ECM to check ECM f unction. (ECM may be the cause of an incident, but
this is a rare case.)
2. Perform initialization of IVIS (NATS) system and registration of all IVIS (NATS) ignition key IDs.
Refer to BL-185
.
>> GO TO 4.
19.INSPECTION END
Did you replace the ECM, referring this Basic Inspection procedure?
Ye s o r N o
Ye s > > 1 . P e r f o r m EC-84, "VIN Registration".
2. INSPECTION END
No >> INSPECTION END
650
± 50 rpm (in P or N position)
15 ± 5 ° BTDC (in P or N position)
PBIB1602E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

BASIC SERVICE PROCEDUREEC-85
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
4. Follow the instruction of CONSULT-III display.
Accelerator Pedal Releas
ed Position LearningINFOID:0000000001325923
DESCRIPTION
Accelerator Pedal Released Position Learning is an operation to learn the fully released position of the accel-
erator pedal by monitoring the accelerator pedal posit ion sensor output signal. It must be performed each time
harness connector of accelerator pedal position sensor or ECM is disconnected.
OPERATION PROCEDURE
1. Make sure that accelerator pedal is fully released.
2. Turn ignition switch ON and wait at least 2 seconds.
3. Turn ignition switch OFF and wait at least 10 seconds.
4. Turn ignition switch ON and wait at least 2 seconds.
5. Turn ignition switch OFF and wait at least 10 seconds.
Throttle Valve Closed Position LearningINFOID:0000000001325924
DESCRIPTION
Throttle Valve Closed Position Learning is an operation to l earn the fully closed position of the throttle valve by
monitoring the throttle position sensor output signal . It must be performed each time harness connector of
electric throttle control ac tuator or ECM is disconnected.
OPERATION PROCEDURE
1. Make sure that accelerator pedal is fully released.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
Make sure that throttle valve moves during above 10 seconds by confirming the operating sound.
Idle Air Volume LearningINFOID:0000000001325925
DESCRIPTION
Idle Air Volume Learning is an operation to learn the idle air volume that keeps each engine within the specific
range. It must be performed under any of the following conditions:
 Each time electric throttle control actuator or ECM is replaced.
 Idle speed or ignition timing is out of specification.
PREPARATION
Before performing Idle Air Volume Learning, make sure that all of the following conditions are satisfied.
Learning will be cancelled if any of the following conditions are missed for even a moment.
 Battery voltage: More than 12.9V (At idle)
 Engine coolant temperature: 70 - 100 °C (158 - 212 °F)
 Park/neutral position switch: ON
 Electric load switch: OFF (Air conditioner, headlamp, rear window defogger)
On vehicles equipped with daytime light systems, if the parking brake is applied before the engine is
started the headlamp will not be illuminated.
 Steering wheel: Neutral (Straight-ahead position)
 Vehicle speed: Stopped
 Transmission: Warmed-up
- For models with CONSULT-III, drive vehicle until “A TF TEMP SE 1” in “DATA MONITOR” mode of “A/T” sys-
tem indicates less than 0.9V.
- For models without CONSULT-III, drive vehicle for 10 minutes.
OPERATION PROCEDURE
With CONSULT-III
1. Perform EC-85, "Accelerator Pedal Released Position Learning".
2. Perform EC-85, "
Throttle Valve Closed Position Learning".
3. Start engine and warm it up to normal operating temperature.
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

EC-86
< SERVICE INFORMATION >[VQ35DE]
BASIC SERVICE PROCEDURE
4. Check that all items listed under the topic PREP
ARATION (previously mentioned) are in good order.
5. Select “IDLE AIR VOL LEARN” in “WORK SUPPORT” mode.
6. Touch “START” and wait 20 seconds.
7. Make sure that “CMPLT” is displayed on CONSULT-III screen. If “CMPLT” is not displayed, Idle Air Vol- ume Learning will not be carried out successfully. In this case, find the cause of the incident by referring to
the DIAGNOSTIC PROCEDURE below.
8. Rev up the engine two or three times and make sure that idle speed and ignition timing are within the specifications.
Without CONSULT-III
NOTE:
It is better to count the ti me accurately with a clock.
 It is impossible to switch the di agnostic mode when an accelerator pedal position sensor circuit has
a malfunction.
1. Perform EC-85, "
Accelerator Pedal Released Position Learning".
2. Perform EC-85, "
Throttle Valve Closed Position Learning".
3. Start engine and warm it up to normal operating temperature.
4. Check that all items listed under the topic PREP ARATION (previously mentioned) are in good order.
5. Turn ignition switch OFF and wait at least 10 seconds.
6. Confirm that accelerator pedal is fully released, then turn ignition switch ON and wait 3 seconds.
7. Repeat the following procedure quickly 5 times within 5 seconds.
a. Fully depress the accelerator pedal.
b. Fully release the accelerator pedal.
8. Wait 7 seconds, fully depress the accelerator pedal and keep it for approx. 20 seconds until the MIL stops
blinking and turned ON.
9. Fully release the accelerator pedal within 3 seconds after the MIL turned ON.
10. Start engine and let it idle.
11. Wait 20 seconds.
12. Rev up the engine two or three times and make sure that idle speed and ignition timing are within the specifications.
13. If idle speed and ignition timing are not within the specification, Idle Air Volume Learning will not be carried out successfully. In this case, find the cause of the incident by referring to the DIAGNOSTIC PROCE-
DURE below.
DIAGNOSTIC PROCEDURE
If idle air volume learning cannot be performed successfully, proceed as follows:
ITEM SPECIFICATION
Idle speed 650 ± 50 rpm (in P or N position)
Ignition timing 15 ± 5 ° BTDC (in P or N position)
ITEM SPECIFICATION
Idle speed 650 ± 50 rpm (in P or N position)
Ignition timing 15 ± 5 ° BTDC (in P or N position)
SEC897C
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

TROUBLE DIAGNOSISEC-89
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
TROUBLE DIAGNOSIS
Trouble Diagnosis IntroductionINFOID:0000000001325927
INTRODUCTION
The engine has an ECM to control major systems such as fuel con-
trol, ignition control, idle air c
ontrol system, etc. The ECM accepts
input signals from sensors and instantly drives actuators. It is essen-
tial that both input and output si gnals are proper and stable. At the
same time, it is important that there are no malfunctions such as vac-
uum leaks, fouled spark plugs, or other malfunctions with the engine.
It is much more difficult to diagnose an incident that occurs intermit-
tently rather than continuously. Most intermittent incidents are
caused by poor electric connections or improper wiring. In this case,
careful checking of suspected circuits may help prevent the replace-
ment of good parts.
A visual check only may not find t he cause of the incidents. A road
test with CONSULT-III (or GST) or a circuit tester connected should
be performed. Follow the WORK FLOW on “WORK FLOW”.
Before undertaking actual checks, take a few minutes to talk with a
customer who approaches with a driveability complaint. The cus-
tomer can supply good information about such incidents, especially
intermittent ones. Find out what symptoms are present and under
what conditions they occur. A DIAGNOSTIC WORKSHEET like the
example on “DIAGNOSTIC WORKSHEET” should be used.
Start your diagnosis by looking for conventional malfunctions first.
This will help troubleshoot driveability malfunctions on an electroni-
cally controlled engine vehicle.
WORK FLOW
MEF036D
SEF233G
SEF234G
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

EC-92
< SERVICE INFORMATION >[VQ35DE]
TROUBLE DIAGNOSIS
Are they within the SP value?
Ye s > > G O T O 9 .
No >> GO TO 8.
8.DETECT MALFUNCTIONING PART BY TROUBL
E DIAGNOSIS - SPECIFICATION VALUE
Detect malfunctioning part according to EC-131
.
Is malfunctioning part detected?
Ye s > > G O T O 11 .
No >> GO TO 9.
9.DETECT MALFUNCTIONING SYSTEM BY SYMPTOM MATRIX CHART
Detect malfunctioning system according to EC-96, "
Symptom Matrix Chart" based on the confirmed symptom
in step 4, and determine the trouble diagnosis order based on possible causes and symptom.
>> GO TO 10.
10.DETECT MALFUNCTIONING PA RT BY DIAGNOSTIC PROCEDURE
Inspect according to Diagnostic Procedure of the system.
NOTE:
The Diagnostic Procedure in EC section described based on open circuit inspection. A short circuit inspection
is also required for the circuit check in the Diagnostic Procedure. For details, refer to Circuit Inspection in GI-
25, "How to Perform Efficient Diagnosis for an Electrical Incident".
Is malfunctioning part detected?
Ye s > > G O T O 11 .
No >> Monitor input data from related sensors or check voltage of related ECM terminals using CON-
SULT-III. Refer to EC-127, "
CONSULT-III Reference Value in Data Monitor Mode", EC-109, "ECM
Terminal and Reference Value".
11 .REPAIR OR REPLACE THE MALFUNCTIONING PART
1. Repair or replace the malfunctioning part.
2. Reconnect parts or connectors disconnected during Diagnostic Procedure again after repair and replace- ment.
3. Check DTC. If DTC is displayed, erase it, refer to EC-55, "
Emission-Related Diagnostic Information".
>> GO TO 12.
12.FINAL CHECK
When DTC was detected in step 2, perform DTC Conf irmation Procedure or Overall Function Check again,
and then make sure that the malfunction have been repaired securely.
When symptom was described from the customer, refer to confirmed symptom in step 3 or 4, and make sure
that the symptom is not detected.
OK or NG
NG (DTC*1 is detected)>>GO TO 10.
NG (Symptom remains)>>GO TO 6.
OK >> 1. Before returning the vehicle to the customer, make sure to erase unnecessary DTC*
1 in ECM
and TCM (Transmission Control Module). (Refer to EC-55, "
Emission-Related Diagnostic
Information" and AT-38, "OBD-II Diagnostic Trouble Code (DTC)".)
2. If the completion of SRT is needed, drive vehicl e under the specific driving pattern. Refer to
EC-55, "
Emission-Related Diagnostic Information".
3. INSPECTION END
*1: Include 1st trip DTC.
*2: Include 1st trip freeze frame data.
DIAGNOSTIC WORKSHEET
Description
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

EC-94
< SERVICE INFORMATION >[VQ35DE]
TROUBLE DIAGNOSIS

If DTC U1000 or U1001 is displayed with other DT C, first perform the trouble diagnosis for DTC
U1000, U1001. Refer to EC-146
.
 If DTC U1010 is displayed with other DTC, fi rst perform the trouble diagnosis for DTC U1010.
Refer to EC-148
.
*: Models with ICC.Priority Detected items (DTC)
1  U1000 U1001 CAN communication line  U1010 CAN communication
 P0101 P0102 P0103 Mass air flow sensor
 P0112 P0113 P0127 Intake air temperature sensor
 P0117 P0118 P0125 Engine coolant temperature sensor
 P0128 Thermostat function
 P0122 P0123 P0222 P0223 P1225 P1226 P2135 Throttle position sensor
 P0181 P0182 P0183 Fuel tank temperature sensor
 P0327 P0328 Knock sensor
 P0335 Crankshaft position sensor (POS)
 P0340 P0345 Camshaft position sensor (PHASE)
 P0460 P0461 P0462 P0463 Fuel level sensor
 P0500 Vehicle speed sensor
 P0605 ECM
 P0643 Sensor power supply
 P0700 TCM
 P0705 Park/neutral position (PNP) switch
 P0850 Park/neutral position (PNP) switch
 P1610 - P1615 NATS
 P2122 P2123 P2127 P2128 P2138 Accelerator pedal position sensor
2  P0031 P0032 P0051 P0052 Air fuel ratio (A/F) sensor 1 heater  P0037 P0038 P0057 P0058 Heated oxygen sensor 2 heater
 P0075 P0081 Intake valve timing control solenoid valve
 P0130 P0131 P0132 P0133 P0150 P0151 P0152 P0153 P2A00 P2A03 Air fuel ratio (A/F) sensor 1
 P0137 P0138 P0139 P0157 P0158 P0159 Heated oxygen sensor 2
 P0441 EVAP control system purge flow monitoring
 P0443 P0444 P0445 EVAP canister purge volume control solenoid valve
 P0447 P0448 EVAP canister vent control valve
 P0451 P0452 P0453 EVAP control system pressure sensor
 P0550 Power steering pressure sensor
 P0603 ECM power supply
 P0710 P0717 P0720 P0731 P0732 P0733 P0734 P0735 P0740 P0744 P0745 P1730 P1752 P1757 P1762 P1767
P1772 P1774 A/T related sensors, solenoid valves and switches
 P1217 Engine over temperature (OVERHEAT)
 P1805 Brake switch
 P2100 P2103 P2118 Electric throttle control actuator
 P2101 Electric throttle control function
3  P0011 P0021 Intake valve timing control  P0171 P0172 P0174 P0175 Fuel injection system function
 P0300 - P0306 Misfire
 P0420 P0430 Three way catalyst function
 P0442 EVAP control system (SMALL LEAK)
 P0455 EVAP control system (GROSS LEAK)
 P0456 EVAP control sys tem (VERY SMALL LEAK)
 P0506 P0507 Idle speed control system
 P1148 P1168 Closed loop control
 P1211 TCS control unit
 P1212 TCS communication line
 P1421 COLD START CONTROL
 P1564 ICC steering switch/ASCD steering switch
 P1568 ICC command valve*
 P1572 ICC brake switch/ASCD brake switch
 P1574 ICC vehicle speed sensor/ASCD vehicle speed sensor
 P1715 Turbine revolution sensor
 P2119 Electric throttle control actuator
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

TROUBLE DIAGNOSISEC-95
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Fail-Safe ChartINFOID:0000000001325929
When the DTC listed below is detected, the EC
M enters fail-safe mode and the MIL lights up.
 When there is an open circuit on MIL circuit, the ECM c annot warn the driver by MIL lighting up when there
is malfunction on engine control system.
Therefore, when electrical controlled throttle and pa rt of ECM related diagnoses are continuously detected
as NG for 5 trips, ECM warns the driver that engi ne control system malfunctions and MIL circuit is open by
means of operating fail-safe function.
The fail-safe function also operates when above diagnos es except MIL circuit are detected and demands the
driver to repair the malfunction.
DTC No. Detected items Engine operating condition in fail-safe mode
P0102
P0103 Mass air flow sensor circuit Engine speed will not rise more than 2,400 rpm due to the fuel cut.
P0117
P0118 Engine coolant tempera-
ture sensor circuit Engine coolant temperature will be determined by ECM based on the following condition.
CONSULT-III displays the engine coolant temperature decided by ECM.
Condition Engine coolant temperature decided
(CONSULT-III display)
Just as ignition switch is turned ON
or START 40
°C (104 °F)
Approx. 4 minutes or more after
engine starting. 80
°C (176 °F)
Except as shown above 40 - 80
°C (104 - 176 °F)
(Depends on the time)
When the fail-safe system for engine coolant temperature sensor is activated, the cooling
fan operates while engine is running.
P0122
P0123
P0222
P0223
P2135 Throttle position sensor The ECM controls the electric throttle control actuator in regulating the throttle opening in
order for the idle position to be within +10 degrees.
The ECM regulates the opening speed of the throttle valve to be slower than the normal
condition.
So, the acceleration will be poor.
P0643 Sensor power supply ECM stops the electric throttle control actuator control, throttle valve is maintained at a fixed opening (approx. 5 degrees) by the return spring.
P2100
P2103 Throttle control motor relay ECM stops the electric throttle control actuator control, throttle valve is maintained at a
fixed opening (approx. 5 degrees) by the return spring.
P2101 Electric th rottle control
function ECM stops the electric throttle control actuator control, throttle valve is maintained at a
fixed opening (approx. 5 degrees) by the return spring.
P2118 Throttle control motor ECM stops the electric throttle control actuator control, throttle valve is maintained at a fixed opening (approx. 5 degrees) by the return spring.
P2119 Electric thro ttle control ac-
tuator (When electric throttle control actuator does not function properly due to the return spring
malfunction:)
ECM controls the electric throttle actuator by regulating the throttle opening around the
idle position. The engine speed will not rise more than 2,000 rpm.
(When throttle valve opening angle in fail-safe mode is not in specified range:)
ECM controls the electric throttle control actuator by regulating the throttle opening to 20
degrees or less.
(When ECM detects the throttle valve is stuck open:)
While the vehicle is driving, it slows down gradually by fuel cut. After the vehicle stops, the
engine stalls.
The engine can restart in N or P position, and engine speed will not exceed 1,000 rpm or
more.
P2122
P2123
P2127
P2128
P2138 Accelerator pedal position
sensor
The ECM controls the electric throttle control actuator in regulating the throttle opening in
order for the idle position to be within +10 degrees.
The ECM regulates the opening speed of the throttle valve to be slower than the normal
condition.
So, the acceleration will be poor.
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

EC-96
< SERVICE INFORMATION >[VQ35DE]
TROUBLE DIAGNOSIS
Symptom Matrix Chart
INFOID:0000000001325930
SYSTEM — BASIC ENGINE CONTROL SYSTEM
Engine operating condition in fail-safe mode Engine speed will not rise more than 2,500 rpm due to the fuel cut
SYMPTOM
Reference
page
HARD/NO START/RESTART (EXCP. HA)
ENGINE STALL
HESITATION/SURGING/FLAT SPOT
SPARK KNOCK/DETONATION
LACK OF POWER/POOR ACCELERATION
HIGH IDLE/LOW IDLE
ROUGH IDLE/HUNTING
IDLING VIBRATION
SLOW/NO RETURN TO IDLE
OVERHEATS/WATER TEMPERATURE HIGH
EXCESSIVE FUEL CONSUMPTION
EXCESSIVE OIL CONSUMPTION
BATTERY DEAD (UNDER CHARGE)
Warranty symptom code AA AB AC AD AE AF AG AH AJ AK AL AM HA
Fuel Fuel pump circuit 11232 22 3 2 EC-558
Fuel pressure regulator system 334444444 4EC-87
Fuel injector circuit 11232 22 2EC-552
Evaporative emission system 334444444 4EC-40
Air Positive crankcase ventilation sys-
tem 334444444 41
EC-51
Incorrect idle speed adjustment 1 1 1 1 1 EC-80
Electric throttle control actuator 112332222 2 2EC-494,
EC-504
IgnitionIncorrect ignition timing adjustment33111 11 1 EC-80
Ignition circuit 11222 22 2EC-569
Power supply and ground circuit 22333 33 23 EC-140
Mass air flow sensor circuit
1
12 2
222 2 EC-175,
EC-182
Engine coolant temperature sensor circuit
333
EC-193,
EC-204
Air fuel ratio (A/F) sensor EC-220
EC-220
EC-228
EC-236
EC-532
Throttle position sensor circuit
22EC-198
,
EC-302
,
EC-447
,
EC-449
,
EC-518
Accelerator pedal position sensor circuit 3 2 1 EC-424
,
EC-506
,
EC-512
,
EC-524
Knock sensor circuit 2 3 EC-315
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
