3. Check voltage between intake sensor harness connector M254 terminal 2 and ground.
OK or NG
OK >> GO TO 2.
NG >> GO TO 4.
2.CHECK CIRCUIT CONTINUITY BETWEEN INTAKE SENSOR AND UNIFIED METER AND A/C AMP.
1. Turn ignition switch OFF.
2. Disconnect unified meter and A/C amp. connector.
3. Check continuity between intake sensor harness connector M254 terminal 1 and unified meter and A/C amp. harness con-
nector M57 terminal 49.
OK or NG
OK >> GO TO 3.
NG >> Repair harness or connector.
3.CHECK INTAKE SENSOR
Refer to "Intake Sensor".
OK or NG
OK >> 1. Replace unified meter and A/C amp. 2. Go to self-diagnosis ATC-43, "
Self-Diagnosis Function" and perform self-diagnosis STEP-2.
Confirm that code No. 20 is displayed.
NG >> 1. Replace intake sensor. 2. Go to self-diagnosis ATC-43, "
Self-Diagnosis Function" and perform self-diagnosis STEP-2.
Confirm that code No. 20 is displayed.
4.CHECK CIRCUIT CONTINUITY BETWEEN INTAKE SENSOR AND UNIFIED METER AND A/C AMP.
1. Turn ignition switch OFF.
2. Disconnect unified meter and A/C amp. connector.
3. Check continuity between intake sensor harness connector M254 terminal 2 and unified meter and A/C amp. harness con-
nector M57 terminal 41.
4. Check continuity between intake sensor harness connector M254 terminal 2 and ground.
OK or NG
OK >> 1. Replace unified meter and A/C amp. 2. Go to self-diagnosis ATC-43, "
Self-Diagnosis Function" and perform self-diagnosis STEP-2.
Confirm that code No. 20 is displayed.
NG >> Repair harness or connector.
COMPONENT INSPECTION
Intake Sensor
2 – Ground : Approx. 5 V
RJIA2031E
1 – 49 : Continuity should exist.
RJIA2032E
2 – 41 : Continuity should exist.
2 – Ground : Continuity should not exist.
RJIA2033E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

ATC-96
< SERVICE INFORMATION >
TROUBLE DIAGNOSIS
After disconnecting intake sensor connector M254, measure resis-
tance between terminals 1 and 2 at sensor side. Refer to the table
below.
If NG, replace intake sensor.
Temperature °C ( °F) Resistance k Ω
− 15 (5) 12.34
− 10 (14) 9.62
− 5 (23) 7.56
0 (32) 6.00
5 (41) 4.80
10 (50) 3.87
15 (59) 3.15
20 (68) 2.57
25 (77) 2.12
30 (86) 1.76
35 (95) 1.47
40 (104) 1.23 45 (113) 1.04
RJIA2034E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

AMBIENT SENSORATC-99
< SERVICE INFORMATION >
C
DE
F
G H
I
K L
M A
B
AT C
N
O P
AMBIENT SENSOR
Removal and InstallationINFOID:0000000001328202
REMOVAL
1. Remove front grille. Refer to EI-22.
2. Disconnect ambient sensor c onnector, and then remove ambi-
ent sensor.
INSTALLATION
Installation is basically the reverse order of removal.
RJIA2016E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

ATC-100
< SERVICE INFORMATION >
IN-VEHICLE SENSOR
IN-VEHICLE SENSOR
Removal and InstallationINFOID:0000000001328203
REMOVAL
1. Remove instrument driver lower panel. Refer to IP-10.
2. Remove mounting screw, and then remove in-vehicle sensor.
INSTALLATION
Installation is basically the reverse order of removal.
RJIA2036E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

SUNLOAD SENSORATC-101
< SERVICE INFORMATION >
C
DE
F
G H
I
K L
M A
B
AT C
N
O P
SUNLOAD SENSOR
Removal and InstallationINFOID:0000000001328204
REMOVAL
1. Remove front defroster grille (RH). Refer to IP-10.
2. Disconnect sunload sensor connector, and then remove the sunload sensor.
INSTALLATION
Installation is basically the reverse order of removal.
RJIA2026E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

ATC-102
< SERVICE INFORMATION >
INTAKE SENSOR
INTAKE SENSOR
Removal and InstallationINFOID:0000000001328205
REMOVAL
1. Remove low-pressure pipe 2 and high-pressure pipe 3. Refer to ATC-133, "Removal and Installation of
Low-Pressure Pipe 2 and High-pressure Pipe 3".
CAUTION:
Cap or wrap the joint of evaporator, low-pressure pipe 1 and high-pressure pipe 2 with suitable
material such as vinyl tape to avoid the entry of air.
2. Slide evaporator to passenger side, and then remove intake sensor.
INSTALLATION
Installation is basically the reverse order of removal.
CAUTION:
 Replace O-rings of low-pressure pipe 1, 2 and high-p ressure pipe 2, 3 with new ones, and then apply
compressor oil to it when installing it.
 Mark the mounting position of intake sensor bracket prior to removal so that the reinstalled sensor
can be located in the same position.
 Female-side piping connection is thin and easy to deform. Slowly insert the male-side piping
straight in axial direction.
 Insert piping securely until a click is heard.
 After piping connection is comp leted, pull male-side piping by hand to make sure that connection
does not come loose.
 When recharging refrigerant, check for leaks.
