2008 INFINITI FX35 Brake System

SYSTEM DESCRIPTIONBRC-11
< SERVICE INFORMATION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
 Stopping distance may be longer than that of vehicles without ABS when vehicle drives on rough, gravel, or
snow-covered (fresh, deep snow) roads.
EBD
 The Electronic Brake Distribution is a function that detects subtle slippages between front and rear wheels
during braking, and it improves handling stability by elec tronically controlling the brake fluid pressure which
results in reduced rear wheel slippage.
 In case of electrical system malfunction, the fail- safe function is activated, EBD and ABS becomes inopera-
tive, and ABS warning lamp and brake warning lamp are turned on.
 Electrical system diagnosis by CONSULT-III is available.
 During EBD operation, brake pedal lightly vibrates and a mechanical noise may be heard. This is normal.
 When starting engine, or just after starting vehicle, brake pedal may vibrate or motor operating noises may
be heard from engine compartment. This is a normal status of operation check.
 Stopping distance may be longer than that of vehicles without EBD when vehicle drives on rough, gravel, or
snow-covered (fresh, deep snow) roads.
Fail-Safe FunctionINFOID:0000000001327662
VDC / TCS SYSTEM
In case of malfunction in the VDC/TCS system, VDC O FF indicator lamp and SLIP indicator lamp are turned
on, and the condition of vehicle is the same as the c ondition of vehicles without VDC/TCS system. In case of
malfunction in the VDC/TCS system, the ABS control c ontinues to operate normally without VDC/TCS control.
CAUTION:
If the fail-safe function is acti vated, then perform the self-diagnos is for VDC/TCS/ABS control system.
ABS, EBD SYSTEM
In case of electrical malfunctions with the ABS, ABS warning lamp, VDC OFF indicator lamp and SLIP indica-
tor lamp will turn on. In case of electrical malfunc tions with the EBD, brake warning lamp, ABS warning lamp,
VDC OFF indicator lamp and SLIP indicator lamp wil l turn on. Simultaneously, the VDC/TCS/ABS become one
of the following conditions of the fail-safe function.
 For malfunction of ABS, only the EBD is activated and t he condition of vehicle is the same condition of vehi-
cles without TCS/ABS system.
NOTE:
ABS self-diagnosis sound may be heard. That is a no rmal condition because a self-diagnosis for “Ignition
switch ON” and “The first starting” are being performed.
 For malfunction of EBD, EBD and ABS become inoperative, and the condition of vehicle is the same as the
condition of vehicles wit hout TCS/ABS, EBD system.
