INTRODUCTION
RADIO
SCAN FUNCTION
(station scanning)
Press button SCAN to start scanning the
stations in the frequency band selected
(FM, AM, MW, LW). Each station found
will be heard for a few seconds and the
relevant frequency is shown on the dis-
play.
During scanning, the display will show the
message “TUNER SCAN”, with the word
“SCAN” flashing.
When the SCAN function is on, all the
other functions are cancelled.
The SCAN function is interrupted in the
following cases:
– pressing again button SCAN
– turning the sound system off
– changing the sound source (Radio, CD
Changer)
– changing the selected frequency band (or
the storage block)
– pressing one presetting button
– turning the AutoSTore function on (au-
tomatic storage)SCANNING PRESET STATIONS
Keep button SCAN pressed for at least
2 seconds to start scanning the preset sta-
tions in the current frequency band;
– FM: FM 1, FM 2, …., FM II 1, FM II 2,…
FM III 1, FM III 2,… FMAST 1,
FMAST 2,….
– AM: MW 1, MW 2, …. MW 6, LW 1,
LW 2, …. LW 6, AMAST 1,
AMAST 2,…
Each preset station will be heard for a few
seconds and its frequency shown on the
display.
The Scan function is interrupted in the fol-
lowing cases:
– pressing again button SCAN
– turning the sound system off
– pressing one presetting button
– turning the AutoSTore function on (au-
tomatic storage)
– changing the sound source (Radio, CD
Changer)
– changing the selected frequency band or
the FM level MANUAL TUNING
This allows manual station searching in the
chosen band. To turn this function on use
the MENU (see paragraph “Manual station
tuning on/off (TUNING SEEK) in section
“Radio”).
For manual tuning proceed as follows:
– Select the band using the button BAND
AS: FM1, FM2, FM3, MW or LW.
– Press briefly and repeatedly button Èor
Í.
Keeping one of the buttons Èor Í
pressed obtains fast forward seeking,
which is stopped when the button is re-
leased.

17
QUICK
GUIDE
FUNCTIONS AND
ADJUSTMENTS
COMPACT
DISC PLAYER
MP3 CD
PLAYER
CD
CHANGER
INTRODUCTION
RADIO
MANUAL STATION STORAGE
Use buttons from 1 to 6 to store the sta-
tion being heard in the selected band.
Keep pressed one of these buttons (1 to
6), when station storing is completed the
display will show the corresponding but-
ton number and a confirmation beep will
be given.AUTOSTORE FUNCTION
(automatic station storage)
To switch on the AutoSTore function (au-
tomatic station storage), keep button
BAND
AS. With this function the radio au-
tomatically stores the stations with the
strongest signal in decreasing order of in-
tensity in the FMAST frequency band (if
tuned on FM band) or AMAST (if tuned on
AM band).
IMPORTANT Activating the AutoSTore
function cancels the stations stored pre-
viously in the FMAST or AMAST band.
During automatic storage the display
shows “TUNER FMAST” or “TUNER
AMAST” if TUNER mode (Radio) with FM
or AM frequency band is selected. To in-
terrupt the automatic station storage,
press button BAND
ASagain: the radio will
automatically tune to the station heard be-
fore activation of the AutoSTore function.LISTENING TO STORED
STATIONS
Proceed as follows:
– select the required frequency band and
the storage block (FM1, FM2, FM3,
FMAST, MW, LW, AMAST);
– briefly press one of the six station stor-
age buttons.
The display will show the station name (if
present) and frequency, whereas at the
bottom of the display is shown “Pn”
where n is the number corresponding to
the current station.
In bands FM1, FM2 and FM3, if reception
is poor or weak and the AF alternative fre-
quency search function is active, the sta-
tion with the strongest signal that is broad-
casting the same programme will be
sought automatically.

QUICK
GUIDE
18
FUNCTIONS AND
ADJUSTMENTS
COMPACT
DISC PLAYER
MP3 CD
PLAYER
CD
CHANGER
INTRODUCTION
RADIO
When the signal of the RDS station tuned
weakens, the following two cases may oc-
cur:
– With “AF SWITCHING: ON” the RDS
system activates automatic tuning of the
optimum frequency of the station chosen,
with the stations enabled, therefore the
radio is automatically tuned to the station
with the strongest signal that is broad-
casting the same programme. During the
journey it will thus be possible to contin-
ue listening to the station chosen with-
out having to change the frequency when
changing area. Of course, the station be-
ing listened to must be receivable in the
area the car is crossing.
– With “AF SWITCHING: OFF” the ra-
dio will not tune the strongest station au-
tomatically and it will have to be found
manually using the tuner buttons. AF FUNCTION
(alternative frequency search)
To turn the AF function on/off, press
briefly button AF
PTY. RDS name (if avail-
able) will stay on the display and if the
function is on the wording is shown.
– “AF SWITCHING: ON” = alternative
frequency search on
– “AF SWITCHING: OFF” = alternative
frequency search off.TA FUNCTION
(traffic information)
Certain stations in the FM band (in stor-
age blocks FM1, FM2, FM3 and FMAST)
are enabled to also broadcast information
about traffic conditions. During a traffic
bulletin, the message “TRAFFIC INFO”
will be displayed alternate with the cur-
rent one (e.g.: station name).
To turn the TA function on/off, press
briefly button TA. When the TA function
is on the display will show the message
“TA-ON”.
When the TA function is on, an incoming
traffic bulletin will stop temporarily the
current broadcasted programme or the
CD being played. Switching from the se-
lected station to the station broadcasting
traffic announcements is only possible if
connection for EON function is enabled.

19
QUICK
GUIDE
FUNCTIONS AND
ADJUSTMENTS
COMPACT
DISC PLAYER
MP3 CD
PLAYER
CD
CHANGER
INTRODUCTION
RADIO
PTY FUNCTION
(selecting a type of programme)
Several radio station offer the programme
type service (PTY) within the FM band
(FM1, FM2, FM3). For example, stations
broadcasting info/news will display as PTY
code the message “NEWS”.
The PTY function activates a seek filter
that tunes only stations broadcasting pro-
grammes with the preselected PTY code
(e.g.: “POP”).
To turn on the PTY function, keep button
AF
PTYpressed.
The programme types offered by a radio
station may vary according to the pro-
gramme:
NEWS News and magazine
AFFAIRS Politics and
news
INFO Special information
programmes
SPORT Sport
programmes
EDUCATE Educational
programmes
DRAMA Radio dramas
and literature
CULTURE Culture, church
and religion
SCIENCE ScienceVARIED Variety
POP M Pop music
(hits)
ROCK M Rock music
EASY M Easy music
LIGHT M Light classic
music
CLASSICS Classic music
OTHER M Other types of music
(e.g. folklore)
WEATHER Weather report
FINANCE Finance news
CHILDRENChild’s programmes
SOCIAL Social information
RELIGIONReligion and philoso-
phy
PHONE INListener’s calls (other
than “
PHONE IN” func-
tion active only with
hands-free kit connec-
tion for mobile phone)
TRAVEL Tourist’s
informationLEISURE Free time and hobbies
JAZZ Jazz
COUNTRY Country music
NATION M National
broadcasting
OLDIES Golden Oldies
FOLK M Folk music
DOCUMENT Special reports
PTY automatic seek
To select a PTY through automatic seek,
select the required type of programme
from the list stored and then start auto-
matic seek. Procedure is described in next
paragraphs.
PTY function reactivation
Press button AF
PTYfor over 2 seconds.
The last programme type selected (e.g.
“POP”) will then be displayed.

QUICK
GUIDE
20
FUNCTIONS AND
ADJUSTMENTS
COMPACT
DISC PLAYER
MP3 CD
PLAYER
CD
CHANGER
INTRODUCTION
RADIO
PTY setting
Press button AF
PTYfor over 2 seconds to
display the PTY code of the current sta-
tion. Select the required code by turning
the button/knob ON/OFF and then press
button Èor Íto start automatic seek-
ing of stations with the PTY code select-
ed. Automatic seek will stop automatical-
ly to the next station broadcasting the PTY
programme selected. The type of pro-
gramme will be displayed (e.g. “POP”) with
the word “PTY” flashing.
IMPORTANT If no station is broadcasting
the selected PTY, the last station will be
tuned and the PTY function is aborted.
PTY function deactivation
After entering the PTY mode, if no oper-
ation is performed within 10 seconds, the
radio returns to the mode active before
pressing the AF
PTYbutton and it will store
the last PTY code selected. MENU
MENU
RDSbutton options
To activate the Menu, press briefly the
button MENU
RDS.
In this way you open the first level Menu.
To open the second level menu keep the
MENU
RDSbutton pressed for over 2 sec-
onds.
To scroll the Menu options press repeat-
edly the MENU
RDSbutton.
First levelMenu options are the follow-
ing:
1 MANUAL TUNING SEEK on/off
2 CD Compression
3 Confirmation beep (BEEP)
4 Tuning sensitivity adjustment (SENS
DX/LO)
5 News programmes on/off (NEWS)
6 Automatic volume adjustment with car
speed (SVC)
7 Traffic announcements tuning (EON
TA)
8 Loudness on/off (LOUD- NESS)
9 CD naming (CD NAMING) (only in CD
Changer mode);
10 CD naming/track selection (TPM =
Track Program Memory)
Press buttons Èor Íto activate/deacti-
vate the function selected.Second levelMenu options are the fol-
lowing:
1 Time display of the current RDS station
(if available)
2 “Audio distortion clipper” on/off (AU-
DIO CLIP DETECT)
3 Max volume setting at switching on
(MAX VOLUME)
4 Telephone volume adjustment (PHONE)
5 AUTO setting selection which enables
to set radio turning on/off depending on
car ignition/switching off.
Use the button/knob ON/OFF to turn
on/off the function selected.
NOTE Each time you pass to next setting,
the previous one will be stored.

21
QUICK
GUIDE
FUNCTIONS AND
ADJUSTMENTS
COMPACT
DISC PLAYER
MP3 CD
PLAYER
CD
CHANGER
INTRODUCTION
RADIO
AVAILABLE SETTINGS
First level Menu options
1 - TUNING SEEK
(manual tuning on/off)
This option enables to seek manually
(MANUAL) or automatically (AUTO) the
stations stored.
To switch between manual and automat-
ic seek use buttons Èor Í.
The display will show the current tuning
seek mode:
– “TUNING SEEK: AUTO”: automatic
seek on
– “TUNING SEEK: MANUAL”: manual
seek on.2 - CD Compression
This option enables to optimize the sound
level according to the music being played
by the CD.
Use buttons Èor Íto turn this function
on/off.
The display will show the current function
condition:
– “COMPRESSION: ON” = function on
– “COMPRESSION: OFF” = function off
3 - BEEP (confirmation beep)
The system provides the BEEP function ac-
tive (message “ROGER BEEP-ON” on the
display).
This function gives sound confirmation
(BEEP) when pressing buttons.
Use buttons Èor Íto turn this function
on/off.
The display will show the current function
condition:
– “ROGER BEEP: ON” = function on
– “ROGER BEEP: OFF” = function off.4 - SENS DX/LO
(tuning sensitivity adjustment)
With this function it is possible to change
the sensitivity of automatic station tun-
ing. When low sensitivity is set “SENSI-
TIVITY: LOCAL” only stations with ex-
cellent reception are sought; when high
sensitivity is set “SENSITIVITY: DIS-
TANT” all stations are sought. Therefore,
if the car is in an area with a considerable
number of stations and you want to
choose only those with a strong signal, set
to low sensitivity “SENSITIVITY: LOCAL”.
Use buttons Èor Íto turn this function
on/off.
The display will show the current function
condition:
– “SENSITIVITY: LOCAL” = low sensi-
tivity
– “SENSITIVITY: DISTANT” = high sen-
sitivity.

QUICK
GUIDE
22
FUNCTIONS AND
ADJUSTMENTS
COMPACT
DISC PLAYER
MP3 CD
PLAYER
CD
CHANGER
INTRODUCTION
RADIO
5 - NEWS (new programmes on/off)
This function is similar to the TA function:
with FM station tuned and NEWS function
active if a news bulletin is broadcast, the
sound system will:
– set the same volume as for TA function,
if TUNER (Radio) is on;
– switch the current audio source (CD or
CD Changer) to TUNER (Radio) and set
the same volume as for TA function.
It is necessary that in TUNER mode (Ra-
dio), the radio is tuned to a FM station
broadcasting the NEWS code.
Use buttons Èor Íto turn this function
on/off.
The display will show the current function
condition:
– “NEWS: ON” = function on
– “NEWS: OFF” = function off6 - SVC (automatic volume
adjustment with car speed)
The SVC function makes it possible to au-
tomatically adapt the volume level to the
speed of the car, increasing it as the speed
increases to maintain the ratio with the
noise level inside the passenger compart-
ment.
Press Èor Íto change the SVC setting,
from OFF to the gain level (1 to 7) se-
lected. High gain level values correspond
to high volume levels when the car speed
increases.
The display will show the current function
condition:
– “SPEED VOLUME OFF” = function off
– “SPEED VOLUME: +3” = function on
and gain level set.7 - EON TA DX/LO (traffic
announcements tuning sensitivity)
This function enables to change the re-
ception sensitivity of radio stations broad-
casting traffic announcements.
Use buttons Èor Íto turn this function
on/off.
The display will show the current function
condition:
– “TRAFFIC: LOCAL” = low sensitivity
– “TRAFFIC: DISTANT” = high sensitivi-
ty
8 - LOUDNESS (loudness on/off)
The Loudness function improves the
sound volume when listening at low lev-
el, increasing the basses and trebles.
Use buttons Èor Íto turn this function
on/off.
The display will show the current function
condition:
– “LOUDNESS: ON” = loudness on
– “LOUDNESS: OFF” = loudness off

23
QUICK
GUIDE
FUNCTIONS AND
ADJUSTMENTS
COMPACT
DISC PLAYER
MP3 CD
PLAYER
CD
CHANGER
INTRODUCTION
RADIO
9 - CD NAMING
(allocating a name to the CD)
(only in CD Changer mode)
This function shall be used to give a name
(max. name length is 8 characters) to the
CDs contained in the CD Changer.
This function can be selected only if in CD
Changer mode.
To name a CD (CD Naming) proceed as
follows:
– the display shows “Name 1:”
– use the button/knob ON/OFF to select
the CD (1 to 10) to name (only active if
all the 10 memories for CD names are
used);
– use button Íto confirm the CD to re-
name
– the first character of the CD name will
flash to show the cursor position
– use the button/knob ON/OFF to select
the letters (“A” to “Z”) for composing the
CD name– use button Íor Èto move the cursor
through the characters
– press the MENU
RDSbutton to confirm
the CD name and to go to the TPM (Track
Program Memory) function
– the display will show as standard the
message “PLAY TRACK: ALL”; selecting
the TPM option “ALL”, the display will
show the message “PLAY TRACK: ALL”;
otherwise the message “PLAY TRACK: 10
– Y or N” (YES or NO) will be displayed
– use the button/knob ON/OFF to select
between ALL, 1, 2, 3 … max track no.
– use button Íor Èto enter or to ex-
clude the number of the current track
from the TPM list
– press the
RDSMENU button to confirm
the CD playlist thereby moving to the next
menu function10 - TPM
(CD naming/track selection)
This function can be selected only if a
Compact Disc is loaded.
If the CD already has a name, this will be
shown on the display.
The TPM option enables the following:
– give a name to 10 CDs with max. 12
characters
– to select played tracks (in the original se-
quence and up to 99 max.)
Every CD is identified by the total play-
back time and by the total number of
tracks.
IMPORTANT When entering name or
TPM, the radio will return to the current
source without storing modifications if no
button is pressed for at least 20 seconds.
