2008 DODGE DAKOTA Owners Manual

Then proceed with Step 4 under ªProgramming
HomeLink.º earlier in this section.
Using HomeLinkT
To operate, simply press and release the programmed
HomeLinktbutton. Activation will now occur for the
trained device (i.e. garage door opener, gate operator,
security system, entry door lock, home/office lighting,
etc. The hand-held transmitter of the device may also be
used at any time.
Reprogramming a Single HomeLinkTButton
To re-program a channel that has been previously
trained, follow these steps:
1. Turn the ignition switch to the ON/RUN position.
2. Press and hold the desired HomeLinktbutton for 20
seconds until the indicator(s) starts to flash.Do not
release the button.3.Without releasing the button,proceed with PRO-
GRAMMING HOMELINK Step #2 and follow all remain-
ing steps.
Security
It is advised to erase all channels before you sell or turn
in your vehicle.
To do this, press and hold the two outside buttons for 20
seconds until the indicators begin to flash. Note that all
channels will be erased. Individual channels cannot be
erased.
The HomeLinktUniversal Transceiver is disabled when
the Vehicle Theft Alarm is active.
Troubleshooting Tips
If you are having trouble programming HomeLinkt, here
are some of the most common solutions:
²Replace the battery in the original transmitter.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137
3

²Press the Learn Button on the Garage Door Opener to
complete the training for Rolling Code.
²Did you unplug the device for training, and remember
to plug it back in?
If you are have any problems, or require assistance,
please call toll-free 1±800±355±3515 or, on the Internet at
www.HomeLink.com for information or assistance.
General Information
This device complies with FCC rules part 15 and Industry
Canada RSS-210. Operation is subject to the following
two conditions:
1. This device may not cause harmful interference
2. This device must accept any interference that may be
received including interference that may cause undesired
operationNOTE:The transmitter has been tested and it complies
with FCC and IC rules. Changes or modifications not
expressly approved by the party responsible for compli-
ance could void the user 's authority to operate the
device.
The term ªIC:º before the certification/registration num-
ber only signifies that Industry Canada technical specifi-
cations were met.ELECTRICAL POWER OUTLETS
This vehicle has two 12V auxiliary power outlets that can
provide up to 20 Amps of current for accessories de-
signed for use with standard power outlet adapters. The
outlets are located in the instrument panel, below the
temperature control setting knob, and the other inside the
full - size center console. When the optional Cigar Lighter
heating element is used, it heats when pushed in and
138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

pops out automatically when ready for use.To preserve
the heating element, do not hold the lighter in the
heating position.
The instrument panel outlet can be reconfigured by the
customer to operate only when the ignition is On (switch
battery fed) or with the ignition switch On/Off (battery
fed) to allow for cellular phone charging and/or opera-
tion while the ignition is Off. This can be done by moving
the power outlet (switchable) fuse (fuse #22) from the
inboard position to the outboard position.
NOTE:All accessories connected to these outlets should
be removed or turned OFF when the vehicle is not in use
to protect the battery against discharge (unless the cus-
tomer has reconfigured the fuse block to switched battery
feed).Electrical Outlet Use With Engine OFF
(Battery Fed Configuration)
CAUTION!
²Many accessories that can be plugged in draw
power from the vehicle's battery, even when not in
use (i.e. cellular phones, etc.). Eventually, if
plugged in long enough, the vehicle's battery will
discharge sufficiently to degrade battery life
and/or prevent engine starting.
²Accessories that draw higher power (i.e. coolers,
vacuum cleaners, lights, etc.), will discharge the
battery even more quickly. Use these only inter-
mittently and with greater caution.
²After the use of high power draw accessories, or
long periods of the vehicle not being started (with
accessories still plugged in), the vehicle must be
driven a sufficient length of time to allow the
generator to recharge the vehicle's battery.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 139
3

FLOOR CONSOLE Ð IF EQUIPPED
Floor Console Features
The Floor Console between the driver's and front pas-
senger's seat has the following features:
²Miscellaneous storage compartments
²3 cup holders (2 are removable)
²iPod/Phone storage bin
²12 Volt power outlet inside storage compartment
²Side open armrest lid
²Tissue holder & 2 pen holders
²Coin slots
The coin slots are located under the instrument panel
center stack.
Storage Compartments
Some miscellaneous storage compartments and cup
holders are both removable and dishwasher safe for
cleaning purposes (upper rack of dishwasher only). Vari-
ous storage compartments provide versatile and useful
storage. A coin holder is also provided inside the driver
side storage bin.
Power Outlet and Portable Phone Storage
The console is equipped with a power outlet and an
iPod/ phone storage bin. The phone storage bin can be
used when easy access to the phone is needed. Also, the
power outlet inside console compartment can be used to
charge the phone while it is being stored in the bin. The
power outlet may be used for any portable item with a
standard 12 volt power plug.
Side Open Armrest Lid
Pressing the button on the left side of the console opens
the console armrest lid. The armrest lid will remain open
140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

until armrest lid is closed manually by pressing the lid
back into place. Two pen holders are provided on the
inside of the armrest lid. A tissue holder is also provided
on the inside of the armrest lid, which holds a pocket size
soft pack of tissue.
CENTER STORAGE COMPARTMENT Ð IF
EQUIPPED
The center portion of the seat folds down to provide an
armrest with unique storage compartments under the lid.
Push the button on the armrest to raise the lid. Compart-
ments include a holder which will accommodate five
compact disks with finger notches for easier access, a
pencil tray, a coin holder, and a large open area for
miscellaneous items.
CUP HOLDERS
If your vehicle has bucket seats with a center console,
there are three cup holders located on the console. Refer
to the section on floor console.
A two-cavity cup holder is available on all Crew Cab
with rear seats mounted on the floor.
Front Cup Holders ± Crew Cab with Automatic
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 141
3

REAR STORAGE ± IF EQUIPPED
Rear Convenience Storage Crates
WARNING!
Do not sit or stand on this crate. It may collapse
causing serious injury.
The rear convenience storage crates are located under the
rear seat lower cushion and consist of two removable,
collapsible storage crates.
Rear Cup Holders ± Crew Cab with Automatic
142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

CAUTION!
Do not lift up on the ªEnd Flapsº to open the crate,
damage to the ªEnd Flapsº may occur.
NOTE:The maximum loading capacity for the 40%
crate is 30 lbs. and 50 lbs. for the 60% crate.
To open the storage crate, lift upwards on the crate
handles, and engage the crate end flaps.
To remove the crate, press on the release lever and lift up
on the crate.
Open Crate
1 - Crate Handles
2 - Crate End Flaps
3 - Release LeverUNDERSTANDING THE FEATURES OF YOUR VEHICLE 143
3

To install the crate into the base, insert the crate into the
inboard slot and push down on the outboard side of the
crate and snap into place.
To collapse the crate, push the crate end flaps inward to
disengage. Push the sides inward and snap into the base.
Plastic Grocery Bag Retainers
Retainer hooks which will hold plastic grocery bag
handles are built into the back panel of the cab.
Insert Crate
Grocery Bag Retainers
144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
