2007 VOLVO XC70 key

2007 Volvo XC70
P.O. Box 914
Rockleigh, New Jersey 07647-0914
1-800-458-1552
www.volvocars.us
In Canada:
Volvo Cars of Canada Corp.
National Customer Service
175 Gordon Baker Road
North York, Ontario M2H 2N7
1-800-663-8255
www.volvocanada.com
2006 © Volvo Car Corporation
pg. 2 Introduction
General Information
Shiftlock (automatic transmission)
When your vehicle is parked, the gear selector is locked in the (P)ark position. To release the selector from this
position, turn the ignition key to position II (or start the engine), \
depress the brake pedal, press the button on the
front side of the gear selector and move the selector from (P)ark.
Keylock (automatic transmission)
When you switch off the ignition, the gear selector must be in the (P)ark position before the key can be removed
from the ignition switch.
Anti-lock Brake System (ABS)
The ABS system in your vehicle performs a self-diagnostic test when the \
vehicle first reaches the speed of
approximately 12 mph (20 km/h). The brake pedal will pulsate several t\
imes and a sound may be audible from the
ABS control module. This is normal.
Fuel filler door
The fuel filler door, located on the right rear fender, is connected to \
your vehicle's central locking system.
Press the button on the light switch panel (see illustration on
page 56) when the vehicle is at a standstill to unlock
the fuel filler door. Please note that the fuel filler door will remain \
unlocked until the vehicle begins to move
forward. An audible click will be heard when the fuel filler door relock\
s.
Fuel filler cap
After refueling, close the fuel filler cap by turning it clockwise until\
it clicks into place. If this cap is not closed
tightly or if the engine is running when the vehicle is refueled, the Ma\
lfunction Indicator Lamp ("Check Engine"
light) will illuminate.
Important information
file:///K|/ownersdocs/2007/2007_XC70/07xc70_00.htm (2 of 6)12/30/2006 \
5:51:24 PM

2007 Volvo XC70
occupant weight sensor, and inflatable curtains. All of these systems ar\
e monitored by the SRS control
module. An SRS warning light in the instrument panel (see the illustrat\
ion above) illuminates when the
ignition key is turned to position I, II, or III, and will normally go o\
ut after approximately 7 seconds if
no faults are detected in the system.
Where applicable, a text message will also be displayed when the SRS war\
ning light illuminates. If this
warning symbol is not functioning properly, the general warning symbol
illuminates and a text
message will be displayed.
WARNING!
l If the SRS warning light stays on after the engine has started or if it \
illuminates while you are
driving, have the vehicle inspected by a trained and qualified Volvo ser\
vice technician as soon as
possible.
l Never try to repair any component or part of the SRS yourself. Any inter\
ference in the system
could cause malfunction and serious injury. All work on these systems sh\
ould be performed by an
authorized Volvo service technician.
WARNING!
If your vehicle has been subjected to flood conditions (e.g. soaked car\
peting/ standing water on the
floor of the vehicle) or if your vehicle has become flood-damaged in an\
y way, do not attempt to start
the vehicle or put the key in the ignition before disconnecting the batt\
ery (see below). This may cause
airbag deployment which could result in personal injury. Have the vehicl\
e towed to a trained and
qualified Volvo service technician for repairs.
Automatic transmission:
Before attempting to tow the vehicle, use the following procedure to ove\
rride the shiftlock system to
move the gear selector to the neutral position:
l Switch off the ignition for at least 10 minutes and disconnect the batte\
ry.
l Wait at least one minute.
l Insert the key in the ignition and turn it to position II.
l Press firmly on the brake pedal.
l Move the gear selector from (P)ark to the (N)eutral position.
pg. 16 Safety
Front airbags
file:///K|/ownersdocs/2007/2007_XC70/07xc70_01.htm (7 of 38)12/30/2006\
5:51:26 PM

2007 Volvo XC70
Please see page 135 for information on adjusting the active chassis settings.

Dynamic Stability Traction Control (DSTC) button
This button is available on R-models only and is used to temporarily dea\
ctivate the Spin control and
Active Yaw Control functions. See
page 126 for more information. On non R-models, DSTC is
controlled via the menu control ring on the left steering wheel lever, s\
ee
page 125.
WARNING!
Please be aware that the vehicle's handling characteristics may be affec\
ted if the Spin Control
function is switched off.

Temporarily disconnecting the alarm sensors (option)
See
page 117 for more details.
12 volt socket
This 12 volt socket can be used to plug in certain accessories such as c\
ellular telephones, etc. The
ignition key must be in position 1 (or higher) for the auxiliary socke\
t to function.
NOTE: The auxiliary sockets can also be used for cigarette lighters, which ar\
e available at your Volvo
retailer

Front/rear park assist (option/accessory)
See
page 153 for more information on this function.
file:///K|/ownersdocs/2007/2007_XC70/07xc70_02.htm (11 of 35)12/30/200\
6 5:51:30 PM

2007 Volvo XC70
driver. Pull down the lever on the left of the steering column. Adjust t\
he steering wheel to a suitable
position and press the lever back into place to lock the steering wheel \
in the new position. Check that the
steering wheel is locked in the new position.
WARNING!
Never adjust the steering wheel while
driving.
pg. 55 Instruments and controls
Lighting panel
1. Headlight/parking light switch
2. Front fog lights
3. Rear fog light
4. Instrument panel lighting
5. Fuel filler door unlock button
Parking lights
The front and rear parking lights can be turned on even when the ignitio\
n is switched off.
- Turn switch 1 to position
.
The license plate lights also illuminate when the parking lights are swi\
tched on.
Headlights
- Turn the ignition key to position II.
- The low beam headlights (daytime running lights) illuminate automati\
cally, except when the light
switch (1) is in position
1.
See
page 57 for information on switching between high and low beams.
file:///K|/ownersdocs/2007/2007_XC70/07xc70_02.htm (13 of 35)12/30/200\
6 5:51:30 PM

2007 Volvo XC70
NOTE: Active Bi-Xenon headlights (option): Turn the headlight switch to pos\
ition 0 to activate a
daylight sensor, which automatically switches the low beams on or off, d\
epending on ambient light
conditions. When driving in daylight, the headlights will switch off and\
the daytime running lights will
come on. In darkness, the daytime running lights will switch off and the\
Active Bi-Xenon headlights
will switch on.
Active Bi-Xenon headlights (ABL) - option
When the ABL function is activated, the headlight beams adjust laterally\
to help light up a curve
according to movements of the steering wheel (see the right-pointing be\
am in the illustration above).
This function is activated automatically when the engine is started and \
can be deactivated/ reactivated by
pressing the ABL button (see
page 53).
1. On Canadian models, the daytime running lights will remain on with th\
e light switch in this position.
pg. 56 Instruments and controls
Lighting panel
Fog lights
Front fog lights (option)
The front fog lights can be used in combination with either the headligh\
ts or the parking lights.
- Turn the ignition key to position II.
- Press button 2 to turn on the front fog lights.
An indicator light in the button illuminates when the front fog lights a\
re on.
Rear fog light
The single rear fog light is located in the driver's side tail light clu\
ster.
The rear fog light will only function in combination with the high/low b\
eam headlights or the optional
file:///K|/ownersdocs/2007/2007_XC70/07xc70_02.htm (14 of 35)12/30/200\
6 5:51:30 PM

2007 Volvo XC70
front fog lights.
- Turn the ignition key to position II.
- Press button 3 to turn on the rear fog light.
An indicator light in the button illuminates when the rear fog light is \
on.
NOTE: The rear fog light is considerably brighter than the normal tail lights\
and should be used only
when conditions such as fog, rain, snow, smoke or dust reduce visibility\
for other vehicles to less than
500 ft. (150 meters).
Instrument panel lighting
The instrument panel lighting illuminates when the ignition key is in po\
sition II and the light switch (1)
is in either position
or .
- Move the thumb wheel (4) up to increase brightness or down to decrea\
se brightness.
Unlocking the fuel filler door
Press button 5 when the vehicle is at a standstill to unlock the fuel fi\
ller door. Please note that the fuel
filler door will remain unlocked until the vehicle begins to move forwar\
d. An audible click will be heard
when the fuel filler door relocks.
NOTE: If the fuel filler door does not unlock after the button has been press\
ed, drive the vehicle at a
speed of at least 5 mph (8 km/h), stop the vehicle, and press the butt\
on again.
See the information to the right on unlocking the fuel filler door manua\
lly.
pg. 57 Instruments and controls
Left-side steering wheel lever
Lever positions
file:///K|/ownersdocs/2007/2007_XC70/07xc70_02.htm (15 of 35)12/30/200\
6 5:51:30 PM

2007 Volvo XC70
1. Turn signals, lane change position
2. Turn signals, position for normal turns
3. High beam flash
4. Toggle between high and low beams, Home Safe lighting
Turn signals
When turning
Move the lever as far up or down as possible (to position 2) to start \
the turn signals. The turn signals will
be cancelled automatically by the movement of the steering wheel, or the\
lever can be returned to its
initial position by hand.
When changing lanes
The driver can automatically flash the turn signals 3 times by:
l Moving the turn signal lever up or down to position 1 and releasing it. \
l Moving the lever up or down to position 2 and immediately back to its or\
iginal position.
NOTE:
l This automatic flashing sequence can be interrupted by immediately movin\
g the lever in the opposite
direction.
l If the turn signal indicator flashes faster than normal, check for a bur\
ned-out turn signal bulb.
High/low beam headlights
Continuous high beams
- Turn the ignition key to position II.
- With the light switch (1) in position
, (see page 55) pull the turn signal lever toward the steering
wheel (position 4) to toggle between high and low beams (this also ap\
plies on models equipped with the
optional Active Bi-Xenon headlights).
High beam flash
- Turn the ignition key to position II.
- Pull the turn signal lever to position 3. The high beams will remain o\
n until the lever is released.
Home safe lighting
When you leave your vehicle at night, you can make use of the home safe \
lighting function to illuminate
the area in front of the vehicle.
- Remove the key from the ignition switch.
- Pull the direction indicator lever as far as possible towards the stee\
ring wheel (to position 4) and
release it.
- Exit the vehicle and lock the doors.
file:///K|/ownersdocs/2007/2007_XC70/07xc70_02.htm (16 of 35)12/30/200\
6 5:51:30 PM

2007 Volvo XC70
CAUTION!
Use ample washer fluid when washing the windshield. The windshield shoul\
d be thoroughly wet
when the wipers are in operation.
l To conserve washer fluid in driving conditions where the windshield wash\
ers are used frequently, the
headlights will only be washed once for every five times the windshield \
is washed within a 10-minute
period.
l A short pull on the lever will wash the windshield only.
l When approximately 1 US quart (1 liter) remains in the washer fluid re\
servoir, the headlights will not
be washed when the lever is pulled to conserve washer fluid for the wind\
shield.
NOTE: R-models are also equipped with headlight wipers, which are activated a\
long with the washer
function.
Rain sensor (option)
The rain sensor automatically regulates wiper speed according to the amo\
unt of water on the windshield.
The sensitivity of the sensor can be adjusted by twisting ring 1 up (the wipers will s\
weep the windshield
more frequently) or down (the wipers will sweep the windshield less fr\
equently).
Activating the rain sensor:
- Turn the ignition key to at least position I and put the windshield wi\
per lever in position 0.
- Press button 2.
An LED in the button will light up to indicate that the rain sensor is a\
ctive.
Deactivating the rain sensor:
- Press button 2.
or
- Move the windshield wiper lever down to another position.
Moving the lever up will not deactivate the rain sensor. Doing so will c\
ause the wipers to sweep the
windshield until the lever is released, at which time the wipers return \
to rain sensor mode.
pg. 59 Instruments and controls
Right-side steering wheel lever
file:///K|/ownersdocs/2007/2007_XC70/07xc70_02.htm (18 of 35)12/30/200\
6 5:51:30 PM
