2007 Volvo XC70
When applying the parking brake
- Press firmly on the brake pedal.
- Pull up the parking brake lever as far as possible.
WARNING!
Always apply the parking brake fully when the vehicle is parked. The ind\
icator light will light up
even if the parking brake has only been partially applied. Always pull u\
p the lever as far as possible.
- Release the brake pedal and ensure that the vehicle is at a standstill\
.
- Put the gear selector in P (automatic transmission) or in 1st gear (\
manual transmission).
Parking on a hill
l If the vehicle is pointing uphill, turn the front wheels so that they po\
int away from the curb.
l If the vehicle is pointing downhill, turn the front wheels so that they \
point toward the curb.
Releasing the parking brake
- Press firmly on the brake pedal.
- Pull the lever up slightly, press the button at the end of the lever a\
nd lower the lever completely.
Auxiliary sockets
The 12 volt sockets can be used to plug in certain accessories such as c\
ellular telephones, etc. The key
must be in position I (or higher) for the auxiliary socket to function\
.
NOTE: The cover should be folded down when the auxiliary socket is not in use.\

Cigarette lighter/ashtrays
file:///K|/ownersdocs/2007/2007_XC70/07xc70_02.htm (25 of 35)12/30/200\
6 5:51:30 PM

2007 Volvo XC70
The auxiliary sockets can also be used for cigarette lighters, which are\
available at your Volvo retailer.
NOTE: Volvo vehicles in North America do not have an ashtray in the front sea\
t as standard equipment.
If you want to have an ashtray in the front seat, please contact your Vo\
lvo retailer.
pg. 65 Instruments and controls
Power windows
The power windows are controlled by buttons in the arm rests. The igniti\
on switch must be ON1
(ignition key in position I, II or the engine running) for the electri\
cally operated windows to function.
To lower: Press down the front edge of the button to the first detent (\
"stop").
To raise: Lightly pull up the front edge of the button to the first dete\
nt ("stop").
Auto up/down function (front doors only):
Either front door window can be opened or closed automatically.
Auto down: Press the front part of the button as far down as possible and release \
it immediately. To
stop the window at any time, pull the button up.
Auto up: Pull the front part of the button up as far as possible and release it \
immediately. To stop the
window at any time, press the button down.
NOTE: The electrically operated windows in the front seat have an overload pr\
otecting circuit breaker
which reverses movement of the electrically operated windows to their st\
arting points if they are
obstructed in any way. Thereafter the windows will operate normally agai\
n.
file:///K|/ownersdocs/2007/2007_XC70/07xc70_02.htm (26 of 35)12/30/200\
6 5:51:30 PM

2007 Volvo XC70
WARNING!
Always remove the ignition key when the vehicle is unattended.
Make sure that the windows are completely unobstructed before they are o\
perated.
Never leave children unattended in the vehicle.
1. The electrically operated windows will also function after the igniti\
on has been switched off as long as neither
of the front doors has been opened.
pg. 66 Instruments and controls
Power windows
Cutout switch for rear windows
The electrically operated rear door windows can be disabled by a switch \
located on the driver's door (see
illustration).
If the LED in the switch is OFF: The rear door windows can be raised or lowered with the buttons on
the rear door armrests or with the buttons on the driver's door armrest.\
If the LED in the switch is ON: The rear door windows can only be raised or lowered with the buttons
on the driver's door armrest.
file:///K|/ownersdocs/2007/2007_XC70/07xc70_02.htm (27 of 35)12/30/200\
6 5:51:30 PM

2007 Volvo XC70
WARNING!
The mirrors should always be adjusted prior to driving. Objects seen in \
the passenger's side wide-
angle sideview mirror are closer than they appear to be.
Remote central locking and sideview mirror memory-option
If you lock the vehicle and later unlock it with the same remote control and open the driver's door, the
sideview mirrors (and the driver's seat) will automatically move to th\
e position they were in when you
left the vehicle. This feature will work in the same way with all of the\
remote control transmitters (up to
3) that you use with your vehicle. This feature will not function if yo\
u lock your vehicle with the key.
Water repellent glass-option on certain models

The side door windows can be treated with a water repellent coating. The\
symbol to the left indicates
these windows have this coating. The optional laminated side windows alw\
ays have this coating.
The coating improves vision by causing the water to run off quickly.
See
page 179 for information on cleaning this type of glass.
CAUTION!
Use only suitable plastic scrapers to remove ice or snow from the mirror\
s. Using a metal ice scraper
could damage the water repellent coating.
pg. 70 Instruments and controls
Power moonroof (option)
file:///K|/ownersdocs/2007/2007_XC70/07xc70_02.htm (32 of 35)12/30/200\
6 5:51:30 PM

2007 Volvo XC70
Power moonroof
To operate the moonroof, turn the ignition key to position I or II, or s\
tart the engine. The moonroof can
be operated in two ways:
A. Tilt position
B. Sliding moonroof
A. Tilt position
Open: With the moonroof closed, push up the rear edge of the switch (positio\
n 5 in the illustration
below).
Close: Pull down and hold the rear edge of the switch (position 6 in the illu\
stration below) until the
moonroof has closed completely.
B. Sliding moonroof
Manual open: Pull the switch rearward to position 3 and hold it until the moonroof h\
as opened to the
position of your choice.
Auto open: Pull the switch as far back as possible (position 4) and release it t\
o automatically slide open
the moonroof to the "comfort"
1 position. Pull the switch rearward again to open the moonroof
completely.
Manual close: Push the switch to position 2 and hold it until the moonroof has closed\
completely or to
file:///K|/ownersdocs/2007/2007_XC70/07xc70_02.htm (33 of 35)12/30/200\
6 5:51:30 PM

2007 Volvo XC70
The air conditioning is momentarily disengaged during full-throttle acce\
leration.
Climate control maintenance
Special tools and equipment are required to maintain and carry out repai\
rs on the climate system. Work of this type
should only be done by a trained and qualified Volvo service technician.\
Refrigerant
Volvo cares about the environment. The air conditioning system in your v\
ehicle contains a CFC-free refrigerant -
R134a (HFC134a). This substance will not deplete the ozone layer. The \
system contains 1.5 lbs (700 g) R134a and
uses PAG oil.
Climate system blower
The climate system blower will be automatically switched off when the en\
gine is not running (even if the ignition
key is in position I or II) to avoid unnecessary battery drain. To acti\
vate the blower, turn the control to the desired
setting.
Passenger compartment blower
Approximately 50 minutes after the ignition is turned off, the blower ma\
y come on automatically, and run for seven
minutes, to remove condensation in the A/C evaporator.
pg. 75 Climate
Air distribution
Air distribution
The incoming air is distributed through 14 ventilation points in the pas\
senger compartment.
file:///K|/ownersdocs/2007/2007_XC70/07xc70_03.htm (2 of 11)12/30/2006\
5:51:31 PM

2007 Volvo XC70
WARNING!
Cover sharp edges on the load to help prevent injury to occupants. Secur\
e the load to help prevent
shifting during sudden stops.
pg. 86 Interior
Front seats
Power seat - (option on certain models)
Operation
Driver's seat: The seat can be adjusted if the ignition key is in position I, II or if\
the engine is running.
It can also be adjusted as follows with the ignition off:
l Within several minutes after the driver's door has been unlocked from th\
e outside, has been opened,
and remains open.
l Within a short period if the driver's door has just been closed.
l Within a short period if the driver's door has not been opened after the\
ignition has been switched off.
Passenger seat: The seat can only be adjusted if the ignition key is in position I, II \
or if the engine is
running.

Power seat control panel
Seat adjustment
If your Volvo is equipped with power seats, the following may be adjuste\
d with the two switches at the
side of the seat:
A. Front edge of seat (raise/lower)
B. Front - rear
C. Rear edge of seat (raise/lower)
D. Backrest tilt
file:///K|/ownersdocs/2007/2007_XC70/07xc70_04.htm (3 of 29)12/30/2006\
5:51:33 PM

2007 Volvo XC70
NOTE: The power seats have an overload protector that activates if a seat is \
blocked by any object. If
this occurs, switch off the ignition (key in position 0) and wait for \
a short period before operating the
seat again.
Emergency stop
If the seat accidentally begins to move, press any of the buttons to sto\
p the seat.
NOTE: Please refer to the following page for information on programming the m\
emory function in the
driver's seat.
Remote keyless entry system and the driver's seat
The remote control transmitter also controls the position of the electri\
cally operated driver's seat in the
following way:
- Adjust the seat to your preferences.
- When you leave your vehicle, lock it using the remote control.
The position of the seat is now stored in the remote control.
Automatic seat adjustment
To move the seat to the position in which you left it:
- Unlock the driver's door with the same remote control (the one used t\
o lock the doors).
- Open the driver's door within 2 minutes.
The driver's seat will automatically move to the position in which you l\
eft it.
NOTE:
l The seat will move to this position even if someone else has moved it to\
a different seating position
and locked the vehicle with a different remote control.
pg. 87 Interior
Front seats
l This feature will work in the same way with all of the remote control tr\
ansmitters (up to 3) that you
use with your vehicle.
l This feature will not function if your lock your vehicle with the key.
