2007 Volvo XC70
The courtesy lights will come on and remain on for approximately 10 minu\
tes when:
l One of the doors is opened (assuming the courtesy lighting has not prev\
iously been switched off)
The courtesy lighting will go off when:
l The engine is started
l The vehicle is locked from the outside with the remote control or key
The automatic function can be disconnected by pressing button 2 for more\
than 3 seconds.
Briefly pressing the button again automatically reconnects the function.\

The courtesy light timer periods can be changed. Contact your Volvo reta\
iler.
1. This function is light dependent and is only activated in dark condit\
ions.
pg. 89 Interior
Interior lighting
Vanity mirror
The light comes on when you open the cover.
file:///K|/ownersdocs/2007/2007_XC70/07xc70_04.htm (7 of 29)12/30/2006\
5:51:33 PM

2007 Volvo XC70
using the lock button on the door and the door is then closed. A sound f\
rom the lock will be audible at
this time.
Please note that this function will not unlock the doors if the engine i\
s running.
Immobilizer (start inhibitor)
Each of the keys supplied with your vehicle contains a coded transmitter\
. The code in the key is
transmitted to an antenna in the ignition switch where it is compared to\
the code stored in the start
inhibitor module. The vehicle will start only with a properly coded key.\

Each key has a unique code, which your Volvo retailer uses if new keys a\
re required. A maximum of six
remote controls/keys can be programmed and used for one vehicle.
If you misplace a key, take the other keys to an authorized Volvo retail\
er for reprogramming as an
antitheft measure.
NOTE: This device complies with part 15 of the FCC rules. Operation is subjec\
t to the following
condition: (1) This device may not cause harmful interference, and (2\
) this device must accept any
interference received, including interference that may cause undesired o\
peration.
pg. 111 Locks and alarm
Remote control
Your vehicle is equipped with two coded remote control transmitters with\
integrated ignition keys called
Key Integrated Remote (KIR). These transmitters use a radio frequency \
that will enable you to lock/
unlock all doors and the tailgate from a distance of 10-15 feet (3-5 me\
ters).
The transmitters will also activate or allow "keyless" entry into the pa\
ssenger compartment or the
tailgate. They will also activate or deactivate your vehicle's alarm sys\
tem(s). The vehicle can also be
locked/ unlocked with the key.
If one of the transmitters is misplaced, contact your nearest authorized\
Volvo retailer for replacement.
file:///K|/ownersdocs/2007/2007_XC70/07xc70_05.htm (3 of 12)12/30/2006\
5:51:34 PM

2007 Volvo XC70
1. Fold key in/out
2. Lock
3. Approach lighting
4. "Panic" function
5. Unlock tailgate
6. Unlock
Using the remote control
Button 1: Press to extend the key. This button must also be pressed when the key \
is folded back into the
slot in the side of the remote control unit.
Button 2 (Lock): Press once to lock all doors, and the tailgate.
Button 3 (Approach lighting): Press this button when approaching the vehicle at night to light up the\

interior courtesy light, parking lights, and license plate lights.
Button 4 (Panic): See
page 116 for more information on this function.
Button 5 (Unlock tailgate): Press this button to unlock the tailgate (without unlocking the other \
doors).
NOTE: This function does not open the tailgate.
Button 6 (Unlock): Press this button once to unlock the driver's door only. Wait for at le\
ast 1 second
and press the button again (within 10 seconds) to unlock all doors, an\
d the tailgate.
NOTE:
l If an airbag deploys, your vehicle's SRS control module will attempt to \
automatically unlock all
doors.
l The keys may also be used to lock and unlock the doors, and to activate \
and deactivate the alarm
system.
l To avoid leaving your keys in the vehicle, make a habit of always lockin\
g the vehicle with the remote
control.
l If the key blade section of the remote is not fully folded out when star\
ting the vehicle, the immobilizer
function may make it impossible to start the engine.
file:///K|/ownersdocs/2007/2007_XC70/07xc70_05.htm (4 of 12)12/30/2006\
5:51:34 PM

2007 Volvo XC70
WARNING!
Before starting, check that the seat, steering wheel and mirrors are adj\
usted properly. Make sure the
brake pedal can be depressed completely. Adjust the seat if necessary. S\
ee page
84 and 86.
- Apply the parking brake (hand brake) if not already set. The gear se\
lector (automatic transmission) is
locked in the (P)ark position (SHIFTLOCK). Manual transmission: the clutch must be fully depressed.
- Without touching the accelerator pedal, turn the ignition key
1 to the starting position. Allow the starter
to operate for up to 10 seconds. Release the key as soon as the engine s\
tarts. If the engine fails to start,
repeat this step.
NOTE:
l If the key blade section of the remote is not fully folded out when star\
ting the vehicle, the immobilizer
function may make it impossible to start the engine.
l After a cold start, idle speed may be noticeably higher than normal for \
a short period. This is done to
help bring components in the emission control system to their normal ope\
rating temperature as quickly
as possible, which enables them to control emissions and help reduce the\
vehicle's impact on the
environment.
l For cold starts at altitudes above 6000 ft (1800 meters), depress the \
accelerator pedal halfway and turn
the key to the starting position. Release the pedal slowly when the engi\
ne starts.
l To release the gear selector from the (P)ark position, the engine must be running (or the ignition key
must be in position II) and the brake pedal must be depressed.
l Select the desired gear. The gear engages after a very slight delay whic\
h is especially noticeable when
selecting R.
NOTE: Your vehicle is equipped with a KEYLOCK system (automatic transmission). When the engine
is switched off, the gear selector must be in the (P)ark position before the key can be removed from the
ignition switch.
When starting in cold weather, the transmission may shift up at slightly\
higher engine speeds than
normal until the automatic transmission fluid reaches normal operating t\
emperature.
1. If two of the keys to your vehicle are close together, e.g. on the sa\
me key ring, when you try to start the
vehicle, this could cause interference in the immobilizer system and res\
ult in the vehicle not starting. If this
should occur, remove one of the keys from the key ring before trying to \
start the vehicle again.
file:///K|/ownersdocs/2007/2007_XC70/07xc70_06.htm (7 of 41)12/30/2006\
5:51:37 PM

2007 Volvo XC70
CAUTION!
The optional supplementary amplifier (HU-850) may be mounted under the\
front passenger's seat. If
the floor of the vehicle has become soaked for any reason, do not turn o\
n the radio. This would cause
damage to the amplifier. Contact a Volvo retailer.
Low battery voltage
If the level of battery voltage is low, a message will be displayed. The\
vehicle's energy conservation
function may switch off the audio system. Recharge the battery by starti\
ng the engine.
pg. 243 Audio
HomeLink® Universal Transceiver (option)
HomeLink® Universal Transceiver
HomeLink® is an advanced system that can be programmed to learn the c\
odes of three different remote
controlled-devices (e.g., garage door openers, remote lighting, entry d\
oor lock). HomeLink®'s sun visor-
mounted transceiver, powered by your vehicle's electrical system, may th\
en be used in place of your
hand-held remote controls.
NOTE: For your security, the HomeLink® Universal Transceiver is designed t\
o not function if you lock
your vehicle from the outside.
Programming the transceiver
- The ignition switch must be turned to the "accessory" position (II) \
before programming the
HomeLink® Universal Transceiver.
file:///K|/ownersdocs/2007/2007_XC70/07xc70_11.htm (19 of 22)12/30/200\
6 5:51:47 PM
