2007 TOYOTA LAND CRUISER Navigation Manual

cli
(b) Windshield defogging and
defrosting
To remove interior fog on the windshield

Push the “FRONT WINDSHIELD” button.
To remove frost or exterior fog on the
windshield
1. Push the upper side of the temperature
control button until maximum figure appears
on the temperature display.
2. Push the “FRONT WINDSHIELD” but-
ton.
3. Push the “HI” of the air flow control
switch to obtain a maximum air flow.
4. Leave the air conditioning on−off button
off.For further information for removing frost
and fog, see “Lower vent” on page clii.
When the “FRONT WINDSHIELD” button is
pushed while operating in automatic mode,
the air conditioning is set to operate and the
OUTSIDE AIR mode is set.
Push the “A/C” switch for dehumidified
heating or cooling. This setting clears the
front view more quickly.
If you push the “FRONT WINDSHIELD”
button once again while in the FRONT
WINDSHIELD mode, the mode then returns
to the last mode used.CAUTION
Do not use the “FRONT WINDSHIELD”
button during cooled air operation in
extremely humid weather. The differ-
ence between the temperature of the
outside air and that of the windshield
could cause the outer surface of the
windshield to fog up blocking your vi-
sion.
(c) Rear air conditioning switch
To turn on the rear air conditioning when
you sit on the front seat, push this switch.
The rear air conditioning operates in the
automatic mode. To adjust the air flow
and setting temperature, follow the steps
in accordance with “Rear air condition-
ing controls” in the Lexus Owner’s Manu-
al.

clii
Center vents
The center vents may be opened or
closed as shown.
Side vents
The side vents may be opened or closed
as shown.
Lower vent
The lower vent may be opened or closed
as shown.
For removing frost or fog, it is recommended
that you close the lower vent when you use the
“Floor”, the “Floor/Windshield” or the “Wind-
shield” mode.

cliii

cliv
AUDIO SYSTEM
Audio system Audio system
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . c
lv
SECTION VI

For the JBL brand audio system, “JBL” logo is provided on the panel.
7ulc001a
clv
Audio system
Quick reference for your audio system
Page
1Audio operation screen display
button clvi. . . . . . . . . . . . . . . . . . . . . . . .
2Function switch display
screen clvii. . . . . . . . . . . . . . . . . . . . . . .
3Cassette tape slot clxx. . . . . . . . . . . . .
4Frequency turning knob clx. . . . . . . .
5[Radio mode] Preset tuning clxi. . . .
[Tape mode] Side change of
cassette tape clxx. . . . . . . . . . . . . . . . .
[DISC mode] Disc selection clxxiv. .
6SCAN button clxi, clxxv. . . . . . . . . . . .
7Mode selectors clvii. . . . . . . . . . . . . . . .
8Stopping and ejecting a
cassette tape clxx. . . . . . . . . . . . . . . . .
9[Radio mode] Seek tuning clxi. . . . . .
[Tape/DISC mode] Direct access to
a desired program clxxii, clxxv. . . . . .
10Turning the system on and
adjusting volume clvi. . . . . . . . . . . . . .

clvi
Using your audio system:
some basics
This section describes some of the basic
features of the Toyota audio system. Some
information may not pertain to your system.
Your audio system works when the ignition
key is in the “ACC” or “ON” position.
NOTICE
To prevent the battery from being
discharged, do not leave the car
audio on longer than necessary when
the engine is not running.
oxu002
By pushing the above button, you can
operate the speech command system.
For the operation of the speech command
system and the command, see page cxxxix
and cxli.
(a) Turning the system on and off
UNX602
POWERVOL: Push this knob to turn the
audio system on and off. Turn this knob to
adjust the volume. The system turns on in
the last mode used.
AUDIO: Push this button to display switches
for audio system.
VI

clvii
7wlc002a
Push the “AM”, “FM”, “TAPE” or “DISC”
button to turn on that mode. The selected
mode turns on directly.
Push these buttons if you want to switch
from one mode to another.
If the tape or disc is not set, the cassette
player or compact disc player does not turn
on.
You can turn off the cassette player by eject-
ing the cassette tape. If the audio system
was previously off, then the entire audio sys-
tem will be turned off when you eject the cas-
sette tape. If another function was previous-
ly playing, it will come on again.
lxb001a
lxb006a
lxb008a
The switches for radio, cassette tape and
disc player operation are displayed on
the liquid crystal display. Touch them
lightly and directly on the screen.
The selected switch is highlighted in green.

clviii
(b) Tone and balance
How good an audio program sounds to you
is largely determined by the mix of the treble,
mid−range, and bass levels. In fact, different
kinds of music and vocal programs usually
sound better with different mixes of treble,
mid−range, and bass.
A good balance of the left and right stereo
channels and of the front and rear sound lev-
els is also important.
Keep in mind that if you are listening to a ste-
reo recording or broadcast, changing the
right/left balance will increase the volume of
one group of sounds while decreasing the
volume of another.
lxb001a
Touching the “SOUND” switch on the
screen displays the sound adjustment
screen.BASS “+” or “–”: Adjusts low−pitched
tones.
MID “+” or “–”: Adjusts mid−pitched tones.
TREB “+” or “–”: Adjusts high−pitched
tones.
“FRONT” or “REAR”: Adjusts sound bal-
ance between the front and rear speakers.
“L” or “R”: Adjusts sound balance be-
tween the left and right speakers.
“OK”: The previous screen returns.
VI
