2007 TOYOTA LAND CRUISER light

ii
Touch switch operation
This system is operated mainly by the
switches on the screen. To prevent dam-
age to the screen, lightly touch switches
on the screen with your finger. When you
touch a switch on the screen, a beep
sounds.Do not use objects other than your finger
to touch the screen.
INFORMATION
If the system does not respond to a
touch of a switch, move your finger
away from the screen and then
touch it again.
You cannot operate dimmed
switches.
Wipe off fingerprints on the surface
of the display using a glass cleaning
cloth.
The displayed image may become
darker and moving images may be
slightly distorted when the display is
cold.
When you look at the screen through
polarised material such as polarised
sunglasses, the screen may be dark
and hard to see. If so, change the
angle of the screen or take off your
sunglasses.
Inputting letters and numbers
When searching for an address or a name,
or entering a memo, you can input letters
and numbers via the touch screen.
To input letters
To display the alphabet keys, touch the
“AZ” switch or the “ÀÝ” switch.
Enter letters by touching the alphabet keys
directly.
:Touching this switch erases one
letter. Holding this switch will con-
tinue to erase letters.

li
— Route guidance screen
When starting route guidance, the following
screen is displayed.
This screen displays the route that guides
the driver to the destination.
The route to the destination is indicated by
a highlighted line. Drive along the guided
route.
When the vehicle approaches a guidance
point such as an intersection or a freeway,
the screen automatically divides in two to
display the guidance screen. (For details,
see page lxiii.)
The current street name will be displayed at
the bottom of the screen.
In some areas, the roads have not been
completely digitized in our database yet. For
this reason, the route guidance may guide
the road that is not allowed to pass.
— Typical voice guidance
prompts
The voice guidance provides various mes-
sages as you approach an intersection, or
other point where you need to maneuver the
vehicle.
1“Proceed about 5 miles.”
2“In a quarter of a mile, right turn.”
3“Right turn.”
4(Beep sound only)
INFORMATION
On freeways, interstates or other high-
ways with higher speed limits, the
voice guidance will be made at earlier
points than on city streets in order to al-
low time to maneuver.

lxxiv
Volume
You can use voice guidance when ap-
proaching a destination.
You can adjust the volume of the voice or
turn off voice guidance.
Push the “MENU” button to display the
“Menu” screen, and touch the “Vol-
ume”
switch.
To adjust the volume, select the desired level
by touching the appropriate number.
If you do not need voice guidance, touch the
“Off” switch.
The selected item is highlighted in green.
INFORMATION
During route guidance, the voice guid-
ance continues even if the navigation
screen is changed to other screens.
“Adaptive Volume Control”: If you turn the
“Adaptive Volume Control” on, the volume is
turned up automatically when the vehicle
speed exceeds 50 mph (80 km/h).
To turn the “Adaptive Volume Control”
system on, touch the switch. The indicator
will be highlighted.
User selection
The system can memorize the following
settings for up to three users.
Map direction
Map scale
Guidance mode
Setup
Volume
Language
Push the “MENU” button to display the
“Menu” screen. Then touch the
“Select
User”
switch.

xci
3. Touch the “km” or “miles” switch
of “Distance” to choose the distance
unit.
The selected switch is highlighted in green.
4. Touch the
“OK” switch.
Estimated travel time
You can set the speed that is used for the
calculation of the estimated travel time.
1. Push the “MENU” button.
2. Touch the “Setup” switch.
3. Touch the “Set Speed” switch of
the “Estimated Travel Time”.

xciii
3. Touch the “On” switch of “Auto
Reroute”.
The selected switch is highlighted in green.
INFORMATION
If your vehicle strays from the guidance
route, the system searches for a new
route to the destination. The new route
may or may not take you back to the
previous route depending on how far
you are off the original guidance route.
Adjusting time zone
1. Push the “MENU” button.
2. Touch the “Setup” switch.
3. Touch the “Change” switch. The
“Adjust Time Zone” screen appears on
the display.

xciv
4. Touch the desired time zone.
The selected switch is highlighted in green.
5. Touch the
“OK” switch on the screen
and the “Setup” screen will be displayed.
Auto voice guidance
When the “Auto Voice Guidance” feature
is turned on, the voice guidance can be
heard automatically.
When the “Auto Voice Guidance” feature
is turned off, the voice guidance can be
heard only if you push the
“MAP/
VOICE”
button.
To turn the “Auto Voice Guidance” mode
on:
1. Push the
“MENU” button.
2. Touch the “Setup” switch. Then
touch
switch to display page 2 of the
“Setup” screen.
3. Touch the “On” switch of “Auto
Voice Guidance”.
The selected switch is highlighted in
green.

cxx
Trip information
Trip information such as driving time,
driving distance, average vehicle speed,
fuel consumption, etc. can be displayed
on the screen.
1. Push the
“INFO” button to display
the information menu screen.
5u004
2. Touch the “Trip Information”switch.
Consumption
The consumption is calculated and dis-
played based on the driving distance and
the fuel consumption for 2 seconds with
engine running.
The value is updated every 2 seconds.
If you are driving at low speeds just before
stopping, the accurate figure way not be
shown.
After Refueling
The consumption after refueling is calcu-
lated and displayed based on the total
driving distance and the total fuel con-
sumption after refueling.
The value is updated every 10 seconds.
When refueling, be sure to stop your vehicle
and turn the ignition switch off.Cruising Range
How far you can drive with the remaining
fuel is displayed.
Even though the display indicates sufficient
miles to run, if the fuel level on the fuel gauge
approaches “E” or the low fuel level warning
light comes on, fill the fuel tank as soon as
possible.
INFORMATION
When you first start driving your new
vehicle, the correct cruising range
may not be shown. One or more re-
fills of 10 gallons or more may be re-
quired for the system to set its cal-
ibration.
The cruising range displayed is cal-
culated based on past fuel con-
sumption and may vary according to
your driving style and road condi-
tion.

cxliii
5u009
Contrast and brightness adjustment
CONTRAST “+”:
Strengthens the contrast of the screen.
CONTRAST “–”:
Weakens the contrast of the screen.
BRIGHTNESS “+”: Brightens the screen.
BRIGHTNESS “–”: Darkens the screen.
The screen turns off when you push the
“SCREEN OFF”. To turn the display screen
back on, push any bezel switch such as “OP-
TION”, etc. The selected screen appears.Color and tone adjustment
You can adjust the color and the tone while
the DVD video and Video CD are being
played.
COLOR “RED”:
Strengthens the red color of the screen.
COLOR “GREEN”:
Strengthens the green color of the screen.
TONE “+”: Strengthens the tone of the
screen.
TONE “–”: Weakens the tone of the screen.
5u0095u009
Depending on the position of the head-
light switch, the screen changes to the
day mode or night mode.
To display the screen in the day mode even
with the headlight switch on, touch “DAY
MODE” on the adjustment screen for bright-
ness and contrast control.
However, if the instrument panel light control
switch is turned fully to the right, mode
switching cannot be done. It remains in the
day mode. In this case, “DAY MODE” is not
shown on the screen.
If the screen is set in the day mode with the
headlight switch turned to on, this condition
is memorized in the system even with the en-
gine turned off.
