Electrical System
Add-On Electrical Equipment
Notice:Do not add anything electrical to your
vehicle unless you check with your retailer
rst. Some electrical equipment can damage
your vehicle and the damage would not
be covered by your warranty. Some add-on
electrical equipment can keep other
components from working as they should.
Your vehicle has an airbag system. Before
attempting to add anything electrical to your
vehicle, seeServicing Your Airbag-Equipped
Vehicle on page 88.
Windshield Wiper Fuses
The windshield wiper motor is protected by a
circuit breaker and a fuse. If the motor overheats
due to heavy snow or ice, the wiper will stop
until the motor cools. If the overload is caused by
some electrical problem, have it xed.
Power Windows and Other
Power Options
Circuit breakers in the fuse panel protect the
power windows and other power accessories.
When the current load is too heavy, the circuit
breaker opens and closes, protecting the circuit
until the problem is xed.
Fuses and Circuit Breakers
The wiring circuits in your vehicle are protected
from short circuits by fuses. This greatly reduces
the chance of circuit overload and re caused
by electrical problems.
There are two fuse blocks — the underhood fuse
block, and the instrument panel fuse block.
To identify and check fuses and relays, refer to
the Fuse Usage Chart on the inside surface of the
fuse panel door.
409
ProCarManuals.com

Instrument Panel Fuse Block
The instrument panel fuse block is located on the
passenger’s side of the lower console.
Fuses Usage
CRUISE Cruise Control Switch, Brake Switch
EPS Electronic Power Steering
IGN 1Instrument Cluster, Brake
Transmission Shift Interlock
Solenoid, Traction Switch, Fog
Lamp Switch
LOCK/MIRRORPower Door Locks, Power Mirror,
Entry Control
BCMBody Control Module, Front Wipers,
Windows, Sunroof
BCM (IGN 1) Body Control Module
AIR BAG Sensing and Diagnostic Module
RADIO (IGN)Radio, Power Mirror, Premium
Radio Amplier
TURN Turn Lamps
HVAC HVAC Control Head
HAZARD Hazard Lamps
HTD SEATS Heated Seats
RADIO Radio, Data Link Connector
PARKPark Lamps, Taillamps, Side Marker
Lamps, License Lamps
410
ProCarManuals.com

Fuses Usage
BCM/CLUSTERBody Control Module, Instrument
Cluster
INT LTS Body Control Module, OnStar
®
DR LKS Door Locks
Relays Usage
AFTER BLOW Not Used
HVAC
BLOWERHVAC Control Head
PK LP Parking Lamps
DR LCK All Door Lock Switch
PSG DR
UNLCKPassenger Door Unlock Switch
DRV DR
UNLCKDriver Door Unlock Switch
HDLP Headlamps
Underhood Fuse Block
The underhood fuse block is located in the
forward part of the engine compartment near
the battery.
Fuses Usage
ECM/TCMBattery Voltage to ECM, TCM, PCM
(3.5L V6 (L66))
BATT FEED Instrument Panel Fuse Box
HORN Horn
* * Emissions
411
ProCarManuals.com

Fuses Usage
ABS PWR Anti-lock Brake System Battery
REAR DEFOG Rear Defogger
COOL HI (L4)/
COOL 1 (V6)Cooling Fans High (L4)/Cooling
Fan 1 (V6)
FOG LP Fog Lamps
LH HDLP Driver’s Side Headlamp
RR WIPER Rear Wiper
ABS Anti-lock Brake System Module
PWR WDW Power Window Relay and Sunroof
CIGAR/AUX2 Cigarette Lighter
HVAC
BLOWERHVAC Blower Motor
RH HDLP Right Headlamp
FRT WIPER Front Wiper
ETCEngine Control Module (ECM),
Electronic Throttle Control (V6)
SUNROOF Sunroof Module
BRAKE Stoplamps
IGN Ignition switchFuses Usage
IGN/INJ (L4),
ECM/
CAM (V6)Engine Ignition Module, Fuel
Injectors (2.2L L4 (L61))
Camshaft Sensor, Main Relay
Voltage To PCM, Ignition Coils 1-6
INJECTORS
(3.5L V6 (L66))Fuel Injection
PWR TRAINEngine Control Module (ECM),
Transaxle Control Module (TCM),
Transaxle, L66 Powertrain Control
Module (PCM)
BACKUPLow Coolant Switch, Backup Lamps
(2.2L L4 (L61)), Vehicle Speed
Sensor (Manual), Transaxle Range
Switch (2.2L L4 (L61))
HTD SEATS Heated Seats
COOL
LO (L4)/
COOL 2 (V6)Cooling Fan Low (L4), Cooling
Fan (V6)
A/C CLUTCHAir Conditioning Clutch, Back Up
Lamps (3.5L V6 (L66))
FUEL PUMP Fuel Pump
AUX 1
OUTLETFront Auxiliary Power Outlet
412
ProCarManuals.com

Fuses Usage
PREM AUD Premium Radio Amplier
ABS Anti-lock Brake System Ignition
PWR SEAT Power Seats
Relays Usage
FOG LP Fog Lamps
COOL FAN
HI (L4)Cooling Fan Motor High
ENG MAINEngine Control Module/CAM,
Emissions, Injectors, Electronic
Throttle Control
REAR DEFOG Rear Defog System
HORN Horn
DRL Daytime Running Lamps
COOL
FAN 1 (V6)Cooling Fan
WIPER
SYSTEMWiper System
Relays Usage
PRW WDOPower Window Switch, Sunroof
Module
FRT WIPER Front Wiper System
COOL FAN
LOW (L4)Cooling Fan Motor Low
A/C CLUTCH Air Conditioning Clutch
BACKUP
LAMPS (V6)Back-up Lamps (V6)
FUEL PUMP Fuel Pump System
RR WIPER Rear Wiper System
COOL
FAN 2 (V6)Cooling Fan (V6)
Misc. Usage
FUSE PULLER Fuse Puller
Diode Air Conditioning Diode
413
ProCarManuals.com

Capacities and Specications
ApplicationCapacities
English Metric
Air Conditioning Refrigerant R134aFor the air conditioning system refrigerant charge
amount, see the refrigerant caution label located
under the hood. See your dealer for more
information.
Cooling System
2.2L L4 Automatic Engine 8.8 qt 8.3 L
2.2L L4 Manual Engine 9.1 qt 8.6 L
3.5L V6 Engine 10.3 qt 9.7 L
Engine Oil with Filter
2.2L L4 Engine 5.0 qt 4.7 L
3.5L V6 Engine 4.5 qt 4.3 L
Fuel Tank 16.6 gal 62.8 L
Transaxle
Five-Speed Automatic 4.5 qt 4.3 L
Five-Speed Automatic AWD 4.1 qt 3.9 L
Four-Speed Automatic 7.0 qt 6.6 L
Five-Speed Manual 1.7 qt 1.6 L
Wheel Nut Torque 100 ft lb
140Y
All capacities are approximate. When adding, be sure to ll to the approximate level, as recommended in this
manual. Recheck uid level after lling.
414
ProCarManuals.com

Engine Specications
Engine VIN Code Transaxle Spark Plug Gap
2.2L L4 (L61) DAutomatic
Manual0.040 inches (1.01 mm)
3.5L V6 (L66) 4 Automatic 0.043 inches (1.1 mm)
415
ProCarManuals.com
