2007 SATURN VUE HYBRID Owners Manual

The Tire and Loading Information label also shows
the size of the original equipment tires (C) and
the recommended cold tire ination pressures (D).
For more information on tires and ination see
Tires on page 339andInation - Tire Pressure on
page 345.
There is also important loading information on the
vehicle Certication/Tire label. It tells you the
Gross Vehicle Weight Rating (GVWR) and
the Gross Axle Weight Rating (GAWR) for the
front and rear axle. See “Certication/Tire Label”
later in this section.Steps for Determining Correct Load Limit
1. Locate the statement “The combined
weight of occupants and cargo should never
exceed XXX lbs” on your vehicle’s placard.
2. Determine the combined weight of the driver
and passengers that will be riding in your
vehicle.
3. Subtract the combined weight of the driver
and passengers from XXX kg or XXX lbs.
4. The resulting gure equals the available
amount of cargo and luggage load capacity.
For example, if the “XXX” amount equals
1400 lbs and there will be ve 150 lb
passengers in your vehicle, the amount of
available cargo and luggage load capacity is
650 lbs (1400−750 (5 x 150) = 650 lbs).
265
ProCarManuals.com

5. Determine the combined weight of luggage
and cargo being loaded on the vehicle. That
weight may not safely exceed the available
cargo and luggage load capacity calculated in
Step 4.
6. If your vehicle will be towing a trailer, the load
from your trailer will be transferred to your
vehicle. Consult this manual to determine how
this reduces the available cargo and luggage
load capacity of your vehicle.
SeeTowing a Trailer on page 274for important
information on towing a trailer, towing safety rules
and trailering tips.
Item Description Total
AVehicle Capacity
Weight for Example 1=1,000 lbs (453 kg)
BSubtract
Occupant Weight
150 lbs (68 kg)×2=300 lbs (136 kg)
CAvailable Occupant
and Cargo Weight =700 lbs (317 kg) Example 1
266
ProCarManuals.com

Item Description Total
AVehicle Capacity
Weight for Example 2=1,000 lbs (453 kg)
BSubtract
Occupant Weight
150 lbs (68 kg)×5=750 lbs (340 kg)
CAvailable Occupant
and Cargo Weight =250 lbs (113 kg)Item Description Total
AVehicle Capacity
Weight for Example 3=1,000 lbs (453 kg)
BSubtract
Occupant Weight
200 lbs (91 kg)×5=1,000 lbs (453 kg)
CAvailable Occupant
and Cargo Weight =0 lbs (0 kg)
Refer to your vehicle’s tire and loading information
label for specic information about your vehicle’s
capacity weight and seating positions. The
combined weight of the driver, passengers and
cargo should never exceed your vehicle’s
maximum vehicle capacity weight.
Example 2Example 3
267
ProCarManuals.com

Certication/Tire Label
A vehicle specic Certication/Tire label is attached
to the rear edge of the driver’s door. The label
shows the gross weight capacity of your vehicle.
This is called the Gross Vehicle Weight Rating
(GVWR). The GVWR includes the weight of the
vehicle, all occupants, fuel, cargo, and trailer
tongue weight, if your vehicle is pulling a trailer.
The Certication/Tire label also tells you the
maximum weights for the front and rear axles,
called Gross Axle Weight Rating (GAWR).To nd out the actual loads on your front and rear
axles, you need to go to a weigh station and
weigh your vehicle. Your retailer can help you with
this. Be sure to spread out your load equally on
both sides of the centerline.
Never exceed the GVWR for your vehicle, or the
GAWR for either the front or rear axle.
Similar looking vehicles may have different
GVWRs and payloads. Please consult your
vehicle’s Certication/Tire label or your retailer
for additional details.
{CAUTION:
Do not load your vehicle any heavier than
the Gross Vehicle Weight Rating (GVWR),
or either the maximum front or rear Gross
Axle Weight Rating (GAWR). If you do,
parts on your vehicle can break, and it
can change the way your vehicle handles.
These could cause you to lose control
and crash. Also, overloading can shorten
the life of your vehicle.
268
ProCarManuals.com

Using heavier suspension components to get
added durability might not change your vehicle’s
weight ratings. Ask your retailer to help you
load your vehicle correctly if you are using these
components.
Notice:Overloading your vehicle may cause
damage. Repairs would not be covered by your
warranty. Do not overload your vehicle.
If you put things inside your vehicle — like
suitcases, tools, packages, or anything
else — they will go as fast as the vehicle goes.
If you have to stop or turn quickly, or if there is a
crash, they will keep going.
{CAUTION:
Things you put inside your vehicle can
strike and injure people in a sudden stop
or turn, or in a crash.
Put things in the cargo area of your
vehicle. Try to spread the weight
evenly.
Never stack heavier things, like
suitcases, inside the vehicle so that
some of them are above the tops of
the seats.
Do not leave an unsecured child
restraint in your vehicle.
When you carry something inside the
vehicle, secure it whenever you can.
Do not leave a seat folded down
unless you need to.
269
ProCarManuals.com

Towing
Towing Your Vehicle
Consult your retailer or a professional towing
service if you need to have your disabled vehicle
towed. SeeRoadside Assistance Program on
page 413.
If you want to tow your vehicle behind another
vehicle for recreational purposes (such as behind
a motorhome), see “Recreational Vehicle
Towing” following.
Recreational Vehicle Towing
Recreational vehicle towing means towing your
vehicle behind another vehicle – such as behind a
motorhome. The two most common types of
recreational vehicle towing are known as “dinghy
towing” (towing your vehicle with all four wheels
on the ground) and “dolly towing” (towing
your vehicle with two wheels on the ground and
two wheels up on a device known as a “dolly”).
With the proper preparation and equipment,
many vehicles can be towed in these ways.
See “Dinghy Towing” and “Dolly Towing” following
in this section.
270
ProCarManuals.com

Here are some important things to consider before
you do recreational vehicle towing:
What’s the towing capacity of the towing
vehicle? Be sure you read the tow vehicle
manufacturer’s recommendations.
How far will you tow? Some vehicles have
restrictions on how far and how long they
can tow.
Do you have the proper towing equipment?
See your retailer or trailering professional
for additional advice and equipment
recommendations.
Is your vehicle ready to be towed? Just as
you would prepare your vehicle for a long
trip, you’ll want to make sure your vehicle is
prepared to be towed. SeeBefore Leaving on
a Long Trip on page 253.
Dinghy Towing
Your hybrid vehicle may be dinghy towed from the
front. It may also be towed by putting the front
wheels on a dolly. See “Dolly Towing” later in this
section.
To tow your vehicle from the front with all
four wheels on the ground, do the following:
1. Position and attach the vehicle to tow it behind
the recreational vehicle.
2. Turn the ignition key to ACC.
3. Turn fog lamps and all accessories off.
271
ProCarManuals.com

4. Shift the transaxle from DRIVE (D) to
NEUTRAL (N) and let the engine run for
three minutes. Then turn it off.
Due to transaxle uid drain back, the transaxle
lubrication procedure in Step 4 is required
every seven hours after the initial procedure
has been completed, regardless of the vehicle
being towed or parked. Once the procedure
is performed, the transaxle is adequately
lubricated and can be recreational vehicle
towed for seven hours prior to repeating the
lubrication procedure.
As an example, if you initially perform the
lubrication procedure and tow your vehicle for
three hours, then park for four hours, the
lubrication procedure will need to be
performed again, prior to dinghy towing the
vehicle.
Notice:Towing your vehicle after shifting the
transaxle from anything other than DRIVE (D)
to NEUTRAL (N) can cause internal damage to
the transaxle. Always shift the transaxle
from DRIVE (D) to NEUTRAL (N) as the last
shift before towing.5. Locate and remove the large IGN fuse from
the underhood fuse block. SeeUnderhood
Fuse Block on page 382.
Notice:If you tow your vehicle without
performing each of the steps listed under
“Dinghy Towing,” you could damage the
automatic transaxle. Be sure to follow all steps
of the dinghy towing procedure prior to and
after towing your vehicle.
Notice:Your vehicle can be dinghy towed
from the front for unlimited miles at 65 mph
(105 km/h). If you exceed 65 mph (105 km/h)
while towing your vehicle, it could be damaged.
The repairs would not be covered by your
warranty. Never exceed 65 mph (105 km/h)
while towing your vehicle.
272
