System settingsLanguage/Unit:
The LANGUAGE/UNIT screen will appear when
selecting the “Language/Unit” key and pushing
the “ENTER” button.
Language: English or French
Unit: US — Mile, °F, MPG
Metric — km, °C, L/100 km
You can select the language and unit using the
joystick and “ENTER” button.Clock:
Adjusting the time
Select the “Hours” or “Minutes” key and move
the joystick to the right or left to adjust the time.
The time will change step by step.
After completion of the setting, push the “BACK”
button.
Setting daylight saving time
Turn ON or OFF daylight saving time.
Every time the “Daylight Saving Time” key is
selected, the light turns ON and OFF alternately.ON: The displayed time advances by one hour.
OFF: The current time is displayed.
Adjusting the time to the GPS
Select the “Auto Adjust” key.
The time will be reset to the GPS time.
SAA1327
SAA1328
4-18
Display screen, heater, air conditioner and audio systems


06.7.5/Z50-D/V5.0


Selecting the time zone
1. Select the “Select Time Zone” key.
The TIME ZONE screen will appear.
2. Select one of the following zones depending
on the current location.

“Pacific” zone

“Mountain” zone

“Central” zone

“Eastern” zone

“Atlantic” zone
“Newfoundland” zone
After selection, the CLOCK SETTINGS screen
will appear.
The GPS time (manual time) corresponding to
the selected zone will be displayed.
“Pacific” zone has been set as the initial (default)
setting.
Beep setting:
When Beep setting is on (indicator light on), a
beep will sound if any audio button is pushed.
“DAY/NIGHT” BUTTONPushing the “DAY/NIGHT” button will change
the display to the DAY or NIGHT display. Then,
adjust the brightness moving the joystick right or
left.
If no operation is done within 10 seconds, or if
the “BACK” button is pushed, the display will
return to the previous display.
Pushing the “DAY/NIGHT” button for more than
approximately 2 seconds will turn the display off
and on.When the selector lever is shifted into the R
(Reverse) position, the monitor display shows
view to the rear of the vehicle.
The system is designed as an aid to the driver in
detecting large stationary objects to help avoid
damaging the vehicle. The system will not detect
small objects below the bumper and may not
detect objects close to the bumper or on the
ground.
WARNING

The rear view camera is a conve-
nience but it is not a substitute for
proper backing. Always turn and
check that it is safe to do so before
backing up. Always back up slowly.

Objects viewed in the RearView
Monitor differ from actual distance
because a wide-angle lens is used.
Objects in the RearView Monitor will
appear visually opposite like ones
viewed in the inside and outside mir-
rors.

Make sure that the lift gate is se-
curely closed when backing up.
SAA1329
REARVIEW MONITOR (if so
equipped)
Display screen, heater, air conditioner and audio systems
4-19


06.7.5/Z50-D/V5.0


Underneath the bumper and the cor-
ner areas of the bumper cannot be
viewed on the RearView Monitor be-
cause of its monitoring range limita-
tion.

Do not put anything on the rear view
camera. The rear view camera is in-
stalled above the license plate.

When washing the vehicle with high-
pressure water, be sure not to spray
it around the camera. Otherwise, wa-
ter may enter the camera unit caus-
ing water condensation on the lens, a
malfunction, fire or an electric shock.

Do not strike the camera. It is a pre-
cision instrument. Otherwise, it may
malfunction or cause damage result-
ing in a fire or an electric shock.
CAUTION
There is a plastic cover over the camera.
Do not scratch the cover when cleaning
dirt or snow from it.
HOW TO READ THE DISPLAYED
LINESLines which indicate the vehicle clearance and
distances to objects with reference to the
bumper line
A
are displayed on the monitor.
They are indicated as reference distances to
objects. Displayed lines indicate distances 1.5
feet (red)
1, 3 feet (yellow)
2, 7 feet (green)
3and 10 feet (green)
4from the lower part of
the bumper line
A.
The vehicle clearance lines are wider than
the actual clearance.
REARVIEW MONITOR SETTING
WARNING
Do not adjust the Brightness, Contrast,
Tint and Color of the RearView Monitor
while the vehicle is moving. Make sure
the parking brake is firmly applied and
the engine is not running.
To adjust the Brightness, Contrast, Tint and
Color of the RearView Monitor, push the “SET-
TING” button with the RearView Monitor on,
select the item key and adjust the level using the
joystick.OPERATING TIPS
When the selector lever is shifted to R, the
monitor screen automatically changes to the
RearView Monitor mode. However, the radio
can be heard.

It may take some time until the RearView
Monitor is displayed after the selector lever
has been shifted to R. Objects may be dis-
torted momentarily until the RearView Moni-
tor screen is displayed completely. When the
selector lever is returned to a position other
than R, it may take some time until the screen
SAA0889
4-20
Display screen, heater, air conditioner and audio systems


06.7.5/Z50-D/V5.0


changes. Objects on the screen may be
distorted until they are completely displayed.

When the temperature is extremely high or
low, the screen may not clearly display ob-
jects. This is not a malfunction.

When strong light directly enters the camera,
objects may not be displayed clearly.

Vertical lines may be seen in objects on the
screen. This is due to strong reflected light
from the bumper. This is not a malfunction.

The screen may flicker under fluorescent
light. This is not a malfunction.

The colors of objects on the RearView Moni-
tor may differ somewhat from those of the
actual object.

When the contrast of objects is low at night,
pushing the “ENTER” button may not change
the brightness.

Objects on the monitor may not be clear in a
dark place or at night.

If dirt, rain or snow attaches to the camera,
the RearView Monitor may not clearly display
objects. Clean the camera.

Do not use alcohol, benzine or thinner to
clean the camera. This will cause discolora-
tion. To clean the camera, wipe with a clothdampened with diluted mild cleaning agent
and then wipe with a dry cloth.

Do not damage the camera as the monitor
screen may be adversely affected.

Do not use body wax on the camera window.
Wipe off any wax with a clean cloth damp-
ened with mild detergent diluted with water.
SAA1064
Center ventilators
SAA1065A
Side ventilators
VENTILATORS
Display screen, heater, air conditioner and audio systems
4-21


06.7.5/Z50-D/V5.0


Open or close, and/or adjust the air flow direc-
tion of ventilators.
: This symbol indicates that the vents are
closed when the vent switch is moved to
the left.: This symbol indicates that the vents are
open when the vent switch is moved to
the right.
SAA1066
Rear ventilator (if so equipped)
4-22
Display screen, heater, air conditioner and audio systems


06.7.5/Z50-D/V5.0


1. “AUTO” climate control ON button
2. “
” fresh air button
3. “” air recirculation button
4. “” front defroster button5. “
” rear window defroster switch; refer
to the “2. Instrument and controls” section.
6. “A/C” air conditioner ON/OFF button
7. “MODE” manual air flow control button8. Temperature control knob(driver only, or
driver and passenger)
9. “OFF” button for climate control system
10. Fan speed control knob
11. “DUAL” passenger side temperature con-
trol ON/OFF button
12. Temperature control knob(passenger side)
SAA0641
HEATER AND AIR CONDITIONER
(Automatic)
Display screen, heater, air conditioner and audio systems
4-23


06.7.5/Z50-D/V5.0


WARNING

The air conditioner cooling function
operates only when the engine is
running.

On hot, sunny days, temperatures in
a closed vehicle could quickly be-
come high enough to cause severe or
possibly fatal injuries to people or
animals. Do not leave children or
adults who would normally require
the assistance of others in your ve-
hicle. Unattended pets should also
not be left alone.

Do not use the recirculation mode for
long periods as it may cause the
interior air to become stale and the
windows to fog up.
Start the engine and operate the controls to
activate the air conditioner.
AUTOMATIC OPERATION
Cooling and/or dehumidified heating
(AUTO)This mode may be normally used all year round
as the system automatically works to keep a
constant temperature. Air flow distribution and
fan speed are also controlled automatically.
1. Push the AUTO button on. (AUTO will be
displayed.)
2. Turn the temperature set dial to the left or
right to set the desired temperature.

Adjust the temperature set dial to about 75°F
(24°C) for normal operation.

The temperature of the passenger compart-
ment will be maintained automatically. Air
flow distribution and fan speed are also con-
trolled automatically.
3. You can individually set driver and front pas-
senger side temperature using each tem-
perature control knob. When the DUAL but-
ton is pushed or passenger side temperature
control knobis turned, the DUAL indicator
will come on. To turn off the passenger side
temperature control, push the DUAL button.
A visible mist may be seen coming from the
ventilators in hot, humid conditions as the air iscooled rapidly. This does not indicate a malfunc-
tion.
Heating (A/C OFF)The air conditioner does not activate. When you
need to heat only, use this mode.
1. Push the A/C button. (A/C OFF will be
displayed and A/C indicator will turn off.)
2. Turn the temperature set dial to the left or
right to set the desired temperature.

The temperature of the passenger compart-
ment will be maintained automatically. Air
flow distribution and fan speed are also con-
trolled automatically.

Do not set the temperature lower than the
outside air temperature. Otherwise the sys-
tem may not work properly.

Not recommended if windows fog up.Dehumidified defrosting or defogging1. Push the
FRONT defroster button on.
(The indicator light on the button will come
on.)
2. Turn the temperature set dial to the left or
right to set the desired temperature.

To quickly remove ice from the outside of the
windows, turn the fan speed control knobto
4-24
Display screen, heater, air conditioner and audio systems


06.7.5/Z50-D/V5.0


right and set to the maximum position.

As soon as possible after the windshield is
clean, push the AUTO button to return to the
auto mode.

When the
front defroster button is
pushed, the air conditioner will automatically
be turned on at outside temperatures above
23°F (−5°C) to defog the windshield, and the
air recirculate mode will automatically be
turned off.
Outside air is drawn into the passenger
compartment to improve the defogging per-
formance.
MANUAL OPERATION
Fan speed controlTurn the fan control button
to manually
control the fan speed.
Push the AUTO button to return to automatic
control of the fan speed.
Air recirculationPush the air recirculation button
to recir-
culate interior air inside the vehicle. The indicator
light on the
button will come on.
The air recirculation
cannot be activatedwhen the air conditioner is in the front defrosting
mode
.
Fresh airPush the button
to draw outside air into
the passenger compartment. The indicator light
on the
button will come on.
Automatic intake air controlIn the AUTO mode, the intake air will be con-
trolled automatically. To manually control the
intake air, push the air recirculate
or fresh
air
button. To return to the automatic
control mode, push the indicator-illuminated but-
ton for about 2 seconds. The indicator lights
(both air recirculate and fresh air buttons) will
flash twice, and then the intake air will be
controlled automatically.
Air flow controlPushing the MODE manual air flow control
button selects the air outlet to:
: Air flows from center and side ventila-
tors.: Air flows from center and side ventila-
tors and foot outlets.: Air flows from foot outlets and side
ventilators.
: Air flows from defroster, foot outlets
and side ventilators.
To turn the system offPush the OFF button.OPERATING TIPSWhen the engine coolant temperature and out-
side air temperature are low, the air flow from the
foot outlets may not operate for a maximum of
150 seconds. However, this is not a malfunction.
After the coolant temperature warms up, the air
flow from the foot outlets will operate normally.
Display screen, heater, air conditioner and audio systems
4-25


06.7.5/Z50-D/V5.0
