your vehicle before doing so.
To open, push the cellular phone holder lid
1
as illustrated.
The inner tray can be removed
2
as illustrated.
Do not place valuable items in the holder.
Do not use the cellular phone holder as an
ashtray.
CUP HOLDERS
CAUTION

Avoid abrupt starting and braking
when the cup holder is being used to
prevent spilling the drink. If the liquid
is hot, it can scald you or your pas-
senger.

Use only soft cups in the cup holder.
Hard objects can injure you in an
accident.
FrontPush the cup holder opener button
A
to open.
The flap
Bwill be folded down when inserting a
bigger container.
Pull up the inner tray
Cto remove for cleaning.
SIC3039
2-32
Instruments and controls


06.7.5/Z50-D/V5.0


RearType A:
Pull the armrest forward until it is horizontal.Type B:
Push
A
to open the cup holder.
GLOVE BOX
WARNING
Keep glove box lid closed while driving
to help prevent injury in an accident or a
sudden stop.
To open the glove box, pull the handle
A.
To close, push the lid in until the lock latches.
To lock
2
or unlock
1
the glove box, use the
master key, mechanical key (Intelligent Key sys-
tem) or wallet key.
SIC3042
Type A
SIC2315A
Type B
SIC2669
Instruments and controls
2-33


06.7.5/Z50-D/V5.0


CONSOLE BOX
Type APush the button
A
to open the upper console
box lid.The partition
C
can be removed.
Pull up the buttonBto open the lower console
box lid.
Push the button
Dand adjust the armrest to the
desired position.
SIC3043
Type A
2-34
Instruments and controls


06.7.5/Z50-D/V5.0


Type BPush the button
A
to open the console box lid.
The inside of the console box lid is designed to
be used as a holderB
such as pen, etc. There
is a power outlet
C
inside the console box.Remove the inside tray
D
to store a large
object.
To lock the console box, turn the key to the
1
position.To unlock the console box, turn the key to the
2
position.
Push the button
3and adjust the armrest to the
desired position.
SIC2208A
Type B
Instruments and controls
2-35


06.7.5/Z50-D/V5.0


DOOR POCKETSThe door pockets are located on the driver’s and
front passenger’s doors. The door pocket open-
ing can be expanded to make it easier to store
and retrieve items. Items stored in the door
pocket should not be larger than the door pocket
opening in its closed position. Make sure that the
item does not hold the door pocket in the open
position.
CAUTION
Do not store items in the door pocketthat are larger than the opening in the
closed position. Do not force the door
pocket closed if an item holds the door
pocket in the open position. Doing so
may damage the door pocket.
CARGO NET (if so equipped)The cargo net helps keep packages in the cargo
area from moving around while your vehicle is
driven.
To install the cargo net, attach the hooks to the
retainers
A
on both sides.
To remove the cargo net, detach the hooks from
the cargo net retainers.
For more retainers, refer to “Vehicle loading
information” in the “9. Technical and consumer
information” section.
SIC3171
SIC2061
2-36
Instruments and controls


06.7.5/Z50-D/V5.0


WARNING

Properly secure all cargo to help pre-
vent it from sliding or shifting.

Be sure to secure all four hooks into
the retainers. The cargo restrained in
the net must not exceed 30 lbs (13.6
kg) or the net may not stay secured.
TONNEAU COVER (if so equipped)The tonneau cover keeps the luggage compart-
ment contents hidden from the outside.
To use the tonneau cover, pull it out
1, hang
both sides on the hooks
2
and open the flap
3.
To use the subcover, pull out
4and hang both
sides on the hooks behind the rear seat head
restraint
5.
To stow the tonneau cover and the subcover,
remove them from the hooks and hold until they
are retracted.
To remove the tonneau cover, stow the cover
and pull the holder to the opposite side
6.
WARNING

Never put anything on the tonneau
cover, no matter how small. Any ob-
ject on it could cause an injury in an
accident or sudden stop.

Close the tonneau and sub covers
when folding the rear seat.

Do not leave the tonneau cover in the
vehicle with it disengaged from the
SIC3058
Instruments and controls
2-37


06.7.5/Z50-D/V5.0


holder.

Properly secure all cargo to help pre-
vent it from sliding or shifting. Do not
place cargo higher than the seat-
backs. In a sudden stop or collision,
unsecured cargo could cause per-
sonal injury.

The child restraint top tether strap
may be damaged by contact with the
tonneau cover or items in the cargo
area. Remove the tonneau cover from
the vehicle or secure it in the cargo
area. Also secure any items in the
cargo area. Your child could be seri-
ously injured or killed in a collision if
the top tether strap is damaged.
POWER WINDOWS
WARNING

Make sure that all passengers have
their hands, etc. inside the vehicle
while it is in motion and before clos-
ing the windows. Use the window
lock switch to prevent unexpected
use of the power windows.

Do not leave children unattended in-
side the vehicle. They could unknow-
ingly activate switches or controls
and become trapped in a window.
Unattended children could become
involved in serious accidents.
The power windows operate when the ignition
switch is in the ON position and for about 45
seconds, after the ignition switch is turned to the
ACC or OFF position. If the driver’s door or the
front passenger’s door is opened during this
period of about 45 seconds, power to the
windows is canceled.
Main power window switch (driver’s
side)1. Rear left passenger’s side window
2. Driver’s side window
3. Window lock button
4. Rear right passenger’s side window
5. Front passenger’s side window
To open or close the window, push down
A
or
pull up
B
the switch and hold it. The main
switch (driver side switches) will open or close
all the windows.
SIC3283
WINDOWS
2-38
Instruments and controls


06.7.5/Z50-D/V5.0


Locking passenger’s windowsWhen the lock button
C
is pushed in, only the
driver side window can be opened or closed.
Push it in again to cancel.
Passenger side power window switchThe passenger side switch will open or close
only the corresponding window. To open or
close the window, hold the switch down
A
or
up
B.
Automatic operationTo fully open or close the driver’s or front
passenger’s side window, completely push
down or pull up the switch and release it; it need
not be held. The window will automatically open
or close all the way. To stop the window, just
push or lift the switch on the opposite side.Auto reverse function (if so equipped)If the control unit detects something caught in a
front window as it moves up, the window will be
immediately lowered.
The auto reverse function can be activated when
a front window is closed by automatic operation
SIC3284
SIC3285
Instruments and controls
2-39


06.7.5/Z50-D/V5.0
