2007 NISSAN MURANO automatic transmission fluid

Shift lock releaseIf the battery charge is low or discharged, the
selector lever may not be moved from the P
(Park) position even with the brake pedal de-
pressed.
To move the selector lever, depress the brake
pedal, remove the cover (if so equipped) using a
suitable tool and push the shift lock release
button. The selector lever can be moved to N
(Neutral). This allows the vehicle to be moved if
the battery is discharged.
If the selector lever cannot be moved out of P
(Park), have a NISSAN dealer check the CVTsystem as soon as possible.
Accelerator downshift
— In D position —For rapid passing or hill climbing, fully depress
the accelerator pedal to the floor. This shifts the
transmission down into lower range, depending
on the vehicle speed.High fluid temperature protection
modeThis transmission has a high fluid temperature
protection mode. If the fluid temperature be-
comes too high (for example, when climbing
steep grades in high temperature with heavy
loads, such as when towing a trailer), engine
power and, under some conditions, vehicle
speed will be decreased automatically to reduce
the chance of transmission damage. Vehicle
speed can be controlled with the accelerator
pedal, but the vehicle may not accelerate above
approximately 40 to 50 MPH (65 to 80 km/h).Fail-safeIf the vehicle is driven under extreme con-
ditions, such as excessive wheel spinning
and subsequent hard braking, the fail-safe
system may be activated. The MIL may
come on to indicate the fail-safe mode is
activated, see “Malfunction indicator light(MIL)” in the “2. Instrument and controls”
section. This will occur even if all electrical
circuits are functioning properly. In this
case, turn the ignition switch to the OFF
position and wait for 10 seconds. Then turn
the switch back to the ONposition. The
vehicle should return to its normal operat-
ing condition. If it does not return to its
normal operating condition, have a
NISSAN dealer check the transmission and
repair if necessary.
WARNING
When the high fluid temperature protec-
tion mode or fail-safe operation occurs,
vehicle speed may be gradually re-
duced. The reduced speed may be lower
than other traffic, which could increase
the chance of a collision. Be especially
careful when driving. If necessary, pull
to the side of the road at a safe place
and allow the transmission to return to
normal operation, or have it repaired if
necessary.
SSD0290
5-16
Starting and driving


06.7.5/Z50-D/V5.0


N (Neutral):
Neither forward or reverse gear is engaged. The
engine can be started in this position. You may
shift to N (Neutral) and restart a stalled engine
while the vehicle is moving.
D (Drive):
Use this position for all normal forward driving.Manual shift modeWhen the selector lever is shifted from D to the
manual shift gate with the vehicle stopped or
while driving, the transmission enters the manual
shift mode. Shift ranges can be selected manu-
ally.
In the manual shift mode, the shift range is
displayed on the position indicator in the meter.
Shift ranges up or down one by one as follows:M1→
←M2→
←M3→
←M4→
←M5→
←M6M6 (Sixth):
Use this position for all normal forward driving.
M5 (Fifth):
For driving up or down long slopes where engine
braking would be advantageous.M4 (Fourth), M3 (Third) and M2 (Second):
Use for hill climbing or engine braking on down-
hill grades.
M1 (First):
Use this position when climbing steep hills
slowly or driving slowly through deep snow, or
for maximum engine braking on steep downhill
grades.

Remember not to drive at high speeds for
extended periods of time in lower than M6
range. This reduces fuel economy.

When shifting up, move the selector lever to
the + (up) side. (Shifts to higher range.)

When shifting down, move the selector lever
to the − (down) side. (Shifts to lower range.)

Moving the selector lever to the same side
twice will shift the ranges in succession.
However, if this motion is rapidly done, the
second shifting may not be completed prop-
erly.

In the manual shift mode, the transmis-
sion automatically shifts down to M1
(First) before the vehicle comes to a
stop. When accelerating again, it is nec-
essary to shift up to the desired range.

When canceling the manual shift mode, re-
turn the selector lever to the D position. Thetransmission returns to the normal driving
mode.

In the manual shift mode, the transmis-
sion may not shift to the selected gear.
This helps maintain driving performance
and reduces the chance of vehicle dam-
age or loss of control.

When the CVT fluid temperature is extremely
low, the manual shift mode may not work and
automatically shift as a drive mode. This is not
a malfunction. In this case, return the selector
lever to D range and drive for a while and then
shift to the manual shift mode.

When the CVT fluid temperature is high, the
shift range may upshift in lower rpm than
usual. This is not a malfunction.
Starting and driving
5-19


06.7.5/Z50-D/V5.0


Shift lock releaseIf the battery is discharged, the selector lever
may not be moved from the P (Park) position
even with the brake pedal depressed.
To move the selector lever, push the shift lock
release button while depressing the foot brake
and applying the parking brake. The selector
lever can be moved to N (Neutral). This allows
the vehicle to be moved if the battery is dis-
charged, after releasing the parking brake.
If the battery is discharged in N (Neutral), D
(Drive) or Manual shift mode, the selector lever
may not be moved to the P (Park) position.If it is necessary to park the vehicle, push the
shift lock release button, then move the selector
lever to the P (Park).
To push the shift lock release button, follow the
procedure as illustrated.
If the lever cannot be moved out of P (Park), have
a NISSAN dealer check the CVT system as soon
as possible.
WARNING

If the selector lever cannot be moved
from the P (Park) position while the
engine is running and the brake
pedal is depressed, the stop lights
may not work. Malfunctioning stop
lights could cause an accident injur-
ing yourself and others.

Do not park the vehicle without shift-
ing to the P (Park) position.Accelerator downshift
— In D position —For passing or hill climbing, fully depress the
accelerator pedal to the floor. This shifts the
transmission down into the lower gear, depend-ing on the vehicle speed.
High fluid temperature protection
modeThis transmission has a high fluid temperature
protection mode. If the fluid temperature be-
comes too high (for example, when climbing
steep grades in high temperature with heavy
loads, such as when towing a trailer), engine
power and, under some conditions, vehicle
speed will be decreased automatically to reduce
the chance of transmission damage. Vehicle
speed can be controlled with the accelerator
pedal, but the vehicle may not accelerate above
approximately 40 to 50 MPH (65 to 80 km/h).Fail-safeIf the vehicle is driven under extreme con-
ditions, such as excessive wheel spinning
and subsequent hard braking, the fail-safe
system may be activated. The MIL may
come on to indicate the fail-safe mode is
activated, see “Malfunction indicator light
(MIL)” in the “2. Instrument and controls”
section. This will occur even if all electrical
circuits are functioning properly. In this
case, turn the ignition switch to the OFF
position and wait for 10 seconds. Then turn
the switch back to the ONposition. The
vehicle should return to its normal operat-
SSD0352
5-20
Starting and driving


06.7.5/Z50-D/V5.0


The following are approximate capacities. The actual refill capacities may be a little different. When refilling, follow the procedure
instructed in the “8. Maintenance and do-it-yourself” section to determine the proper refill capacity.
Capacity (Approximate)
Recommended
specifications US
measureImp
measureLiter
Fuel 21-5/8 gal 18 gal 82 Unleaded gasoline with an octane rating of at least 87 AKI (RON 91)*1
Engine oil*5
Drain and refill
With oil filter change 4-1/4 qt 3-1/2 qt 4.0

Engine oil with API Certification Mark*2

Viscosity SAE 5W-30
Without oil filter change 3-7/8 qt 3-1/4 qt 3.7
Cooling system
With reservoir 10-1/8 qt 8-1/2 qt 9.6
50% Genuine NISSAN Long Life Antifreeze/Coolant or equivalent
50% Demineralized or distilled water
Reservoir 7/8 qt 3/5 qt 0.8
Differential gear oil — — —Genuine NISSAN Differential Oil Hypoid Super GL-5 8W-90 or
API GL-5, Viscosity SAE 80W-90*3
CVT fluid — — — Genuine NISSAN CVT Fluid NS-2*4
Transfer oil — — — API GL-5, Viscosity SAE 80W-90
Power steering fluid (PSF)
Refill to the proper oil level according to the instructions in
the “8. Maintenance and do-it-yourself” section.Genuine NISSAN PSF or equivalent*6
Brake fluidGenuine NISSAN Super Heavy Duty Brake Fluid*7 or equivalent DOT 3
Multi-purpose grease — — — NLGI No. 2 (Lithium soap base)
Air conditioning system refrigerant — — — HFC-134a (R-134a)*8
Air conditioning system lubricants — — —NISSAN A/C System Oil
Type S or exact equivalent
Windshield washer fluidGenuine NISSAN Windshield Washer Concentrate Cleaner & Antifreeze or equivalent
*1: For additional information, see later in this paragraph for fuel recommendation.
*2: For additional information, see later in this paragraph for engine oil and oil filter recommendation.
*3: For hot climates, viscosity SAE 90 is suitable for ambient temperatures above 0°C (32°F).
*4:Use only Genuine NISSAN CVT Fluid NS-2. Using transmission fluid other than Genuine NISSAN CVT Fluid NS-2 will damage the CVT transmission,
which is not covered by the Nissan new vehicle limited warranty.
*5: For additional information, see “Engine oil” in the “8. Maintenance and do-it-yourself” section for changing engine oil.
*6: For Canada, NISSAN Automatic Transmission Fluid (ATF), DEXRON
TMIII/MERCON
TMor equivalent ATF may also be used.
*7: Available in mainland U.S.A. through a NISSAN dealer.
*8: For additional information, see “Vehicle identification” in this section for air conditioner specification label.
CAPACITIES AND
RECOMMENDED
FUEL/LUBRICANTS9-2
Technical and consumer information


06.7.5/Z50-D/V5.0


Chimes
Audible reminders............................................... 2-16
Seat belt warning light and chime ................. 2-13
Circuit breaker, Fusible link .................................... 8-22
Cleaning exterior and interior .......................... 7-2, 7-4
Clock (models with navigation
system) .................................................................. 4-4, 4-9
Clock (models without navigation
system) ......................................................................... 4-18
Coin box ...................................................................... 2-31
Cold weather driving ................................................ 5-34
Compact Disc (CD) changer (See audio
system) ......................................................................... 4-42
Compact Disc (CD) player (See audio
system) ......................................................................... 4-36
Compass display ......................................................... 2-6
Console box................................................................ 2-34
Continuously variable transmission (CVT)
indicator light .............................................................. 2-14
Control panel buttons (models with navigation
system) ......................................................................... 4-11
Control panel buttons (models without
navigation system) ....................................................... 4-2
Controls
Control panel buttons (display with
navigation system) .............................................. 4-11
Control panel buttons (display without
navigation system) ................................................ 4-2
Heater and air conditioner controls
(automatic)............................................................ 4-23
Coolant
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Changing engine coolant .................................... 8-9
Checking engine coolant level........................... 8-8Corrosion protection ................................................... 7-5
Cover, Tonneau cover .............................................. 2-37
Cruise control............................................................. 5-22
Cruise set indicator light ......................................... 2-14
Cup holders ................................................................ 2-32
CVT fluid...................................................................... 8-12
CVT, Driving with CVT (Continuously Variable
Transmission) ............................................................. 5-13
D
Daytime running light system ................................. 2-25
Defroster switch, Rear window and outside mirror
defroster switch ......................................................... 2-22
Dimensions and weights ............................................ 9-8
Display controls (See control panel buttons),
With navigation system............................................ 4-11
Display controls (See control panel buttons),
Without navigation system ........................................ 4-2
Door open warning light .......................................... 2-11
Door pockets .............................................................. 2-36
Drive belts ................................................................... 8-16
Drive positioner .......................................................... 3-33
Driving
All-wheel drive (AWD) ...................................... 5-25
Cold weather driving ......................................... 5-34
Driving with CVT (Continuously Variable
Transmission) ....................................................... 5-13
On-pavement and offroad driving ..................... 5-6
Precautions when starting and driving ............ 5-2
Safety precautions ................................................ 5-6E
Economy, Fuel............................................................ 5-24
Emergency unlock lever........................................... 3-25
Emission control information label ........................ 9-10
Emission control system warranty......................... 9-24
Engine
Before starting the engine................................ 5-12
Break-in schedule............................................... 5-24
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Changing engine coolant .................................... 8-9
Changing engine oil ........................................... 8-10
Changing engine oil filter ................................. 8-11
Checking engine coolant level........................... 8-8
Checking engine oil level .................................... 8-9
Coolant temperature gauge ............................... 2-5
Engine block heater ........................................... 5-35
Engine compartment check locations.............. 8-7
Engine cooling system ......................................... 8-8
Engine oil................................................................. 8-9
Engine oil and oil filter recommendation......... 9-5
Engine oil viscosity ............................................... 9-5
Engine serial number ......................................... 9-10
Engine specifications ........................................... 9-7
If your vehicle overheats ................................... 6-11
Starting the engine............................................. 5-13
Entry/exit function, Automatic drive
positioner ..................................................................... 3-33
Event data recorders ................................................ 9-26
Exhaust gas (Carbon monoxide).............................. 5-2


06.7.5/Z50-D/V5.0

10-2

F
F.M.V.S.S./C.M.V.S.S. certification label ............. 9-10
Filter
Air cleaner housing filter ................................... 8-17
Changing engine oil filter ................................. 8-11
Flashers (See hazard warning flasher switch) ... 2-27
Flat tire............................................................................ 6-2
Flat towing .................................................................. 9-22
Floor mat cleaning ....................................................... 7-4
Fluid
Brake fluid............................................................. 8-13
Capacities and recommended fuel/
lubricants ................................................................. 9-2
CVT fluid ............................................................... 8-12
Engine coolant ....................................................... 8-8
Engine oil................................................................. 8-9
Power steering fluid ........................................... 8-12
Window washer fluid ......................................... 8-14
FM-AM-SAT radio with casette player
and CD changer ........................................................ 4-38
FM-AM-SAT radio with CD player ....................... 4-34
Fog light switch ......................................................... 2-27
Front manual seat adjustment .................................. 1-3
Front passenger air bag and status light ............ 1-49
Front power seat adjustment .................................... 1-3
Fuel
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Fuel economy ...................................................... 5-24
Fuel octane rating ................................................. 9-3
Fuel recommendation ........................................... 9-3
Fuel-filler cap ....................................................... 3-26
Fuel-filler door...................................................... 3-26Gauge ...................................................................... 2-5
Fuses ............................................................................ 8-21
Fusible links ................................................................ 8-22
G
Garage door opener, HomeLink
Universal
Transceiver .................................................................. 2-44
Gas cap ....................................................................... 3-26
Gauge ............................................................................. 2-3
Engine coolant temperature gauge .................. 2-5
Fuel gauge .............................................................. 2-5
Odometer ................................................................ 2-4
Speedometer .......................................................... 2-4
Tachometer ............................................................. 2-4
General maintenance .................................................. 8-2
Glove box .................................................................... 2-33
H
Hazard warning flasher switch............................... 2-27
Head restraints ............................................................. 1-7
Headlights
Aiming control ..................................................... 2-25
Bulbreplacement ............................................... 8-27
Headlight switch ................................................. 2-23
Xenon headlights ................................................ 2-22
Heated seats .............................................................. 2-28
Heater
Engine block heater ........................................... 5-35
Heater and air conditioner (automatic) ......... 4-23
HomeLink
Universal Transceiver ......................... 2-44
Hood release .............................................................. 3-24Horn .............................................................................. 2-28
I
Ignition knob(Intelligent Key system) .................. 3-13
Ignition switch
Key positions ....................................................... 5-10
Ignition switch (Except for Intelligent Key
equipped model) .......................................................... 5-9
Ignition switch (Intelligent Key System
equipped model) ....................................................... 5-10
Immobilizer system .................................................... 2-18
In-cabin microfilter .................................................... 4-26
Indicator lights............................................................ 2-14
Continuously variable transmission (CVT)
indicator light ....................................................... 2-14
Cruise set indicator light .................................. 2-14
Malfunction indicator light (MIL) .................... 2-14
Inside
Automatic anti-glare mirror............................... 3-31
Mirror...................................................................... 3-30
Inspection/maintenance (I/M) test ........................ 9-25
Instrument brightness control ................................ 2-26
Instrument panel........................................................... 2-2
Intelligent Key system ................................................. 3-9
Engine starting .................................................... 3-13
Key operating range........................................... 3-15
Key operation....................................................... 3-12
Mechanical key and valet key .......................... 3-23
Operating the engine......................................... 3-13
Remote keyless operation ................................ 3-20
Trouble-shooting guide ..................................... 3-19
Warning light ....................................................... 2-11
Warning signals .................................................. 3-17


06.7.5/Z50-D/V5.0

10-3

Shifting, CVT (Continuously Variable
Transmission) ............................................................. 5-13
Shoulder belt height adjustment ........................... 1-16
Spare tire..................................................................... 8-40
Spark plugs................................................................. 8-16
Speedometer ................................................................ 2-4
Starting
Before starting the engine................................ 5-12
Jump starting .......................................................... 6-9
Precautions when starting and driving ............ 5-2
Push starting ........................................................ 6-11
Starting the engine............................................. 5-13
Status light, Front passenger air bag .................. 1-49
Steering
Power steering fluid ........................................... 8-12
Power steering system ...................................... 5-30
Tilting steering wheel......................................... 3-28
Steering switch for audio control.......................... 4-43
Storage ........................................................................ 2-31
Sun shade ................................................................... 2-41
Sun visors ................................................................... 3-30
Sunroof ........................................................................ 2-40
Automatic sunroof .............................................. 2-40
Supplemental air bag warning labels................... 1-55
Supplemental air bag warning light .......... 1-56, 2-13
Supplemental restraint system............................... 1-41
Precautions on supplemental restraint
system.................................................................... 1-41
Switch
Autolight switch .................................................. 2-23
AWD lock switch operations........................... 5-25
Fog light switch................................................... 2-27
Hazard warning flasher switch ........................ 2-27
Headlight aiming control ................................... 2-25Headlight switch ................................................. 2-23
Power door lock switch....................................... 3-4
Rear window and outside mirror defroster
switch..................................................................... 2-22
Turn signal switch .............................................. 2-27
Vehicle dynamic control (VDC) off switch ... 2-29
T
Tachometer.................................................................... 2-4
Temperature gauge, Engine coolant temperature
gauge .............................................................................. 2-5
Theft (NISSAN Vehicle Immobilizer System),
Engine start................................................................. 2-18
Three-way catalyst....................................................... 5-3
Tilting steering wheel ............................................... 3-28
Tire pressure, Low tire pressure warning
light ............................................................................... 2-12
Tires
Flat tire ..................................................................... 6-2
Low tire pressure warning system .................... 5-3
Spare tire .............................................................. 8-40
Tire and Loading information label ................. 8-31
Tire and Loading Information label................. 9-11
Tire chains ............................................................ 8-37
Tire dressing ........................................................... 7-3
Tire pressure ........................................................ 8-29
Tire pressure information (display)........ 4-6, 4-14
Tire pressure monitoring system ....................... 6-2
Tire pressure monitoring system (TPMS) ....... 5-3
Tire rotation .......................................................... 8-38
Types of tires ....................................................... 8-36
Uniform tire quality grading .............................. 9-23
Wheel/tire size ....................................................... 9-8Wheels and tires ................................................ 8-29
Tonneau cover ........................................................... 2-37
Top tether strap child restraints ............................ 1-25
Towing
Flat towing ............................................................ 9-22
Tow truck towing ................................................ 6-12
Towing a trailer.................................................... 9-17
Towing load/specification chart .......... 9-17, 9-19
Towing safety....................................................... 9-19
TPMS, Tire pressure monitoring system................ 5-3
Trailer towing .............................................................. 9-17
Transceiver, HomeLink
Universal
Transceiver .................................................................. 2-44
Transmission
Driving with CVT (Continuously Variable
Transmission) ....................................................... 5-13
Transmission selector lever lock
release ....................................................... 5-16, 5-20
Transmitter, With Intelligent Key system (See
Intelligent Key system) ............................................. 3-20
Transmitter, Without Intelligent Key system
(See remote keyless entry system) ......................... 3-5
Traveling or registering your vehicle in another
country ............................................................................ 9-9
Trouble-shooting guide (for Intelligent Key
system) ......................................................................... 3-19
Troubleshooting guide (for Bluetooth
Hands-Free Phone System) ................................... 4-33
Troubleshooting guide (for voice-activated
control system) .......................................................... 4-33
Turn signal switch ..................................................... 2-27


06.7.5/Z50-D/V5.0

10-6
