2007 NISSAN MURANO service indicator

Driving could be dangerous. If you
judge it to be safe, drive carefully to
the nearest service station for re-
pairs. Otherwise, have your vehicle
towed because driving it could be
dangerous.

Pressing the brake pedal with the
engine stopped and/or a low brake
fluid level may increase your stop-
ping distance and braking will re-
quire greater pedal effort as well as
pedal travel.

If the brake fluid level is below the
MINIMUM or MIN mark on the brake
fluid reservoir, do not drive until the
brake system has been checked at a
NISSAN dealer.
Anti-lock braking system warning
indicator:
When the parking brake is released and the
brake fluid level is sufficient, if both the brake
warning light and the anti-lock braking warning
light illuminate, it may indicate the anti-lock
braking system is not functioning properly. Have
the brake system checked by a NISSAN dealer.See “Anti-lock braking warning light” earlier in
this section.
Charge warning light
If the light comes on while the engine is running,
it may indicate that the charging system is not
functioning properly. Turn the engine off and
check the generator belt. If the belt is loose,
broken, missing or if the light remains on, see a
NISSAN dealer immediately.
CAUTION
Do not continue driving if the generator
belt is loose, broken or missing.
Door open warning light
This light comes on when any of the doors are
not closed securely while the ignition switch is
ON.
Engine oil pressure warning
light
This light warns of low engine oil pressure. If the
light blinks or comes on during normal driving,
pull off the road in a safe area, stop the engine
immediatelyand call a NISSAN dealer or other
authorized repair shop.The oil pressure warning light is not de-
signed to indicate a low oil level. Use the
dipstick to check the oil level.See “Engine
oil” in the “8. Maintenance and do-it-yourself”
section.
CAUTION
Running the engine with the engine oil
pressure warning light on could cause
serious damage to the engine almost
immediately. Turn off the engine as
soon as it is safe to do so.
Intelligent Key warning light
(for Intelligent Key system)
This light comes on in green when it is possible
to turn the ignition switch.
When the light comes on in red, it is not possible
to turn the ignition switch.

The warning light blinks in red when the
Intelligent Key is outside the vehicle with the
ignition switch in the ACC or ON position.
Confirm the location of the key as soon as
possible when the warning light blinks in red.
Be sure to carry the Intelligent Key with you
while driving the vehicle.
Instruments and controls
2-11


06.7.5/Z50-D/V5.0


Canada. Operation is subject to the follow-
ing two conditions;
(1) This device may not cause harmful in-
terference, and (2) this device must accept
any interference received, including inter-
ference that may cause undesired opera-
tion of the device.
CHANGES OR MODIFICATIONS NOT EX-
PRESSLY APPROVED BY THE PARTY RE-
SPONSIBLE FOR COMPLIANCE COULD
VOID THE USER’S AUTHORITY TO OPER-
ATE THE EQUIPMENT.
Security indicator lightThis light blinks whenever the registered
NISSAN Vehicle Immobilizer System key or me-
chanical key (Intelligent Key) is removed or
turned to the OFF, ACC or LOCK position, or
the ignition switch is turned to the LOCK posi-
tion (Intelligent Key). This function indicates the
security systems equipped on the vehicle are
operational.
If NISSAN Vehicle Immobilizer System is mal-
functioning, this light will remain on while the
registered NISSAN Vehicle Immobilizer System
Key is in the ON position.If the light still remains on and/or the
engine will not start, see a NISSAN dealer
for NISSAN Vehicle Immobilizer System or
Intelligent Key system service as soon as
possible. Bring all NISSAN Vehicle Immo-
bilizer System keys or Intelligent Key that
you have when visiting a NISSAN dealer for
service.
SIC2045
Instruments and controls
2-19


06.7.5/Z50-D/V5.0


To turn the radio off, push the POWER button.
Turn the Volume control knobto adjust the
volume.
AUDIO button/knob:
Push the AUDIO button to change the selecting
mode as follows.
BASS→TREBLE→FADE→BALANCE→
BASS
To adjust Bass, Treble, Fader and Balance, push
the AUDIO button until the desired mode BASS,
TREBLE, FADE or BALANCE appears in the
display. Turn the AUDIO knobto adjust Bass
and Treble to the desired level. Use the Tuning
knobalso to adjust Fader or Balance modes.
Fader adjusts the sound level between the front
and rear speakers and Balance adjusts the
sound between the right and left speakers.
After 10 seconds, the radio or CD display
reappears. Once the sound quality is set to the
desired level, push the AUDIO button repeatedly
until the radio or CD display appears.
Display text:
To indicate the text, push the AUDIO knob
during CD or satellite radio playing.
BASS→TREBLE→FADE→BALANCE→
Display modeTo change the indicated text in display mode,
turn the tuning knobwithin 2 seconds.
Display select:
Display CD text
To indicate the CD text, push the
button
while the CD is playing.
The text will change as follows:
Display FM text
To indicate the FM PS name, push the
button while the FM radio is playing.
The name will change as follows:
ON→OFF→ON
When no data is available, “NO TEXT” will
appear.
Display satellite radio text
To indicate the satellite radio text, push thebutton while the satellite radio is playing.
The text will change as follows:
When no data is available, “——” will appear.FM-AM-SAT radio operation
FM/AM/SAT radio select:
The satellite radio mode will be skipped unless
the optional satellite receiver and antenna are
installed, and an XM
or SIRIUS
TM
satellite radio
service subscription is active.
Pushing the RADIO button will change the band
as follows:
AM→FM→SAT (Satellite)
When the RADIO button is pushed while the
ignition switch is in the ACC or ON, the radio will
come on at the station last played.
The last station played will also come on when
the power knobis turned to ON.
If a compact disc is playing when the RADIO
button is pushed, the compact disc will auto-
matically be turned off and the last radio station
played will come on.
The FM stereo indicator ST will glow during FM
stereo reception. When the stereo broadcast
signal is weak, the radio will automatically
Display screen, heater, air conditioner and audio systems
4-35


06.7.5/Z50-D/V5.0


change from stereo to monaural reception.
TUNE (Tuning):
To tune the radio, turn the TUNE knobto the
right or left.
Use these buttons for manual tuning.
SEEK tuning:
Push the SEEK button
or
for less
than 0.5 second to tune from high to low or low
to high frequencies and stop at the next broad-
casting station (channel).
Push the SEEK button
or
for more
than 0.5 second, to fast tune from high to low or
low to high frequencies.
SCANtuning:
Push the SCAN tuning button to tune from low
to high frequencies and stop at each broadcast-
ing station (channel) for 5 seconds. Pushing the
button again during this 5 seconds period will
stop SCAN tuning and the radio will remain
tuned to that station (channel).
If the SCAN tuning button is not pushed within 5
seconds, SCAN tuning moves to the next station
(channel).
Station memory operations:
Eighteen (18) stations can be set for the FM, AMand SAT band to the A, B and C preset button.
1. Choose preset channel A, B or C using the
preset select button.
2. Tune to the desired station using the SEEK,
SCAN or TUNE button and keep pushing any
of the desired station memory buttons (1 to
6) until a beep sound is heard. (The radio
mutes when the select button is pushed.)
3. The channel indicator will then come on and
the sound will resume. Memorizing is now
complete.
4. Other buttons can be set in the same manner.
If the battery cable is disconnected, or if the fuse
blows, the radio memory will be erased. In that
case, reset the desired stations.
Radio data system (RDS):
RDS stands for Radio Data System, and is a
data information service transmitted by some
radio stations on the FM band (not AM band)
and/or SATELLITE band encoded within a regu-
lar radio broadcast. Currently, most RDS sta-
tions are in large cities, but many stations are
now considering broadcasting RDS data.
RDS can display:

Station call sign, such as “WHFR 98.3”.

Station name, such as “The Groove”.
Music or programming type such as “Classi-
cal”, “Country”, or “Rock”.

Traffic reports about delays or construction.
If the station broadcasts RDS information, the
RDS icon is displayed.
Category (CAT) button:
When the CAT button is pushed for less than
0.5 second, the AM/FM (Satellite) radio frequen-
cies (Category) will move to the next/previous
step (Category). Push and hold the button for
more than 0.5 second to move quickly through
the steps (Categories).
Compact disc (CD) player operationTurn the ignition switch to the ACC or ON
position and insert the compact disc into the slot
with the label side facing up. The compact disc
will be guided automatically into the slot and
start playing.
After loading the disc, the number of tracks on
the disc and the play time will appear on the
display.
If the radio is already operating, it will automati-
cally turn off and the compact disc will play.
If the system has been turned off while the
compact disc was playing, pushing the
POWER/VOL control knobwill start the com-
pact disc.
4-36
Display screen, heater, air conditioner and audio systems


06.7.5/Z50-D/V5.0


Display satellite radio text
To indicate the satellite radio text, push the
button while the satellite radio is playing.
The text will change as follows:
When no data is available, “——” will appear.FM-AM-SAT radio operation
FM/AM/SAT radio select:
The satellite radio mode will be skipped unless
the optional satellite receiver and antenna are
installed, and an XM
or SIRIUS
TM
satellite radio
service subscription is active.
Pushing the RADIO button will change the band
as follows:
AM→FM→SAT (Satellite)
When the RADIO button is pushed while the
ignition switch is in the ACC or ON, the radio will
come on at the station last played.
The last station played will also come on when
the power knobis turned to ON.
If a compact disc or tape is playing when the
RADIO button is pushed, the compact disc ortape will automatically be turned off and the last
radio station played will come on.
The FM stereo indicator ST will glow during FM
stereo reception. When the stereo broadcast
signal is weak, the radio will automatically
change from stereo to monaural reception.
TUNE (Tuning):
To tune the radio, turn the TUNE knobto the
right or left.
Use these buttons for manual tuning.
SEEK tuning:
Push the SEEK button
or
for less
than 0.5 second to tune from high to low or low
to high frequencies and stop at the next broad-
casting station (channel).
Push the SEEK button
or
for more
than 0.5 second, to fast tune from high to low or
low to high frequencies.
SCANtuning:
Push the SCAN tuning button to tune from low
to high frequencies and stop at each broadcast-
ing station (channel) for 5 seconds. Pushing the
button again during this 5 seconds period will
stop SCAN tuning and the radio will remain
tuned to that station (channel).
If the SCAN tuning button is not pushed within 5seconds, SCAN tuning moves to the next station
(channel).
Station memory operations:
Eighteen (18) stations can be set for the FM, AM
and SAT band to the A, B and C preset button.
1. Choose preset channel A, B or C using the
preset select button.
2. Tune to the desired station using the SEEK,
SCAN or TUNE button and keep pushing any
of the desired station memory buttons (1 to
6) until a beep sound is heard. (The radio
mutes when the select button is pushed.)
3. The channel indicator will then come on and
the sound will resume. Memorizing is now
complete.
4. Other buttons can be set in the same manner.
If the battery cable is disconnected, or if the fuse
blows, the radio memory will be erased. In that
case, reset the desired stations.
Radio data system (RDS):
RDS stands for Radio Data System, and is a
data information service transmitted by some
radio stations on the FM band (not AM band)
and/or SATELLITE band encoded within a regu-
lar radio broadcast. Currently, most RDS sta-
tions are in large cities, but many stations are
4-40
Display screen, heater, air conditioner and audio systems


06.7.5/Z50-D/V5.0


Contact a NISSAN dealer if checking or replace-
ment is required.
SELF-ADJUSTING BRAKESYour vehicle is equipped with self-adjusting
brakes.
The disc-type brakes self-adjust every time the
brake pedal is applied.
WARNING
See a NISSAN dealer and have it
checked if the brake pedal height does
not return to normal.BRAKE PAD WEAR INDICATORSThe disc brake pads on your vehicle have au-
dible wear indicators. When a brake pad re-
quires replacement, it will make a high pitched
scraping or screeching sound when the vehicle
is in motion whether or not the brake pedal is
depressed. Have the brakes checked as soon as
possible if the wear indicator sound is heard.
Under some driving or climate conditions, occa-
sional brake squeak, squeal or other noise may
be heard. Occasional brake noise during light to
moderate stops is normal and does not affect
the function or performance of the brake system.
Proper brake inspection intervals shouldbe followed.For additional information, see the
separate Service and Maintenance Guide.
REAR WINDOW WIPER BLADE BRAKES8-20
Maintenance and do-it-yourself


06.7.5/Z50-D/V5.0


1. Wear indicator
2. Location markTire wear and damage
WARNING

Tires should be periodically in-
spected for wear, cracking,
bulging or objects caught in the
tread. If excessive wear, cracks,
bulging or deep cuts are found,the tire(s) should be replaced.

The original tires have built-in
tread wear indicators. When the
wear indicators are visible, the
tire(s) should be replaced.

Tires degrade with age and use.
Have tires, including the spare,
over 6 years old checked by a
qualified technician because
some tire damage may not be
obvious. Replace the tires as
necessary to prevent tire failure
and possible personal injury.

Improper service of the spare
tire may result in serious per-
sonal injury. If it is necessary to
repair the spare tire, contact a
NISSAN dealer.

For additional information re-
garding tires, refer to “Impor-
tant Tire Safety Information”
(US) or “Tire Safety Informa-tion” (Canada) in the Warranty
Information Booklet.
Replacing wheels and tiresWhen replacing a tire, use the same size, tread
design, speed rating and load carrying capacity
as originally equipped. Recommended types and
sizes are shown in “Wheels and tires” in the
“Technical and consumer information” section of
this manual.
WARNING

The use of tires other than those
recommended or the mixed use of
tires of different brands, construction
(bias, bias-belted or radial), or tread
patterns can adversely affect the ride,
braking, handling, ground clearance,
body-to-tire clearance, tire chain
clearance, speedometer calibration,
headlight aim and bumper height.
Some of these effects may lead to
accidents and could result in serious
personal injury.
SDI1663
Maintenance and do-it-yourself
8-39


06.7.5/Z50-D/V5.0
